Asus ROG Strix, 1000W, ATX 3.1, 80PLUS Platinum, PCIe 5.1

8-pin 12V power connectors - 0
Accessories included -
Brand - ASUS
BrandPartCode - 90YE00W1-B0NA00
category - PC Components|Power Supplies|PSUs above 800 Watts
Category - Power Supply Units
Certificates - Certification - Cybenetics Noise Level Certification A+
Certificates 80+ - 80 PLUS Platinum
code - 90YE00W1-B0NA00
Description - Zasilacz ROG STRIX 1000W 80+ Platinum czarny ROG STRIX 1000W Platinum to pracująca cicho i w niskiej temperaturze jednostka zasilająca zapewniająca stabilne zasilanie, zaprojektowana pod kątem wysokiej sprawności energetycznej, z tranzystorami MOSFET typu GaN oraz inteligentnym stabilizatorem, z przykuwającym uwagę wzornictwem. Tranzystory MOSFET typu GaN zapewniają o 30% wyższą sprawność energetyczną i bardziej uporządkowany układ wewnętrzny, co przekłada się na niższą temperaturę pracy.   Czujnik napięcia GPU-FIRST z opatentowanym inteligentnym stabilizatorem napięcia zwiększa dostarczanie napięcia do Twojej karty graficznej nawet o 45%, co przekłada się na większą płynność gier i stale wysoką wydajność. Duże radiatory ROG  obejmują swoim zasięgiem najważniejsze komponenty, zapewniając niższe temperatury i mniejszy hałas niż porównywalne konstrukcje. Podwójne łożysko kulkowe wentylatora zapewnia dwukrotnie dłuższą żywotność w porównaniu do rozwiązań z łożyskiem kołnierzowym. Technologia 0dB  pozwala Ci cieszyć się mniej wymagającymi grami przy względnej ciszy. Zgodność z ATX 3.1: ROG Strix Platinum to rozwiązanie zgodne ze standardem ATX 3.1, co gwarantuje lepszą regulację napięcia i prądu. Obsługa PCIe 5.1: Jednostka zasilająca ROG Strix Platinum jest wyposażona natywnie w złącze 12 V-2x6 do zasilania kart graficznych najnowszej generacji. Certyfikacja Lambda A+: Certyfikowana niska emisja hałasu, poniżej 20 dB. Certyfikat 80 PLUS Platinum: ROG Strix Platinum wykorzystuje kondensatory typu low ESR i komponenty najwyższej jakości, zapewniając wiodącą w branży sprawność energetyczną.
Design - Cooling type - Semi-passive
Design - Illumination - Yes
Design - Number of fans - 1 fan(s)
Design - On/off switch - Yes
Design - Product colour - Black
Design - Product colour - Black, Silver
Design - Product colour - Silver
Designation - CE+WEEE
dimensionalWeight - 1430
dimension depth - 110 mm
dimension height - 200 mm
Dimensions - 86 x 150 x 160 mm
dimension weight - 3900 g
dimension width - 330 mm
ean - 4711387594384
Fan - 13.5 cm
Filters / protection - Circuit
Filters / protection - Current too high
Filters / protection - Overload
Filters / protection - Surge
Filters / protection - Thermal
Floppy power connectors - 0
GTIN - 4711387594384
guarantee - 120
guarantee_type - normal
LongDesc - Superior Stability. Next-Level EfficiencyThe ROG Strix Platinum PSU delivers the top-tier performance and unwavering stability demanded by gamers. Featuring next-gen GaN MOSFET for superior power efficiency. The “GPU-FIRST” voltage sensing with patented-intelligent voltage stabilizer ensures a steady flow of power to the graphics card. Plus, it is ready for latest hardwares with ATX 3.1 compliance and a native 12V-2x6 connector. The ROG Strix Platinum Series ensures your high-end rig has the power to conquer any challenge.ENGINEERINGGaN MOSFETThe ROG Strix Platinum PSU boasts innovative GaN MOSFET that delivers superior power efficiency by up to 30%, resulting in lower energy waste. Plus, the smaller size of GaN MOSFET allows for a more organized internal layout within the PSU. This optimized design provides space for larger heatsinks and enhanced airflow, improving heat dissipation within the PSU."GPU-FIRST" Voltage Sensingwith patented-intelligent voltage stabilizerActivate the "GPU-FIRST" voltage sensing by connecting the IVS cable. This innovative feature enhances voltage stability by up to 45%, even during demanding gaming sessions and overclocking scenarios. If you prefer conventional CPU-focused voltage sensing, just simply disconnect the IVS cable. With this advanced technology, you can experience smooth and consistent gameplay.High-performance Copper PinsUpgraded PCIe® connectors featuring superior thermal conductivity ensure cooler operation and improved power delivery efficiency.This translates to a significant 29% reduction in connector temperatures (up to 12.28°C), promoting optimal performance and stability for even the most demanding graphics cards.ATX 3.1 CompatibleATX 3.1 ushers in tighter voltage and current regulation standard for next-gen hardware - and ROG Strix Platinum steps ahead of the curve by being fully compliant. A 16-pin PCIe cable ripe for piping up to 600W of power to PCIe Gen 5.0 graphics cards is bundled with the PSU, readying your build for the next-gen.80 PLUS Platinum CertificationThe ROG Strix 1000W Platinum utilizes low-ESR Japanese capacitors to ensure efficient operation. These upgrades enable an 80 PLUS Platinum certification, which guarantees 89% efficiency at 100% load and 92% efficiency at 50% load. The increased efficiency results in less heat, reduces fan noise, and increases reliability.Cybenetics Lambda A+ CertificationQuietly deviantOn average, ROG Strix 1000W Platinum PSU emits less than 20 dB of noise – earning a coveted Cybenetics Lambda A+ certification.COOLINGROG HeatsinksCool under pressureROG heatsinks facilitate lower temperatures, longer component lifespan, and extended 0dB operation.Dual Ball Fan Bearings2x longer lifespanDual ball bearings boast a remarkable lifespan of 80,000 hours, lasting twice as long as sleeve bearings and exceeding even fluid dynamic bearings.Ensuring long-lasting, reliable cooling with minimal noise for ROG STRIX Platinum series.0dB TechnologyQuiet intelligenceTo reduce noise output, the PWM-controlled fan shuts off entirely when the PSU load is 40% or below.In 0dB mode (button pressed), the fan continues to spin when transitioning from high to low loads, ensuring safe temperatures are reached before stopping.EXPERIENCEEtched CablesMade from a pliable premium material, these etched cables are easily flexible during installation, and they operate at temperatures 50°C lower than the safety limit when routed for cable management. These cables also meet the rigorous standards of the UL1581 flame test and UL758 certification, helping to ensure a smooth PC DIY experience and exceptional safety.DIY-friendly CPU Power ConnectorEngineered with a distinct clip between the 4+4 pin connectors and a unique color scheme, this CPU power cable simplifies cable identification during installation. The integrated clip helps to ensure a secure and effortless connection to the motherboard's CPU power connector, streamlining the build process and instilling confidence in your PC setup.Cosmetic CustomizationCustomize your own PSU with included stickers that complement the PSU's patterns. Choose your preferred color scheme for a personalized touch.10-year WarrantyA decade of powerWe're so confident about the reliability of the ROG Strix 1000W Platinum that we back it with a 10-year warranty.
LongProductName - ROG Strix 1000W Platinum Gaming power supply (1000 watts, GaN Mosfet, 0dB technology, ATX 3.1 compatible, PCIe 5.0, 10 year warranty)
LongSummaryDescription - ASUS ROG STRIX-1000P-GAMING. Total power: 1000 W, AC input voltage: 100 - 240 V, Power Factor Correction (PFC) type: Active. Motherboard power connector: 20+4 pin ATX, Motherboard power cable length: 61 cm, SATA power cable length: 120,400 mm. Purpose: PC, Power supply unit (PSU) form factor: ATX, 80 PLUS certification: 80 PLUS Platinum. Product colour: Black, Silver, Cooling type: Semi-passive, Number of fans: 1 fan(s). Cables included: AC, CPU, PCIe, Peripheral (Molex), SATA
MB power connector - 20 + 4 pin
Modular power supply - Yes
MOLEX power connectors - 3
name - ASUS ROG Strix 1000P Platinum, 80 PLUS Platinum Netzteil, modular, PCIe 5.1 - 1000 Watt
name - Power supply ROG STRIX 1000W 80+ Platinum black
Number of connectors PATA - 0
Number of power connectors PCI-E 16-pin Gen 5 - 1
Number of power supply connector 4+4-pin 12V - 2
Number of power supply connector 4-pin 12V - 0
Number of power supply connectors PCI-E 6 +2 pin - 4
Number of USB 10p connectors - 0
Other features -
Packaging content - Cables included - AC, CPU, PCIe, Peripheral (Molex), SATA
Packaging data - Package depth - 200 mm
Packaging data - Package height - 108 mm
Packaging data - Package type - Box
Packaging data - Package weight - 3.62 kg
Packaging data - Package width - 320 mm
PCI-E 6-pin power connectors - 0
PCI-E 8-pin power connectors - 0
Performance - 80 PLUS certification - 80 PLUS Platinum
Performance - Bearing technology - Ball bearing
Performance - Mean time between failures (MTBF) - 120000 h
Performance - Noise level - 20 dB
Performance - Power supply unit (PSU) form factor - ATX
Performance - Purpose - PC
PFC - Active
Ports & interfaces - ATX power connector (20+4 pin) - Yes
Ports & interfaces - Cabling type - Fully-Modular
Ports & interfaces - CPU power cable length - 100 cm
Ports & interfaces - CPU power connector (4+4 pin) - Yes
Ports & interfaces - Motherboard power cable length - 61 cm
Ports & interfaces - Motherboard power connector - 20+4 pin ATX
Ports & interfaces - Number of SATA power connectors - 6
Ports & interfaces - PCI Express power cable length - 75 cm
Ports & interfaces - PCI Express power connectors (6+2 pin) - 4
Ports & interfaces - PCI Express power connectors (16-pin) - 1
Ports & interfaces - Peripheral (Molex) power cable length - 150
Ports & interfaces - Peripheral (Molex) power cable length - 150,400 mm
Ports & interfaces - Peripheral (Molex) power cable length - 400 mm
Ports & interfaces - Peripheral (Molex) power connectors (4-pin) - 3
Ports & interfaces - SATA power cable length - 120
Ports & interfaces - SATA power cable length - 120,400 mm
Ports & interfaces - SATA power cable length - 400 mm
Power - AC input voltage - 100 - 240 V
Power - Combined power (+3.3V) - 130 W
Power - Combined power (+5V) - 130 W
Power - Combined power (+5Vsb) - 15 W
Power - Combined power (+12V) - 1000 W
Power - Combined power (-12V) - 3.6 W
Power - Max output current (+3.3V) - 25 A
Power - Max output current (+5V) - 25 A
Power - Max output current (+5Vsb) - 3 A
Power - Max output current (+12V) - 83.3 A
Power - Max output current (-12V) - 0.3 A
Power - Power Factor Correction (PFC) type - Active
Power - Power protection features - Over current
Power - Power protection features - Over current, Over power, Over voltage, Overheating, Short circuit, Under voltage
Power - Power protection features - Overheating
Power - Power protection features - Over power
Power - Power protection features - Over voltage
Power - Power protection features - Short circuit
Power - Power protection features - Under voltage
Power - Total power - 1000 W
Power supply - 1000 W
producer - Asus
producerCode - 90YE00W1-B0NA00
productName - ASUS ROG STRIX-1000P-GAMING power supply unit 1000 W 20+4 pin ATX ATX Black, Silver
ProductName - STRIX-1000P-GAMING
productSize - Normal
SATA power connectors - 6
ShortSummaryDescription - ASUS ROG STRIX-1000P-GAMING, 1000 W, 100 - 240 V, Active, 130 W, 1000 W, 130 W
sizeX - 325
sizeY - 200
sizeZ - 110
Title - ASUS ROG STRIX-1000P-GAMING power supply unit 1000 W 20+4 pin ATX ATX Black, Silver
URL - https://rog.asus.com/power-supply-units/rog-strix/rog-strix-1000p-gaming/
vendpn - 90YE00W1-B0NA00
WarrantyInfo - 10 years
warrantyLength - 120
warrantyType - G
Weight - 1.81 kg
weight - 3735
Weight & dimensions - Depth - 150 mm
Weight & dimensions - Height - 86 mm
Weight & dimensions - Weight - 2.91 kg
Weight & dimensions - Width - 160 mm
