ARTIKEL1 - XH510G S1200 H510 BLACK 180W
ARTIKEL2 - GLN HDMI DISPLAY-PORT
Audio - Built-in speaker(s) - No
Brand - Shuttle
BrandPartCode - XH510G
Breite - 0.29
Category - PC/Workstation Barebones
Category_1 - Computers and Laptops
Category_2 - Computers - Computers Shuttle
Design - Cable lock slot - Yes
Design - Cable lock slot type - Kensington
Design - Cooling type - Active
Design - LED indicators - HDD, Power
Design - On/off switch - Yes
Design - Product colour - Black
Design - Product type - PC barebone
Design - VESA mounting - Yes
EAN - 887993005041
EANCode - 0887993005041
EAN_code - 0887993005041
Expansion slots - PCI Express slots version - 4.0
Expansion slots - PCI Express x16 slots - 1
Gewicht - 3.36
Graphics - Graphics card family - Intel
Graphics - On-board graphics card - Yes
Gross Weight Kg - 3
GRUPPE1 - Computer Systems
GRUPPE2 - PC Barebone
GTIN - 887993005041
GTIN - 0887993005041
HERSTELLER - SHUTTLE
HSTNUMMER - XH510G
Logistics data - Harmonized System (HS) code - 84733080
LongDesc - Flexible 3-litre PC with PCIe slotThe Shuttle XPC slim Barebone XH510G is a 3-litre PC to house one single-slot PCI-Express expansion cards. Together with an LGA 1200 Intel Core desktop processor of the Intel Core Gen 10/11 range, this platform is perfectly suited for many professional applica-tions where performance, flexibility and a compact form factor matter. This includes video wall presentations, graphics workstations, media capturing, surveillance, POS, POI as well as network and industrial applications. Even mid-range gaming is possible.
LongProductName - Socket LGA1200, 2 x SO-DIMM DDR4 max. 64GB, 1 x 2.5" SSD/HDD, 2 x M.2, Gigabit LAN, 180 W
LongSummaryDescription - Shuttle XPC slim Barebone XH510G - S1200, Intel H510, 1xDP, 1xHDMI, 1x PCI-E 16X, 1x LAN, 1x 2.5", 2x M.2, 24/7 permanent operation. Product type: PC barebone. Motherboard chipset: Intel H510, Processor socket: LGA 1200 (Socket H5). Supported memory types: DDR4-SDRAM, Number of memory slots: 2, Maximum internal memory: 64 GB. Supported storage drive types: HDD & SSD, Storage drive interface: M.2, Serial ATA III. Ethernet LAN (RJ-45) ports: 1. Cooling type: Active. Power supply: 180 W
Manufacturer - Shuttle
Manufacturer Code - XH510G
Manufacturer Name - Shuttle
Manufacturer_code - XH510G
Memory - Maximum internal memory - 64 GB
Memory - Memory channels - Dual-channel
Memory - Memory slots type - SO-DIMM
Memory - Non-ECC - Yes
Memory - Number of memory slots - 2
Memory - Supported memory clock speeds - 2666,2933,3200 MHz
Memory - Supported memory types - DDR4-SDRAM
Name - Shuttle XPC slim XH510G, Barebone (black, without operating system)
Network - Ethernet LAN - Yes
Network - LAN controller - Intel® I219-LM
Network - Wi-Fi - No
Operational conditions - Operating relative humidity (H-H) - 10 - 90%
Operational conditions - Operating temperature (T-T) - 0 - 50 °C
Other features - Country of origin - China
Packaging content - Drivers included - Yes
Packaging content - Power cord included - Yes
Packaging content - Quick start guide - Yes
Performance - Audio output channels - 7.1 channels
Performance - Compatible processor series - Intel® Celeron®, Intel® Core™ i3, Intel® Core™ i5, Intel® Core™ i7, Intel® Core™ i9, Intel® Pentium® Gold
Performance - Motherboard chipset - Intel H510
Performance - Number of processors supported - 1
Performance - Processor socket - LGA 1200 (Socket H5)
Performance - Trusted Platform Module (TPM) - Yes
Ports & interfaces - DC-in jack - Yes
Ports & interfaces - DisplayPorts quantity - 1
Ports & interfaces - DisplayPort version - 1.4
Ports & interfaces - Ethernet LAN (RJ-45) ports - 1
Ports & interfaces - HDMI ports quantity - 1
Ports & interfaces - HDMI version - 2.0a
Ports & interfaces - Headphone outputs - 1
Ports & interfaces - Microphone in - Yes
Ports & interfaces - USB 2.0 ports quantity - 4
Ports & interfaces - USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity - 4
Power - AC adapter output current - 9.23 A
Power - AC adapter output voltage - 19.5 V
Power - AC input frequency - 50 - 60 Hz
Power - AC input voltage - 100 - 240 V
Power - Power supply - 180 W
Power - Power supply type - External AC adapter
Processor - Built-in processor - No
ProductName - XPC slim Barebone XH510G - S1200, Intel H510, 1xDP, 1xHDMI, 1x PCI-E 16X, 1x LAN, 1x 2.5", 2x M.2, 24/7 permanent operation
Short description - Shuttle BareboneXPC slim XH510G Black
ShortSummaryDescription - Shuttle XPC slim Barebone XH510G - S1200, Intel H510, 1xDP, 1xHDMI, 1x PCI-E 16X, 1x LAN, 1x 2.5", 2x M.2, 24/7 permanent operation, PC barebone, Intel H510, LGA 1200 (Socket H5), DDR4-SDRAM, M.2, Serial ATA III, 180 W
Software - Linux operating systems supported - Yes
Software - Operating system installed - No
Software - Windows operating systems supported - Windows 10, Windows 11
Stck_Kart - 4
Stck_Pal - 4
Storage - Number of storage drives supported - 2
Storage - NVMe - Yes
Storage - Storage drive interface - M.2, Serial ATA III
Storage - Storage drive sizes supported - 2.5,M.2
Storage - Supported storage drive types - HDD & SSD
Storno - Y
Title - Shuttle XPC slim Barebone XH510G - S1200, Intel H510, 1xDP, 1xHDMI, 1x PCI-E 16X, 1x LAN, 1x 2.5", 2x M.2, 24/7 permanent operation
URL - https://www.shuttle.eu/en/products/slim/xh510g
WarrantyInfo -
Weight - 3,35
Weight & dimensions - Depth - 200 mm
Weight & dimensions - Height - 78.5 mm
Weight & dimensions - Weight - 3.2 kg
Weight & dimensions - Width - 250 mm
