2.4 GHz Features - Yes
5 GHz Features - Yes
6 GHz Features - No
Access Control List (ACL) Security - Yes
Accessories included -
Antenna - Fixed external
Antenna - Antenna direction type - Omni-directional
Antenna - Antenna gain level (max) - 5 dBi
Antenna - Antennas quantity - 4
Antenna - Antenna type - Internal & external
Antenna > Antenna type - External
Antenna direction type Antenna - Omni-directional
Antenna gain - 5 dBi
Antenna gain level (max) Antenna - 5 dBi
Antennas quantity Antenna - 4
Antenna type Antenna - Internal & external
ARTIKEL1 - AX1800 WI-FI 6 OUTDOOR AP
ARTIKEL2 - POE IP65 WEATHERPROOF
Backup function Management features - Yes
Bluetooth Features - Yes
Brand - TP-Link
BrandPartCode - EAP603-OUTDOOR
Breite - 0
Category - Wireless Access Points
Category Code - WAP
Certificates -
Certificates - Compliance certificates - CE, Federal Communications Commission (FCC), RoHS
Cloud-managed Management features - Yes
Code - EAP603-Outdoor
Color - White
Compliance certificates Certificates - CE/Federal Communications Commission (FCC)/RoHS
DC voltage range Power - 42.5 - 57 V
Depth Weight & dimensions - 207.5 mm
Description - AX1800 Indoor/Outdoor Wi-Fi 6 Access Point Smooth 1.8Gbps Wi-Fi 6 speeds: 574Mbps on the 2.4GHz band and 1201Mbps on the 5GHz band. Dual-band omnidirectional coverage: Up to 300m (984ft) range. PoE+ power supply: Supports both 802.3at PoE and passive PoE (adapter included). Ideal for outdoor applications: IP65 weatherproof, 6kV surge protection, and a reliable operating range of -40°C to +70°C. Easy and fast setup: wall/pole mountable; Omada SDN for one-click setup. Advanced features: Omada Mesh, seamless roaming, and centralized cloud management.
Description - TP-LINK EAP603-Outdoor Точка доступу AX1800 Wi-Fi 6 для використання в приміщенні/на вулиці Безшовний Wi-Fi 1,8 Гбіт/с зі швидкістю 6 574 Мбіт/с на 2,4 ГГц і 1201 Мбіт/с на 5 ГГц. Дводіапазонне всеспрямоване покриття Покриття на великій відстані до 300 м (984 фути). Живлення від PoE+ Підтримує як 802.3at PoE, так і пасивний PoE (адаптер у комплекті). Ідеально підходить для зовнішнього середовища Захист від погодних умов IP65, блискавкозахист 6 кВ і надійний робочий діапазон від -40 °C до +70 °C. Просте та швидке налаштування Монтаж на стіну/стовп Omada SDN для налаштування в один клік Розширені функції Omada Mesh, безшовний роумінг та централізоване хмарне управління. Up to 1.8 Gbps Wi-Fi 6 Speeds† Long Coverage with 2× External Antennas 802.3at PoE & Passive PoE (Adapter Included) 1× Gigabit PoE+ Port Omada Mesh & Seamless Roaming Centralized Cloud Management IP65 Weatherproof Easy Setup Power up Your Business with Superior Wi-Fi6 Speeds 1775 Mbps (5 GHz + 2.4 GHz) 5 GHz 1201 Mbps 2.4 GHz 574 Mbps HE 80 HE 80 1024 QAM 1024 QAM MU-MIMO MU-MIMO OFDMA OFDMA Perfect for Outdoor Wi-Fi Coverage Yard Yard Shed/Barn Shed/Barn Farm Farm Swimming Pool Swimming Pool Outdoor Café Outdoor Café Park Park
Long-Range Omni-directional Coverage
2× external antennas equipped with high-power amplifiers utilize Wi-Fi 6 technology to provide strong and expansive wireless coverage to various outdoor environments.*
2.4 GHz up to
2150 ft/200 m
5 GHz up to
3200 ft/300 m
Flexible Deployment with PoE Support
Powered with PoE+ SwitchPoE
Powered with PoE+ Switch
Using the Provided Passive PoE AdapterInternet
Using the Provided Passive PoE Adapter
Seamless Connectivity with Mesh and Roaming
Ensures customers enjoy uninterrupted streaming when moving around by switching clients automatically to the access points with the optimal signal.
PoE+
Omada PoE+ Switch
phone
productproductproduct
Designed for Outdoors
The fully sealed EAP603-0utdoor offers complete dustproof protection and the ability to withstand prolonged submersion in water. It withstands the harsh outdoor environments.
IP65 Weatherproof Enclosure
IP65 Weatherproof
6kV Lightning Protection
6kV Lightning Protection
-30 °C-70 °C Working Range
-30 °C-70 °C Working Range
Wind Resistance
Wind Resistance
Easy and Quick Setup
Easy Installation Through Pole and Wall Mount Options
Pole Mounting
Pole Mounting
Wall Mounting
Wall Mounting
Works with Omada SDN for One-Click Setup
Omada SDN allows users to quickly set up the EAP603-Outdoor through automatic device identification and one-click adoption.
Empowering Businesses
with Reliable Omada SDN Solutions
Omada’s Software-Defined Networking (SDN) solution seamlessly integrates access points (APs), managed switches, and gateways, enabling 100% centralized cloud management for a highly scalable network.
Omada
Ceiling Mount
Wi-Fi 6 AP
Omada
Wall Plate
Wi-Fi 6 AP
Omada
Outdoor Wi-Fi 6 AP
EAP603-Outdoor
Omada
PoE Switch
Omada
VPN Gateway
Cloud Access
On-premises
Controllers
Hardware
Or
Software
Or
Omada Central (Cloud-Based)
Internet
Web Browser
Omada App
†Maximum wireless signal rates are the physical rates derived from IEEE Standard 802.11 specifications. Actual wireless data throughput and wireless coverage are not guaranteed and will vary as a result of 1) environmental factors, including building materials, physical objects, and obstacles, 2) network conditions, including local interference, volume and density of traffic, product location, network complexity, and network overhead, and 3) client limitations, including rated performance, location, connection, quality, and client condition.
§Omada Mesh, Seamless Roaming, Cloud Access, and Captive Portal require the use of Omada controllers.
*The advertised coverage is calculated based on laboratory testing. Actual coverage is not guaranteed and will vary as a result of the performance of the equipped antennas, client limitations, and environmental factors.
**The actual capacity depends on the wireless environment and client traffic and is generally less than the maximum number of client connections.
Seamless 1.8Gbps Wi-Fi 6 Speeds: 574 Mbps on 2.4 GHz and 1201 Mbps on 5 GHz.†
Dual-Band Omnidirectional Coverage: Up to 300 m (984 ft) long-range coverage.*
PoE+ Powered: Supports both 802.3at PoE and Passive PoE (adapter included)
Ideal for Outdoor Environments: IP65 weatherproof, 6 kV lightning protection, and a reliable operating range of -40 °C to +70 °C
Easy and Quick Setup: Wall/pole mounting; Omada SDN for one-click setup
Advanced Features: Omada Mesh, Seamless Roaming, and Centralized Cloud Management.§
Design - International Protection (IP) code - IP65, IP66
Design - Placement - Pole, Wall
Design - Product colour - White
Designation - CE+WEEE
dimension depth - 70 mm
dimension height - 215 mm
Dimensions -
dimension weight - 930 g
dimension width - 215 mm
EAN - 1210002605731
ean - 1210002605731
EANCode - 1210002605731
Environment requirements - Operating temperature: -30°C-70°C Storage temperature: -40°C-70°C Operating humidity: 10%-90% non-condensing Storage humidity: 5%-90% non-condensing
Ethernet LAN (RJ-45) ports Ports & interfaces - 1
Ethernet LAN data rates Features - 10/100/1000 Mbit/s
Features - 2.4 GHz - Yes
Features - 5 GHz - Yes
Features - 6 GHz - No
Features - Bluetooth - Yes
Features - Ethernet LAN data rates - 10,100,1000 Mbit/s
Features - Maximum data transfer rate - 1800 Mbit/s
Features - Maximum data transfer rate (2.4 GHz) - 573 Mbit/s
Features - Maximum data transfer rate (5 GHz) - 1201 Mbit/s
Features - Maximum outdoor range - 300 m
Features - Networking standards - IEEE 802.11a, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11k, IEEE 802.11n, IEEE 802.11r, IEEE 802.11v, IEEE 802.3at
Features > MU-MiMO - No
Gewicht - 0
GRUPPE1 - Network
GRUPPE2 - Wireless Lan Ap
GTIN - 1210002605731
guarantee - 60
guarantee_type - normal
Guest access Security - Yes
Height Weight & dimensions - 69.7 mm
HERSTELLER - TP-LINK
Hoehe - 0
HSTNUMMER - EAP603-OUTDOOR
I/O ports - 1 x 10/100/1000 Mbit/s PoE
Input current Power - 0.36 A
International Protection (IP) code Design - IP65, IP66
IP address filtering Security - Yes
Laenge - 0
Link - https://www.omadanetworks.com/my/business-networking/omada-wifi-outdoor/eap603-outdoor/
LongDesc -
LongProductName - 1× 10M/100M/1000Mbps Gigabit Ethernet Port (RJ45), Wi-Fi 6 2.4 - 5 GHz, 300m, 230 × 207.5 × 69.7 mm
LongSummaryDescription - TP-Link Omada EAP603-Outdoor. 2.4 GHz, 5 GHz, Maximum data transfer rate: 1800 Mbit/s. Security algorithms: EAP, EAP-FAST, EAP-GTC, EAP-MD5, EAP-PEAP, EAP-SIM, EAP-TLS, EAP-TTLS, PEAP, PPSK, SNMP, SSH,.... Ethernet LAN data rates: 10,100,1000 Mbit/s. Power over Ethernet (PoE). Product colour: White. Power consumption (max): 4.8 W
MAC address filtering Security - Yes
Management, monitoring, configuration - Omada App Restore and Backup Firmware Updates via the Internet NTP Cloud Access: Yes. Requires an Omada Controller. Email Alerts LED On/Off Control MAC Access Control SNMP: v1, v2c, v3 SSH Web-Based Management Centralized Management: Omada Hardware Controller Omada Software Controller Omada Central (Cloud-Based) Omada App
Management features - Backup function - Yes
Management features - Cloud-managed - Yes
Management features - Web-based management - Yes
Maximum data transfer rate (2.4 GHz) Features - 573 Mbit/s
Maximum data transfer rate (5 GHz) Features - 1201 Mbit/s
Maximum data transfer rate Features - 1800 Mbit/s
Maximum outdoor range Features - 300 m
Model - EAP603-OUTDOOR
Model name - EAP603-Outdoor
Mounting kit Packaging content - Yes
Name - TP-LINK AX1800 Indoor/Outdoor Wi-Fi 6 Access Point | EAP603-Outdoor | 802.11ax | 10/100/1000 Mbit/s | Ethernet LAN (RJ-45) ports 1 | MU-MiMO No | PoE in | Antenna type External
name - TP-Link EAP603-Outdoor
Network architecture - GigabitEthernet
Networking standards Features - IEEE 802.11a/IEEE 802.11ax/IEEE 802.11b/IEEE 802.11g/IEEE 802.11k/IEEE 802.11n/IEEE 802.11r/IEEE 802.11v/IEEE 802.3at
Number of antennas - 2
Number of SSID supported Security - 16
Operating frequency - 2,4 GHz
Operating frequency - 5 GHz
Operating relative humidity (H-H) Operational conditions - 10 - 90%
Operating temperature (T-T) Operational conditions - -30 - 70 °C
Operational conditions - Operating relative humidity (H-H) - 10 - 90%
Operational conditions - Operating temperature (T-T) - -30 - 70 °C
Operational conditions - Storage relative humidity (H-H) - 5 - 90%
Operational conditions - Storage temperature (T-T) - -40 - 70 °C
Package features > Embeeded battery - No
Package features > Gross depth (mm) - 324.00 mm
Package features > Gross height (mm) - 245.00 mm
Package features > Gross width (mm) - 104.00 mm
Package features > Packing quantity - 1.00 pc(s)
Package features > Palette Qty - 209 pc(s)
Package features > Paper/Pasteboard - 300.00 g
Package features > Plastic (No PET) - 100.00 g
Package features > Tare weight (kg) - 0.40 kg
Package features > Volume (m3) - 0.01 m³
Package features > WEE classification - CL109:5:2017-04-01
Package features > WEEE tax - Yes
Packaging content - Mounting kit - Yes
Packaging content - PoE adapter included - Yes
Packaging content - Quick start guide - Yes
Performance > Ethernet LAN data rates - 10/100/1000 Mbit/s
Placement Design - Pole, Wall
PoE adapter included Packaging content - Yes
Ports & interfaces - Ethernet LAN (RJ-45) ports - 1
Ports & interfaces > Ethernet LAN (RJ-45) ports - 1
Ports & interfaces > POE - PoE in
Power - DC voltage range - 42.5 - 57 V
Power - Input current - 0.36 A
Power - Power consumption (max) - 4.8 W
Power - Power over Ethernet (PoE) - Yes
Power - Power over Ethernet (PoE) type supported - Passive PoE
Power consumption (max) Power - 4.8 W
Power over Ethernet (PoE) Power - Yes
Power over Ethernet (PoE) type supported Power - Passive PoE
Power supply - Input: 802.3at PoE+: 42.5 - 57V, 0.36A
producer - TP-LINK
Product colour Design - White
ProductName - EAP603-Outdoor
Quick start guide Packaging content - Yes
Remote Authentication Dial-In User Service (RADIUS) Security - Yes
Security - Wireless Security: ACL MAC Filter 802.1X Authentication MAC Address-Based Authentication WPA-Personal/Enterprise, WPA2-Personal/Enterprise, WPA3-Personal/Enterprise, Enhanced Open, and None Radius Accounting PPSK without Radius, PPSK with Radius (Generic Radius with Associated MAC Address/EKMS/Generic Radius with Unassociated MAC Address) Authentication Portal: No Authentication, Simple Password, Access Point (Voucher/Local User/SMS/RADIUS/Form Authentication), RADIUS Server, External LDAP Server, External Portal Server, Pre-Authentication Access, and Unauthenticated Client EAP Types: EAP-TLS, EAP-TTLS, EAP-PEAP, EAP-CHAP, EAP-SIM, EAP-AKA EAP-GTC, EAP-FAST, EAP-PEAP, EAP-MD5, EAP-MSCHAPv2, PEAPv0, PEAPv1
Security - Access Control List (ACL) - Yes
Security - Guest access - Yes
Security - IP address filtering - Yes
Security - MAC address filtering - Yes
Security - Number of SSID supported - 16
Security - Remote Authentication Dial-In User Service (RADIUS) - Yes
Security - Security algorithms - EAP, EAP-FAST, EAP-GTC, EAP-MD5, EAP-PEAP, EAP-SIM, EAP-TLS, EAP-TTLS, PEAP, PPSK, SNMP, SSH, WPA-Enterprise, WPA-Personal, WPA2-Enterprise, WPA2-Personal, WPA3-Enterprise, WPA3-Personal
Security - Service Set Identifier (SSID) features - Multiple SSIDs
Security algorithms Security - EAP/EAP-FAST/EAP-GTC/EAP-MD5/EAP-PEAP/EAP-SIM/EAP-TLS/EAP-TTLS/PEAP/PPSK/SNMP/SSH/WPA2-Enterprise/WPA2-Personal/WPA3-Enterprise/WPA3-Personal/WPA-Enterprise/WPA-Personal
Service Set Identifier (SSID) features Security - Multiple SSIDs
ShortSummaryDescription - TP-Link Omada EAP603-Outdoor, 2.4 GHz, 5 GHz, 1800 Mbit/s, EAP, EAP-FAST, EAP-GTC, EAP-MD5, EAP-PEAP, EAP-SIM, EAP-TLS, EAP-TTLS, PEAP, PPSK, SNMP, SSH,..., 10,100,1000 Mbit/s
Standards - 802.11a
Standards - 802.11ac
Standards - 802.11ax
Standards - 802.11b
Standards - 802.11g
Standards - 802.11n
Stck_Kart - 16
Stck_Pal - 0
Storage relative humidity (H-H) Operational conditions - 5 - 90%
Storage temperature (T-T) Operational conditions - -40 - 70 °C
Storno - Y
Summary - TP-Link Omada EAP603-Outdoor. 2.4 GHz, 5 GHz, Maximum data transfer rate: 1800 Mbit/s. Security algorithms: EAP, EAP-FAST, EAP-GTC, EAP-MD5, EAP-PEAP, EAP-SIM, EAP-TLS, EAP-TTLS, PEAP, PPSK, SNMP, SSH,.... Ethernet LAN data rates: 10,100,1000 Mbit/s. Power over Ethernet (PoE). Product colour: White. Power consumption (max): 4.8 W
Technical details > Gross weight - 1.80 kg
Technical details > Net weight - 1.40 kg
Technical details > Producer - TP-LINK
Technical details > Producer product family - AX1800 Indoor/Outdoor Wi-Fi 6 Access Point
Technical details > Producer product name - EAP603-Outdoor
Title - TP-Link Omada EAP603-Outdoor 1800 Mbit/s White Power over Ethernet (PoE)
Unit Box Height - 0.07
Unit Box Length - 0.219
Unit Box Width - 0.218
Unit Calculated Volume - 0.003342 cubm
Unit Calculated Weight - 0.93 kg
Units per Pallet - 0
Units per Shipping Box - 1
URL - https://www.omadanetworks.com/ae/business-networking/omada-wifi-outdoor/eap603-outdoor/#specifications
Vendor Homepage - https://www.omadanetworks.com/ae/business-networking/omada-wifi-outdoor/eap603-outdoor/#specifications
vendpn - EAP603-Outdoor
Warranty - 60
Warranty - 60 month(s)
Warranty - 60 months
WarrantyInfo -
Web-based management Management features - Yes
Weight & dimensions - Depth - 207.5 mm
Weight & dimensions - Height - 69.7 mm
Weight & dimensions - Width - 230 mm
Width Weight & dimensions - 230 mm
Wireless LAN features > Wi-Fi band - 802.11ax
