10GbE Ports - 2
Accessories included -
Antenna - Built-in
Antenna - Antenna type - Internal
Antenna gain - 5.5 dBi
Antenna Type - Built-in
ARTIKEL1 - BE19000 WI-FI 7 ACCESS POINT
ARTIKEL2 - OMADA CEILING MOUNT TRI-BAND
Brand - TP-Link
BrandPartCode - EAP783
Breite - 0
Category - Wireless Access Points
Category 1 - Netzwerk
Category 2 - Accesspoints
Category Code - WAP
Certificates - CE, FCC, RoHS, IC
Color - White
Colour - White
Data transmission speed - 22000 Mbps
Description - BE22000 Ceiling Mount Tri-Band Wi-Fi 7 Access Point. BE22000 Tri-Band Wi-Fi 7 (11520 Mbps on 6 GHz + 8640 Mbps on 5 GHz + 1148 Mbps on 2.4 GHz). A clear 6 GHz band brings cleaner and wider band resources. 2× 10G ports unlock the full potential of Wi-Fi 7. 320 MHz bandwidth enables many more simultaneous transmissions. Multi-Link Operation and Multi-RUs ensure the high performance of your network. Advanced Functions: Centralized management, mesh, and AI roaming.
Description - Czysty pasmo 6 GHz: zapewnia czystsze i szerokie spektrum zasiÄgu dla gĹĂłwnego Wi-Fi. 2Ă Port 10G: Odblokuj peĹen potencjaĹ Wi-Fi 7. Pasmo 320 MHz: Do 320 MHz szerokoĹÄ pasma umoĹźliwia wykorzystanie wiÄcej jednoczesnych transmisji przy maksymalnych prÄdkoĹciach. Niska konsekwencja i zakĹĂłcenia: Operacja Multi-Link oraz Multi-RU, ktĂłre powodujÄ wyciek z sieci.
Design - LED indicators - Yes
Design - Placement - Ceiling, Wall
Design - Product colour - White
Design - Reset button - Yes
Designation - CE+WEEE
dimension depth - 90 mm
dimension height - 350 mm
Dimensions - 280 x 280 x 46.5 mm
dimension weight - 2549 g
dimension width - 380 mm
ean - 4895252503517
EAN - 4895252503517
EANCode - 4895252503517
Environment requirements - Operating Temperature: 0°C-40°C; Storage Temperature: -40°C-70°C; Operating Humidity: 10%-90%, non-condensing; Storage Humidity: 5%-90%, non-condensing
Features - 2.4 GHz - Yes
Features - 5 GHz - Yes
Features - 6 GHz - Yes
Features - Airtime Fairness (ATF) - Yes
Features - Automatic channel scanning - Yes
Features - Automatic channel selection - Yes
Features - Band steering - Yes
Features - BeamForming - Yes
Features - Ethernet LAN data rates - 10000 Mbit/s
Features - Flow control support - Yes
Features - Frequency band - 2.4 - 6 GHz
Features - Maximum data transfer rate - 19000 Mbit/s
Features - Maximum data transfer rate (2.4 GHz) - 1376 Mbit/s
Features - Maximum data transfer rate (5 GHz) - 5760 Mbit/s
Features - Maximum data transfer rate (6 GHz) - 11520 Mbit/s
Features - MIMO - Yes
Features - MIMO type - Multi User MIMO
Features - Networking standards - IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11be, IEEE 802.11g, IEEE 802.11n
Features - Number of users - 760 user(s)
Features - Quality of Service (QoS) support - Yes
Features - Rate limiting - Yes
Features - VLAN support - Yes
Gewicht - 2.46
Gross Weight Kg - 2,44
GRUPPE1 - Network
GRUPPE2 - Wireless Lan Ap
GTIN - 0840030710070
GTIN - 840030710070
GTIN - 4895252503517
guarantee - 60
guarantee_type - normal
HERSTELLER - TP-LINK
Hoehe - 0
HSTNUMMER - EAP783
I/O ports - 2 x 10 Gbit/s
IEEE 802.11a/b/g Network standard - Yes
IEEE 802.11ac Network standard - Yes
IEEE 802.11ax Network standard - Yes
IEEE 802.11n Network standard - Yes
Laenge - 0
LongDesc - Multi-Link Operation (MLO)Enables devices to simultaneously send and receive data across different frequency bands and channels. Two 10G PoE++ PortsBoosts overall throughput and offers flexible deployment with two 10 Gbps PoE++ ports.Auto Channel Selection and Power AdjustmentBoost WiFi performance and minimize interference for your network.Intelligent Power ManagementOffers more reliable network operation for your business.Centralized Cloud ManagementManage the whole network locally or from the cloud.Omada Mesh TechnologyMore flexible and convenient wireless deployment.△PoE++ PowerSupports both 12V DC and 802.3bt PoE++ for flexible installations.
LongProductName - 2.4GHz (1376 Mbps), 5GHz (5760 Mbps), 6GHz (11520 Mbps), 802.11 a/b/g/n/ac/ax/be, 2× 10G Ethernet Ports, 280 x 280 x 46.5 mm
LongSummaryDescription - TP-Link Omada BE22000 Ceiling Mount Tri-Band Wi-Fi 7 Access Point. 2.4 GHz, 5 GHz, 6 GHz, Maximum data transfer rate: 19000 Mbit/s. Security algorithms: WPA, WPA2, WPA3. Ethernet LAN data rates: 10000 Mbit/s. Power over Ethernet (PoE). Product colour: White
Management, monitoring, configuration -
Manufacturer - TP-Link
Manufacturer Code - EAP783
Manufacturer Name - TP-LINK
Model name - EAP783
MPN - EAP783
name - TP-Link EAP783 Access P oint BE19000
Name - TP-LINK Omada EAP783 Wifi 7
Network architecture - GigabitEthernet
Network Device Type - Wireless Access Point
Operating frequency - 2,4 GHz
Operating frequency - 5 GHz
Operating frequency - 6 GHz
Operational conditions - Operating relative humidity (H-H) - 10 - 90%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Operational conditions - Storage relative humidity (H-H) - 5 - 90%
Operational conditions - Storage temperature (T-T) - -40 - 70 °C
Other features - MLO 4K-QAM MU-MIMO HE320 Mesh Automatic Channel Selection and Power Adjustment BBS Coloring OFDMA Load Balance Band Steering Beamforming Airtime Fairness Multiple SSIDS Wireless Schedule Reboot Schedule
Packaging content - Mounting kit - Yes
Packaging content - Quantity per pack - 1 pc(s)
Packaging content - Quick start guide - Yes
Packaging data - Package type - Box
Ports & interfaces - DC-in jack - Yes
Ports & interfaces - Ethernet LAN (RJ-45) ports - 2
Power - DC voltage range - 12 V
Power - Power over Ethernet (PoE) - Yes
Power supply - Zasilanie 802.3bt PoE++ lub 12V DC
producer - TP-LINK
ProductName - BE22000 Ceiling Mount Tri-Band Wi-Fi 7 Access Point
Product Net Weight - 2 kg
Security - PPSK Captive Portal Authentication WPA-Personal/Enterprise, WPA2-Personal/Enterprise,WPA3-Personal/Enterprise
Security - Access Control List (ACL) - Yes
Security - Security algorithms - WPA, WPA2, WPA3
Short description - TP-LINK WLAN BE19000 Access Point Tri-Band EAP783 Wi-Fi 7, PoE++, 1376MB/s at 2.4 GHz, MU-MIMO
ShortSummaryDescription - TP-Link Omada BE22000 Ceiling Mount Tri-Band Wi-Fi 7 Access Point, 2.4 GHz, 5 GHz, 6 GHz, 19000 Mbit/s, WPA, WPA2, WPA3, 10000 Mbit/s
Software -
Special functions -
Standards - 802.11a
Standards - 802.11ac
Standards - 802.11ax
Standards - 802.11b
Standards - 802.11be
Standards - 802.11g
Standards - 802.11n
Stck_Kart - 4
Stck_Pal - 0
Storno - N
System Requirements -
Title - TP-Link Omada BE22000 Ceiling Mount Tri-Band Wi-Fi 7 Access Point
Unit Box Height - 0.095
Unit Box Length - 0.355
Unit Box Width - 0.325
Unit Calculated Volume - 0.01096 cubm
Unit Calculated Weight - 2.5 kg
Units per Shipping Box - 1
URL - https://www.tp-link.com/sg/business-networking/omada-sdn-access-point/eap783/#overview
Vendor Homepage - www.tp-link.com/us/business-networking/omada-wifi-ceiling-mount/eap783/
vendpn - EAP783
Warranty - 60 months
WarrantyInfo -
Weight - 2.42
Weight & dimensions - Depth - 280 mm
Weight & dimensions - Height - 46.5 mm
Weight & dimensions - Width - 280 mm
Wireless Frequency Range - 6 GHz, 5 GHz, and 2.4 GHz
