ADATA CORE REACTOR II, 1200W, 80PLUS Gold, PCIe 5.0

80 PLUS certification Performance - 80 PLUS Gold
AC input frequency Power - 50/60 Hz
AC input voltage Power - 100 - 240 V
ATX power connector (12+4 pin) Ports & interfaces - Yes
ATX Power connector (24-pin) Ports & interfaces - Yes
ATX version Performance - 3.0
Bearing technology Performance - FDB
Brand - XPG
BrandPartCode - 75261221
Cabling type Ports & interfaces - Fully-Modular
Category - Power Supply Units
Category Code - PSU
Certificates - Certification - CE | CB| FCC(IC) | TUV | cTUVus | TUV S-Zeichen | NOM | BSMI | UKCA | EAC | CCC | RCM
Certificates - Compliance certificates - BSMI, CB, CE, China Compulsory Certification (CCC), EAC, Federal Communications Commission (FCC), Norma Oficial Mexicana (NOM), RCM, cTUVus, UKCA
Certification Certificates - CE | CB| FCC(IC) | TUV | cTUVus | TUV S-Zeichen | NOM | BSMI | UKCA | EAC | CCC | RCM
Compliance certificates Certificates - BSMI/CB/CE/China Compulsory Certification (CCC)/cTUVus/EAC/Federal Communications Commission (FCC)/Norma Oficial Mexicana (NOM)/RCM/UKCA
Depth Weight & dimensions - 150 mm
Description - CORE REACTOR II
IMPROVE YOUR CORE, ENHANCE YOUR PERFORMANCE
CORE REACTOR II is a top-performing power supply unit designed for ATX 3.0 & ATX 3.1 compliance with a modular cable design and an 80 PLUS GOLD certification. These power supplies thrive in high-performance scenarios like servers or workstation setups, where a lot of power is needed. Next-Gen Ready - ATX 3.0 & ATX 3.1 COMPLIANT
CORE REACTOR II series power supply units meet Intel ATX 3.0 & ATX 3.1 design guide specifications and feature a 12VHPWR connector. By upgrading to an ATX 3.0 & ATX 3.1-compliant power supply, you'll be fully equipped for the upcoming wave of high-performance components. A must for the modern gamer, creator, or AI developer. Stay ahead of the curve by upgrading to an ATX 3.0 & ATX 3.1 PSU, the new standard in PC hardware. Certified GOLD Efficiency
CORE REACTOR II units recieved 80 PLUS GOLD certifications for efficiency, achieving up to 91.40% (115V) efficiency at 50% load. It comes in 1200W, 1000W, 850W, 750W, and 650W models for varying user needs and scenarios. It's the perfect PSU for mid-to-high level components, including the latest CPUs and GPUs. Intelligent Fan-Curve Design
The intelligent fan curve ensures quiet operation, even under full power load. By starting the fan at a low RPM, fan performance is both enhanced and extended, thereby increasing the power supply unit's lifespan. Premium all 105°C Japanese Capacitors
CORE REACTOR II features top-tier 105°C Japanese capacitors, ensuring exceptional stability and reliability of the PSU for many years of dependable performance. PEAK PERFORMANCE AND RELIABILITY
All XPG ATX 3.0 and ATX 3.1 power supplies are designed to support up to 235% power excursion, enabling the system to handle sudden power spikes, ensuring stability, and preventing crashes during intense workloads like gaming, rendering, and data processing.
Design - Fan diameter - 13.5 cm
Design - Product colour - Black
EPS power connector (8-pin) Ports & interfaces - Yes
EPS version Performance - 2.92
Fan diameter Design - 135 mm
GTIN - 0842243029437
GTIN - 842243029437
GTIN - 4711085942401
Height Weight & dimensions - 86 mm
Input current Power - 15 A
LongDesc - CORE REACTOR IIIMPROVE YOUR CORE, ENHANCE YOUR PERFORMANCECORE REACTOR II is a top-performing power supply unit designed for ATX 3.0 & ATX 3.1 compliance with a modular cable design and an 80 PLUS GOLD certification. These power supplies thrive in high-performance scenarios like servers or workstation setups, where a lot of power is needed.Next-Gen Ready - ATX 3.0 & ATX 3.1 COMPLIANTCORE REACTOR II series power supply units meet Intel ATX 3.0 & ATX 3.1 design guide specifications and feature a 12VHPWR connector. By upgrading to an ATX 3.0 & ATX 3.1-compliant power supply, you'll be fully equipped for the upcoming wave of high-performance components. A must for the modern gamer, creator, or AI developer. Stay ahead of the curve by upgrading to an ATX 3.0 & ATX 3.1 PSU, the new standard in PC hardware.Certified GOLD EfficiencyCORE REACTOR II units recieved 80 PLUS GOLD certifications for efficiency, achieving up to 91.40% (115V) efficiency at 50% load. It comes in 1200W, 1000W, 850W, 750W, and 650W models for varying user needs and scenarios. It's the perfect PSU for mid-to-high level components, including the latest CPUs and GPUs.Intelligent Fan-Curve DesignThe intelligent fan curve ensures quiet operation, even under full power load. By starting the fan at a low RPM, fan performance is both enhanced and extended, thereby increasing the power supply unit's lifespan.Premium all 105°C Japanese CapacitorsCORE REACTOR II features top-tier 105°C Japanese capacitors, ensuring exceptional stability and reliability of the PSU for many years of dependable performance.PEAK PERFORMANCE AND RELIABILITYAll XPG ATX 3.0 and ATX 3.1 power supplies are designed to support up to 235% power excursion, enabling the system to handle sudden power spikes, ensuring stability, and preventing crashes during intense workloads like gaming, rendering, and data processing.
LongProductName - 1200 W, PLATINUM, GOLD, ATX 12V v3.0 und EPS v2.92, 0.99 PFC, 2400 RPM
LongSummaryDescription - XPG COREREACTOR II 1200W Power Supply. Total power: 1200 W, AC input voltage: 100 - 240 V, AC input frequency: 50/60 Hz. Motherboard power connector: 24-pin ATX, Cabling type: Fully-Modular. Purpose: PC, Power supply unit (PSU) form factor: ATX, 80 PLUS certification: 80 PLUS Gold. Product colour: Black, Fan diameter: 13.5 cm. Compliance certificates: BSMI, CB, CE, China Compulsory Certification (CCC), EAC, Federal Communications Commission (FCC),..., Certification: CE | CB| FCC(IC) | TUV | cTUVus | TUV S-Zeichen | NOM | BSMI | UKCA | EAC | CCC | RCM
Max output current (+3.3V) Power - 22 A
Max output current (+5V) Power - 22 A
Max output current (+5Vsb) Power - 3 A
Max output current (+12V) Power - 100 A
Max output current (-12V) Power - 0.3 A
Mean time between failures (MTBF) Performance - 100000 h
Model name - CORE REACTOR II
Motherboard power connector Ports & interfaces - 24-pin ATX
Number of SATA power connectors Ports & interfaces - 9
Package depth Packaging data - 338 mm
Package height Packaging data - 157 mm
Package weight Packaging data - 3430 g
Package width Packaging data - 210 mm
Packaging data - Package depth - 338 mm
Packaging data - Package height - 157 mm
Packaging data - Package weight - 3.43 kg
Packaging data - Package width - 210 mm
PCI Express power connectors (6+2 pin) Ports & interfaces - 8
Performance - 80 PLUS certification - 80 PLUS Gold
Performance - ATX version - 3.0
Performance - Bearing technology - FDB
Performance - EPS version - 2.92
Performance - Mean time between failures (MTBF) - 100000 h
Performance - Power supply unit (PSU) form factor - ATX
Performance - Purpose - PC
Peripheral (Molex) power connectors (4-pin) Ports & interfaces - 3
Ports & interfaces - ATX power connector (12+4 pin) - Yes
Ports & interfaces - ATX Power connector (24-pin) - Yes
Ports & interfaces - Cabling type - Fully-Modular
Ports & interfaces - EPS power connector (8-pin) - Yes
Ports & interfaces - Motherboard power connector - 24-pin ATX
Ports & interfaces - Number of SATA power connectors - 9
Ports & interfaces - PCI Express power connectors (6+2 pin) - 8
Ports & interfaces - Peripheral (Molex) power connectors (4-pin) - 3
Power - AC input frequency - 50/60 Hz
Power - AC input voltage - 100 - 240 V
Power - Input current - 15 A
Power - Max output current (+3.3V) - 22 A
Power - Max output current (+5V) - 22 A
Power - Max output current (+5Vsb) - 3 A
Power - Max output current (+12V) - 100 A
Power - Max output current (-12V) - 0.3 A
Power - Power factor - 0.99
Power - Power protection features - Over current, Over power, Over voltage, Overheating, Short circuit, Surge & inrush protection (SIP), Under voltage
Power - Total power - 1200 W
Power factor Power - 0.99
Power protection features Power - Over current/Over power/Over voltage/Overheating/Short circuit/Surge & inrush protection (SIP)/Under voltage
Power supply unit (PSU) form factor Performance - ATX
Product colour Design - Black
ProductName - COREREACTOR II 1200W Power Supply
Purpose Performance - PC
ShortSummaryDescription - XPG COREREACTOR II 1200W Power Supply, 1200 W, 100 - 240 V, 50/60 Hz, 15 A, 22 A, 100 A
Summary - XPG COREREACTOR II 1200W Power Supply. Total power: 1200 W, AC input voltage: 100 - 240 V, AC input frequency: 50/60 Hz. Motherboard power connector: 24-pin ATX, Cabling type: Fully-Modular. Purpose: PC, Power supply unit (PSU) form factor: ATX, 80 PLUS certification: 80 PLUS Gold. Product colour: Black, Fan diameter: 13.5 cm. Compliance certificates: BSMI, CB, CE, China Compulsory Certification (CCC), EAC, Federal Communications Commission (FCC),..., Certification: CE | CB| FCC(IC) | TUV | cTUVus | TUV S-Zeichen | NOM | BSMI | UKCA | EAC | CCC | RCM
Title - XPG COREREACTOR II 1200W Power Supply
Total power Power - 1200 W
Unit Box Height - 0.212
Unit Box Length - 0.34
Unit Box Width - 0.16
Unit Calculated Volume - 0.01342 cubm
Unit Calculated Weight - 4.05 kg
Units per Shipping Box - 4
URL - https://www.xpg.com/en/xpg/pc-components-core-reactor-ii
Vendor Homepage - https://www.xpg.com/en/xpg/pc-components-core-reactor-ii
Warranty - 36 months
WarrantyInfo - 10 years
Weight & dimensions - Depth - 150 mm
Weight & dimensions - Height - 86 mm
Weight & dimensions - Width - 160 mm
Width Weight & dimensions - 160 mm
