8-pin 12V power connectors - 0
Accessories included - Power cord Motherboard power cable (600 mm) 2 x CPU Cable (650 mm) PCIE 16-pin cable (675 mm) 6 x PCIE 1 to 1 Cable (675mm) 2 x PCIE 1 to 2 cable (675+75 mm) 3 x SATA 1 to 4 Cable (400+120+120+120 mm) 3 x Peripheral cable 1 to 2 (450+120 mm) Addressable RGB cable (800 mm) ROG sticker 6 x ROG Cable Ties Screw package 12 x Cable Ties User manual
Brand - ASUS
BrandPartCode - 90YE00K0-B0NA00
category - PC Components|Power Supplies|PCIe 5.0
Category - Power Supply Units
Category - Root/Electronics/PC parts/PC power supply units
Category_1 - Power
Category_2 - Computer Power Supplies
Certificates - Compliance certificates - CE, Low Voltage Directive (LVD), RoHS
Certificates 80+ - 80 PLUS Platinum
code - 90YE00K0-B0NA00
Description - Rog Thor Titanium 1600W 80+ ATX 3.0 power supply The quietest power unit with a power of 1600 W The latest Thor power unit model features a redesigned core that delivers higher power efficiency, improved cooling and lower noise levels for high-performance systems that effortlessly handle any task they are tasked with. Digital power control The digital controller provides precise control of the GaN power system, facilitating rapid response to load changes. GaN MOSFET transistors Gallium nitride MOSFETs are the power source of the Thor power unit. Offering lower switching losses and improved efficiency compared to conventional silicon transistors, GaN FETs allow the Thor 1600W power supply to deliver massive amounts of current without unnecessary energy waste. 80 Plus Titanium certification Low ESR capacitors made in Japan further improve efficiency and reduce heat generation. Thanks to this, Thor is ready to reliably power your system for many years. ROG heatsinks Integrated ROG heatsinks have twice the surface area of conventional designs, resulting in 20% lower temperatures inside the power supply unit. As a result, the life of the components is extended. PWN 135 mm fan The Axial-tech PWM fan drives 21% more air and requires a lower RPM to cool critical components. Because Thor is designed from the ground up to stay cool, the fan turns off completely when the power supply load is 50% or less. Lambda A++ certification Cooling improvements to the Thor Titanium deliver the low Lambda A++ noise levels desired by users. This confirms that the latest versions of these power units offer enormous power while being almost inaudible. Braided cables The Thor power unit comes with a complete braided cable package, and we also provide a 20% discount on CableMod products. Compatibility WITH ATX 3.0 The latest power solutions are now available. ATX 3.0 introduces more stringent voltage and current regulation guidelines for the latest generation of hardware, and ROG Thor 1600W Titanium is ahead of the competition in this respect, ensuring full compliance with this standard. The power unit comes with a 16-pin PCIe cable that allows you to deliver up to 600W of power to graphics cards connected via PCIe Gen 5.0, so your system will be ready for the latest technologies. 10 years warranty We are so confident in the reliability of the ROG Thor 1600W Titanium Power Supply that we provide it with a 10-year* warranty. *The main functionality of the product is guaranteed for a period of 10 years. The OLED panel and LEDs are covered by a 3-year warranty.
Design - Cooling type - Active
Design - Fan diameter - 13.5 cm
Design - Illumination - Yes
Design - On/off switch - Yes
Design - Product colour - Black, Silver
Designation - CE+WEEE
dimension depth - 120 mm
dimension height - 310 mm
Dimensions - 190 x 150 x 86 mm
dimension weight - 4030 g
dimension width - 370 mm
ean - 4711081198390
Eans - 4711081198390
EAN_code - 4711081198390
Fan - 13.5 cm
Floppy power connectors - 0
GTIN - 4711081198390
guarantee - 120
guarantee_type - normal
Logistics data - Harmonized System (HS) code - 84733020
LongDesc - THE QUIETEST 1600W POWER SUPPLYThe ultimate expression of Thor wields a redesigned core that brings higher power efficiency, improved cooling, and lower noise to monstrous rigs that slay everything in their path.Based on Cybenetics PSU test result database entries before October 2021.COMPONENTSGAN MOSFETSGallium nitride MOSFETs are the source of Thor’s power. Boasting lower switching losses and improved efficiency compared to conventional silicon transistors, GaN FETs allow the 1600W Thor to swing massive amounts of current without being needlessly wasteful.DIGITAL POWER CONTROLA digital controller provides precise control over the GaN power array, facilitating lightning-fast response to load changes.80 PLUS TITANIUM CERTIFICATIONLow-ESR Japanese capacitors further improve efficiency and reduce heat, readying Thor to reliably fuel your build for years to come.THERMAL CONTROLROG HEATSINKSIntegrated ROG heatsinks have 2x more volume than traditional designs, resulting in 20% lower temperatures inside the PSU, further extending component lifespan.135MM PWM FANThe PWM-controlled Axial-tech fan shifts 21% more air and needs fewer revolutions to cool critical components. And because Thor is designed from the ground up to stay cool, the fan shuts off entirely when the PSU load is 50% or below.LAMBDA A++ CERTIFICATIONThor Titanium cooling upgrades result in a coveted Lambda A++ noise rating, confirming the latest iteration wields menacing power in absolute stealth.EXPERIENCESLEEVED CABLESA range of sleeved cables are bundled with Thor, and we also provide a 20% CableMod discount.PCIE GEN 5.0 READYEach ROG Thor 1600W Titanium PSU is bundled with a 16-pin PCIe cable that can pipe up to 600W of power to PCIe Gen 5.0 graphics cards. Get ready for the future of power delivery.EXPERIENCE10-YEAR WARRANTYWe're so confident about the reliability of the ROG Thor 1600W Titanium that we back it with a 10-year* warranty.*Core product operation is guaranteed for 10 years. The OLED panel and RGB LEDs are subject to a 3-year warranty.
LongProductName - ROG-THOR-1600T-GAMING
LongSummaryDescription - ASUS ROG THOR 1600W Titanium. Total power: 1600 W, AC input voltage: 100 - 240 V, Combined power (+3.3V): 100 W. Motherboard power connector: 20+4 pin ATX, Cabling type: Fully-Modular. Purpose: PC, Power supply unit (PSU) form factor: ATX, 80 PLUS certification: 80 PLUS Titanium. Product colour: Black, Silver, Cooling type: Active, Fan diameter: 13.5 cm. Cables included: AC, CPU, PCIe, Peripheral (Molex), SATA
Manufacturer - Asus
Manufacturer_code - 90YE00K0-B0NA00
MB power connector - 20 + 4 pin
Modular power supply - Yes
MOLEX power connectors - 6
Name - ASUS ROG-THOR-1600T-GAMING
name - ASUS ROG Thor 1600T Gaming, 80 PLUS Titanium Netzteil, modular, PCIe 5.0 - 1600 Watt
Name - ASUS ROG THOR 1600W Titanium 1600W, PC power supply (black, with Aura Sync and an OLED display, 1600 watts)
name - Power supply Rog Thor Titanium 1600W 80+ ATX 3.0
Number of connectors PATA - 0
Number of power connectors 12VHPWR - 0
Number of power connectors PCI-E 16-pin Gen 5 - 1
Number of power supply connector 4+4-pin 12V - 2
Number of power supply connector 4-pin 12V - 0
Number of power supply connectors PCI-E 6 +2 pin - 10
Other features -
Packaging content - Cables included - AC, CPU, PCIe, Peripheral (Molex), SATA
Packaging content - Cable tie(s) included - Yes
Packaging data - Package type - Box
Packaging data - Package weight - 2.71 kg
PCI-E 6-pin power connectors - 0
PCI-E 8-pin power connectors - 0
Performance - 80 PLUS certification - 80 PLUS Titanium
Performance - Power supply unit (PSU) form factor - ATX
Performance - Purpose - PC
PFC - Active
Ports & interfaces - ATX power connector (20+4 pin) - Yes
Ports & interfaces - Cabling type - Fully-Modular
Ports & interfaces - CPU P4 connector (4-pin) - 2
Ports & interfaces - CPU power connector (4+4 pin) - Yes
Ports & interfaces - Motherboard power connector - 20+4 pin ATX
Ports & interfaces - Number of SATA power connectors - 12
Ports & interfaces - PCI Express power connectors (6+2 pin) - 10
Ports & interfaces - PCI Express power connectors (16-pin) - 1
Ports & interfaces - Peripheral (Molex) power connectors (4-pin) - 6
Power - AC input voltage - 100 - 240 V
Power - Combined power (+3.3V) - 100 W
Power - Combined power (+5V) - 100 W
Power - Combined power (+5Vsb) - 15 W
Power - Combined power (+12V) - 1600 W
Power - Combined power (-12V) - 3.6 W
Power - Max output current (+3.3V) - 20 A
Power - Max output current (+5V) - 20 A
Power - Max output current (+5Vsb) - 3 A
Power - Max output current (+12V) - 133.3 A
Power - Max output current (-12V) - 0.3 A
Power - Power protection features - Over power, Overcharge, Overheating, Overload, Short circuit, Under voltage
Power - Total power - 1600 W
Power supply - 1600 W
producer - Asus
Producer - Asus
ProducerCode - 90YE00K0-B0NA00
ProductName - ROG THOR 1600W Titanium
SATA power connectors - 12
ShortDescription - 1600 | ATX | 135mm | 20 + 4 pin | 80 Plus Titanium| 190 x 150 x 86 mm |
ShortSummaryDescription - ASUS ROG THOR 1600W Titanium, 1600 W, 100 - 240 V, 100 W, 1600 W, 100 W, 3.6 W
Technical details - Sustainability compliance - Yes
Title - ASUS ROG THOR 1600W Titanium power supply unit 20+4 pin ATX ATX Black, Silver
URL - https://rog.asus.com/power-supply-units/rog-thor/rog-thor-1600t-gaming-model/
vendpn - 90YE00K0-B0NA00
WarrantyInfo -
Weight - 6,30
Weight & dimensions - Depth - 150 mm
Weight & dimensions - Height - 86 mm
Weight & dimensions - Weight - 2.69 kg
Weight & dimensions - Width - 190 mm
