Brand - be quiet!
BrandPartCode - BP029EU
category - PC Components|Power Supplies|PSUs above 800 Watts
Category - Power Supply Units
Category 1 - Netzteile
Category_1 - Power
Category_2 - Computer Power Supplies
Certificates - Compliance certificates - BSMI, CB, CCC, CE, Federal Communications Commission (FCC), IRAM, RCM, RoHS, TÜV mark, UKCA, WEEE, cTUVus
Certificates - Waste Electrical and Electronic Equipment (WEEE) compliance - Yes
code - BP029EU
Design - Cooling type - Active
Design - Fan diameter - 12 cm
Design - Fan speed - 0 - 2700 RPM
Design - Number of fans - 1 fan(s)
Design - On/off switch - Yes
Design - Product colour - Black
ean - 4260052193655
EAN - 4260052193655
EAN_code - 4260052193655
GTIN - 4260052193655
Logistics data - Products per shipping (inner) case - 6 pc(s)
Logistics data - Shipping (inner) case gross weight - 20.8 kg
Logistics data - Shipping (inner) case height - 24.5 cm
Logistics data - Shipping (inner) case length - 59 cm
Logistics data - Shipping (inner) case width - 32 cm
LongDesc - Exceptional quiet, superior featuresPure Power 13 M 1200W is an ATX 3.1 compliant and PCIe 5.1 compatible power supply with semi-passive cooling. It offers peerless dependability with best-in-class features. Having both a PCIe 5.1 cable and PCIe 6+2 cables in the scope of delivery, this PSU offers outstanding compatibility with current-gen and next-gen graphics cards. Pure Power 13 M 1200W offers the best combination of features with outstanding compatibility.
LongProductName - 1200W, 80 PLUS Gold, ATX 3.1, EPS 12V 2.92, 160 x 150 x 86 mm
LongSummaryDescription - be quiet! Pure Power 13 M | 1200W. Total power: 1200 W, AC input voltage: 110 - 240 V, Peak power: 1250 W. Motherboard power connector: 20+4 pin ATX, Motherboard power cable length: 55 cm, SATA power cable length: 500,650,800,950 mm. Purpose: PC, Power supply unit (PSU) form factor: ATX, 80 PLUS certification: 80 PLUS Gold. Product colour: Black, Cooling type: Active, Fan diameter: 12 cm. Cables included: AC, CPU, PCIe, Peripheral (Molex), SATA
Manufacturer - Be quiet
Manufacturer - Be Quiet!
Manufacturer_code - BP029EU
MPN - BP029EU
Name - 1200W be quiet! Pure Power PRO 13 | 80+ Gold ATX 3.1
name - be quiet! Pure Power 13M 80 PLUS Gold Netzteil, ATX 3.1, PCIe 5.1 - 1.200 Watt, schwarz
Name - Be quiet Pure Power 13 M 1200W (black, 1x 12-pin high power GPU, 4x PCIe, cable management, 1200 watts)
Operational conditions - Operating relative humidity (H-H) - 0 - 85%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Operational conditions - Storage relative humidity (H-H) - 0 - 95%
Operational conditions - Storage temperature (T-T) - -40 - 70 °C
Other features - Cable ties included - Yes
Other features - Screws included - Yes
Packaging content - Cables included - AC, CPU, PCIe, Peripheral (Molex), SATA
Packaging data - Manual - Yes
Packaging data - Manual languages - German, English, Spanish, French, Polish, Russian, Ukrainian
Packaging data - Package depth - 284 mm
Packaging data - Package height - 100 mm
Packaging data - Package type - Box
Packaging data - Package weight - 3.14 kg
Packaging data - Package width - 220 mm
Performance - 80 PLUS certification - 80 PLUS Gold
Performance - ATX version - 3.1
Performance - Bearing technology - Rifle
Performance - EPS version - 2.92
Performance - Mean time between failures (MTBF) - 100000 h
Performance - Noise level - 32.3 dB
Performance - Power supply unit (PSU) form factor - ATX
Performance - Purpose - PC
Ports & interfaces - Cabling type - Fully-Modular
Ports & interfaces - CPU P4 connector (4-pin) - 2
Ports & interfaces - CPU power cable length - 65 cm
Ports & interfaces - CPU power connector (4+4 pin) - Yes
Ports & interfaces - EPS power connector (8-pin) - Yes
Ports & interfaces - Motherboard power cable length - 55 cm
Ports & interfaces - Motherboard power connector - 20+4 pin ATX
Ports & interfaces - Number of SATA power cables - 2
Ports & interfaces - Number of SATA power connectors - 6
Ports & interfaces - PCI Express power cable length - 60 cm
Ports & interfaces - PCI Express power connectors (6+2 pin) - 4
Ports & interfaces - PCI Express power connectors (12-pin) - 1
Ports & interfaces - Peripheral (Molex) power cable length - 800,950 mm
Ports & interfaces - Peripheral (Molex) power connectors (4-pin) - 2
Ports & interfaces - SATA power cable length - 500,650,800,950 mm
Power - AC input frequency - 50/60 Hz
Power - AC input voltage - 110 - 240 V
Power - Combined power (+3.3V) - 120 W
Power - Combined power (+5V) - 120 W
Power - Combined power (+5Vsb) - 15 W
Power - Combined power (+12V) - 1200 W
Power - Combined power (-12V) - 3.6 W
Power - Efficiency - 90.8%
Power - Hold time - 19.11 ms
Power - Maximum input current (@110V) - 15 A
Power - Maximum input current (@220V) - 7.5 A
Power - Max output current (+3.3V) - 22 A
Power - Max output current (+5V) - 22 A
Power - Max output current (+5Vsb) - 3 A
Power - Max output current (+12V) - 100 A
Power - Max output current (-12V) - 0.3 A
Power - Number of +12V rail(s) - 1
Power - Peak power - 1250 W
Power - Power factor - 0.97
Power - Power Factor Correction (PFC) type - Active
Power - Power protection features - Over current, Over power, Over voltage, Overheating, Short circuit, Surge & inrush protection (SIP), Under voltage
Power - Total power - 1200 W
ProductName - Pure Power 13 M | 1200W
ShortSummaryDescription - be quiet! Pure Power 13 M | 1200W, 1200 W, 110 - 240 V, 1250 W, 50/60 Hz, 15 A, 7.5 A
Technical details - Sustainability certificates - ENERGY STAR, ErP
Title - be quiet! Pure Power 13 M | 1200W power supply unit 20+4 pin ATX ATX Black
URL - https://www.bequiet.com/en/download/products
WarrantyInfo - 10-year manufacturer’s warranty
Weight - 3,14
Weight - 3.279
Weight & dimensions - Depth - 160 mm
Weight & dimensions - Height - 86 mm
Weight & dimensions - Weight - 2.69 kg
Weight & dimensions - Width - 150 mm
