Audio Chipset - Realtek ALC897
Audio Integrated - yes
Audio interfeiss - 6 (3,5 mm miniatūrligzda)
Audio izvades režīms - 7.1 Channel Surround
Augstums (mm) - 245 milimetrs
BIOS - SAPPHIRE CORE BIOS
Bluetooth - Bluetooth 5.4
category - PC Components|Mainboards|AMD Mainboards|Socket AM5
Category_1 - Motherboards
Category_2 - Motherboards - AMD AM5
Chipset - AMD X870
Chipset manufacturer - AMD
Chipset type - AMD X870
code - 52122-02-40G
COM connector / port - No
Compliant Audio Standards - High Definition Audio
CPU Maximum Quantity Supports - 1
CPU socket - Socket AM5
CPU Socket Standard - Socket AM5
Data Link Protocol Supports - 5 Gbps
Description - PURE X870A WIFI 7 AMD AM5 CPU SUPPORT SAPPHIRE CORE BIOS 16+2+1 Phase CPU Power, 55A Per Phase, Robust VRM, M.2 and PCH Cooling Dual Channel, 8400 MHz Memory OC WIFI 7 Support PCI Express 5.0 x16 PCIe 5.0 M.2 Support Debug LED
Designation - CE+WEEE
Detailed data on disk/drive interfaces - PCI-E Expansion Slots 1x PCIe 5.0 x16 1x PCIe 4.0 x4 in 16x slot 1x PCIe 3.0 x1 in 1x slot Storage 1x PCIe 5.0 M.2 2x PCIe 4.0 M.2 4x SATA
dimensionalWeight - 2164
dimension depth - 90 mm
dimension height - 320 mm
Dimensions - 305 x 245 mm
dimension weight - 1760 g
dimension width - 395 mm
DisplayPort - 1
ean - 4895106296909
EAN kods - 4895106296909
EAN_code - 4895106296909
Expansion slots - 1 x PCIe 3.0 x 1
Expansion slots - 1 x PCIe 4.0 x 4
Expansion slots - 1 x PCIe 5.0 x 16
Expansion slots - 2 x M.2
Expansion slots - 1st M.2 highest PCI Express generation - 5.0
Expansion slots - 1st M.2 largest key size - 2280
Expansion slots - 2nd M.2 highest PCI Express generation - 4.0
Expansion slots - 2nd M.2 largest key size - 2280
Expansion slots - 3rd M.2 highest PCI Express generation - 4.0
Expansion slots - 3rd M.2 largest key size - 2280
Expansion slots - Number of M.2 (M) slots - 3
Expansion slots - PCI Express x4 (Gen 4.x) slots - 1
Expansion slots - PCI Express x16 (Gen 5.x) slots - 1
External connectors - 1 x Central Speaker / Subwoofer
External connectors - 1 x DisplayPort
External connectors - 1 x Flash BIOS Button
External connectors - 1 x HDMI
External connectors - 1 x Line In
External connectors - 1 x Line Out
External connectors - 1 x MIC
External connectors - 1 x Rear Speaker
External connectors - 1 x RJ-45
External connectors - 1 x Side Speaker
External connectors - 1 x USB 3.2 Gen 2 Type-A
External connectors - 1 x USB4 Type-C
External connectors - 2 x SMA
External connectors - 2 x USB 2.0
External connectors - 4 x USB 3.2 Gen 1 Type-A
Features - Audio chip - Realtek ALC897
Features - Audio output channels - 7.1 channels
Features - Motherboard chipset - AMD X870
Features - Motherboard chipset family - AMD
Features - Motherboard form factor - ATX
Features - Product colour - White, Silver
Features - Windows operating systems supported - Windows 11
FireWire (IEEE 1394) - No
Formas faktors - ATX
Form factor - micro ATX
Gabali iepakojumā - 5
Garantija Produkti atgriežami - Jā
Garantijas apstiprināšanas kritēriji - Sērijas numurs
Garantijas termiņš (mēnesis) - 36 mēnesis(-i)
Graphics - Parallel processing technology support - Not supported
guarantee - 36
guarantee_type - normal
HDMI - 1 (HDMI (A tips))
Iepakojuma augstums (mm) - 80 milimetrs
Iepakojuma garums (mm) - 354 milimetrs
Iepakojuma platums (mm) - 300 milimetrs
Iepakojuma svars Brutto (kg) - 1.2 kilograms
Iepakojuma svars Netto (kg) - 0.6 kilograms
Iepakojuma tips - Mazumtirdzniecība
Iepakojums kastē - 5
Ierīces atrašanās vieta - Integrēts
Integrated CPU - No
Integrēts - Storage Controller:PCI Express 5.0 x4 (1 x M.2 (Key M))Storage Controller:PCI Express 4.0 x4 (2 x M.2 (Key M))Storage Controller:SATA III-600 (4)
Internal I/O - 12V power connector - Yes
Internal I/O - ATX Power connector (24-pin) - Yes
Internal I/O - Audio connector - Yes
Internal I/O - CPU fan connector - Yes
Internal I/O - Front panel connector - Yes
Internal I/O - Number of chassis fan connectors - 3
Internal I/O - Number of CPU fan connectors - 1
Internal I/O - Number of RGB LED pin headers - 4
Internal I/O - Number of SATA III connectors - 4
Internal I/O - Number of water pump connectors - 1
Internal I/O - RGB LED pin header - Yes
Internal I/O - Serial port headers - 1
Internal I/O - USB 2.0 connectors - 2
Internal I/O - USB 3.2 Gen 1 (3.1 Gen 1) connectors - 1
Kastes svars Brutto (kg) - 12.5 kilograms
LAN - 1 (RJ-45)
LAN Chipset - Realtek RTL8126
LAN Integrated - yes
LPT connector / port - No
Manufacturer - Sapphire
Manufacturer_code - 52122-02-40G
Max. number of SATA devices - 4
Maximum Installable System Memory Storage Capacity - 256 gigabaits
Max memory size - 256 GB
Memory - Maximum internal memory - 256 GB
Memory - Maximum internal memory per slot - 64 GB
Memory - Memory channels - Dual-channel
Memory - Memory slots type - DIMM
Memory - Number of memory slots - 4
Memory - Supported memory clock speed (max) - 8400 MHz
Memory - Supported memory types - DDR5-SDRAM
Memory bus frequency - 8400 MHz
Memory Features - Two DDR Channels
Memory Form Factor - DIMM 288-pin
Memory Slot Total Quantity - 4
Memory Speed - 8400MHz
Memory Type - DDR5 SDRAM
Memory type - DDR5
Model - 52122-02-40G
name - Motherboard PURE X870A WIFI7 AM5 4DDR5 mATX
Name - Sapphire PURE X870A WIFI 7 (white)
name - Sapphire Pure X870A WiFi7 Motherboard, Socket AM5, AMD X870, ATX, DDR5
Network - Bluetooth - Yes
Network - Bluetooth version - 5.4
Network - Ethernet interface type - 5 Gigabit Ethernet
Network - Ethernet LAN - Yes
Network - LAN controller - Realtek RTL8126
Network - Top Wi-Fi standard - Wi-Fi 7 (802.11be)
Network - Wi-Fi - Yes
Network - Wi-Fi standards - 802.11 ac
Network - Wi-Fi standards - 802.11 ax
Network - Wi-Fi standards - 802.11a
Network - Wi-Fi standards - 802.11b
Network - Wi-Fi standards - 802.11g
Network - Wi-Fi standards - 802.11n
Network - Wi-Fi standards - IEEE 802.11be
Network interface - 1 x 10/100/1000/2500/5000 Mbit/s
Network interface - Bluetooth
Network interface - Realtek RTL8126 5 Gigabit Ethernet M.2 WiFi 7 Module, Support 802.11 a/b/g/n/ac/ax/be, 2.4 GHz / 5GHz / 6GHz band, Bluetooth 5.4 Support
Network interface - Wi-Fi 802.11a/b/g/n/ac/ax/be
Number of DDR5 slots - 4
Number of USB 3.0/USB 3.1 gen 1/USB 3.2 gen 1 ports - 6
Number of USB 3.1/USB 3.1 gen 2/USB 3.2 gen 2 ports - 2
Onboard connectors - 1 x USB 3.2 Gen 1 Type-A
Onboard connectors - 1 x USB 3.2 Gen 2 Type-C
Onboard connectors - 2 x USB 2.0/1.1 header
Packaging content - Antenna included - Yes
PCI Express 3.0 x1 - 1
PCI Express 4.0 x4 - 1
PCI Express 5.0 x16 - 1
Platums (mm) - 305 milimetrs
Plug-in-card - Wi-Fi Controller:1 x M.2 (Key E)
Processor - Compatible processor series - AMD Ryzen 7000 Series
Processor - Compatible processor series - AMD Ryzen 8000 Series
Processor - Compatible processor series - AMD Ryzen 9000 Series
Processor - Processor manufacturer - AMD
Processor - Processor socket - Socket AM5
Processor - Supported processor sockets - Socket AM5
Processor family - AMD Ryzen 3
Processor family - AMD Ryzen 5
Processor family - AMD Ryzen 7
Processor family - AMD Ryzen 9
producer - Sapphire Technology
producerCode - 52122-02-40G
ProductCard - https://content.it4profit.com/itshop/itemcard_cs.jsp?ITEM=250814134051752796&THEME=asbis&LANG=lv
ProductCategory - Komponenti
ProductCode - 52122-02-40G
ProductDescription - SAPPHIRE AMD X870E AM5 PURE Ryzen R9/R7, 4x DDR5 8400MHz, PCIE 5, 1x M.2 Gen5, 2x M.2 Gen4, LAN 5 Gbps, WIFI7, USB, ATX
productName - SAPPHIRE PURE X870A WIFI 7 Motherboard
productSize - Normal
ProductType - Main Board Desktop
Rear panel I/O ports - DisplayPorts quantity - 1
Rear panel I/O ports - Ethernet LAN (RJ-45) ports - 1
Rear panel I/O ports - HDMI ports quantity - 1
Rear panel I/O ports - Headphone outputs - 1
Rear panel I/O ports - Line-in - Yes
Rear panel I/O ports - Microphone in - Yes
Rear panel I/O ports - USB 2.0 ports quantity - 2
Rear panel I/O ports - USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity - 1
Rear panel I/O ports - USB connector type - USB Type-A
Rear panel I/O ports - USB connector type - USB Type-C
Rear panel I/O ports - WiFi-AP antenna jack - 2
sizeX - 395
sizeY - 87
sizeZ - 315
Sound card - Realtek ALC897 HD Audio, 7.1 Channe
Special functions - Debug LED DRAM: Yellow CPU: Red GPU: White Boot: Green
Storage controllers - Number of storage drives supported - 2
Storage controllers - Supported storage drive interfaces - PCI Express 4.0, PCI Express 5.0, SATA III
Storage controllers - Supported storage drive types - HDD & SSD
Supported operating systems - Windows 10
Supported operating systems - Windows 11
Supports Central Processor Unit - AMD Ryzen 7000 Series AMD Ryzen 8000 Series AMD Ryzen 9000 Series
USB 2.0 - 2 (USB 2.0 (A tipa))
USB 3.2 Gen 1 - 4 (USB 3.2 (type A))
USB 3.2 Gen 2 - 1 (USB 3.2 (type A))
USB 4.0 - 1 (USB 4.0 (type C))
USB ports at back panel - 8
USB ports on motherboard - 7
Vendor - SAPPHIRE
vendpn - 52122-02-40G
warrantyLength - 36
warrantyType - G
Weight - 2,74
weight - 2750
Weight & dimensions - Depth - 245 mm
Weight & dimensions - Width - 305 mm
Wi-Fi - IEEE 802.11aIEEE 802.11bIEEE 802.11gIEEE 802.11n Wi-Fi 4IEEE 802.11ac Wi-Fi 5IEEE 802.11ax Wi-Fi 6IEEE 802.11be Wi-Fi 7
Wi-Fi Antenna - 2
