Aero2 support - No
Antenna - Detachable external
Brand - D-Link
BrandPartCode - DWM-550-G
Card reader - None
Category - Cellular Network Devices
Certificates - CE UKCA
Color - Black
Data transmission - LTE
Description - 5G M2M Router DWM-550-G 5G SA & NSA speeds up to 3.4 Gb/s - fast internet access and data transmission Wi-Fi speeds up to 1.8 Gb/s - connect multiple Wi-Fi devices simultaneously 1 x Gigabit Ethernet WAN/LAN port - configurable as a wired WAN access 3 x Gigabit Ethernet LAN ports - reliable wired connections 2 x SIM slots - WAN connection redundancy for enhanced reliability Plug-and-play setup - no configuration required; simply connect and the network is ready Durable galvanized steel housing - corrosion-resistant for long device lifespan Operating temperature range from -30°C to 70°C - built for harsh environments Optional wall-mount bracket - allows optimal device placement 5G SA & NSA support - flexible 4G/5G mode compatibility for various mobile networks Dual-SIM Redundancy Two SIM card slots with automatic failover ensure uninterrupted WAN connectivity via cellular networks. Ethernet & 5G Redundancy Seamless switching between Ethernet WAN and 5G connections provides reliable connectivity. Industrial-Grade Durability Corrosion-resistant galvanized steel housing and robust construction ensure reliability in demanding environments. Secure VPN Protection Encrypted VPN tunnels safeguard data transmission against unauthorized network access. Wi-Fi 6 AX1800 Supports Wi-Fi 6 for a wide range of portable devices and IoT networks. Operator Diversity & Network Redundancy The DWM-550-G 5G M2M router ensures continuous operation with dual Nano-SIM (4FF) support, enhancing operator flexibility and network reliability. Stable connectivity is possible even in areas with limited coverage. The device features four LAN ports, one of which can be configured as a WAN, offering flexible switching between Ethernet WAN and 5G to always ensure optimal network access. Secure Your Network with VPN The DWM-550-G 5G M2M router provides high-level network security with advanced VPN protocols such as IPSec, OpenVPN, PPTP, L2TP, GRE, and WireGuard. This enables encrypted connections, flexible tunneling, and secure remote access for effective data protection. Ideal for retail, small shops, pop-up locations, and smart parking systems, the DWM-550-G safeguards financial transactions and customer data. Robust Construction Designed for maximum reliability and M2M connectivity availability, the DWM-550-G features corrosion-resistant galvanized steel, wide input voltage range, broad operating temperature range, and moisture resistance, making it suitable for the most demanding M2M applications in nearly any environment. High-Speed 5G & Wi-Fi 6 for Modern IoT Deployments Discover the capabilities of the DWM-550-G 5G M2M Router, engineered for high performance with fast 5G connectivity and Wi-Fi 6 AX1800 technology for M2M applications. Dual SIM support ensures continuous communication by switching to a backup network if the primary network fails. The router secures data using advanced VPN features and allows centralized management via the D-ECS cloud platform. Ideal for NVR systems, kiosks, industrial computers, digital signage, and mobile POS systems, the DWM-550-G is perfect for remote locations, pop-up sites, and bus stops, enhancing operational efficiency and network quality.
Design - Device type - Cellular network router
Design - LED indicators - Yes
Design - Product colour - Black
Design - Reset button - Yes
Designation - CE+WEEE
dimension depth - 210 mm
dimension height - 148 mm
Dimensions - 160 x 125 x 35 mm
dimension weight - 1480 g
dimension width - 170 mm
ean - 790069475290
Environment requirements - Operating/Storage Temperature: Operating Temperature: -30°C to 70°C Storage Temperature: -40°C to 85°C Humidity: Operating Humidity: 10% to 95% (non-condensing) Storage Humidity: 0% to 95% (non-condensing)
Ethernet LAN features - DHCP server - Yes
Ethernet LAN features - Ethernet LAN - Yes
Ethernet LAN features - Ethernet LAN data rates - 10,100,1000 Mbit/s
Ethernet LAN features - Ethernet LAN interface type - Gigabit Ethernet
Ethernet LAN features - Networking standards - IEEE 802.11a, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
GTIN - 0790069475290
GTIN - 790069475290
guarantee - 24
guarantee_type - external
I/O ports - 1 x WAN (RJ-45)
I/O ports - 3 x 10/100/1000 Mbit/s
LongDesc - 5G SA & NSALeverage flexible 4G/5G dual-mode compatibility to adapt seamlessly to diverse carrier networks.Dual-SIM FailoverTwo SIM slots with auto-failover redundancy to ensure uninterrupted cellular WAN connectivity.Ethernet & 5G RedundancySeamless failover between Ethernet WAN and 5G for reliable connectivity.Industrial-Grade DurabilityCorrosion-resistant zinc-plated steel casing and robust design ensure reliable operation in harsh environments.Secure VPN ProtectionProtect sensitive data transmission via secure VPN tunnels to prevent unauthorized network access.Wi-Fi 6 AX1800Drive Wi-Fi 6 to cover various portable and IoT device networking services.Carrier Diversity and Network RedundancyThe DWM-550-G 5G M2M Router ensures continuous service with Dual SIM (Nano-SIM 4FF) support for enhanced carrier diversity and network redundancy. Reliable connectivity even in locations with limited coverage is now possible. Additionally, it includes four LAN ports, one configurable as a WAN, giving you flexible options to seamlessly switch between Ethernet WAN and 5G connections, ensuring you always have the best network access.Secure Your Network with VPNThe DWM-550-G 5G M2M Router boosts network security with robust VPN support, offering protocols such as IPSec, OpenVPN, PPTP, L2TP, GRE and WireGuard. These features enable encrypted connections, versatile tunneling, and secure remote access to protect sensitive data effectively. Ideal for retail operations, small shops, pop-up booths, and smart parking systems, the DWM-550-G ensures that financial transactions and customer information are securely managed and transmitted.Robust Build QualityThe DWM-550-G is designed to maximize M2M connection reliability and availability, featuring a corrosion-resistant zinc-plated steel casing, wide voltage input range, wide operating temperature range and humidity tolerance, making it suitable for the most demanding M2M applications in virtually any environment.
LongProductName - 4 x SMA 4G/5G, 2 x RP-SMA Wi-Fi, 5G NR, 1 x WAN/LAN GE, 3 x LAN GE, 160 x 125 x 35mm
LongSummaryDescription - D-Link 5G M2M VPN Wi-Fi 6 Router. Device type: Cellular network router, Product colour: Black. Ethernet LAN interface type: Gigabit Ethernet, Ethernet LAN data rates: 10,100,1000 Mbit/s, Networking standards: IEEE 802.11a, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n. Wi-Fi standards: 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), WLAN data transfer rates supported: 574 Mbit/s. Data network: 4G, 5G, LTE, 4G standard: LTE, 5G standard: Sub6 NSA, Sub6 SA. Security algorithms: SNMP, SNMPv2, SNMPv3
LTE network - 600 MHz
LTE network - 700 MHz
LTE network - 800 MHz
LTE network - 850 MHz
LTE network - 900 MHz
LTE network - 1500 MHz
LTE network - 1800 MHz
LTE network - 2100 MHz
LTE network - 2300 MHz
LTE network - 2500 MHz
LTE network - 2600 MHz
LTE network - 3400 MHz
LTE network - 3600 MHz
Memory standard - Not applicable
Mobile network - 4G standard - LTE
Mobile network - 5G standard - Sub6 NSA, Sub6 SA
Mobile network - Data network - 4G, 5G, LTE
Mobile network - Number of SIM cards - 2
Model - DWM-550-G
name - 5G Router DWM-550-G
Number of antennas - Six connectors
Operating frequency - 2,4 GHz
Operating frequency - 5 GHz
Operational conditions - Operating relative humidity (H-H) - 10 - 95%
Operational conditions - Operating temperature (T-T) - -30 - 70 °C
Operational conditions - Storage temperature (T-T) - -40 - 85 °C
Performance - Antenna connector type - SMA
Performance - Antennas quantity - 6
Performance - Antenna type - External
Ports & interfaces - Ethernet LAN (RJ-45) ports - 4
Power - Input voltage - 12 - 36 V
Power - Power source type - DC
Power supply - DC 12-36V (TB)
producer - D-Link
ProductName - 5G M2M VPN Wi-Fi 6 Router
Security - Firewall: SPI firewall with Stealth Mode, Intrusion Prevention System (IPS), WAN ping blocking Access Control: packet filtering, URL blocking, MAC address control
Security - DMZ support - Yes
Security - Firewall - Yes
Security - Network address translation (NAT) - Yes
Security - Port forwarding - Yes
Security - Security algorithms - SNMP, SNMPv2, SNMPv3
ShortSummaryDescription - D-Link 5G M2M VPN Wi-Fi 6 Router, Cellular network router, Black, Gigabit Ethernet, 10,100,1000 Mbit/s, IEEE 802.11a, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
SIM card - Nano
Standards - 802.11a
Standards - 802.11ac
Standards - 802.11ax
Standards - 802.11b
Standards - 802.11g
Standards - 802.11h
Standards - 802.11n
Standards - IPv4
Standards - IPv6
Title - D-Link 5G M2M VPN Wi-Fi 6 Router
Type - v
URL - https://www.dlink.com/uk/en/products/dwm-550-g-5g-m2m-router
vendpn - DWM-550-G
WarrantyInfo -
Weight & dimensions - Depth - 125 mm
Weight & dimensions - Height - 35 mm
Weight & dimensions - Width - 160 mm
Wireless LAN features - Wi-Fi - Yes
Wireless LAN features - Wi-Fi standards - 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
Wireless LAN features - WLAN data transfer rates supported - 574 Mbit/s
