ARTIKEL1 - LM551 55IN LFD IFP UHD
ARTIKEL2 - 500CD/QM OPS SLOT ANDROID SOC
Audio - Built-in speaker(s) - Yes
Audio - Number of built-in speakers - 2
Audio - RMS rated power - 20 W
Brand - Sharp
BrandPartCode - 60006142
Category - Signage Displays
Certificates - Certification - ISO 9241-307, Class 1
Computer system - Built-in processor - Yes
Computer system - Internal memory - 4 GB
Computer system - Internal storage capacity - 32 GB
Computer system - Operating system installed - Android 14
Computer system - Operating system version - 14
Computer system - Processor architecture - ARM Cortex-A53+Cortex-A73
Computer system - Processor cores - 8
Computer system - Processor family - ARM Cortex
Computer system - Processor manufacturer - ARM
Computer system - Processor model - Cortex-A53
Design - Bezel width (bottom) - 1.5 cm
Design - Bezel width (side) - 1.5 cm
Design - Bezel width (top) - 1.5 cm
Design - Orientation - Horizontal/Vertical
Design - Panel mounting interface - 400 x 400 mm
Design - Placement supported - Indoor
Design - Product colour - Black
Design - Product design - Interactive flat panel
Design - Screen shape - Flat
Design - VESA mounting - Yes
Display - Contrast ratio (typical) - 5000:1
Display - Display brightness - 500 cd/m²
Display - Display diagonal - 139.7 cm (55")
Display - Display diagonal (metric) - 138.8 cm
Display - Display number of colours - 1.07 billion colours
Display - Display resolution - 3840 x 2160 pixels
Display - Display technology - LED
Display - Haze rate - 25%
Display - HD type - 4K Ultra HD
Display - Horizontal scan range - 31.5 - 135 kHz
Display - LED backlight - Yes
Display - LED backlighting type - Direct-LED
Display - Multi-touch - Yes
Display - Native aspect ratio - 16:9
Display - Native refresh rate - 60 Hz
Display - Number of simultaneous touchpoints - 20
Display - Panel type - VA
Display - Response time - 8 ms
Display - Touchscreen - Yes
Display - Touchscreen technology - Infrared
Display - Vertical scan range - 24 - 70 Hz
Display - Viewing angle, horizontal - 178°
Display - Viewing angle, vertical - 178°
EANCode - 5028695127807
Features - Base material - Metal
Features - Suitable for indoor use - Yes
Features - Wall mountable - Yes
GRUPPE1 - Displays
GRUPPE2 - Led Large Format
GTIN - 5028695127807
HERSTELLER - SHARP
HSTNUMMER - 60006142
LongDesc - Multi-purpose for interactive engagementsFor best-in-class touch performance and value, the Sharp LM series commands feature-rich professional capabilities for small meeting spaces and interactive signage applications. An integrated System on Chip (SoC) with Android 14 CTS-compliant Operating System offers the most up to date features and security for seamless out-of-the-box collaboration.Boosting creativity in group collaboration, the Sharp LM series features intuitive Pen-on-Paper writing, a built-in whiteboard, annotation overlay mode and Windows Ink support. Using the on-board EShare app, content can be wirelessly shared from any personal device to the display without the need for apps or dongles. A single USB-C cable transmits data, video/audio output and power delivery between notebook and display for the simplest and seamless BYOD workflows.With its 4-sided uniform slim bezel design, the Sharp LM series supports installations in both landscape and portrait as well as tilted desk. Dedicated features including hide side bars, application lock and a built-in web browser make the Sharp LM series the perfect display for budget-driven interactive signage applications.
LongProductName - LCD 55", 4K UHD 3840 x 2160, 500 cd/m², 8 ms, 1265 x 736 x 73 mm, 33 kg
LongSummaryDescription - Sharp LM551. Product design: Interactive flat panel. Display diagonal: 139.7 cm (55"), Display technology: LED, Display resolution: 3840 x 2160 pixels, Display brightness: 500 cd/m², HD type: 4K Ultra HD, Touchscreen. Wi-Fi. Operating hours (hours/days): 18/7. Operating system installed: Android 14. Product colour: Black
Network - Ethernet LAN data rates - 10,100,1000 Mbit/s
Network - Wi-Fi - Yes
Network - Wi-Fi standards - 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
Operational conditions - Operating relative humidity (H-H) - 20 - 80%
Operational conditions - Operating temperature (T-T) - 5 - 35 °C
Operational conditions - Storage relative humidity (H-H) - 10 - 80%
Operational conditions - Storage temperature (T-T) - -20 - 60 °C
Other features - Bluetooth - Yes
Other features - Bluetooth version - 5.3
Packaging content - Batteries included - Yes
Packaging content - Cables included - AC, HDMI
Packaging content - Remote control included - Yes
Packaging content - Stand included - No
Packaging data - Package depth - 185 mm
Packaging data - Package height - 885 mm
Packaging data - Package volume - 43000 cm³
Packaging data - Package weight - 43 kg
Packaging data - Package width - 1410 mm
Performance - HDCP - Yes
Performance - HDCP version - 2.3
Performance - Operating hours (hours/days) - 18/7
Performance - Purpose - Universal
Ports & interfaces - Audio Return Channel (ARC) - Yes
Ports & interfaces - DVI port - No
Ports & interfaces - Ethernet LAN (RJ-45) ports - 1
Ports & interfaces - HDMI input ports quantity - 3
Ports & interfaces - HDMI output ports quantity - 1
Ports & interfaces - HDMI ports quantity - 4
Ports & interfaces - OPS module slot - Yes
Ports & interfaces - RS-232 interface - Yes
Ports & interfaces - USB 2.0 Type-B ports quantity - 1
Ports & interfaces - USB connector type - USB Type-A, USB Type-B, USB Type-C
Ports & interfaces - USB port - Yes
Ports & interfaces - USB ports quantity - 7
Power - AC input frequency - 50/60 Hz
Power - AC input voltage - 100 - 240 V
Power - Power consumption (standby) - 0.5 W
Power - Power consumption (typical) - 145 W
ProductName - LM551
ShortSummaryDescription - Sharp LM551, Interactive flat panel, 139.7 cm (55"), LED, 3840 x 2160 pixels, Wi-Fi, 18/7
Stck_Kart - 1
Stck_Pal - 0
Storno - N
Technical details - Compliance certificates - CE, Electromagnetic Compatibility (EMC), RoHS, UKCA
Technical details - Sustainability certificates - ENERGY STAR
Technical details - Warranty period - 3 year(s)
Title - Sharp LM551 Interactive flat panel 139.7 cm (55") LED Wi-Fi 500 cd/m² 4K Ultra HD Black Touchscreen Built-in processor Android 14 18/7
URL - https://www.sharpnecdisplays.eu/p/uk/en/products/details/technicaldata/t/large-format-displays/midrange-collaboration-displays/rp/lm551.xhtml
WarrantyInfo -
Weight & dimensions - Display depth - 73 mm
Weight & dimensions - Display height - 736 mm
Weight & dimensions - Display weight - 33 kg
Weight & dimensions - Display width - 1265 mm
