3G/4G USB modem compatibility WAN connection - No
3G Mobile network - No
4G Mobile network - No
Antenna > Antenna type - 4xFixed
Antenna design Antenna - External
Antenna gain level (max) Antenna - 5 dBi
Antennas quantity Antenna - 4
Category - Root/Electronics/Networks and communication/Routers
Category Code - WRO
Cechy podstawowe: Zarządzanie - WWW
CnCode - 85176200
Code - AC10
Dane techniczne: Funkcje urządzenia - router DSL
Dane techniczne: Gwarancja - 3 lata w serwisie zewnętrznym
Dane techniczne: Producent - Mercusys
Dane techniczne: Standard - Wi-Fi 5 (802.11a/b/g/n/ac)
Dane techniczne: Tryb pracy - router
Dane techniczne: Zastosowanie - domowy
Description - Non-Stop Entertainment with Dual-Band Wi-Fi
Complying with the powerful 802.11ac standard, AC10 delivers blazing-fast Wi-Fi speeds up to 1200 Mbps, which is 3× faster than the speed of the previous 802.11n standard. Choose the 300 Mbps (2.4 GHz) for internet surfing, email, and social media or 867 Mbps (5 GHz) for bandwidth-intensive tasks like HD streaming and gaming. Broader Coverage
Four external 5dBi antennas powered with advanced antenna technology provide users with larger wireless coverage throughout your home or office. With the combination of Beamforming Technology, the AC10 can detect the location of your connected devices and concentrate wireless signal strength towards them, making your connection more stable. MU-MIMO Technology
With MU-MIMO, AC10 communicates with multiple devices at the same time to allow connected devices to achieve faster speeds than standard AC routers, increasing overall network throughput. Easy Installation
With no need for complicated configuration, you can simply follow the step-by-step instructions on the intuitive webpage to set up your AC10 in minutes. Ready for Smooth IPTV
IGMP Proxy/Snooping, Bridge, and Tag VLAN technology allow your streaming activities to pass through fast LAN ports, optimizing Hi-Resolution videos.High-Speed Wi-Fi – Stream with fast and stable connections, reaching speeds up to 1167 Mbps (300 Mbps on the 2.4 GHz band and 867 Mbps on the 5 GHz band)4 High-Gain External Antennas – Receive strong Wi-Fi signals in every corner of your homeEasy Installation – Set up in minutes guided by an intuitive web UIActive Parental Controls – Protect your family by setting appropriate access policies for responsible, safe internet useMulti-Mode — Access Point Mode, Range Extender Mode, and Router Mode supported to satisfy all application scenariosIPTV and IPv6 Supported
Design > Colour of product - White
DSL WAN WAN connection - No
EAN - 6957939005757
Eans - 6935364088040
Ethernet LAN (RJ-45) ports Ports & interfaces - 1
Ethernet LAN data rates Network - 10,100 Mbit/s
Ethernet LAN interface type Network - Fast Ethernet
Ethernet LAN Network - Yes
Ethernet WAN WAN connection - Yes
Features > Mesh Support - No
Features > Mobile Broadband - No mobile broadband
Features > MU-MiMO - Yes
Link - https://www.mercusys.com/en/product/details/ac10
Model name - AC10
MU-MIMO technology Management features - Yes
Name - Mercusys AC10
Name - Mercusys | AC1200 Wireless Dual Band Router | AC10 | 802.11ac | 300+867 Mbit/s | 10/100 Mbit/s | Ethernet LAN (RJ-45) ports 2 | Mesh Support No | MU-MiMO Yes | No mobile broadband | Antenna type 4xFixed | No
Networking standards Network - IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Other features > Ethernet LAN (RJ-45) ports - 2
Other features > USB ports quantity - No
Output current Power - 0.85 A
Output voltage Power - 9 V
Package features > Classification of battery - CL126:NEN:2025-08-18
Package features > Composition of battery - CL127:KT:2016-12-09
Package features > Embeeded battery - No
Package features > Gross depth (mm) - 229 mm
Package features > Gross depth master carton - 475 mm
Package features > Gross height (mm) - 60.00 mm
Package features > Gross height master carton - 387 mm
Package features > Gross width (mm) - 160.00 mm
Package features > Gross width master carton - 344 mm
Package features > Net weight master carton - 8.952 kg
Package features > Packing quantity - 24 pc(s)
Package features > Palette Qty - 648 pc(s)
Package features > Paper/Pasteboard - 200.00 g
Package features > Plastic (No PET) - 50.00 g
Package features > Tare weight (kg) - 0.25 kg
Package features > Tare weight master carton - 1.075 kg
Package features > TI weight (kg) - 0.15 kg
Package features > Type of battery - Accumulator
Package features > Volume (m3) - 0.0021984 m³
Package features > WEE classification - CL109:6:2017-04-01
Package features > WEEE tax - Yes
Performance > Ethernet LAN data rates - 10/100 Mbit/s
Performance > Wi-Fi data rate (max) - 300+867 Mbit/s
Ports & interfaces > WAN connection - 1*10/100Mbps WAN Port
Power source type Power - AC
Pozostałe cechy: Rodzaj anteny - zewnętrzna (4 x 5dBi)
Pozostałe cechy: Wymiary - 114 x 94 x 26 mm
Pozostałe cechy: Zasilanie - zasilacz AC
Praca bezprzewodowa: Częstotliwość - 2.4 GHz
Praca bezprzewodowa: Częstotliwość - 5 GHz
Praca bezprzewodowa: Szybkość dla 2.4 GHz - 300 Mbps
Praca bezprzewodowa: Szybkość dla 5 GHz - 867 Mbps
Praca bezprzewodowa: Szyfrowanie - 64/128-bit WEP
Praca bezprzewodowa: Szyfrowanie - WPA
Praca bezprzewodowa: Szyfrowanie - WPA-PSK
Praca bezprzewodowa: Szyfrowanie - WPA2
Praca bezprzewodowa: Szyfrowanie - WPA2-PSK
Praca przewodowa: Interfejsy LAN - RJ-45
Praca przewodowa: Interfejsy WAN - 1 x 10/100 Mb/s
Praca przewodowa: Liczba portów LAN 10/100 - 2 szt.
Praca przewodowa: Liczba portów WAN - 1 szt.
Praca przewodowa: Wbudowany przełącznik [switch] - tak
Praca przewodowa: Złącza - 3 x RJ45
Producent: Nazwa producenta / importera - Mercusys
TP-LINK Polska Sp. z o.o.
Ożarowska 40/42
05-850 Duchnice
Producer - Mercusys
ProducerCode - AC10
Producer product family - AC1200 Wireless Dual Band Router
Producer product name - AC10
Product colour Design - White
Product Net Weight ELKO Logistics Data - 0.32 kg
Product type Design - Tabletop router
Reset button Management features - Yes
Security algorithms Security - WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
Shipping Box Depth ELKO Internal Logistics Data - 47.5 cm
Shipping Box Height ELKO Internal Logistics Data - 39 cm
Shipping Box Weight ELKO Internal Logistics Data - 9.89999961853027 kg
Shipping Box Width ELKO Internal Logistics Data - 34 cm
ShortDescription -
SIM card slot WAN connection - No
Summary - Mercusys AC10. Wi-Fi band: Dual-band (2.4 GHz / 5 GHz), Top Wi-Fi standard: Wi-Fi 5 (802.11ac), WLAN data transfer rate (max): 867 Mbit/s. Ethernet LAN interface type: Fast Ethernet, Ethernet LAN data rates: 10,100 Mbit/s, Networking standards: IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n. Security algorithms: WEP, WPA, WPA-PSK, WPA2, WPA2-PSK. Product type: Tabletop router, Product colour: White. Antenna design: External, Antenna gain level (max): 5 dBi
Technical details > Gross weight - 0.373 kg
Technical details > Net weight - 0.123 kg
Technical details > Producer - Mercusys
Top Wi-Fi standard Wireless LAN features - Wi-Fi 5 (802.11ac)
Unit Box Height - 0.16
Unit Box Length - 0.23
Unit Box Width - 0.06
Unit Calculated Volume ELKO Internal Logistics Data - 0.002624 cubm
Unit Calculated Weight ELKO Logistics Data - 0.412 kg
Units per Pallet ELKO Logistics Data - 0
Units per Shipping Box ELKO Logistics Data - 24
Vendor Homepage - https://www.mercusys.com/en/product/details/ac10#specifications
Warranty - 24
Warranty - 24 month(s)
Warranty - 36 months
Wi-Fi band Wireless LAN features - Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards Wireless LAN features - 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Wireless LAN features > Wi-Fi band - 802.11ac
WLAN data transfer rate (first band) Wireless LAN features - 300 Mbit/s
WLAN data transfer rate (max) Wireless LAN features - 867 Mbit/s
WLAN data transfer rate (second band) Wireless LAN features - 867 Mbit/s
WPS push button Management features - Yes
