10/100/1000M LAN Ports - 1
Antenna - Antenna gain level (max) - 5 dBi
Antenna - Antennas quantity - 4
Antenna - Antenna type - External
Antenna - Transmitting power (CE) - Antenna - Transmitting power (FCC) - Brand - TP-Link
BrandPartCode - EAP673-EXTENDER
Category - Network Extenders
Category Code - WRE
Certificates - Compliance certificates - CE
Certificates - Compliance certificates - CE, Federal Communications Commission (FCC), JRF, RCM, RoHS, UL, VCCI
Certificates - Compliance certificates - Federal Communications Commission (FCC)
Certificates - Compliance certificates - JRF
Certificates - Compliance certificates - RCM
Certificates - Compliance certificates - RoHS
Certificates - Compliance certificates - UL
Certificates - Compliance certificates - VCCI
Colour - White
Data transmission speed - 5400 Mbps
Description - AX5400 Mesh Wi-Fi 6 Extender AX5400 Dual-Band WiFi 6: Up to 5.4 Gbps wireless speeds . WiFi Dead-Zone Killer: Four high-gain external antennas extend WiFi signals to every dead zone. AP Mode: Simply plug in an Ethernet cable to create a new WiFi AP. Seamless Mesh Networking: Supports Omada Mesh and Roaming for reliable networking, ideal for large-scale scenarios.§ Easy & Quick Installation: Standard AC power supply for flexible deployment. Quick adoption: Conveninet operation via Omada web or app once the extender powers on. Centralized Cloud Management: Integrates into Omada SDN for cloud access and remote management.
Design - Housing material - Polycarbonate (PC)
Design - Product colour - White
Design - Quantity per pack - 1 pc(s)
Design - Reset button - Yes
dimensionalWeight - 705
Dimensions - 160 × 80 × 37.8 mm
GTIN - 8885020622874
LongDesc - Seamless Coverage to Remove Dead ZonesEAP673-Extender, featuring four high-gain antennas and mesh technology, eliminates dead zones, extending coverage by 1500 ft² (140 m²) . Enjoy seamless roaming for uninterrupted connectivity.Effortless Installation with AC PowerOvercome cabling challenges with EAP673-Extender, delivering seamless Wi-Fi via AC power. Enjoy stable, high-performance coverage—no extra wires needed.AP Mode for Flexible DeploymentEAP673-Extender's built-in AP mode delivers a robust, stable Wi-Fi signal without a PoE switch or infrastructure renovations, enhancing flexibility and reducing costs.
LongProductName - AX5400 Mesh Wi-Fi 6 Extender
LongSummaryDescription - TP-Link Omada EAP673-Extender. Type: Network repeater, Ethernet LAN data rates: 10,100,1000 Mbit/s, Number of users: 250 user(s). Antenna gain level (max): 5 dBi, Antenna type: External, Transmitting power (CE): Management features - Airtime scheduling - Yes
Model - EAP673-Extende
Network - Networking standards - IEEE 802.11a
Network - Networking standards - IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Network - Networking standards - IEEE 802.11ac
Network - Networking standards - IEEE 802.11ax
Network - Networking standards - IEEE 802.11b
Network - Networking standards - IEEE 802.11g
Network - Networking standards - IEEE 802.11n
Network - Quality of Service (QoS) support - Yes
Network - Security algorithms - 64-bit WEP
Network - Security algorithms - 64-bit WEP, 128-bit WEP, WPA-PSK, WPA2-PSK
Network - Security algorithms - 128-bit WEP
Network - Security algorithms - WPA-PSK
Network - Security algorithms - WPA2-PSK
Network - Web-based management - Yes
Network - Wi-Fi - Yes
Network - Wi-Fi band - Dual-band (2.4 GHz / 5 GHz)
Network - Wi-Fi data rate (max) - 4800 Mbit/s
Network - Wi-Fi Multimedia (WMM)/(WME) - Yes
Network - Wi-Fi standards - 802.11a
Network - Wi-Fi standards - 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
Network - Wi-Fi standards - 802.11b
Network - Wi-Fi standards - 802.11g
Network - Wi-Fi standards - Wi-Fi 4 (802.11n)
Network - Wi-Fi standards - Wi-Fi 5 (802.11ac)
Network - Wi-Fi standards - Wi-Fi 6 (802.11ax)
Network Device Type - Range Extender
Number of antennas - 4
Operational conditions - Operating relative humidity (H-H) - 10 - 90%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Operational conditions - Storage relative humidity (H-H) - 5 - 90%
Operational conditions - Storage temperature (T-T) - -40 - 70 °C
Packaging content - Quick start guide - Yes
Performance - BeamForming - Yes
Performance - Ethernet LAN data rates - 10
Performance - Ethernet LAN data rates - 10,100,1000 Mbit/s
Performance - Ethernet LAN data rates - 100
Performance - Ethernet LAN data rates - 1000 Mbit/s
Performance - Number of users - 250 user(s)
Performance - Type - Network repeater
Ports & interfaces - Ethernet LAN (RJ-45) ports - 1
Power - AC input frequency - 50/60 Hz
Power - AC input voltage - 100 - 240 V
Power - Power consumption (max) - 18 W
producerCode - EAP673-Extender
ProductName - EAP673-Extender
productName - TP-Link Omada EAP673-Extender Network repeater White 10, 100, 1000 Mbit/s
Product Net Weight - 1 kg
productSize - Normal
ShortSummaryDescription - TP-Link Omada EAP673-Extender, Network repeater, 10,100,1000 Mbit/s, 250 user(s), 5 dBi, External, sizeX - 120
sizeY - 210
sizeZ - 140
Title - TP-Link Omada EAP673-Extender Network repeater White 10, 100, 1000 Mbit/s
Unit Box Height - 0.12
Unit Box Length - 0.205
Unit Box Width - 0.14
Unit Calculated Volume - 0 cubm
Unit Calculated Weight - 1 kg
Units per Shipping Box - 1
URL - https://www.omadanetworks.com/en/business-networking/omada-wifi-wall-plate/eap673-extender/
Vendor Homepage - www.omadanetworks.com/my/business-networking/omada-wifi-wall-plate/eap673-extender/
Warranty - 36 months
WarrantyInfo -
warrantyLength - 60
warrantyType - G
weight - 650
Weight & dimensions - Depth - 80 mm
Weight & dimensions - Height - 37.8 mm
Weight & dimensions - Weight - 436.6 g
Weight & dimensions - Width - 160 mm
Wi-Fi 6 Network standard - Yes
Wireless Frequency Range - 2.4 GHz and 5 GHz
