AC adapter output voltage Power - 12 V
Adjustable height (max) Ergonomics - 115 mm
Adobe RGB coverage Display - 83 %
Backlight type Display - LED
Brand - Dahua Technology
BrandPartCode - DHI-LM30-E330CA
Built-in USB hub Ports & interfaces - No
Cables included Packaging content - DisplayPort
Category - Computer Monitors
Category Code - LC3
Contrast ratio (typical) Display - 3000:1
Data Sheet (Link) Energy Efficiency - https://eprel.ec.europa.eu/api/product/1716107/fiches?language=EN
Depth (without stand) Weight & dimensions - 121.7 mm
Description - R1500 curved screen makes the vision more shockingThe back of the monitor is equipped with a light effect200HZ high refresh rate and 1ms fast response time to seize thegame and improve the odds of winningDCR intelligent processing chip restore the most realistic pictureAdaptive-sync technology reduces image quality loss andimproves visual fluencyGameplus function optimizes special scenes of popular gamesThe screen aspect ratio is 21:9, bringing an immersive experience
Design - Market positioning - Gaming
Design - Product colour - Black, Red
Display - Adobe RGB coverage - 83%
Display - Backlight type - LED
Display - Contrast ratio (typical) - 3000:1
Display - Display brightness (typical) - 250 cd/m²
Display - Display diagonal - 76.2 cm (30")
Display - Display resolution - 2560 x 1080 pixels
Display - Display technology - LCD
Display - HD type - UltraWide Full HD
Display - Maximum refresh rate - 200 Hz
Display - Native aspect ratio - 21:9
Display - NTSC coverage (typical) - 85%
Display - Panel type - VA
Display - Response time - 1 ms
Display - Screen curvature rating - 1500R
Display - Screen shape - Curved
Display - sRGB coverage (typical) - 120%
Display - Touchscreen - No
Display - Viewing angle, horizontal - 178°
Display - Viewing angle, vertical - 178°
Display brightness (typical) Display - 250 cd/m²
Display diagonal Display - 30 "
DisplayPorts quantity Ports & interfaces - 2
DisplayPort version Ports & interfaces - 1.2
Display resolution Display - 2560 x 1080 pixels
Display technology Display - LCD
Energy efficiency class (SDR) Power - F
Energy efficiency class Energy Efficiency - F
EPREL Registration Number Energy Efficiency - 1716107
EPREL Version Number Energy Efficiency - 2
Ergonomics - Adjustable height (max) - 11.5 cm
Ergonomics - Height adjustment - Yes
Ergonomics - Panel mounting interface - 75 x 75 mm
Ergonomics - Swivel angle range - -25 - 25°
Ergonomics - Swivelling - Yes
Ergonomics - Tilt adjustment - Yes
Ergonomics - Tilt angle range - -5 - 20°
Ergonomics - VESA mounting - Yes
European Product Registry for Energy Labelling (EPREL) code Power - 1716107
GTIN - 6923172579119
HDMI Ports & interfaces - Yes
HDMI ports quantity Ports & interfaces - 2
HDMI version Ports & interfaces - 2.0
HD type Display - UltraWide Full HD
Headphone out Ports & interfaces - Yes
Height (without stand) Weight & dimensions - 317.8 mm
Height adjustment Ergonomics - Yes
LongDesc -
LongProductName - 30", VA, 2560 x 1080, LED, 250 nits, 3000:1, 1 ms, 200Hz, Black/Red
LongSummaryDescription - Dahua Technology LM30-E330CA. Display diagonal: 76.2 cm (30"), Display resolution: 2560 x 1080 pixels, HD type: UltraWide Full HD, Display technology: LCD, Response time: 1 ms, Native aspect ratio: 21:9, Viewing angle, horizontal: 178°, Viewing angle, vertical: 178°. VESA mounting, Height adjustment. Product colour: Black, Red
Market positioning Design - Gaming
Maximum refresh rate Display - 200 Hz
Model - DHI-LM30-E330CA
Native aspect ratio Display - 21:9
NTSC coverage (typical) Display - 85 %
Operating relative humidity (H-H) Operational conditions - 10 - 85 %
Operating temperature (T-T) Operational conditions - 0 - 40 °C
Operational conditions - Operating relative humidity (H-H) - 10 - 85%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Package depth Packaging data - 248 mm
Package height Packaging data - 450 mm
Package weight Packaging data - 9000 g
Package width Packaging data - 817 mm
Packaging content - Cables included - DisplayPort
Packaging content - Stand included - Yes
Packaging data - Package depth - 248 mm
Packaging data - Package height - 450 mm
Packaging data - Package weight - 9 kg
Packaging data - Package width - 817 mm
Panel mounting interface Ergonomics - 75 x 75 mm
Panel type Display - VA
Ports & interfaces - Built-in USB hub - No
Ports & interfaces - DisplayPorts quantity - 2
Ports & interfaces - DisplayPort version - 1.2
Ports & interfaces - HDMI - Yes
Ports & interfaces - HDMI ports quantity - 2
Ports & interfaces - HDMI version - 2.0
Ports & interfaces - Headphone out - Yes
Power - AC adapter output voltage - 12 V
Power - Energy efficiency class (SDR) - F
Power - European Product Registry for Energy Labelling (EPREL) code - 1716107
Power - Power consumption (max) - 55 W
Power - Power consumption (standby) - 0.5 W
Power - Power consumption (typical) - 48 W
Power - Power supply type - External
Power consumption (max) Power - 55 W
Power consumption (standby) Power - 0.5 W
Power consumption (typical) Power - 48 W
Power supply type Power - External
Product colour Design - Black,Red
ProductName - LM30-E330CA
Product Net Weight - 6.5 kg
Response time Display - 1 ms
Screen curvature rating Display - 1500R
Screen shape Display - Curved
ShortSummaryDescription - Dahua Technology LM30-E330CA, 76.2 cm (30"), 2560 x 1080 pixels, UltraWide Full HD, LCD, 1 ms, Black, Red
sRGB coverage (typical) Display - 120 %
Stand included Packaging content - Yes
Summary - Dahua Technology LM30-E330CA. Display diagonal: 76.2 cm (30"), Display resolution: 2560 x 1080 pixels, HD type: UltraWide Full HD, Display technology: LCD, Response time: 1 ms, Native aspect ratio: 21:9, Viewing angle, horizontal: 178°, Viewing angle, vertical: 178°. VESA mounting, Height adjustment. Product colour: Black, Red
Swivel angle range Ergonomics - -25 - 25 °
Swivelling Ergonomics - Yes
Tilt adjustment Ergonomics - Yes
Tilt angle range Ergonomics - -5 - 20 °
Title - Dahua Technology LM30-E330CA computer monitor 76.2 cm (30") 2560 x 1080 pixels UltraWide Full HD LCD Black, Red
Touchscreen Display - No
Unit Box Height - 0.44
Unit Box Length - 0.815
Unit Box Width - 0.25
Unit Calculated Volume - 0.08965 cubm
Unit Calculated Weight - 8.6 kg
URL - https://display.dahuasecurity.com/consumer/en/products/productDetail?product_id=133337
Vendor Homepage - https://display.dahuasecurity.com/consumer/en/products/productDetail?product_id=133337
VESA mounting Ergonomics - Yes
Viewing angle, horizontal Display - 178 °
Viewing angle, vertical Display - 178 °
Warranty - 36 months
WarrantyInfo -
Weight & dimensions - Depth (without stand) - 121.7 mm
Weight & dimensions - Height (without stand) - 317.8 mm
Weight & dimensions - Weight (without stand) - 6.5 kg
Weight & dimensions - Width (without stand) - 701.1 mm
Weight (without stand) Weight & dimensions - 6500 g
Width (without stand) Weight & dimensions - 701.1 mm
