Brand - FSP
BrandPartCode - PPA10A3803
Category - Power Supply Units
Category 1 - Netzteile
Design - Cooling type - Active
Design - Fan diameter - 13.5 cm
Design - Fan location - Top
Design - Number of fans - 1 fan(s)
Design - On/off switch - Yes
Design - Product colour - Black
EAN - 4713224527456
GTIN - 4713224527456
LongDesc - New ATX PSU SpecificationsUpdated ATX 3.0 specifications for the next-generation hardware power demands and ensure users get the most stable and cost-optimized performance possible with the highest power efficiency.Ultra Power DensityCompared to general high-efficiency & high wattage PSU 170mm length, Hydro Ti PRO series delivers high power with shorter size of 150mm.80 Plus® Titanium CertificationHydro Ti PRO series is a power supply with 80 PLUS® Titanium provides over 94% efficiency at the load of 50 % and Cybenetics-certified for lower power consumption.Lambda A++ CertificationHydro Ti PRO ATX3.0(PCIe5.0) 1000W got Lambda A++ noise rating. By averaging the noise measurements that take from Cybenetics test results.Smarter, Quieter and Longer Lasting Eco Friendly FanUnder 50% loading, you will enjoy Zero RPM experience when eco semi-fanless fan control switch is on, , and get the benefit of long lifespan from a 135mm fluid dynamic bearing fan.Off-Wet, Off-Dust and Off-Stain CoatingCovered with exclusive conformal coating which guarantees to offer better and reliable performance in harsh environments and is tested to work in environments up to 95% relative humidity.LLC TopologyZero voltage switching of the main switches thereby dramatically lowering switching losses and boosting efficiency.450V, 105°C Japanese E-CapacitorsHydro Ti PRO series uses Japanese bulk capacitors to ensure a longer lifetime and protect your equipment from the infamous capacitor leakage problem.Unleash +12V Power OutputVGA card is a power-hungry component that needs most power. A single +12V rail design can deliver stable power and avoid any overloading conditions.Fully Modular Design Fully-modular design not just for easier installation, but also provides your system a neat and tidy look.Stylish & Changeable Side StickerIncludes unique side stickers for DIY enthusiasts and gamers.
LongProductName - 1000 W, 80 PLUS Titanium, ATX 3.1, 100-240V, 50/60 Hz, 150 x 150 x 85 mm
LongSummaryDescription - FSP Hydro Ti PRO 1000W. Total power: 1000 W, AC input voltage: 100 - 240 V, AC input frequency: 50/60 Hz. Motherboard power connector: 20+4 pin ATX, Motherboard power cable length: 60 cm, PCI Express power connectors (12+4 pin) cable length: 700 mm. Purpose: PC, Power supply unit (PSU) form factor: ATX, 80 PLUS certification: 80 PLUS Titanium. Product colour: Black, Cooling type: Active, Fan diameter: 13.5 cm. Cables included: CPU, PCIe, Peripheral (Molex), SATA
Manufacturer - FSP
MPN - PPA10A3807
Name - 1000W FSP Hydro TI PRO ATX 3.0 80+TITANIUM Gen 5.1
Packaging content - Cables included - CPU, PCIe, Peripheral (Molex), SATA
Performance - 80 PLUS certification - 80 PLUS Titanium
Performance - ATX version - 3.1
Performance - Bearing technology - FDB
Performance - EPS version - 2.92
Performance - Noise level - 15 dB
Performance - Power supply unit (PSU) form factor - ATX
Performance - Purpose - PC
Ports & interfaces - Cabling type - Fully-Modular
Ports & interfaces - CPU power cable length - 70 cm
Ports & interfaces - CPU power connector (4+4 pin) - Yes
Ports & interfaces - Motherboard power cable length - 60 cm
Ports & interfaces - Motherboard power connector - 20+4 pin ATX
Ports & interfaces - Number of SATA power connectors - 12
Ports & interfaces - PCI Express power connectors (6+2 pin) - 5
Ports & interfaces - PCI Express power connectors (12+4 pin) cable length - 700 mm
Ports & interfaces - Peripheral (Molex) power connectors (4-pin) - 4
Power - AC input frequency - 50/60 Hz
Power - AC input voltage - 100 - 240 V
Power - Combined power (+3.3V) - 120 W
Power - Combined power (+5V) - 120 W
Power - Combined power (+5Vsb) - 18.6 W
Power - Combined power (+12V) - 1000 W
Power - Combined power (-12V) - 18.6 W
Power - Efficiency - 94%
Power - Input current - 13-6 A
Power - Max output current (+3.3V) - 20 A
Power - Max output current (+5V) - 20 A
Power - Max output current (+5Vsb) - 3 A
Power - Max output current (+12V) - 83.33 A
Power - Max output current (-12V) - 0.3 A
Power - Power protection features - Over current, Over power, Over voltage, Overheating, Short circuit
Power - Total power - 1000 W
ProductName - Hydro Ti PRO 1000W
ShortSummaryDescription - FSP Hydro Ti PRO 1000W, 1000 W, 100 - 240 V, 50/60 Hz, 13-6 A, 120 W, 1000 W
Title - FSP Hydro Ti PRO 1000W power supply unit 20+4 pin ATX ATX Black
URL - https://www.fsplifestyle.com/en/product/HydroTIPRO1000W.html
WarrantyInfo - 10 years
Weight - 4.34
Weight & dimensions - Depth - 150 mm
Weight & dimensions - Height - 86 mm
Weight & dimensions - Width - 150 mm
