AC adapter output voltage Power - 12 V
Audio output Ports & interfaces - Yes
Backlight type Display - Edge LED
Bezel width (bottom) Weight & dimensions - 22.3 mm
Bezel width (side) Weight & dimensions - 8.21 mm
Bezel width (top) Weight & dimensions - 8.21 mm
Brand - Dahua Technology
BrandPartCode - DHI-LM27-E231BN
Built-in camera Multimedia - No
Built-in speaker(s) Multimedia - No
Built-in USB hub Ports & interfaces - No
Cables included Packaging content - DisplayPort
Category - Computer Monitors
Category Code - LC3
Colour depth Display - 8 bit
Colour gamut standard Display - NTSC
Compliance certificates Other features - CE/Electromagnetic Compatibility (EMC)/Low Voltage Directive (LVD)
Contrast ratio (typical) Display - 1000:1
Current rating Power - 4 A
Data Sheet (Link) Energy Efficiency - https://eprel.ec.europa.eu/api/product/2307456/fiches?language=EN
Depth (without stand) Weight & dimensions - 57.2 mm
Description - Wide color gamut, 85% NTSC. It meets the designer's demand of image texture;178°H/178°V extra-wide viewing angle for all-round viewing performance;Adaptive sync can effectively solve picture lagging and tearing problems;0.5 ms fast response time with no image blurring or ghosting (with OD).
Design - Detachable stand - Yes
Design - Feet colour - Black
Design - Frameless design - Yes
Design - Front bezel colour - Black
Design - Market positioning - Gaming
Design - Product colour - Black
Detachable stand Design - Yes
Display - Backlight type - Edge LED
Display - Colour depth - 8 bit
Display - Colour gamut standard - NTSC
Display - Contrast ratio (typical) - 1000:1
Display - Display brightness (typical) - 350 cd/m²
Display - Display diagonal - 68.6 cm (27")
Display - Display diagonal (metric) - 69 cm
Display - Display number of colours - 16.7 million colours
Display - Display resolution - 1920 x 1080 pixels
Display - Display technology - LED
Display - Haze rate - 25%
Display - HD type - Full HD
Display - High Dynamic Range (HDR) supported - Yes
Display - High Dynamic Range (HDR) technology - High Dynamic Range 10 (HDR10)
Display - LED backlight - Yes
Display - Maximum refresh rate - 200 Hz
Display - Native aspect ratio - 16:9
Display - NTSC coverage (typical) - 85%
Display - Panel type - IPS
Display - Pixel density - 81.59 ppi
Display - Pixel pitch - 0.3114 x 0.3114 mm
Display - Response time - 0.5 ms
Display - Response time (MPRT) - 1 ms
Display - Screen shape - Flat
Display - Surface hardness - 3H
Display - Touchscreen - No
Display - Viewable size, horizontal - 59.8 cm
Display - Viewable size, vertical - 33.6 cm
Display - Viewing angle, horizontal - 178°
Display - Viewing angle, vertical - 178°
Display brightness (typical) Display - 350 cd/m²
Display diagonal (metric) Display - 69 cm
Display diagonal Display - 27 "
Display number of colours Display - 16.7 million colours
DisplayPorts quantity Ports & interfaces - 1
DisplayPort version Ports & interfaces - 1.4
Display resolution Display - 1920 x 1080 pixels
Display technology Display - LED
Energy consumption (HDR) per 1000 hours Power - 28 kWh
Energy consumption (SDR) per 1000 hours Power - 21 kWh
Energy efficiency class (HDR) Power - G
Energy efficiency class (SDR) Power - E
Energy efficiency class Energy Efficiency - E
EPREL Registration Number Energy Efficiency - 2307456
EPREL Version Number Energy Efficiency - 1
Ergonomics - Height adjustment - No
Ergonomics - LED indicators - Yes
Ergonomics - Panel mounting interface - 100 x 100 mm
Ergonomics - Plug and Play - Yes
Ergonomics - Tilt adjustment - Yes
Ergonomics - Tilt angle range - -5 - 20°
Ergonomics - VESA mounting - Yes
Ergonomics - Wall mountable - Yes
Feet colour Design - Black
Frameless design Design - Yes
Front bezel colour Design - Black
Haze rate Display - 25 %
HDMI Ports & interfaces - Yes
HDMI ports quantity Ports & interfaces - 1
HDMI version Ports & interfaces - 2.0
HD type Display - Full HD
Height (without stand) Weight & dimensions - 366.8 mm
Height adjustment Ergonomics - No
High Dynamic Range (HDR) supported Display - Yes
High Dynamic Range (HDR) technology Display - High Dynamic Range 10 (HDR10)
LED backlight Display - Yes
LED indicators Ergonomics - Yes
LongDesc -
LongProductName - 27" FHD ELED, IPS, 16:9, 200 Hz, 0.5 ms, 350 cd/m², 1000:1, DP, HDMI, 3.5 mm, 12 VDC, 4 A, 3.55 kg
LongSummaryDescription - Dahua Technology LM27-E231BN. Display diagonal: 68.6 cm (27"), Display resolution: 1920 x 1080 pixels, HD type: Full HD, Display technology: LED, Response time: 0.5 ms, Native aspect ratio: 16:9, Viewing angle, horizontal: 178°, Viewing angle, vertical: 178°. VESA mounting. Product colour: Black
Low Blue Light technology Performance - Yes
Manual Packaging content - Yes
Market positioning Design - Gaming
Maximum refresh rate Display - 200 Hz
Mean time between failures (MTBF) Other features - 30000 h
Model - DHI-LM27-E231BN
Multimedia - Built-in camera - No
Multimedia - Built-in speaker(s) - No
Native aspect ratio Display - 16:9
NTSC coverage (typical) Display - 85 %
Operating relative humidity (H-H) Operational conditions - 10 - 85 %
Operating temperature (T-T) Operational conditions - 0 - 40 °C
Operational conditions - Operating relative humidity (H-H) - 10 - 85%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Operational conditions - Storage relative humidity (H-H) - 5 - 90%
Operational conditions - Storage temperature (T-T) - -20 - 60 °C
Other features - Compliance certificates - CE, Electromagnetic Compatibility (EMC), Low Voltage Directive (LVD)
Other features - Mean time between failures (MTBF) - 30000 h
Package depth Packaging data - 150 mm
Package height Packaging data - 460 mm
Package type Packaging data - Box
Package weight Packaging data - 4850 g
Package width Packaging data - 695 mm
Packaging content - Cables included - DisplayPort
Packaging content - Manual - Yes
Packaging content - Power adapter included - Yes
Packaging content - Stand included - Yes
Packaging data - Package depth - 150 mm
Packaging data - Package height - 460 mm
Packaging data - Package type - Box
Packaging data - Package weight - 4.85 kg
Packaging data - Package width - 695 mm
Panel mounting interface Ergonomics - 100 x 100 mm
Panel type Display - IPS
Performance - Low Blue Light technology - Yes
Pixel density Display - 81.59 ppi
Pixel pitch Display - 0.3114 x 0.3114 mm
Plug and Play Ergonomics - Yes
Ports & interfaces - Audio output - Yes
Ports & interfaces - Built-in USB hub - No
Ports & interfaces - DisplayPorts quantity - 1
Ports & interfaces - DisplayPort version - 1.4
Ports & interfaces - HDMI - Yes
Ports & interfaces - HDMI ports quantity - 1
Ports & interfaces - HDMI version - 2.0
Power - AC adapter output voltage - 12 V
Power - Current rating - 4 A
Power - Energy consumption (HDR) per 1000 hours - 28 kWh
Power - Energy consumption (SDR) per 1000 hours - 21 kWh
Power - Energy efficiency class (HDR) - G
Power - Energy efficiency class (SDR) - E
Power - Power consumption (max) - 32 W
Power - Power consumption (standby) - 0.5 W
Power - Power consumption (typical) - 24.6 W
Power - Power supply type - External
Power adapter included Packaging content - Yes
Power consumption (max) Power - 32 W
Power consumption (standby) Power - 0.5 W
Power consumption (typical) Power - 24.6 W
Power supply type Power - External
Product colour Design - Black
ProductName - LM27-E231BN
Product Net Weight - 3.55 kg
Response time (MPRT) Display - 1 ms
Response time Display - 0.5 ms
Screen shape Display - Flat
ShortSummaryDescription - Dahua Technology LM27-E231BN, 68.6 cm (27"), 1920 x 1080 pixels, Full HD, LED, 0.5 ms, Black
Stand included Packaging content - Yes
Storage relative humidity (H-H) Operational conditions - 5 - 90 %
Storage temperature (T-T) Operational conditions - -20 - 60 °C
Summary - Dahua Technology LM27-E231BN. Display diagonal: 68.6 cm (27"), Display resolution: 1920 x 1080 pixels, HD type: Full HD, Display technology: LED, Response time: 0.5 ms, Native aspect ratio: 16:9, Viewing angle, horizontal: 178°, Viewing angle, vertical: 178°. VESA mounting. Product colour: Black
Surface hardness Display - 3H
Tilt adjustment Ergonomics - Yes
Tilt angle range Ergonomics - -5 - 20 °
Title - Dahua Technology LM27-E231BN LED display 68.6 cm (27") 1920 x 1080 pixels Full HD Black
Touchscreen Display - No
Unit Box Height - 0.46
Unit Box Length - 0.69
Unit Box Width - 0.15
Unit Calculated Volume - 0.04761 cubm
Unit Calculated Weight - 4.9 kg
Units per Pallet - 0
URL - https://www.dahuasecurity.com/search/products?keyword=DHI-LM27-E231BN-A5-V1
Vendor Homepage - https://www.dahuasecurity.com/search/products?keyword=DHI-LM27-E231BN-A5-V1
VESA mounting Ergonomics - Yes
Viewable size, horizontal Display - 597.888 mm
Viewable size, vertical Display - 336.312 mm
Viewing angle, horizontal Display - 178 °
Viewing angle, vertical Display - 178 °
Wall mountable Ergonomics - Yes
Warranty - 36 months
WarrantyInfo -
Weight & dimensions - Bezel width (bottom) - 2.23 cm
Weight & dimensions - Bezel width (side) - 8.21 mm
Weight & dimensions - Bezel width (top) - 8.21 mm
Weight & dimensions - Depth (without stand) - 57.2 mm
Weight & dimensions - Height (without stand) - 366.8 mm
Weight & dimensions - Weight (without stand) - 3.55 kg
Weight & dimensions - Width (without stand) - 614.3 mm
Weight (without stand) Weight & dimensions - 3550 g
Width (without stand) Weight & dimensions - 614.3 mm
