ACinputfrequency - 50/60 Hz
ACinputvoltage - 100 - 240 V
ARTIKEL1 - TE8612MIS-B4AG 86IN UHD
ARTIKEL2 - IR 40P TOUCH
Audio -
Audio - Built-in speaker(s) - Yes
Audio - Number of built-in speakers - 2
Audio - RMS rated power - 32 W
Audioformatssupported -
Batteriesincluded - Yes
Brand - iiyama
BrandPartCode - TE8612MIS-B4AG
Breite - 1.3
Builtinspeakers - Yes
Cablesincluded - AC, USB, HDMI
Category - Signage Displays
Certificates - Certification - CB, CE, TÜV-Bauart, EAC, ErP, WEEE, REACH
Computersystem - Yes
Computer system - Built-in processor - Yes
Computer system - Computer system - Yes
Computer system - Internal memory - 8 GB
Computer system - Internal storage capacity - 128 GB
Computer system - On-board graphics card model - ARM Mali-G52
Computer system - Operating system installed - Android
Computer system - Operating system version - 14
Computer system - Processor architecture - ARM Cortex-A53+Cortex-A72
Computer system - Processor family - ARM Cortex
Computer system - Processor manufacturer - ARM
Contrastratiodynamic - 4000:1
Contrastratiotypical - 1200:1
Design -
Design - Anti-glare screen - Yes
Design - Bezel colour - Black
Design - Bezel width (bottom) - 3 cm
Design - Bezel width (side) - 1.65 cm
Design - Bezel width (top) - 1.65 cm
Design - Mounting type - Wall
Design - Orientation - Horizontal
Design - Panel mounting interface - 800 x 600 mm
Design - Placement supported - Indoor
Design - Product colour - Black
Design - Product design - Kiosk design
Design - VESA mounting - Yes
Display -
Display - Active display area (W x H) - 1895 x 1066 mm
Display - Contrast ratio (dynamic) - 4000:1
Display - Contrast ratio (typical) - 1200:1
Display - Display brightness - 400 cd/m²
Display - Display diagonal - 2.17 m (85.6")
Display - Display diagonal (metric) - 217.4 cm
Display - Display number of colours - 1.07 billion colours
Display - Display resolution - 3840 x 2160 pixels
Display - Display technology - LCD
Display - Glass thickness - 3 mm
Display - HD type - 4K Ultra HD
Display - Horizontal scan range - 30 - 135 kHz
Display - LED backlight - Yes
Display - LED backlighting type - Direct-LED
Display - Multi-touch - Yes
Display - Native aspect ratio - 16:9
Display - Native refresh rate - 60 Hz
Display - Number of simultaneous touchpoints - 40
Display - Panel type - IPS
Display - Pixel pitch - 0.493 x 0.493 mm
Display - Response time - 6.5 ms
Display - Surface hardness - 7H
Display - Touchscreen - Yes
Display - Touchscreen technology - PureTouch-IR
Display - Viewing angle, horizontal - 178°
Display - Viewing angle, vertical - 178°
Displaybrightness - 400 cd/m²
Displaydepth - 98 mm
Displaydiagonal - 2.17 m (85.6")
Displayheight - 1160 mm
Displaynumberofcolours - 1.07 billion colours
DisplayPortsin - 1
DisplayPortsout -
DisplayPortsquantity - 1
Displayresolution - 3840 x 2160 pixels
Displaytechnology - LCD
Displayweight - 48.5 kg
Displaywidth - 1957 mm
DVIIportsquantity -
DVIport -
EANCode - 4948570125500
EnergyconsumptionSDRper1000hou - 181 kWh
EnergyefficiencyclassSDR - G
Energyefficiencyscale - A to G
EthernetLAN - Yes
EthernetLANRJ45ports - 1
EUEnergyLabel - https://www.tdbaltic.ee/leaflets/IIYAMA/TE8612MIS-B4AG_eu_energy_label.pdf
Gewicht - 75
GRUPPE1 - Displays
GRUPPE2 - Lcd Large Format
GTIN - 4948570125500
Hazerate -
HDMIinputportsquantity - 1
HDMIoutputportsquantity - 1
HDMIportsquantity - 3
HDMIversion - 2.0
HDtype - 4K Ultra HD
HERSTELLER - IIYAMA CONSIGNMENT
HighLights -
Hoehe - 0.22
HSTNUMMER - TE8612MIS-B4AG
Imageformatssupported -
Laenge - 2.1
LongDesc -
LongDesc - The TE8612MIS-B4AG is an exceptional 4K UHD interactive display designed by iiyama to enhance collaboration, communication, and engagement. With key features like Zero Airgap LCD DLED screen eliminating parallax, accurate PureTouch-IR, iiWare 13E with Android 14, WiFi and the iiyama DMS (Device management System), this display transforms the way you engage with content, making it an indispensable tool for modern workspaces and educational settings. Boasting a new 4K Interface with User Profiles for simple login and access to your very own bespoke application and Cloud Drives or harmonize with your existing estate and unleash the true power of Windows and Office applications. iiyama TE8612MIS-B4AG becomes a highly personalised & flexible device within a busy hybrid environment for multiple users. Share wirelessly more easily than ever before with iiyama Share and EShare app, bringing effortless ideation and efficient collaboration in your enterprise or school. This affordable display transforms the modern workplaces, educational institutions, dynamic meeting spaces and beyond. Elevate your interactive experience with the iiyama TE12 SERIES displays and embrace the future of visual communication.
LongProductName - 86" Interactive 4K UHD Touchscreen elevating interactive collaboration
LongSummaryDescription - iiyama TE8612MIS-B4AG. Product design: Kiosk design. Display diagonal: 2.17 m (85.6"), Display technology: LCD, Display resolution: 3840 x 2160 pixels, Display brightness: 400 cd/m², HD type: 4K Ultra HD, Touchscreen. Wi-Fi. Operating hours (hours/days): 24/7. Operating system installed: Android. Product colour: Black
ManufDatasheet - https://www.tdbaltic.ee/leaflets/IIYAMA/TE8612MIS-B4AG.pdf
Nativerefreshrate - 60 Hz
Network - Ethernet LAN - Yes
Network - Ethernet LAN data rates - 1000 Mbit/s
Network - Wi-Fi - Yes
Network - Wi-Fi standards - Wi-Fi 6 (802.11ax), Wi-Fi 5 (802.11ac), Wi-Fi 4 (802.11n), 802.11g, 802.11a, 802.11b
Numberofbuiltinspeakers - 2
Operatinghourshoursdays - 24/7
OperatingrelativehumidityHH -
OperatingtemperatureTT - 0 - 40 °C
Operationalconditions -
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Operational conditions - Storage temperature (T-T) - -20 - 60 °C
Orientation - Horizontal
Other features - Audio output - 3.5mm
Other features - Backlight type - Direct LED
Other features - Bluetooth - Yes
Other features - Bluetooth version - 5.0
Other features - Compatible operating systems - All iiyama monitors are Plug & Play and compatible with Windows and Linux. For details regarding the supported OS for the touch models, please refer to the driver instruction file available in the downloads section.
Other features - Headphone connectivity - 3.5 mm
Other features - Headphone outputs - 1
Other features - Housing material - Metal
Other features - Plug and Play - Yes
Other features - Power supply type - Internal
Other features - Quick start guide - Yes
Packagingcontent -
Packaging content - Batteries included - Yes
Packaging content - Cables included - AC, USB, HDMI
Packaging content - Number of stylus pens - 4
Packaging content - Remote control included - Yes
Packaging content - Stylus pen - Yes
Packaging data - Package depth - 225 mm
Packaging data - Package height - 1291 mm
Packaging data - Package weight - 64.5 kg
Packaging data - Package width - 2110 mm
Panellife -
Panelmountinginterface - 800 x 600 mm
Paneltype - IPS
Performance -
Performance - HDCP - Yes
Performance - HDCP version - 2.2
Performance - Mean time between failures (MTBF) - 50000 h
Performance - Number of OSD languages - 14
Performance - On Screen Display (OSD) - Yes
Performance - On Screen Display (OSD) languages - Czech, Danish, German, English, Spanish, Finnish, French, Italian, Norwegian, Dutch, Polish, Russian, Swedish
Performance - Operating hours (hours/days) - 24/7
Performance - Purpose - Universal
Pixelpitch - 0.493 x 0.493 mm
Placementsupported - Indoor
Ports & interfaces - Audio Return Channel (ARC) - Yes
Ports & interfaces - Card reader integrated - Yes
Ports & interfaces - Compatible memory cards - MicroSD (TransFlash)
Ports & interfaces - DisplayPorts in - 1
Ports & interfaces - DisplayPorts quantity - 1
Ports & interfaces - DisplayPort version - 1.2
Ports & interfaces - Ethernet LAN (RJ-45) ports - 1
Ports & interfaces - HDMI input ports quantity - 1
Ports & interfaces - HDMI output ports quantity - 1
Ports & interfaces - HDMI ports quantity - 3
Ports & interfaces - HDMI version - 2.0
Ports & interfaces - OPS module slot - Yes
Ports & interfaces - PC Audio in - Yes
Ports & interfaces - Remote (IR) input - 1
Ports & interfaces - RS-232C - Yes
Ports & interfaces - USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity - 3
Ports & interfaces - USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity - 2
Ports & interfaces - USB connector type - USB Type-A, USB Type-C
Ports & interfaces - USB port - Yes
Ports & interfaces - USB ports quantity - 5
Ports & interfaces - USB Power Delivery (USB PD) - Yes
Ports & interfaces - USB Power Delivery up to - 65 W
Ports & interfaces - USB version - 3.2 Gen 1 (3.1 Gen 1)
Ports & interfaces - VGA (D-Sub) input ports - 1
Portsinterfaces -
Power -
Power - AC input frequency - 50/60 Hz
Power - AC input voltage - 100 - 240 V
Power - Energy consumption (SDR) per 1000 hours - 181 kWh
Power - Energy efficiency class (HDR) - Not available
Power - Energy efficiency class (SDR) - G
Power - Energy efficiency scale - A to G
Power - Power consumption (off) - 0.3 W
Power - Power consumption (standby) - 0.4 W
Power - Power consumption (typical) - 181 W
Powerconsumptionstandby - 0.4 W
Powerconsumptiontypical - 181 W
ProdDesc - iiyama 86" iiWare13E , Android 14, 8/128GB, 40-Points PureTouch IR with Zero Gap - Air bonding, 3840x2160, UHD IPS panel
Productcolour - Black
Productcondition - Original
Productdesign - Kiosk design
ProductHighLights -
- Indoor Kiosk design Black
- 2.17 m (85.6") 3840 x 2160 pixels LCD 400 cd/m²
- Touchscreen Direct-LED 60 Hz 6.5 ms
- Ethernet LAN Wi-Fi
- Built-in speaker(s) 32 W
ProductName - TE8612MIS-B4AG
ProductPicture - https://www.tdbaltic.ee/images/products/IIYAMA/TE8612MIS-B4AG_1.jpg
ProductPicture1 - https://www.tdbaltic.ee/images/products/IIYAMA/TE8612MIS-B4AG_2.jpg
ProductPicture2 - https://www.tdbaltic.ee/images/products/IIYAMA/TE8612MIS-B4AG_3.jpg
ProductPicture3 - https://www.tdbaltic.ee/images/products/IIYAMA/TE8612MIS-B4AG_4.jpg
ProductPicture4 - https://www.tdbaltic.ee/images/products/IIYAMA/TE8612MIS-B4AG_5.jpg
ProductPicture5 - https://www.tdbaltic.ee/images/products/IIYAMA/TE8612MIS-B4AG_6.jpg
Purpose - Universal
Remotecontrolincluded - Yes
RemoteIRinput - 1
RemoteIRoutput -
Responsetime - 6.5 ms
RMSratedpower - 32 W
RS232C - Yes
ShortSummaryDescription - iiyama TE8612MIS-B4AG, Kiosk design, 2.17 m (85.6"), LCD, 3840 x 2160 pixels, Wi-Fi, 24/7
Stck_Kart - 1
Stck_Pal - 0
StoragerelativehumidityHH -
StoragetemperatureTT - -20 - 60 °C
Storno - Y
Technical details - Audio in (mini jack) - Yes
Technical details - Compliance certificates - CB, CE, EAC, REACH, RoHS, TÜV mark, WEEE
Technical details - OPS slot - 1
Technical details - Playback media - Y
Technical details - Sustainability certificates - ErP
Technical details - User controls - general settings (input, volume, backlight), audio settings (volume, bass, treble, balance, sound mode, mute), screen settings (aspect ratio, pixel shift), display settings (brightness, contrast, hue, sharpness, display mode, colour temp.), adjust settings (H-position, V-position, clock, phase, auto), settings (wireless & networks, personal, input & output, application, system)
Technical details - Warranty period - 5 year(s)
Title - iiyama TE8612MIS-B4AG Signage Display Kiosk design 2.17 m (85.6") LCD Wi-Fi 400 cd/m² 4K Ultra HD Black Touchscreen Built-in processor Android 24/7
URL - https://iiyama.com/
USBport - Yes
USBportsquantity - 5
USBversion - 3.2 Gen 1 (3.1 Gen 1)
VESAmounting - Yes
Videoformatssupported -
Viewinganglehorizontal - 178°
Viewinganglevertical - 178°
Warranty - 36 months
Warrantyandmisc -
WarrantyInfo -
Weight & dimensions - Depth - 98 mm
Weight & dimensions - Display depth - 98 mm
Weight & dimensions - Display height - 1160 mm
Weight & dimensions - Display weight - 48.5 kg
Weight & dimensions - Display width - 1957 mm
Weight & dimensions - Height - 1160 mm
Weight & dimensions - Weight - 48.5 kg
Weight & dimensions - Width - 1957 mm
Weightdimensions -
