NZXT C1000 Black (2024), 1000W, 80PLUS Gold, PCIe 5.0

80 PLUS certification Performance - 80 PLUS Gold
AC input frequency Power - 50/60 Hz
AC input voltage Power - 100 - 240 V
ATX Power connector (24-pin) Ports & interfaces - Yes
ATX version Performance - 3.1
Bearing technology Performance - FDB
Cabling type Ports & interfaces - Fully-Modular
Category Code - PSU
Category_1 - Power
Category_2 - Computer Power Supplies
Certification Certificates - CB/ (IEC 950/62368-1) / CCC / CEC /BSMI / RCM / EAC / CE / LVD / UKCA
Combined power (+3.3V) Power - 120 W
Combined power (+5V) Power - 120 W
Combined power (+5Vsb) Power - 15 W
Combined power (+12V) Power - 1000 W
Compliance certificates Certificates - BSMI, CCC, CE, EAC, UKCA
Cooling type Design - Active
CPU power connector (4+4 pin) Ports & interfaces - Yes
Depth Weight & dimensions - 160 mm
Description - 1000 Watt 80 PLUS Gold Fully Modular ATX 3.1 PSU Designed for maximum performance with minimal noise, NZXT C Series Gold ATX 3.1 PSUs are ready to fuel the demands of top-tier GPUs and CPUs. NZXT Gold ATX 3.1 PSU
ATX 3.1 compliant PSUs featuring high efficiency, low noise, and premium construction. ATX 3.1 Compliant
ATX 3.1 powers high-performance components with stable delivery and improved efficiency. 40 Series Ready
12V-2x6 cable delivers up to 600 watts of power to NVIDIA® GeForce RTX™ 40 Series GPUs. Certified for High Efficiency & Low Noise
80 PLUS Gold Efficiency, Cybenetics Gold Efficiency, and Cybenetics A Noise Level Ratings. Silence is Golden
135mm FDB fan with Zero Fan Mode stops spinning under 50% load for total silence. 100% Japanese Capacitors
Improved hold-up time and reduced ripple noise for stable, reliable power delivery. Fully Modular
Only connect the cables needed to keep a tidy build. Full cable set included. Space-Saving Size
Compact form factor frees up room for cable management and improved airflow. Peace of Mind
Backed by a 10-year warranty and reliable customer support.
Compliant with the ATX 3.1 standard to fuel high-performance PC components with stability, efficiency, and power spike resistanceDurable, heat-resistant 12V-2x6 connector pumps up to 600 watts to NVIDIA® GeForce RTX™ 40 Series graphics cards135mm fluid dynamic bearing fan with Zero Fan Mode is completely silent when under 50% load100% premium Japanese capacitors improve hold-up time and minimal ripple noise, ensuring reliable and stable power deliveryFully modular design allows for only connecting essential cables, reducing clutter for better airflow and a neater buildCompact form factor frees up valuable room for cable management and more case airflowThanks to high-quality construction and rigorous product testing, NZXT PSUs are backed by a 10-year warranty
EAN_code - 5056547204710
Efficiency Power - 91.9%
EPS version Performance - 2.92
Fan diameter Design - 13.5 cm
Fan speed Design - 0 - 2300 RPM
Height Weight & dimensions - 86 mm
Input current Power - 13 - 6.5 A
Manufacturer - NZXT
Manufacturer_code - PA-0G2BB-EU
Max output current (+3.3V) Power - 22 A
Max output current (+5V) Power - 22 A
Max output current (+5Vsb) Power - 3 A
Max output current (+12V) Power - 83.3 A
Mean time between failures (MTBF) Performance - 100000 h
Model name - PA-0G2BB-EU
Motherboard power connector Ports & interfaces - 24-pin ATX
Name - NZXT C1000 Gold ATX 3.1 (black, 1x 16-pin graphics card connector, 6x PCIe, cable management, 1000 watts)
Noise level Performance - 44.5 dB
Number of fans Design - 1 fan(s)
Number of SATA power connectors Ports & interfaces - 12
On/off switch Design - Yes
Operating temperature (T-T) Operational conditions - 0 - 50 °C
Peripheral (Molex) power connectors (4-pin) Ports & interfaces - 4
Power supply unit (PSU) form factor Performance - ATX
Product colour Design - Black
Purpose Performance - PC
Summary - NZXT C1000 Gold ATX 3.1. Total power: 1000 W, AC input voltage: 100 - 240 V, AC input frequency: 50/60 Hz. Motherboard power connector: 24-pin ATX, Cabling type: Fully-Modular. Purpose: PC, Power supply unit (PSU) form factor: ATX, 80 PLUS certification: 80 PLUS Gold. Product colour: Black, Cooling type: Active, Fan diameter: 13.5 cm. Compliance certificates: BSMI, CCC, CE, EAC, UKCA, Certification: CB/ (IEC 950/62368-1) / CCC / CEC /BSMI / RCM / EAC / CE / LVD / UKCA
Total power Power - 1000 W
Unit Box Height - 0.215
Unit Box Length - 0.32
Unit Box Width - 0.12
Unit Calculated Volume - 0.00988 cubm
Unit Calculated Weight - 3.88 kg
Units per Shipping Box - 4
Vendor Homepage - https://nzxt.com/product/c1000-gold-atx#
Warranty - 72 months
Warranty period Logistics data - 10 year(s)
Weight - 3,60
Width Weight & dimensions - 150 mm
