8-pin 12V power connectors - 0
Accessories included -
Brand - Zalman
BrandPartCode - ZM600-LX3
Category - Power Supply Units
Certificates - Compliance certificates - CB, CE, EAC, KC, RoHS
Certificates 80+ - 80 PLUS
Description -
Design - Fan diameter - 12 cm
Design - Product colour - Black
Designation - CE+WEEE
dimension depth - 185 mm
dimension height - 105 mm
Dimensions - 86 x 150 x 140 mm
dimension weight - 1800 g
dimension width - 275 mm
ean - 8809213764073
Fan - 12 cm
Floppy power connectors - 0
GTIN - 8809213764073
guarantee - 24
guarantee_type - normal
LongDesc - 80 PLUS 230V EUStandard CertifiedSuperior Efficiency & Energy SavingsINTEL 5Vsb 3.0A CompatibleReady to 5Vsb 3.0A for Intel Desktop Platform Form Factor Power Supply 1.42Decamax 600WGuaranteed Rated OutputActive AFC With 99%Active PFC system with maximum power factor of 99% providing consistent and stable output as well as high energy efficiencyHigh performance Capacitor (105˚C)Highly reliable capacitor used to supply stable Voltage even at high temperatures up to 105˚CBuilt-In EMI FilterEMI Filter is installed to suppress frequency that causes noise for better system operationSwitching TransformStable current is provided by the switching transformer without over loading the input current 12V Single Rail 91% Availability Single rail design delivers up to +12V of available power at 91% output to provide stable voltage to CPU and GPU that are main PC componentsBuilt-in Aluminum HeatsinkDual Aluminum heatsink block has been installed to minimize internal heat productionActive PFC with Up to 99%Maximum Power FactorActive PFC system with maximum power factor of 99% providing consistent and stable output as well as high energy efficiencyMultiple Protection Circuit SystemOPP, OVP, UVP, SCPOPP (Over Power Protection)OVP (Over Voltage Protection)UVP (Under Voltage Protection)SCP (Short-Circuit Protection)HDB(Hydro-Dynamic Bearing)Quiet and Long LifespanCooling TechnologyHDB(Hydro-Dynamic Bearing) has benefits of low noise and long life spanIt discharges internal that quickly and providessufficient cooling at a low RPM to maximize stable, safe power supply120mm HDB Fan120mm Low-noise fan delivers powerful spin even at a low RPM to quickly removes heat from power supply for optimal cooling performanceHighly Energy-Efficient StandbyPower Supply(ErP Lot 6 Certified)ZALMAN’s power supply has such remarkable energy efficiency, that during standby the power supply can be kept under 0.5W to avoid any unnecessary power consumption.The power supply has acquired ErP LOT 6 which passedEuropean energy saving standards for environmental friendly and energy efficient experience for users.Eco-Friendly ProductsAll Materials included are Environmentally safe and HarmlessRoHS CompliantCertified products are environmentally safe that do nor cause harm to the human bodyCertification is received when XRF testing determines that the 10 hazardous substances is below the standard value for the electronic products exported to EuropeUnlike other inexpensive products, Zalman products are produced from the beginning with RoHS standards in mindSafety/EMI ApprovalsKC, CE, CB, RCM, EAC, RoHSZalman’s Power supply has acquired many domestic and overseas certifications to ensure a safe and stable PC experience for all usersStandard-ATXStandard ATX size provides wide compatibility 140 x 150 x 86(H)mmAll Black and simple CablesConvenient Sleeve CableUsers can install the system easily by delicately processed Sleeve cableBlack Flat CableZalman applies flat cable to all cables, which makes the cables easier organize when building system
LongProductName - Decamax 600W, Intel ATX 12V Ver 2.31, Active PFC, 80PLUS STANDARD
LongSummaryDescription - Zalman Decamax. Total power: 600 W, AC input voltage: 200 - 240 V, AC input frequency: 50/60 Hz. Purpose: PC, Power supply unit (PSU) form factor: ATX, 80 PLUS certification: 80 PLUS. Product colour: Black, Fan diameter: 12 cm. Compliance certificates: CB, CE, EAC, KC, RoHS. Width: 140 mm, Depth: 150 mm, Height: 86 mm
MB power connector - 20 + 4 pin
Modular power supply - No
MOLEX power connectors - 3
name - Power supply ZM600-LX3 Decamax 600W
Number of connectors PATA - 0
Number of power connectors 12VHPWR - 0
Number of power connectors PCI-E 16-pin Gen 5 - 0
Number of power supply connector 4+4-pin 12V - 1
Number of power supply connector 4-pin 12V - 0
Number of power supply connectors PCI-E 6 +2 pin - 2
Operational conditions - Operating temperature (T-T) - 10 - 45 °C
Other features -
PCI-E 6-pin power connectors - 0
PCI-E 8-pin power connectors - 0
Performance - 80 PLUS certification - 80 PLUS
Performance - Bearing technology - HDB
Performance - Mean time between failures (MTBF) - 100000 h
Performance - Power supply unit (PSU) form factor - ATX
Performance - Purpose - PC
PFC - Active
Power - AC input frequency - 50/60 Hz
Power - AC input voltage - 200 - 240 V
Power - Combined power (+3.3V) - 100 W
Power - Combined power (+5V) - 100 W
Power - Combined power (+5Vsb) - 15 W
Power - Combined power (+12V) - 552 W
Power - Combined power (-12V) - 3.6 W
Power - Efficiency - 85%
Power - Input current - 5 A
Power - Max output current (+3.3V) - 18 A
Power - Max output current (+5V) - 18 A
Power - Max output current (+5Vsb) - 3 A
Power - Max output current (+12V) - 46 A
Power - Max output current (-12V) - 0.3 A
Power - Power protection features - Over power, Over voltage, Short circuit, Under voltage
Power - Total power - 600 W
Power supply - 600 W
producer - Zalman
ProductName - Decamax
SATA power connectors - 6
ShortSummaryDescription - Zalman Decamax, 600 W, 200 - 240 V, 50/60 Hz, 5 A, 100 W, 552 W
Title - Zalman Decamax power supply unit 600 W ATX Black
URL - https://www.zalman.com/EN/Product/ProductDetail.do?pageIndex=1&pageSize=10&productSeq=1567&searchCategory1=0&searchCategory2=-99&searchCategory3=-99&searchKey=&searchWord=ZM700-LX3
vendpn - ZM600-LX3
WarrantyInfo -
Weight & dimensions - Depth - 150 mm
Weight & dimensions - Height - 86 mm
Weight & dimensions - Weight - 1.5 kg
Weight & dimensions - Width - 140 mm
