Accessories included - RUT260 router 9W power supply 2 x LTE antennas (swivel, SMA male) 1 x Wi-Fi antenna (rotatable, RP-SMA male) Ethernet cable (1.5 m) SIM adapter set QSG (Quick Start Guide)
Aero2 support - No
Antenna - Detachable external
Antenna connector type Performance - SMA/RP-SMA
Antennas quantity Performance - 3
Antenna type Performance - External
Assisted GPS (A-GPS) GPS Performance - No
BeiDou GPS Performance - No
Built-in battery Power - No
Built-in display Design - No
Built-in processor Performance - Yes
Category 1 - Netzwerk
Category 2 - Router
Category Code - CND
Certificates - CE/RED, UKCA, UCRF, RCM, EAC, WEEE
CnCode - 85176200
Code - RUT260000000
Color - Black
Connections - Ethernet (RJ-45)
Data network Mobile network - 3G, LTE
Data transfer rate (LTE) (download) Mobile network - 300 Mbit/s
Data transfer rate (LTE) (upload) Mobile network - 50 Mbit/s
Data transmission - LTE
Depth Weight & dimensions - 74 mm
Description - RUT260 is a Category 6 LTE router from Teltonika Networks with WAN failover functionality. It combines the key features of the RUT240 and RUT360 router, is powerful, lightweight and supports a wide range of industrial protocols including MQTT, SNMP, Modbus and more.
Description - RUT260 is a Teltonika Networks LTE Cat 6 cellular router with WAN failover. Balancing the key features of the RUT240 and RUT360, this cellular router is powerful, lightweight, and supports a wide variety of industrial protocols, including MQTT, SNMP, Modbus, and more.
Description - TELTONIKA RUT260 IOT ROUTER 4G (CAT6) 2X10/100 RJ45 WIFI
Designation - CE+WEEE
Detachable antenna(s) Performance - Yes
Device type Design - Cellular network router
DHCP client Ethernet LAN features - Yes
DHCP server Ethernet LAN features - Yes
dimension depth - 150 mm
dimension height - 70 mm
Dimensions - 83 x 25 x 74 mm
Dimensions W x D x H, mm - 83 x 74 x 25
dimension weight - 370 g
dimension width - 180 mm
DMZ support Security - Yes
EAN - 4779051841332
ean - 4779051841332
Electronic compass GPS Performance - No
Embedded GNSS GPS Performance - No
Environment requirements - Operating temperature: -40 to 75 degrees Celsius Operating humidity: 10% to 90% (non-condensing) Ingress protection class: IP30
Ethernet LAN (RJ-45) ports Ports & interfaces - 2
Ethernet LAN (RJ-45) ports quantity - 2
Ethernet LAN data rates Ethernet LAN features - 10,100 Mbit/s
Ethernet LAN data transfer rates, Mbit/s - 10/100
Ethernet LAN Ethernet LAN features - Yes
Ethernet LAN interface type Ethernet LAN features - Fast Ethernet
Features > Mesh Support - No
Features > Mobile Broadband - 4G
Features > MU-MiMO - No
Firewall Security - Yes
Full duplex Ethernet LAN features - Yes
Galileo GPS Performance - No
GLONASS GPS Performance - No
GPS (satellite) Performance - No
guarantee - 24
guarantee_type - normal
Height - 72.000000
Height Weight & dimensions - 25 mm
Housing material Design - Aluminium, Plastic
I/O ports - 1 x 10/100 Mbit/s
I/O ports - 1 x 10/100 Mbit/s WAN
Internal memory - 128 MB
Internal storage capacity Performance - 0.016 GB
IP address filtering Security - Yes
LED indicators - 2 x Connection type status, 5 x Mobile connection strength, 1 x LAN status, 1 x WAN status, 1 x Power
LED indicators Design - LAN, Network, Power, Signal strength, WAN
Length - 148.000000
Link - https://teltonika-networks.com/products/routers/rut260
Management, monitoring, configuration - WEB UI: Web UI (HTTP/HTTPS), status, configuration, firewall software (FW) update, command line interface (CLI), troubleshooting, event log, system log. FOTA: Software update from the server, automatic notifications. SSH: SSH (v1, v2). SMS: SMS status, SMS configuration, sending/reading SMS via HTTP POST/GET. Connection: Reboot, status, enable/disable mobile data, enable/disable output, receive/disconnect clock from timer, enable/disable Wi-Fi. TR-069: OpenACS, EasyCwmp, ACSLite, tGem, LibreACS, GenieACS, FreeACS, LibCWMP, Friendly tech, AVSystem. SNMP: SNMP (v1, v2, v3), SNMP trap. JSON-RPC: Management API over HTTP/HTTPS. MODBUS: MODBUS TCP status/control. RMS: Teltonika Remote Management System (RMS).
Manufacturer - Teltonika
ManufacturerPartNumber - RUT260000000
Market positioning Design - Industrial
Mobile broadband - Yes
Model - RUT260
Mounting Design - DIN-rail/Wall mounting
MPN - RUT260000000
Name - LTE Cat 6 Router | RUT260 | 802.11n | 10/100 Mbit/s | Ethernet LAN (RJ-45) ports 2 | Mesh Support No | MU-MiMO No | 4G
name - Router RUT260 4G, 3G, 2G, WIFI, 2x10/100 Mbps Ethernet
Name - Teltonika RUT260 Industrial LTE CAT6 WiFi Router
Network address translation (NAT) Security - Yes
Networking standards Ethernet LAN features - IEEE 802.11b, IEEE 802.11e, IEEE 802.11g, IEEE 802.11n, IEEE 802.11r, IEEE 802.3, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3bt, IEEE 802.3u
Number of antennas - 3
Number of SIM cards Mobile network - 1
Operating relative humidity (H-H) Operational conditions - 10 - 90%
Operating system installed Performance - RutOS
Operating system provided - Linux
Operating temperature (T-T) Operational conditions - -40 - 75 °C
Operating temperature range (T-T), °C - - 40 - 75
Other features - Housing material: aluminum housing, plastic panels
Other features > Ethernet LAN (RJ-45) ports - 2
Package features > Embeeded battery - No
Package features > Gross depth (mm) - 90 mm
Package features > Gross height (mm) - 40 mm
Package features > Gross width (mm) - 100 mm
Package features > Packing quantity - 1 pc(s)
Package features > Palette Qty - 2400 pc(s)
Package features > Paper/Pasteboard - 100 g
Package features > Tare weight (kg) - 0.1 kg
Package features > Volume (m3) - 0.00036 m³
Package features > WEE classification - CL109:6:2017-04-01
Package features > WEEE tax - Yes
Performance > Ethernet LAN data rates - 10/100 Mbit/s
PeriodofWarranty - 2 Y
Power source type Power - DC
Power supply - Input voltage range: 9 - 30 VDC, reverse polarity protection, overvoltage/surge protection.
Processor frequency Performance - 0.58 GHz
Processor manufacturer Performance - Mediatek
producer - TELTONIKA
Product colour Design - Black, Blue
Quasi-Zenith Satellite System (QZSS) GPS Performance - No
RAM capacity Performance - 0.128 GB
Security - Authorization: Shared key, digital certificates, X.509 certificates, TACACS+, RADIUS, blocking login attempts from the IP address. Mobile package limit control: Mobile data limit, customizable period, start time, warning limit, phone number. VLAN: VLAN separation based on port and VLAN tag. Attack Prevention: DDoS attack prevention (SYN flood attack protection, SSH attack prevention, HTTP/HTTPS attack prevention), port scanning prevention (SYN-FIN, SYN-RST, X-mas, NULL flags, FIN scan attacks). Firewall: Pre-configured firewall rules can be enabled via web interface (WebUI), unlimited firewall configuration via command line interface (CLI); demilitarized zone (DMZ); network address translation (NAT); NAT-T. Web Filter: Blacklist to block unwanted websites, Whitelist to define only allowed websites. Access control: Flexible access control to TCP, UDP, ICMP packets, MAC address filter.
Security algorithms Security - AES-CCMP, TKIP, WEP, WPA2-Enterprise-PEAP, WPA2-PSK, WPA3-EAP, WPA3-SAE
Short Message Service (SMS) Mobile network - Yes
SIM card - Standard
SIM card type - mini-SIM
SIM card type Mobile network - MiniSIM
Software -
Special functions -
Standards - 802.11b
Standards - 802.11g
Standards - 802.11n
Standards - IPv4
Standards - IPv6
Standards and Protocols - TCP, UDP, IPv4, IPv6, ICMP, NTP, DNS, HTTP, HTTPS, FTP, SMTP, SSLv3, TLS 1.3, ARP, PPP, PPPoE, DHCP, Telnet
Suitable for indoor use Design - Yes
Summary - Teltonika RUT260. Device type: Cellular network router, Product colour: Black, Blue, Housing material: Aluminium, Plastic. Ethernet LAN interface type: Fast Ethernet, Ethernet LAN data rates: 10,100 Mbit/s, Networking standards: IEEE 802.11b, IEEE 802.11e, IEEE 802.11g, IEEE 802.11n, IEEE 802.11r, IEEE 802.3, IEEE 802.3af,.... Wi-Fi standards: 802.11b, 802.11g, Wi-Fi 4 (802.11n), WLAN data transfer rates supported: 300 Mbit/s. Data network: 3G, LTE, SIM card type: MiniSIM, Data transfer rate (LTE) (download): 300 Mbit/s. Security algorithms: AES-CCMP, TKIP, WEP, WPA2-Enterprise-PEAP, WPA2-PSK, WPA3-EAP, WPA3-SAE
System Requirements -
Technical details > Gross weight - 0.23 kg
Technical details > Net weight - 0.13 kg
Technical details > Producer - Teltonika
Technical details > Producer product family - LTE Cat 6 Router
Technical details > Producer product name - RUT260
Total storage capacity - 16 MB
Type - GSM 3G/4G
Unit Box Height - 0.072
Unit Box Length - 0.148
Unit Box Width - 0.175
Unit Calculated Volume - 0.001865 cubm
Unit Calculated Weight - 0.42 kg
Units per Pallet - 0
Units per Shipping Box - 1
USB port Ports & interfaces - No
Vendor Homepage - https://teltonika-networks.com/products/routers/rut260
vendpn - RUT260000000
WAN port - 1
Warranty - 24
Warranty - 24 month(s)
Warranty - 24 months
Web-based management Performance - Yes
Weight - 0.4
Weight - 0.400000
Weight - 130 g
Weight, g - 130
Weight Weight & dimensions - 130 g
Wi-Fi - Yes
Wi-Fi standards Wireless LAN features - 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Wi-Fi Wireless LAN features - Yes
Width - 175.000000
Width Weight & dimensions - 83 mm
Wireless LAN features > Wi-Fi band - 802.11n
Wireless LAN features > Wi-Fi standards - IEEE 802.11b/g/n
Wireless standard - 802.11 b
Wireless standard - 802.11 g
Wireless standard - 802.11 n
WLAN data transfer rates supported Wireless LAN features - 300 Mbit/s
