AV-out Input/Output connectors - 1
Brand - Dahua Technology
BrandPartCode - DHI-LM27-P501
Brightness - 400
Category - Computer Monitors
Category Code - LC3
Colour - Silver
Contrast - 2000:1
Data Sheet (Link) Energy Efficiency - https://eprel.ec.europa.eu/api/product/2059253/fiches?language=EN
Depth Product Dimensions - 36.2 mm
Description - LM27-P501 Dahua 27-inch 5K Monitor
> The 5120 2880 resolution produces clearer and more vivid images. > 178 (H) / 178 (V) extra-wide viewing angle for overall viewing performance. > High fidelity digital processing for a brilliant and vivid video. > Supports multiple signal inputs such as HDMI, DP and Type-c. > Type-c reverse charge 65 W.
Design - Detachable stand - Yes
Design - Feet colour - Silver
Design - Frameless design - Yes
Design - Front bezel colour - Silver
Design - Market positioning - Business
Design - Product colour - Silver
Display - Backlight type - Edge LED
Display - Colour depth - 8 bit
Display - Colour gamut standard - DCI-P3
Display - Contrast ratio (typical) - 2000:1
Display - DCI-P3 coverage - 98%
Display - Display brightness (typical) - 400 cd/m²
Display - Display diagonal - 68.6 cm (27")
Display - Display diagonal (metric) - 69 cm
Display - Display resolution - 5120 x 2880 pixels
Display - Display technology - LED
Display - HD type - 5K Ultra HD
Display - LED backlight - Yes
Display - Maximum refresh rate - 60 Hz
Display - Native aspect ratio - 16:9
Display - Panel type - IPS
Display - Response time - 5 ms
Display - Screen shape - Flat
Display - Touchscreen - No
Display - Viewing angle, horizontal - 178°
Display - Viewing angle, vertical - 178°
Displayable colours - 16.7 million
DisplayPort Input/Output connectors - 1
Energy consumption, standard - 25 kWh/1000h
Energy efficiency class Energy Efficiency - F
EPREL Registration Number Energy Efficiency - 2059253
EPREL Version Number Energy Efficiency - 2
Ergonomics - Height adjustment - No
Ergonomics - Plug and Play - Yes
Ergonomics - Tilt adjustment - Yes
Ergonomics - Tilt angle range - -5 - 18°
Ergonomics - VESA mounting - No
GTIN - 6923172563200
HDMI Input/Output connectors - 1
Height Product Dimensions - 363.7 mm
LongDesc -
LongProductName - 27" 5K ELED, IPS, 16:9, 60 Hz, 5 ms, 400 cd/m², 2000:1, DP, HDMI, USB Type-C, 3.5 mm, 24 VDC, 5 A, 5.78 kg
LongSummaryDescription - Dahua Technology LM27-P501. Display diagonal: 68.6 cm (27"), Display resolution: 5120 x 2880 pixels, HD type: 5K Ultra HD, Display technology: LED, Response time: 5 ms, Native aspect ratio: 16:9, Viewing angle, horizontal: 178°, Viewing angle, vertical: 178°. Product colour: Silver
Model name - LM27-P501
Monitor features - Business
Multimedia - Built-in camera - No
Multimedia - Built-in speaker(s) - No
Native resolution - 5120x2880
Operational conditions - Operating relative humidity (H-H) - 10 - 90%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Operational conditions - Storage relative humidity (H-H) - 5 - 90%
Operational conditions - Storage temperature (T-T) - -20 - 60 °C
Other features - Compliance certificates - CE, Electromagnetic Compatibility (EMC), Low Voltage Directive (LVD)
Other features - Mean time between failures (MTBF) - 30000 h
Packaging content - Cables included - HDMI
Packaging content - Manual - Yes
Packaging content - Power adapter included - Yes
Packaging content - Stand included - Yes
Packaging data - Package depth - 138 mm
Packaging data - Package height - 533 mm
Packaging data - Package type - Box
Packaging data - Package weight - 8 kg
Packaging data - Package width - 702 mm
Panel type - IPS
Ports & interfaces - Audio output - Yes
Ports & interfaces - Built-in USB hub - No
Ports & interfaces - DisplayPorts quantity - 1
Ports & interfaces - DisplayPort version - 1.4
Ports & interfaces - HDMI - Yes
Ports & interfaces - HDMI ports quantity - 2
Ports & interfaces - HDMI version - 2.1
Ports & interfaces - Number of USB Type-C upstream ports quantity - 1
Power - AC adapter output voltage - 24 V
Power - Current rating - 5 A
Power - Energy consumption (HDR) per 1000 hours - 41 kWh
Power - Energy consumption (SDR) per 1000 hours - 25 kWh
Power - Energy efficiency class (HDR) - G
Power - Energy efficiency class (SDR) - F
Power - Energy efficiency scale - A to G
Power - Power consumption (max) - 120 W
Power - Power consumption (standby) - 0.5 W
Power - Power consumption (typical) - 41 W
Power - Power supply type - External
Power consumption - 36 Watts
ProductName - LM27-P501
Product Net Weight - 5.78 kg
Refresh rate - 60Hz
Response time - 5 ms
Screen form factor - 16:9
Screen LED backlight - Yes
Screen size - 27"
ShortSummaryDescription - Dahua Technology LM27-P501, 68.6 cm (27"), 5120 x 2880 pixels, 5K Ultra HD, LED, 5 ms, Silver
Standby consumption - 0.5 Watts
Title - Dahua Technology LM27-P501 LED display 68.6 cm (27") 5120 x 2880 pixels 5K Ultra HD Silver
Unit Box Height - 0.53
Unit Box Length - 0.7
Unit Box Width - 0.135
Unit Calculated Volume - 0.050085 cubm
Unit Calculated Weight - 6.8 kg
URL - https://www.dahuasecurity.com/search/products?keyword=DHI-LM27-P501
Vendor Homepage - www.dahuasecurity.com/mena/products/All-Products/Display--Control/Monitors/Commercial-Series/LM27-P501=V1
Viewing angle horizontal - 178 degrees
Viewing angle vertical - 178 degrees
Warranty - 36 months
WarrantyInfo -
Weight & dimensions - Bezel width (bottom) - 1.78 cm
Weight & dimensions - Bezel width (side) - 2.4 mm
Weight & dimensions - Bezel width (top) - 2.4 mm
Weight & dimensions - Depth (without stand) - 36.2 mm
Weight & dimensions - Height (without stand) - 363.7 mm
Weight & dimensions - Weight (without stand) - 5.78 kg
Weight & dimensions - Width (without stand) - 614.2 mm
Width Product Dimensions - 614.2 mm
