Accessories included - Mounting plate Mounting screws
Antenna - Built-in
Antenna - Antenna gain level (max) - 3.17 dBi
Antenna - Antenna type - Internal
Antenna gain - 3.17 dBi
Brand - Zyxel
BrandPartCode - WBE630S-EU0101F
Category - Wireless Access Points
Certificates - Radio FCC Part 15C FCC Part 15E FCC Part 2.1091 ETSI EN 300 328 EN 301 893 Draft EN 303 687 EN 50385 EN 50665 EN IEC 62311 LP0002 EMC FCC Part 15B EN 301 489-1 EN 301 489-17 EN55032 EN55035 EN61000-3-2/-3 EN60601-1-2 BSMI CNS15936 Security EN 62368-1 IEC 62368-1 BSMI CNS15598-1
Color - White
Data Act - Link
Description - Building resilient educational connectivity with next-gen WiFi 7
Designed for educational environments, the WBE630S features a quad-core Qualcomm processor and robust hardware, delivering blazing-fast speeds of up to 12.3 Gbps and significantly increased capacity to ensure a seamless online experience for students.
It unlocks the full potential of WiFi 7 connectivity and reliability through MLO support in Nebula, meeting the demands of modern educational applications. Digital learning, virtual classrooms, and VR/AR applications can leverage these incredible speeds to provide a smooth, lag-free educational experience.
Versatility of smart antenna technology
The WBE630S incorporates unique smart antenna technology--an evolution of dual-optimized antenna designs--that automatically adjusts antenna patterns for peak performance. This effectively minimizes interference while ensuring optimal WiFi connectivity and coverage across various scenarios and mounting options.
Nebula: Intelligent cloud management
Nebula offers comprehensive monitoring and reporting capabilities, including real-time notifications for critical events via email or the mobile app.
With Nebula, you benefit from a streamlined network installation and management experience, without the need for additional software costs or hardware controllers. Enhance your Wi-Fi network with Nebula
Nebula automates wireless network management and optimization through features like WiFi Aid and Wireless Health, ensuring the best possible user experience. These features boost network performance and reliability, delivering an exceptional Wi-Fi experience.
Description - ZYXEL WBE630S BE12.3K (2.4GHZ: 2X2:2, 5 OR 6GHZ: 4X4:4) MU-MIMO, SMART ANTENNA, DUAL RADIO 2.4 AND 5 OR 6GHZ, INCL 1 YEAR NEBULA PRO, 2 X 2.5G LAN PORTS, POE+ (802.3AT), STANDALONE/CONTROLLER/NEBULA CLOUD MANAGED EXCLUDING POWER ADAPTER (5Y WARRANTY)
Design - Placement - Desk, Table
Design - Product colour - White
Designation - CE+WEEE
dimensionalWeight - 738
dimension depth - 70 mm
dimension height - 290 mm
Dimensions - 250 x 160 x 47 mm
dimension weight - 1147 g
dimension width - 190 mm
ean - 4718937638857
Environment requirements - Operation Temperature: 0°C to 50°C Humidity: 10% to 95% (non-condensing) Storage Temperature: -40°C to 70°C Humidity: 10% to 90% (non-condensing)
Features - 2.4 GHz - Yes
Features - 5 GHz - Yes
Features - 6 GHz - Yes
Features - Band steering - Yes
Features - Fast roaming - Yes
Features - Maximum data transfer rate - 11530 Mbit/s
Features - Maximum data transfer rate (2.4 GHz) - 688 Mbit/s
Features - Maximum data transfer rate (5 GHz) - 8646 Mbit/s
Features - Maximum data transfer rate (6 GHz) - 11530 Mbit/s
Features - Networking standards - IEEE 802.3af
Features - Networking standards - IEEE 802.3at
Features - Networking standards - IEEE 802.11a
Features - Networking standards - IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11be, IEEE 802.11g, IEEE 802.11k, IEEE 802.11n, IEEE 802.11r, IEEE 802.11v, IEEE 802.3af, IEEE 802.3at
Features - Networking standards - IEEE 802.11ac
Features - Networking standards - IEEE 802.11ax
Features - Networking standards - IEEE 802.11b
Features - Networking standards - IEEE 802.11be
Features - Networking standards - IEEE 802.11g
Features - Networking standards - IEEE 802.11k
Features - Networking standards - IEEE 802.11n
Features - Networking standards - IEEE 802.11r
Features - Networking standards - IEEE 802.11v
GTIN - 4718937638857
guarantee - 24
guarantee_type - external
Height - 70.000000
I/O ports - 2 x 10/100/1000/2500 RJ-45 port
Length - 285.000000
LongDesc - Powerful. Secure. Wireless.Building Resilient Education Connectivity with Next-Gen WiFi 7Building Resilient Education Connectivity with Next-Gen WiFi 7Designed for educational settings, WBE630S features a Qualcomm quad-core CPU and durable hardware, delivering lightning-fast speeds of up to 12.3Gbps and significantly increased capacity to ensure students have a seamless online experience.It unleashes the full potential of WiFi 7connectivity and reliability with MLO support in Nebula to meet the demands of today’s educational applications. Digital learning, virtual classrooms, and VR/AR can also take advantage of its incredible speeds, ensuring a seamless learning experience devoid of any latency.The Versatility of Smart Antenna TechnologyWBE630S incorporates unique Smart Antenna technology, an upgrade from dual-optimized antennas, automatically adapting antenna patterns for peak performance, effectively minimizing interference and ensuring optimal WiFi connectivity and coverage across diverse scenarios and mounting options.Ready to Boost Network Speeds Up to 2.5xPaired with Zyxel WBE630S WiFi 7 AP, the XMG1915-10EP/18EP switch is the perfect choice for upgrading your SB/SMB network’s speed and performance, offering up to 2.5 times faster speeds than today’s Gigabit networks.With this switch, it’s a breeze to boost your network speed using your existing wiring infrastructure without costly and disruptive cable upgrades.
LongProductName - WBE630S 802.11be (WiFi 7) Dual-Radio Unified Pro Access Point EU AND UK
LongSummaryDescription - Zyxel WBE630S. 2.4 GHz, 5 GHz, 6 GHz, Maximum data transfer rate: 11530 Mbit/s. Security algorithms: SNMP, WEP, WPA, WPA2, WPA3. Power over Ethernet (PoE). Product colour: White
Management, monitoring, configuration - Operation Mode Nebula Cloud managed Controller-managed Standalone ZON Utility Discovery of Zyxel switches, access points, and gateways Centralized and batch configurations: IP configuration IP renewal Device reboot Device location Web GUI access Firmware upgrade Password configuration Web GUI/CLI: Yes
SNMP: Yes
Manufacturer - Zyxel
ManufacturerPartNumber - WBE630S-EU0101F
name - Zyxel WBE630S-EU0101F
Network architecture - GigabitEthernet
Number of antennas - 1
Operating frequency - 2,4 GHz
Operating frequency - 5 GHz
Operating frequency - 6 GHz
Other features -
Packaging content - Quantity per pack - 1 pc(s)
Packaging data - Package depth - 180.5 mm
Packaging data - Package height - 66 mm
Packaging data - Package weight - 1.04 kg
Packaging data - Package width - 279.5 mm
PeriodofWarranty - 5 Y
Ports & interfaces - DC-in jack - Yes
Ports & interfaces - Ethernet LAN (RJ-45) ports - 2
Ports & interfaces - Internal RJ-45 ports quantity - 2
Power - Power over Ethernet (PoE) - Yes
Power supply - Power: PoE (802.3at): 21.5 W power consumption DC input: USB PD 15 VDC 2 A (Type-C) PoE modes: IEEE 802.3af: no wireless connectivity IEEE 802.3at: no restrictions IEEE 802.3bt: no restrictions
producer - Zyxel
producerCode - WBE630S-EU0101F
ProductName - WBE630S
productName - Zyxel WBE630S 11530 Mbit/s White Power over Ethernet (PoE)
productSize - Normal
Safety warning - Warnings - Avoid contact with liquids - the unit is not waterproof.
Safety warning - Warnings - Do not dismantle the appliance - internal components may be hazardous to the user's health and should only be handled by qualified personnel.
Safety warning - Warnings - Risk of electric shock – use caution during installation and use.
Security - Encryption WEP WPA WPA2 WPA3 Authentication IEEE 802.1X RADIUS authentication Access management L2 isolation MAC filtering Rogue AP detection
Security - Auto Wireless Distribution System (WDS) - Yes
Security - Security algorithms - SNMP
Security - Security algorithms - SNMP, WEP, WPA, WPA2, WPA3
Security - Security algorithms - WEP
Security - Security algorithms - WPA
Security - Security algorithms - WPA2
Security - Security algorithms - WPA3
ShortSummaryDescription - Zyxel WBE630S, 2.4 GHz, 5 GHz, 6 GHz, 11530 Mbit/s, SNMP, WEP, WPA, WPA2, WPA3
sizeX - 70
sizeY - 285
sizeZ - 185
Software -
Special functions -
Standards - 802.11a
Standards - 802.11ac
Standards - 802.11ax
Standards - 802.11b
Standards - 802.11be
Standards - 802.11g
Standards - 802.11n
System Requirements -
Title - Zyxel WBE630S 11530 Mbit/s White Power over Ethernet (PoE)
URL - https://www.zyxel.com/global/en/products/wireless/be12300-wifi-7-dual-radio-nebulaflex-pro-access-point-wbe630s/specifications
vendpn - WBE630S-EU0101F
WarrantyInfo -
warrantyType - W
Weight - 1.150000
Weight - 815 g
weight - 1190
Weight & dimensions - Depth - 160 mm
Weight & dimensions - Height - 47 mm
Weight & dimensions - Weight - 815 g
Weight & dimensions - Width - 250 mm
Width - 185.000000
