Brand - COUGAR
BrandPartCode - 31PX120001P01
Category - Power Supply Units
Category 1 - Netzteile
Certificates - Compliance certificates - CCC, CE, EAC, Federal Communications Commission (FCC), RoHS, TÜV mark
Design - Cooling type - Active
Design - Fan diameter - 13.5 cm
Design - Number of fans - 1 fan(s)
Design - On/off switch - Yes
Design - Product colour - Silver
EAN - 4710483775420
GTIN - 4710483775420
Logistics data - Country of origin - China
LongDesc - The Polar X2 passes the four strict power excursion tests from PSU ATX 3.1 Guide, in which the spike power consumption must bear up to 200% of the rated power for 100μs.The modular 12+4pin, 12V-2X6, cable delivers perfect power supplies for next-gen graphics cards.Without any 6+2pin adaptor, the 650mm length can reduce connection risk while the PC installation.COUGAR will present the first Platinum efficiency PSU Series, POLAR X2 1200 and 1050. The 100% Japanese capacitors and 50°C ambient operations with LLC, DC-DC structure generate an environmentally friendly PSU with high-efficiency performance. The fine-tune HDB fan with zero noise mode will also provide the perfect experience for all users in different conditions.EVERY OUTPUT IS WORTH SAVINGSave the Earth with Lesser Energy Loss- The Polar X2 series will reduce the energy waste below 7%.- With 80Plus Platinum certified to provide the efficiency level up to 92% at 115Vac.- Less efficiency loss with streamlined board-to-board wave soldering.ZERO NOISE MODEULTRA-SILENCE AT HIGH OUTPUTLower Heat Emission for Steady Temperature- Zero noise mode at 40% loading silent.- Automatic thermal control to provide an optimal speed-noise ratio.Using COUGAR’s 135mm HDB silent fan and large inhalation punched hole, the advanced frame increase the concentration of airflow and its fan curvature has been fine-tuned to reduce vibration.- Hybrid Dynamic Bearing (HDB) fan to expand the durability.- Patented groove design- Centralized oil pressure- No oil leakage- Improved stability- Less friction and noise- Extended lifespanJAPANESE CAPACITORSREFIND ELECTRONIC SOLUTIONReduce the E-waste for the Next Generation- 100% premium Japanese capacitor to prolong the longevity.- Optimally perform in 50ºC working temperature environments.- Tight 2% voltage regulation for ultra-stable operation. FeaturesSupport PCI Express 5.0 Graphics Cards 12+4 Pin ConnectorConnect the 12V-2X6 with true 200% power excursion dynamic outputs80PLUS Platinum CertifiedUp to 92% efficiency power conversion to cut down your electricity bill100% Refined Japanese CapacitorsOutstanding components extend the longevity of PSU.Durable HDB FanHydro Dynamic Bearing Fan: Extended durability and lower noise levelsZero Noise Mode and Fan Curve TuningAdvanced technology for noise minimizationFully Modular Power Supply UnitConnect only the cables you need for less clutter and better airflowFlawless Operation at 50°CPowerful performance at 50°C ambient temperatureCompatible with The Lastest PC TechnologyCreated for user with current and next-generation multi-core CPU platformsProtectionUVP (Under Voltage Protection)If the voltages fall below a certain tolerance value on the single lines, the PSU automatically switches off.OCP (Overcurrent Protection)If the current on a single line is higher than indicated, the PSU automatically switches off.SCP (Short-Circuit Protection)In the case of a short-circuit, this feature prevents damage to the core components of the PSU and its System components.OVP (Over Voltage Protection)If the voltages increase above a certain tolerance value on the single lines, the PSU automatically switches off.OTP (Over Temperature Protection)If the temperature gets too high, the PSU automatically switches off.OPP (Over Power Protection)If the system is oversized and requires more power from the PSU than it can provide, this protection function is activated.Conformal Coating ProtectionPrevention of conductive particles/dust, high humidity, and intruding insects
LongProductName - ATX 3.1, 80Plus Platinum, 1200 W, AC100-240V~ 47-63Hz 15-7A, 12V-2X6, 180 x 150 x 86 mm, 2.09kg
LongSummaryDescription - COUGAR POLAR X2. Total power: 1200 W, AC input voltage: 100 - 240 V, AC input frequency: 47 - 63 Hz. Motherboard power connector: 20+4 pin ATX, Motherboard power cable length: 65 cm, SATA power cable length: 120,500 mm. Purpose: PC, Power supply unit (PSU) form factor: ATX, 80 PLUS certification: 80 PLUS Platinum. Product colour: Silver, Cooling type: Active, Fan diameter: 13.5 cm. Compliance certificates: CCC, CE, EAC, Federal Communications Commission (FCC), RoHS, TÜV mark
Manufacturer - Cougar
MPN - CGR-POLAR-X2-1200
Name - 1200W COUGAR Netzteil POLAR X2 1200W ATX3.1 /80 Plus Plat./Modular
Operational conditions - Operating relative humidity (H-H) - 20 - 85%
Operational conditions - Operating temperature (T-T) - 10 - 50 °C
Operational conditions - Storage relative humidity (H-H) - 5 - 95%
Operational conditions - Storage temperature (T-T) - -40 - 70 °C
Packaging data - Package depth - 331 mm
Packaging data - Package height - 107 mm
Packaging data - Package type - Box
Packaging data - Package weight - 3.59 kg
Packaging data - Package width - 229 mm
Performance - 80 PLUS certification - 80 PLUS Platinum
Performance - ATX version - 3.1
Performance - Bearing technology - HDB
Performance - Mean time between failures (MTBF) - 100000 h
Performance - Noise level - 26 dB
Performance - Power supply unit (PSU) form factor - ATX
Performance - Purpose - PC
Performance - Silent mode - Yes
Ports & interfaces - ATX power connector (20+4 pin) - Yes
Ports & interfaces - Cabling type - Fully-Modular
Ports & interfaces - CPU power cable length - 65 cm
Ports & interfaces - CPU power connector (4+4 pin) - Yes
Ports & interfaces - EPS power connector (8-pin) - Yes
Ports & interfaces - Motherboard power cable length - 65 cm
Ports & interfaces - Motherboard power connector - 20+4 pin ATX
Ports & interfaces - Number of PATA power connectors - 4
Ports & interfaces - Number of SATA power connectors - 12
Ports & interfaces - PCI Express connector - Yes
Ports & interfaces - PCI Express power connectors (6+2 pin) - 6
Ports & interfaces - PCI Express power connectors (8-pin) - 1
Ports & interfaces - PCI Express power connectors (12+4 pin) - 1
Ports & interfaces - PCI Express power connectors (12+4 pin) cable length - 650 mm
Ports & interfaces - Peripheral (Molex) power cable length - 120,500 mm
Ports & interfaces - Peripheral (Molex) power connectors (4-pin) - 4
Ports & interfaces - SATA power cable length - 120,500 mm
Power - AC input frequency - 47 - 63 Hz
Power - AC input voltage - 100 - 240 V
Power - Combined power (+3.3V) - 100 W
Power - Combined power (+5V) - 100 W
Power - Combined power (+5Vsb) - 15 W
Power - Combined power (+12V) - 1200 W
Power - Combined power (-12V) - 3.6 W
Power - Efficiency - 89%
Power - Input current - 15 - 7 A
Power - Max output current (+3.3V) - 20 A
Power - Max output current (+5V) - 20 A
Power - Max output current (+5Vsb) - 3 A
Power - Max output current (+12V) - 100 A
Power - Max output current (-12V) - 0.3 A
Power - Power protection features - Over current, Over power, Over voltage, Overheating, Short circuit, Under voltage
Power - Total power - 1200 W
ProductName - POLAR X2
ShortSummaryDescription - COUGAR POLAR X2, 1200 W, 100 - 240 V, 47 - 63 Hz, 15 - 7 A, 100 W, 1200 W
Title - COUGAR POLAR X2 power supply unit 1200 W 20+4 pin ATX ATX Silver
URL - https://cougargaming.com/products/psus/polar-x2/
WarrantyInfo -
Weight & dimensions - Depth - 180 mm
Weight & dimensions - Height - 86 mm
Weight & dimensions - Weight - 2.09 kg
Weight & dimensions - Width - 150 mm
