ID: 1490362
Tuotekoodi: PPA5506103
Voidaan tilata 12 yksiköt Saatavuus: 14 päivää tilauksen hyväksymisestä
Takuu: 3 vuotta
FSP VITA BD, 550W, 80PLUS Bronze, ATX 3.1
Kuva voi poiketa todellisesta tuotteesta, ja tuotteessa voi olla lisävarusteita ja osia, joita ei toimiteta varsinaisen tuotteen mukana.
-
Postin pakettiautomaatti1-2 työpäivän kuluessa6,99 € -
Postitoimisto1-2 työpäivän kuluessa6,99 €
-
Toimitus Posti-kuriirin postin välityksellä1-2 työpäivän kuluessa10,99 €
Tärkeimmät tuoteparametrit Kaikki parametrit
- Tuottaja: FSP
- Teho: 550W
- 80 PLUS -sertifiointi: 80 PLUS Bronze
- Puhaltimen koko: 120 mm
- Modulaariset kaapelit: Ei mitään
- Prosessori-liitännäinen: 2 x 8-pin(4+4) EPS
- PCI-E: 4 X 6+2pin
Kuvaus
Ostettavissa on FSP-valmistajan virtalähde, jonka 550W teho. Tuotteelle on myönnetty 80 PLUS Bronze -energiatehokkuussertifikaatti.
550W teholla, se riittää Office-ohjelmien käyttöön, internetin selaamiseen ja yksinkertaisten tietokonepelien pelaamiseen. Se pystyy pyörittämään tietokonetta, jossa on budjetti tason prosessori, integroitu näytönohjain, pieni SSD tai HDD levy. Jos tulevaisuudessa on halu päivittää tietokoneen komponentteja, kannattaa ehdottomasti harkita tehokkaampaa virtalähdettä.
120 mm tuulettimet, joilla tämä virtalähde on varustettu, takaavat teollisuusstandardin mukaisen hiljaisen toiminnan. Erityisen hiljaista virtalähteen toimintaa varten suosittelemme hankkimaan 135 mm tai 145 mm halkaisijan tuulettimen.
Virtalähde on saanut 80 PLUS Bronze energiatehokkuustodistuksen, joka takaa vähintään 85% tehokkuuden 50% kuormituksella. Tämä tarkoittaa, että jokaisesta sähköverkosta otetusta 100W tehosta vähintään 85W toimitetaan tietokoneen komponenteille, kun taas loput 15W menetetään lämpönä.
Tämän virtalähteen väri on Melna. Kaapelin väri on Melna ja ne ovat litteitä.
Tämä on virtalähde, joka täyttää ATX 2.0 -vaatimukset. Virtalähteessä on vain
Virtalähdeyksikkö
Perustiedot
Cybenetics Melutason sertifiointi
: Ei ole
Cybeneticsin tehokkuuden sertifiointi
: Ei ole
Virtalähteen tyyppi
: ATX
Teho
550W
Virtalähteen kapasiteetti watteina. Suurempi kapasiteetti tarkoittaa tietokoneen toiminnan vakaampaa toimintaa. Nykyaikaisen keskiverto tietokoneen virtalähteen suositeltu kapasiteetti on vähintään 500 W. Jos käytät useita kiintolevyjä, tehokasta näytönohjainta ja prosessoria, on suositeltavaa ostaa virtalähde, jonka kapasiteetti on vähintään 600 W.
80 PLUS -sertifiointi
: 80 PLUS Bronze
Kokonaisvirta (+12V)
: 45.8A
Puhaltimen koko
: 120 mm
Toiminnallisuus
Kaapelin väri
: Musta
Valaistus
: Ei mitään
Väri
: Musta
Modulaariset kaapelit
: Ei mitään
Satamat ja laitteet
PCI-E 5.0/5.1
: Ei ole
Prosessori-liitännäinen
: 2 x 8-pin(4+4) EPS
Emolevyn virta
: 20+4-pin
PCI-E
: 4 X 6+2pin
SATA-liittimet
: 6
4pin Molex
: 2
Tietokonekotelo
Yksityiskohtaisempi erittely
Brand - FSP
BrandPartCode - PPA5506103
Category - Power Supply Units
Category_1 - Power
Category_2 - Computer Power Supplies
Design - Cooling type - Active
Design - Fan diameter - 12 cm
Design - Fan location - Top
Design - Number of fans - 1 fan(s)
Design - Product colour - Black
EAN_code - 4711498480231
GTIN - 4711498480231
LongDesc - The Future is Now：ATX 3.1 ReadyFollowing the latest ATX 3.1 regulation, this series supports 200% power excursion and ensure peak performance with future hardware upgrades.+5V & 3.3V DC to DC Circuit DesignIncrease the efficiency and stabilize the output voltage to ensure system stability.Powerful Single +12V RailModern CPUs and graphics cards can draw significant amounts of power, especially during peak loads., a single +12V rail PSU offers a good balance of simplicity, power delivery capability, and stability.Premium, Black Flat CablesFeaturing improved black, flat cables that are soft and easy to bend, users can manage them more easily, saving time and creating more space for optimal cooling performance in your PC build.105˚C Japanese Bulk CapacitorThe bulk capacitor inside serves to support working under an extremely harsh environment, such as with high temperatures, peak voltage fluctuations. It stabilizes the performance for high reliability that your system can count on.Compact PSU size：140 x 150 x 86mm140mm in length which is relatively shorter than industry standard, it’s ideal for compact PC or space-constraint environment without compromising on performance.
LongProductName - 550W, 240V, 50/60Hz
LongSummaryDescription - FSP VITA BD 550W Power supply unit ATX ATX3.1 Black. Total power: 550 W, AC input voltage: 200 - 240 V, AC input frequency: 50/60 Hz. Motherboard power connector: 20+4 pin ATX, Motherboard power cable length: 60 cm, SATA power cable length: 500 mm. Purpose: PC, Power supply unit (PSU) form factor: ATX, 80 PLUS certification: 80 PLUS Bronze. Product colour: Black, Cooling type: Active, Fan diameter: 12 cm. Cables included: CPU, Peripheral (Molex), SATA
Manufacturer - Fortron
Manufacturer_code - PPA5506103
Name - FSP VITA BD 550W, PC power supply (2x PCIe, 550 Watt)
Packaging content - Cables included - CPU, Peripheral (Molex), SATA
Performance - 80 PLUS certification - 80 PLUS Bronze
Performance - ATX version - 3.1
Performance - Bearing technology - HYB
Performance - EPS version - 2.92
Performance - Power supply unit (PSU) form factor - ATX
Performance - Purpose - PC
Ports & interfaces - Cabling type - Non-Modular
Ports & interfaces - CPU power cable length - 70 cm
Ports & interfaces - CPU power connector (4+4 pin) - Yes
Ports & interfaces - Motherboard power cable length - 60 cm
Ports & interfaces - Motherboard power connector - 20+4 pin ATX
Ports & interfaces - Number of SATA power connectors - 8
Ports & interfaces - PCI Express power connectors (6+2 pin) - 4
Ports & interfaces - Peripheral (Molex) power connectors (4-pin) - 4
Ports & interfaces - SATA power cable length - 500 mm
Power - AC input frequency - 50/60 Hz
Power - AC input voltage - 200 - 240 V
Power - Combined power (+3.3V) - 100 W
Power - Combined power (+5V) - 100 W
Power - Combined power (+5Vsb) - 12.5 W
Power - Combined power (+12V) - 550 W
Power - Combined power (-12V) - 3.6 W
Power - Efficiency - 90%
Power - Input current - 4 A
Power - Max output current (+3.3V) - 20 A
Power - Max output current (+5V) - 20 A
Power - Max output current (+5Vsb) - 2.5 A
Power - Max output current (+12V) - 45.8 A
Power - Max output current (-12V) - 0.3 A
Power - Power Factor Correction (PFC) type - Active
Power - Power protection features - Over current, Over power, Over voltage, Overheating, Short circuit, Under voltage
Power - Total power - 550 W
ProductName - VITA BD 550W Power supply unit ATX ATX3.1 Black
ShortSummaryDescription - FSP VITA BD 550W Power supply unit ATX ATX3.1 Black, 550 W, 200 - 240 V, 50/60 Hz, 4 A, Active, 100 W
Title - FSP VITA BD 550W Power supply unit ATX ATX3.1 Black
URL - https://www.fsplifestyle.com/en/product/VITAGD550W.html
WarrantyInfo - 5 years
Weight - 1,95
Weight & dimensions - Depth - 140 mm
Weight & dimensions - Height - 86 mm
Weight & dimensions - Width - 150 mm
BrandPartCode - PPA5506103
Category - Power Supply Units
Category_1 - Power
Category_2 - Computer Power Supplies
Design - Cooling type - Active
Design - Fan diameter - 12 cm
Design - Fan location - Top
Design - Number of fans - 1 fan(s)
Design - Product colour - Black
EAN_code - 4711498480231
GTIN - 4711498480231
LongDesc - The Future is Now：ATX 3.1 ReadyFollowing the latest ATX 3.1 regulation, this series supports 200% power excursion and ensure peak performance with future hardware upgrades.+5V & 3.3V DC to DC Circuit DesignIncrease the efficiency and stabilize the output voltage to ensure system stability.Powerful Single +12V RailModern CPUs and graphics cards can draw significant amounts of power, especially during peak loads., a single +12V rail PSU offers a good balance of simplicity, power delivery capability, and stability.Premium, Black Flat CablesFeaturing improved black, flat cables that are soft and easy to bend, users can manage them more easily, saving time and creating more space for optimal cooling performance in your PC build.105˚C Japanese Bulk CapacitorThe bulk capacitor inside serves to support working under an extremely harsh environment, such as with high temperatures, peak voltage fluctuations. It stabilizes the performance for high reliability that your system can count on.Compact PSU size：140 x 150 x 86mm140mm in length which is relatively shorter than industry standard, it’s ideal for compact PC or space-constraint environment without compromising on performance.
LongProductName - 550W, 240V, 50/60Hz
LongSummaryDescription - FSP VITA BD 550W Power supply unit ATX ATX3.1 Black. Total power: 550 W, AC input voltage: 200 - 240 V, AC input frequency: 50/60 Hz. Motherboard power connector: 20+4 pin ATX, Motherboard power cable length: 60 cm, SATA power cable length: 500 mm. Purpose: PC, Power supply unit (PSU) form factor: ATX, 80 PLUS certification: 80 PLUS Bronze. Product colour: Black, Cooling type: Active, Fan diameter: 12 cm. Cables included: CPU, Peripheral (Molex), SATA
Manufacturer - Fortron
Manufacturer_code - PPA5506103
Name - FSP VITA BD 550W, PC power supply (2x PCIe, 550 Watt)
Packaging content - Cables included - CPU, Peripheral (Molex), SATA
Performance - 80 PLUS certification - 80 PLUS Bronze
Performance - ATX version - 3.1
Performance - Bearing technology - HYB
Performance - EPS version - 2.92
Performance - Power supply unit (PSU) form factor - ATX
Performance - Purpose - PC
Ports & interfaces - Cabling type - Non-Modular
Ports & interfaces - CPU power cable length - 70 cm
Ports & interfaces - CPU power connector (4+4 pin) - Yes
Ports & interfaces - Motherboard power cable length - 60 cm
Ports & interfaces - Motherboard power connector - 20+4 pin ATX
Ports & interfaces - Number of SATA power connectors - 8
Ports & interfaces - PCI Express power connectors (6+2 pin) - 4
Ports & interfaces - Peripheral (Molex) power connectors (4-pin) - 4
Ports & interfaces - SATA power cable length - 500 mm
Power - AC input frequency - 50/60 Hz
Power - AC input voltage - 200 - 240 V
Power - Combined power (+3.3V) - 100 W
Power - Combined power (+5V) - 100 W
Power - Combined power (+5Vsb) - 12.5 W
Power - Combined power (+12V) - 550 W
Power - Combined power (-12V) - 3.6 W
Power - Efficiency - 90%
Power - Input current - 4 A
Power - Max output current (+3.3V) - 20 A
Power - Max output current (+5V) - 20 A
Power - Max output current (+5Vsb) - 2.5 A
Power - Max output current (+12V) - 45.8 A
Power - Max output current (-12V) - 0.3 A
Power - Power Factor Correction (PFC) type - Active
Power - Power protection features - Over current, Over power, Over voltage, Overheating, Short circuit, Under voltage
Power - Total power - 550 W
ProductName - VITA BD 550W Power supply unit ATX ATX3.1 Black
ShortSummaryDescription - FSP VITA BD 550W Power supply unit ATX ATX3.1 Black, 550 W, 200 - 240 V, 50/60 Hz, 4 A, Active, 100 W
Title - FSP VITA BD 550W Power supply unit ATX ATX3.1 Black
URL - https://www.fsplifestyle.com/en/product/VITAGD550W.html
WarrantyInfo - 5 years
Weight - 1,95
Weight & dimensions - Depth - 140 mm
Weight & dimensions - Height - 86 mm
Weight & dimensions - Width - 150 mm
