Corsair RM1000e Low-Noise ThermalProtect, 1000W, Cybenetics Platinum, ATX 3.1, PCIe 5.1

8-pin 12V power connectors - 0
ATX version - 3.1
category - PC Components|Power Supplies|Modular Power Supplies
Certificates 80+ - 80 PLUS Gold
code - CP-9020337-EU
Cybenetics Efficiency (ETA) - Platinum
Cybenetics Noise (LAMBDA) - A-
Description -
Design - Cooling type - Active
Design - Product colour - Black
Designation - CE+WEEE
dimensionalWeight - 1478
dimension depth - 130 mm
dimension height - 190 mm
Dimensions - 140 x 150 x 86 mm
dimension weight - 3151 g
dimension width - 290 mm
ean - 0840440430841
ean - 840440430841
Fan - 12 cm
Filters / protection - Circuit
Filters / protection - Current too high
Filters / protection - Overload
Filters / protection - Surge
Filters / protection - Thermal
Filters / protection - Voltage drop
Floppy power connectors - 0
Form Factor - ATX
guarantee - 120
guarantee_type - normal
MB power connector - 24 pin
Modular power supply - Yes
MOLEX power connectors - 2
name - Corsair RMe Series (3rd Gen), RM1000e ThermalProtect Platinum Power Supply, modular, ATX 3.1, PCIe 5.1 - 1000 Watt
name - Power supply RM1000e 3rd Gen 80+GOLD ATX3.1 Thermal Protect
Number of connectors PATA - 0
Number of power connectors 12VHPWR - 0
Number of power connectors PCI-E 16-pin Gen 5 - 1
Number of power supply connector 4+4-pin 12V - 2
Number of power supply connector 4-pin 12V - 0
Number of power supply connectors PCI-E 6 +2 pin - 2
Number of USB 10p connectors - 0
PCI-E 6-pin power connectors - 0
PCI-E 8-pin power connectors - 0
Performance - Power supply unit (PSU) form factor - ATX
Performance - Purpose - PC
PFC - Active
PMBus 5 Pin - 0
Ports & interfaces - CPU power cable length - 75 cm
Ports & interfaces - CPU power connector (4+4 pin) - Yes
Ports & interfaces - Motherboard power cable length - 61 cm
Ports & interfaces - Motherboard power connector - 24-pin ATX
Ports & interfaces - Number of PATA power connectors - 2
Ports & interfaces - Number of SATA power cables - 2
Ports & interfaces - Number of SATA power connectors - 6
Ports & interfaces - PCI Express power connectors (6+2 pin) - 4
Ports & interfaces - PCI Express power connectors (12+4 pin) - 1
Ports & interfaces - PCI Express power connectors (12+4 pin) cable length - 650 mm
Ports & interfaces - SATA power cable length - 750 mm
Power - AC input frequency - 47 - 63 Hz
Power - AC input voltage - 100 - 240 V
Power - Combined power (+3.3V) - 150 W
Power - Combined power (+5V) - 150 W
Power - Combined power (+5Vsb) - 15 W
Power - Combined power (+12V) - 1000 W
Power - Efficiency - 91%
Power - Input current - 12 - 5 A
Power - Max output current (+3.3V) - 20 A
Power - Max output current (+5V) - 20 A
Power - Max output current (+5Vsb) - 3 A
Power - Max output current (+12V) - 83.3 A
Power - Total power - 1000 W
Power supply - 1000 W
producer - Corsair
producerCode - CP-9020337-EU
productName - Corsair RM Series RM1000e Power supply 1000W 24-pin ATX Black
productSize - Normal
Safety warning - Hazard pictogram(s) - GHS02: Flammable
Safety warning - Hazard pictogram(s) - GHS07: Harmful
Safety warning - Hazard pictogram(s) - GHS09: Environmental hazard
Safety warning - Warnings - Avoid contact of the product with water or other liquids.
Safety warning - Warnings - Do not open the appliance housing - risk of electric shock.
Safety warning - Warnings - The product is not suitable for disposal with municipal waste - dispose of in accordance with local regulations.
SATA power connectors - 6
sizeX - 192
sizeY - 131
sizeZ - 294
vendpn - CP-9020337-EU
warrantyLength - 24
warrantyType - G
weight - 3144
