Brand - Chieftec
BrandPartCode - CTG-650C
Category - Power Supply Units
Category Code - PSU
Certificates - Certification - CE, CB, FCC
Certificates - Compliance certificates - RoHS
Description - This popular PSU series is now extended by new models featuring cable management. With many awards granted, these PSUs are perfectly suited for cost aware users, who pay attention to both good price and high efficiency.
Design - Cooling type - Active
Design - Fan diameter - 12 cm
Design - Fan location - Top
Design - Number of fans - 1 fan(s)
Design - Product colour - Black
GTIN - 4710713239371
Logistics data - Harmonized System (HS) code - 84733020
LongDesc - this popular PSU series is now extended by new models featuring cable management. With many awards granted, these PSUs are perfectly suited for cost aware users, who pay attention to both good price and high efficiency.
LongProductName - 650W, 230V/6A, ATX 12V 2.3, PS II, >85%, 120mm fan
LongSummaryDescription - Chieftec CTG-650C. Total power: 650 W, AC input voltage: 230 V, AC input frequency: 50 Hz. Motherboard power connector: 24-pin ATX, Cabling type: Semi-Modular. Purpose: PC, Power supply unit (PSU) form factor: ATX, 80 PLUS certification: 80 PLUS. Product colour: Black, Cooling type: Active, Fan diameter: 12 cm. Compliance certificates: RoHS, Certification: CE, CB, FCC
Packaging data - Package type - Box
Performance - 80 PLUS certification - 80 PLUS
Performance - ATX version - 2.3
Performance - Mean time between failures (MTBF) - 100000 h
Performance - Power supply unit (PSU) form factor - ATX
Performance - Purpose - PC
Ports & interfaces - Cabling type - Semi-Modular
Ports & interfaces - CPU P4 connector (4-pin) - 1
Ports & interfaces - CPU power connectors (8-pin) - 1
Ports & interfaces - EPS power connector (8-pin) - Yes
Ports & interfaces - Floppy drive power connector - 2
Ports & interfaces - Motherboard power connector - 24-pin ATX
Ports & interfaces - Number of SATA power connectors - 6
Ports & interfaces - PCI Express power connectors (6+2 pin) - 2
Ports & interfaces - Peripheral (Molex) power connectors (4-pin) - 4
Power - AC input frequency - 50 Hz
Power - AC input voltage - 230 V
Power - Combined power (+3.3V) - 130 W
Power - Combined power (+5V) - 130 W
Power - Combined power (+5Vsb) - 15 W
Power - Combined power (+12V) - 552 W
Power - Combined power (-12V) - 3.6 W
Power - Efficiency - 85%
Power - Input current - 6 A
Power - Maximum input current (@110V) - +12V1,+12V2,+3.3V,+5V,+5Vsb,-12V
Power - Max output current (+3.3V) - 22 A
Power - Max output current (+5V) - 22 A
Power - Max output current (+5Vsb) - 3 A
Power - Max output current (+12V1) - 300 A
Power - Max output current (+12V2) - 30 A
Power - Max output current (-12V) - 0.3 A
Power - Power factor - 0.9
Power - Power Factor Correction (PFC) type - Active
Power - Power protection features - Over current, Over voltage, Overheating, Overload, Short circuit, Under current, Under voltage
Power - Total power - 650 W
ProductName - CTG-650C
ShortSummaryDescription - Chieftec CTG-650C, 650 W, 230 V, 50 Hz, 6 A, +12V1,+12V2,+3.3V,+5V,+5Vsb,-12V, Active
Title - Chieftec CTG-650C power supply unit 650 W 24-pin ATX ATX Black
Unit Box Height - 0.1
Unit Box Length - 0.25
Unit Box Width - 0.185
Unit Calculated Volume - 0.005995 cubm
Unit Calculated Weight - 2.54 kg
Units per Pallet - 0
Units per Shipping Box - 8
URL - https://www.chieftec.eu/en/psus/a-80-series/ctg-650c.html
Vendor Homepage - www.chieftec.eu/en/psus/ps-2/a-80-series/ctg-650c.html
Warranty - 24 months
WarrantyInfo - 2 year
Weight & dimensions - Depth - 140 mm
Weight & dimensions - Height - 87 mm
Weight & dimensions - Width - 150 mm
