ARTIKEL1 - TX-2202A WHITE
ARTIKEL2 - .
Brand - AG Neovo
BrandPartCode - TX2A00A1E0000
Breite - 0
Category - Computer Monitors
Design - Glass thickness - 2.05 mm
Design - Housing material - Metal
Design - Market positioning - Medical
Design - Product colour - White
Display - Anti-glare screen - Yes
Display - Contrast ratio (typical) - 1000:1
Display - Display brightness (typical) - 250 cd/m²
Display - Display diagonal - 54.6 cm (21.5")
Display - Display number of colours - 16.7 million colours
Display - Display resolution - 1920 x 1080 pixels
Display - Display technology - LCD
Display - Haze rate - 25%
Display - HD type - Full HD
Display - Horizontal scan range - 30 - 84 kHz
Display - Native aspect ratio - 16:9
Display - Number of simultaneous touchpoints - 10
Display - Panel type - VA
Display - Pixel pitch - 0.248 x 0.248 mm
Display - Response time - 5 ms
Display - Screen shape - Flat
Display - Surface hardness - 7H
Display - Touchscreen - Yes
Display - Touchscreen technology - Capacitive
Display - Touch technology - Multi-touch
Display - Vertical scan range - 50 - 76 Hz
Display - Viewing angle, horizontal - 178°
Display - Viewing angle, vertical - 178°
EANCode - 4710739597974
Ergonomics - Panel mounting interface - 100 x 100 mm
Ergonomics - Tilt angle range - -5 - 90°
Ergonomics - VESA mounting - Yes
GRUPPE1 - Displays
GRUPPE2 - Led Small Format
GTIN - 4710739597974
HERSTELLER - AG NEOVO TECHNOLOGY
Hoehe - 0
HSTNUMMER - TX2A00A1E0000
Laenge - 0
LongDesc - The TX-2202A White touch screen monitor utilises PCAP multi-touch technology, which is minimally affected by contamination. It offers 10-point multi-touch capability for an accurate and responsive touch experience, including responsiveness to latex gloves. Featuring a medical-grade power supply and versatile connectivity options (such as DisplayPort, HDMI, and VGA inputs), the TX-2202A White is ideal for uses like medical carts or information kiosks in healthcare settings. The screen is further enhanced by its IP65 and IK08 ratings, metal casing, and an edge-to-edge 7H tempered glass design, ensuring durability for continuous use in clinical environments.10-Point PCAP Touch ScreenThe TX-2202A White touch screen incorporates PCAP touch technology, offering a 10-point multi-touch capability that remains unaffected by contamination. This results in a fast, accurate, and responsive touch experience, comparable to that of smartphones and tablets, and is responsive even when wearing latex gloves.Enhanced Safety with Medical-grade Power SupplyCompliance with IEC/EN 60601-1 standards for power supplies ensures the safety of staff and patients in clinical settings by preventing electric shocks and reducing energy-related and heat-related hazards.Front IP65 Dust and Water ProtectionThe TX-2202A White’s multi-touch monitor features a front-sided IP65 rating, protecting against dust and liquid spills, making it ideal for high-traffic public areas.Impact-Resistant Against VandalismWith an IK08 rating and a metal casing, the touch display is protected against impacts and acts of vandalism, ensuring a long service life in high-traffic areas.Ergonomic Monitors with Flexible MountingThe TX-2202A White 22” 10-point touch screen monitor is VESA compatible, offering various mounting options, including desk, wall, or monitor arm mounting. The included ergonomic stand allows for a wide tilt range of -2 to 180 degrees, enhancing ergonomics during use.Seamless integrationTouch support is compatible with various operating systems, including Windows, Linux, macOS, and certain Android versions. This allows for greater flexibility in choosing your operating system.Versatile ConnectivityThe TX-2202A White offers a range of connectivity options, making it easy for users to connect their devices, such as high-performance PCs or media players, using DisplayPort, HDMI, or VGA inputs.
LongProductName - 21.5", VA, 1920 x 1080px, 250 cd/m², 1000:1, 16.7M, 5 ms, 1 x DisplayPort, 1 x HDMI, 1 x VGA, RJ-11, 2 x 2W, 6.7 kg
LongSummaryDescription - AG Neovo TX-2202A. Display diagonal: 54.6 cm (21.5"), Display resolution: 1920 x 1080 pixels, HD type: Full HD, Display technology: LCD, Response time: 5 ms, Native aspect ratio: 16:9, Viewing angle, horizontal: 178°, Viewing angle, vertical: 178°. Built-in speaker(s). VESA mounting. Product colour: White
Multimedia - Built-in camera - No
Multimedia - Built-in speaker(s) - Yes
Multimedia - Number of speakers - 2
Multimedia - RMS rated power - 4 W
Operational conditions - Operating relative humidity (H-H) - 20 - 80%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Operational conditions - Storage relative humidity (H-H) - 10 - 90%
Operational conditions - Storage temperature (T-T) - -20 - 60 °C
Other features - Compliance certificates - CE, Low Voltage Directive (LVD), REACH, RoHS, UKCA, WEEE
Other features - International Protection (IP) code - IP65
Other features - Protection features - Dust resistant, Waterproof
Other features - Transmission rate - 90%
Packaging content - Cables included - AC, Audio, HDMI, USB, VGA
Packaging content - Power adapter included - Yes
Packaging content - Quick start guide - Yes
Packaging data - Package depth - 320 mm
Packaging data - Package height - 460 mm
Packaging data - Package weight - 9.8 kg
Packaging data - Package width - 610 mm
Performance - AMD FreeSync - No
Performance - Mac operating systems supported - Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave
Performance - NVIDIA G-SYNC - No
Performance - Other operating systems supported - Android
Performance - Windows operating systems supported - Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 IoT Enterprise, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 11, Windows 11 Enterprise, Windows 11 Enterprise x64, Windows 11 Home, Windows 11 Pro, Windows 11 x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 7 x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64
Ports & interfaces - Audio input - Yes
Ports & interfaces - Built-in USB hub - No
Ports & interfaces - DisplayPorts quantity - 1
Ports & interfaces - HDMI - Yes
Ports & interfaces - HDMI ports quantity - 1
Ports & interfaces - HDMI version - 1.4
Ports & interfaces - Headphone out - No
Ports & interfaces - Number of USB Type-B upstream ports quantity - 1
Ports & interfaces - USB upstream port type - USB Type-B
Ports & interfaces - VGA (D-Sub) ports quantity - 1
Power - Energy consumption (SDR) per 1000 hours - 15 kWh
Power - Energy efficiency class (HDR) - Not available
Power - Energy efficiency class (SDR) - E
Power - European Product Registry for Energy Labelling (EPREL) code - 1372216
Power - Power consumption (off) - 0.3 W
Power - Power consumption (standby) - 0.7 W
Power - Power consumption (typical) - 15 W
Power - Power supply type - External
ProductName - TX-2202A
ShortSummaryDescription - AG Neovo TX-2202A, 54.6 cm (21.5"), 1920 x 1080 pixels, Full HD, LCD, 5 ms, White
Stck_Kart - 1
Stck_Pal - 0
Storno - Y
Sustainability - Sustainability compliance - Yes
Title - AG Neovo TX-2202A computer monitor 54.6 cm (21.5") 1920 x 1080 pixels Full HD LCD Touchscreen White
URL - https://www.agneovo.com/global/products/tx-2202a-white?srsltid=AfmBOoovYsYFz3zQ9q6zpx6q_9GLYeofW7A9uVdHM5JzMIURffHjGx2l
WarrantyInfo -
Weight & dimensions - Depth (without stand) - 48.5 mm
Weight & dimensions - Depth (with stand) - 214.2 mm
Weight & dimensions - Height (without stand) - 324.3 mm
Weight & dimensions - Height (with stand) - 346.7 mm
Weight & dimensions - Weight (without stand) - 4.8 kg
Weight & dimensions - Weight (with stand) - 6.7 kg
Weight & dimensions - Width (without stand) - 528.6 mm
Weight & dimensions - Width (with stand) - 528.6 mm
