Acer S1386WH

Accessories included -
AC input voltage Power - 120 - 230 V
Analog signal format system Video - NTSC, PAL, SECAM
Aperture range (F-F) Lens system - 2.8 - 2.8
Aspect ratio - 4:3
Aspect ratio - 16:9
Aspect ratio - 16:10
Audio - Yes
Audio (L/R) in Ports & interfaces - 1
Audio (L/R) out Ports & interfaces - 1
Brightness - 3600 ANSI Lumen
Built-in display Display - No
Built-in speaker(s) Multimedia - Yes
Card reader integrated Storage - No
Category - Root/Electronics/PC peripherals/Projectors and screens/Projectors
Category Code - OTP
Category_1 - Monitors and TV
Category_2 - Beamers
Code - MR.JQU11.001
Color - Black
Compatibility with computer standards -
Compatibility with video standards - Kompatybilność wideo: EDTV HDTV NTSC PAL SDTV SECAM
Composite video in Ports & interfaces - 1
Contrast ratio (typical) Projector - 20000:1
Dane techniczne: Czas pracy lampy - 5000 godz.
Dane techniczne: Grupa produktowa - Projektory Acer
Dane techniczne: Gwarancja - 2 lata w serwisie zewnętrznym
Dane techniczne: Głośnik - tak (1 x 16W)
Dane techniczne: Głośność pracy - 32 dB
Dane techniczne: Głębokość - 255 mm
Dane techniczne: Ilość wyświetlanych kolorów - 1070 mln
Dane techniczne: Jasność - 3600 ANSI lum.
Dane techniczne: Kontrast - 20000:1
Dane techniczne: Krótkoogniskowy - tak
Dane techniczne: Maksymalna obsługiwana rozdzielczość - 1920 x 1200 pikseli
Dane techniczne: Moc lampy - 220 W
Dane techniczne: Obiektyw - 2.8 F
Dane techniczne: Obsługa 3D - tak
Dane techniczne: Producent - Acer
Dane techniczne: Rozdzielczość natywna - 1024 x 768 pikseli
Dane techniczne: Szerokość - 313 mm
Dane techniczne: Technologia - DLP
Dane techniczne: Waga - 3.1 kg
Dane techniczne: Wysokość - 114 mm
Dane techniczne: Złącza zewnętrzne - 1 x audio in (Mini Jack)
Dane techniczne: Złącza zewnętrzne - 1 x audio out (Mini Jack)
Dane techniczne: Złącza zewnętrzne - 1 x Composite
Dane techniczne: Złącza zewnętrzne - 1 x D-sub 15-pin wejście
Dane techniczne: Złącza zewnętrzne - 1 x HDMI
Dane techniczne: Złącza zewnętrzne - 1 x RS232
Dane techniczne: Złącza zewnętrzne - 1 x USB (A)
Dane techniczne: Żywotność lampy w trybie ekonomicznym - 10000 godz.
DC-in jack Ports & interfaces - Yes
Description -
Designation - CE+WEEE
Digital zoom Lens system - 2x
dimension depth - 165 mm
dimension height - 335 mm
Dimensions -
dimension weight - 4200 g
dimension width - 395 mm
Display technology - DLP
EAN - 4713883722711
ean - 4713883722711
Eans - 4713883722711
EAN_code - 4713883722711
Fixed focal length Lens system - 7.51 mm
Focus Lens system - Manual
Frequency, horizontal max. - 100 kHz
Frequency, horizontal min. - 15 kHz
Frequency, vertical max. - 120 Hz
Frequency, vertical min. - 24 Hz
guarantee - 36
guarantee_type - external
Harmonized System (HS) code Logistics data - 85286200
HDMI ports quantity Ports & interfaces - 1
Horizontal synchronization (max) Projector - 100 kHz
Horizontal synchronization (min) Projector - 15 kHz
Housing material Design - Plastic
I/O connectors - 1 x 15-pin D-Sub
I/O connectors - 1 x Audio in
I/O connectors - 1 x Audio out
I/O connectors - 1 x HDMI
Keystone correction, vertical Projector - -40 - 40°
Lamp power Light source - 220 W
Lamps quantity Light source - 1 lamp(s)
Lamp type Light source - OSRAM
LED indicators Design - Yes
Lens - Maksymalna jasność obiektywu: F/2.8 Maksymalna ogniskowa: 7.51 mm
light life time - 5000 h
light life time (ECO mode) - 6000 h
Light source type Light source - Lamp
Mac compatibility Software - Yes
Mac operating systems supported Software - Yes
Manufacturer - Acer
Manufacturer_code - MR.JQU11.001
Maximum digital resolution Other features - 1920 x 1200 pixels
Maximum image diagonal - 300 ''
Maximum throw distance - 3.4 m
Minimum image diagonal - 914.4 mm
Minimum throw distance - 400 mm
Model - S1386WH
Name - Acer S1386WH Projector, DLP 3D, WXGA, 3600lm, 20000/1 | Acer
Name - Acer S1386WH projector WXGA 3600lm 3D white
Name - Acer S1386WH short throw
name - Projector S1386WH ST DLP WXGA/3600lm/20000/2,7kg/HDMI
Native aspect ratio Projector - 16:10
Noise level (economic mode) Features - 24 dB
Noise level Features - 32 dB
Number of built-in speakers Multimedia - 1
Number of colors - 1,07 mld
Number of colours Projector - 1.073 billion colours
Operating temperature (T-T) Operational conditions - 0 - 40 °C
Optical zoom Lens system - 1x
Other features -
Package features > Embeeded battery - No
Package features > Gross depth (mm) - 285.00 mm
Package features > Gross height (mm) - 143.00 mm
Package features > Gross width (mm) - 343.00 mm
Package features > Packing quantity - 1.00 pc(s)
Package features > Palette Qty - 62 pc(s)
Package features > Paper/Pasteboard - 900.00 g
Package features > Plastic (No PET) - 500.00 g
Package features > Tare weight (kg) - 1.40 kg
Package features > Volume (m3) - 0.01 m³
Package features > WEE classification - CL109:5:2017-04-01
Package features > WEEE tax - Yes
Placement Design - Ceiling
Power consumption - 270 W
Power consumption (PowerSave) Power - 210 W
Power consumption (typical) Power - 270 W
Power source Power - AC
Producent: Nazwa producenta / importera - Acer
Acer Italy S.r.l.
Viale delle Industrie 1/A
20044 Aresse

producer - Acer
Producer - Acer
ProducerCode - MR.JQU11.001
Product colour Design - White
Product type Design - Standard throw projector
Projection - Short throw
Projection distance Projector - 0.4 - 3.4 m
Projection modes Features - Ceiling, Front, Rear
Projection ratio (max) - 0,52:1
Projection technology Projector - DLP
Projector brightness Projector - 3600 ANSI lumens
Projector native resolution Projector - WXGA (1280x800)
Quick start guide Packaging content - Yes
Remote control included Packaging content - Yes
Remote control type Packaging content - IR
Resolution - 1280 x 800 (WXGA)
RMS rated power Multimedia - 16 W
Screen size compatibility Projector - 914.4 - 7620 mm (36 - 300")
Service life of light source (economic mode) Light source - 6000 h
Service life of light source Light source - 5000 h
ShortDescription - 1280 x 800 | DLP | 3600 lm | 2 x HDMI | 20 000:1| Full HD
Static contrast - 20 000:1
Summary - Acer S1386WH. Projector brightness: 3600 ANSI lumens, Projection technology: DLP, Projector native resolution: WXGA (1280x800). Light source type: Lamp, Service life of light source: 5000 h, Service life of light source (economic mode): 6000 h. Focus: Manual, Fixed focal length: 7.51 mm, Aperture range (F-F): 2.8 - 2.8. Analog signal format system: NTSC, PAL, SECAM, Supported graphics resolutions: 1280 x 800 (WXGA). Noise level: 32 dB, Noise level (economic mode): 24 dB, Projection modes: Ceiling, Front, Rear
Supported aspect ratios Projector - 4:3, 16:9
Supported graphics resolutions Video - 1280 x 800 (WXGA)
Technical details > Gross weight - 4.50 kg
Technical details > Net weight - 3.10 kg
Technical details > Producer - Acer
Throw ratio Lens system - 0.52:1
Unit Box Height - 0.34
Unit Box Length - 0.395
Unit Box Width - 0.17
Unit Calculated Volume - 0.02283 cubm
Unit Calculated Weight - 4.03 kg
Vendor Homepage - www.acer.com/ac/en/SI/content/professional-model/MR.JQU11.001
vendpn - MR.JQU11.001
Vertical synchronization (max) Projector - 0.12 kHz
Vertical synchronization (min) Projector - 0.024 kHz
VGA (D-Sub) ports quantity Ports & interfaces - 2
Warranty -
Warranty - 36
Warranty - 36 month(s)
Warranty - 36L months
Weight - 3.1 kg
Weight - 4,15
Weight Weight & dimensions - 3.1 kg
Windows operating systems supported Software - Yes
Wireless communication - No
Zoom - 2,0x
Zoom - Automatic (Digital)
