TP-LINK LS105GP 5-Port Gigabit Desktop Switch with  4-Port PoE+

10/100/1000/2500 Mbps ports - None
10G support Network - No
Accessories included -
AC input frequency Power - 50 Hz
AC input voltage Power - 220 V
Application - Home and small office
Auto-negotiation Network - Yes
Auto MDI/MDI-X Network - Yes
Basic switching RJ-45 Ethernet ports quantity Ports & interfaces - 5
Basic switching RJ-45 Ethernet ports type Ports & interfaces - Gigabit Ethernet (10/100/1000)
Brand - TP-Link
BrandPartCode - LS105GP
Cable types supported Network - Cat3, Cat5e, Cat4, Cat5
Category - Network Switches
Category Code - SWI
Certificates - FCC, CE, RoHS
Certificates - Certification - CE, FCC, RoHS
Certification Certificates - CE, FCC, RoHS
Chassis type - Desktop
CnCode - 85176200
Code - LS105GP
Console port - No
Data transmission - Forwarding rate - 7.44 Mpps
Data transmission - Jumbo frames - 16000
Data transmission - MAC address table - 2000 entries
Data transmission - Store-and-forward - Yes
Data transmission - Switching capacity - 10 Gbit/s
DC input voltage Power - 53.5 V
Depth Weight & dimensions - 98 mm
Description - Overview
The TP-Link LiteWave Series PoE Switches require no configuration and provide PoE (Power over Ethernet) ports. They can automatically detect and supply power with all IEEE 802.3af/at compliant Powered Devices (PDs). In this situation, the electrical power is transmitted along with data in one single cable allowing you to expand your network to where there are no power lines or outlets, where you wish to fix devices such as APs, IP Cameras or IP Phones, etc.Full Gigabit Ports: Five gigabit augo-negotiation ports provide up to 10 Gbps switching capacity65 W PoE Budget: Four gigabit 802.3af/at-compliant PoE+ ports easily connect and power fixed devices like IP cameras, access points, and IP phones via a single cable. Up to 30 W PoE output is supported by each PoE port.*Up to 250 m PoE Transmission: With Extend Mode, PoE transmission distance reaches up to 250m, perfect for surveillance camera deployment in large areas.**PoE Auto Recovery: Automatically reboots your dropped or unresponsive PoE-powered devicesPlug and Play: Simply plug and play for instant connectivity with no configuration requiredSilent Operation: Fanless design reduces power consumption and ensures silent operation, ideal for noise-sensitive homes or businessesReliable Hardware Design: Durable metal casing and desktop/wall-mounting design are well-suited for different environments
Description - Porty Gigabit: Pięć gigabitowych portów zapewnia przepustowość do 10 Gbps. Budżet PoE 65 W: Cztery gigabitowe porty PoE+ zgodne z 802.3af/at łatwo łączą i zasilają urządzenia stacjonarne, takie jak kamery IP, punkty dostępu i telefony IP za pomocą pojedynczego kabla. Każdy port PoE obsługuje moc do 30 W. Transmisja PoE do 250 m: W trybie Extend odległość transmisji PoE osiąga do 250 m, co jest idealne do rozmieszczania kamer monitoringu na dużych obszarach. Plug and Play: Wystarczy podłączyć i używać dla natychmiastowej łączności bez konieczności konfiguracji. Cicha praca: Konstrukcja bez wentylatora zmniejsza zużycie energii i zapewnia cichą pracę, co jest idealne dla domów lub firm wrażliwych na hałas. Niezawodna konstrukcja sprzętu: Trwała metalowa obudowa i konstrukcja do montażu na biurku/ścianie są dobrze dostosowane do różnych środowisk.
Design - LED indicators - Yes
Design - Product colour - Black
Design > Form factor - Desktop
Designation - CE+WEEE
dimensionalWeight - 624
dimension depth - 120 mm
dimension height - 130 mm
Dimensions - 99.8 × 98 × 25 mm
dimension weight - 681 g
dimension width - 195 mm
EAN - 4895252504545
ean - 4895252504545
Environment requirements - Temperatura pracy: 0 - 40 stopni Celsjusza Temperatura przechowywania: -40 - 70 stopni Celsjusza Wilgotność robocza: 1090% RH, bez kondensacji Wilgotność przechowywania: 590% RH, bez kondensacji
Fan - No
Flow control support Network - Yes
Forwarding mode - Store-and-forward
Forwarding rate - 7.44 Mpps
Forwarding rate Data transmission - 7.44 Mpps
GTIN - 4895252504545
GTIN - 4895252504552
guarantee - 60
guarantee_type - normal
Heat dissipation Operational conditions - 253.16 BTU/h
Height Weight & dimensions - 25 mm
IGMP snooping Security - Yes
Jumbo frames Data transmission - 16000
Jumbo frame size - 16 KB
L2 features -
L3 features -
LED indicators Design - Yes
Link - https://www.tp-link.com/za/business-networking/soho-switch-unmanaged/ls105gp/
LongDesc - OverviewThe TP-Link LiteWave Series PoE Switches require no configuration and provide PoE (Power over Ethernet) ports. They can automatically detect and supply power with all IEEE 802.3af/at compliant Powered Devices (PDs). In this situation, the electrical power is transmitted along with data in one single cable allowing you to expand your network to where there are no power lines or outlets, where you wish to fix devices such as APs, IP Cameras or IP Phones, etc.
LongProductName - 5× 10/100/1000 Mbps RJ45, PoE+ 65W, 10 Gbps, 7.44 Mpps, 2K MAC, 16 KB Jumbo, 99.8x98x25 mm
LongSummaryDescription - TP-Link LiteWave 5-Port Gigabit Desktop Switch with 4-Port PoE+. Switch type: Unmanaged. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 5. MAC address table: 2000 entries, Switching capacity: 10 Gbit/s. Networking standards: IEEE 802.1p, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x. DC input voltage: 53.5 V. Power over Ethernet (PoE)
MAC address auto-aging supported Network - Yes
MAC address auto-learning supported Network - Yes
MAC address table Data transmission - 2000 entries
MAC address table size - 2000
Management, monitoring, configuration -
Management features - Quality of Service (QoS) support - Yes
Management features - Switch type - Unmanaged
Management features > Switch type - Unmanaged
Model - TP-LINK LS105GP
Model name - LS105GP
name - Switch LS105GP 5xGE PoE+
Name - TP-LINK | 5-Port Gigabit Desktop Switch with 4-Port PoE+ | LS105GP | Unmanaged | Desktop
Network - 10G support - No
Network - Auto-negotiation - Yes
Network - Auto MDI/MDI-X - Yes
Network - Cable types supported - Cat3
Network - Cable types supported - Cat3, Cat5e, Cat4, Cat5
Network - Cable types supported - Cat4
Network - Cable types supported - Cat5
Network - Cable types supported - Cat5e
Network - Flow control support - Yes
Network - MAC address auto-aging supported - Yes
Network - MAC address auto-learning supported - Yes
Network - Networking standards - IEEE 802.1p
Network - Networking standards - IEEE 802.1p, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x
Network - Networking standards - IEEE 802.3ab
Network - Networking standards - IEEE 802.3af
Network - Networking standards - IEEE 802.3at
Network - Networking standards - IEEE 802.3i
Network - Networking standards - IEEE 802.3u
Network - Networking standards - IEEE 802.3x
Network architecture - GigabitEthernet
Networking standards Network - IEEE 802.1p, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x
Number of 10/100 Mbps ports - None
Number of 10/100/1000 Mbps ports - 5
Number of 10Gb ports - None
Number of COMBO ports - None
Number of PoE+ ports - 4
Number of PoE ports (PoE & PoE+) - None
Number of QSFP+ ports - None
Number of SFP+ ports - None
Number of SFP56 ports - None
Number of SFP ports - None
Operating relative humidity (H-H) Operational conditions - 10 - 90%
Operating temperature (T-T) Operational conditions - 0 - 40 °C
Operational conditions - Heat dissipation - 253.16 BTU/h
Operational conditions - Operating relative humidity (H-H) - 10 - 90%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Operational conditions - Storage relative humidity (H-H) - 5 - 90%
Operational conditions - Storage temperature (T-T) - -40 - 70 °C
Other features -
Other functions -
Package features > Embeeded battery - No
Package features > Gross depth (mm) - 196.00 mm
Package features > Gross height (mm) - 131.00 mm
Package features > Gross width (mm) - 121.00 mm
Package features > Packing quantity - 1.00 pc(s)
Package features > Palette Qty - 556 pc(s)
Package features > Paper/Pasteboard - 190.00 g
Package features > Plastic (No PET) - 10.00 g
Package features > Tare weight (kg) - 0.20 kg
Package features > Volume (m3) - 0.00 m³
Package features > WEE classification - CL109:6:2017-04-01
Package features > WEEE tax - Yes
Package type Packaging data - Box
Packaging content - User guide - Yes
Packaging data - Package type - Box
Ports & interfaces - Basic switching RJ-45 Ethernet ports quantity - 5
Ports & interfaces - Basic switching RJ-45 Ethernet ports type - Gigabit Ethernet (10/100/1000)
Ports & interfaces > Predominant port type - 10/100/1000 Mbps (RJ-45)
Power - AC input frequency - 50 Hz
Power - AC input voltage - 220 V
Power - DC input voltage - 53.5 V
Power - Power consumption (max) - 74.46 W
Power - Power source - DC/PoE
Power - Power supply included - Yes
Power consumption - 74.46 W
Power consumption (max) Power - 74.46 W
Power over Ethernet (PoE) - Power over Ethernet (PoE) - Yes
Power over Ethernet (PoE) - Power over Ethernet (PoE) ports quantity - 4
Power over Ethernet (PoE) - Power over Ethernet (PoE) power per port - 30 W
Power over Ethernet (PoE) - Total Power over Ethernet (PoE) budget - 65 W
Power over Ethernet (PoE) > Power over Ethernet (PoE) - Yes
Power over Ethernet (PoE) ports quantity Power over Ethernet (PoE) - 4
Power over Ethernet (PoE) Power over Ethernet (PoE) - Yes
Power over Ethernet (PoE) power per port Power over Ethernet (PoE) - 30 W
Power source Power - DC/PoE
Power supply - Zewnętrzny zasilacz (wyjście: 53,5 VDC / 1,31 A)
Power supply - External
Power supply included Power - Yes
producer - TP-LINK
producerCode - LS105GP
Product colour Design - Black
ProductName - 5-Port Gigabit Desktop Switch with 4-Port PoE+
productName - TP-Link LiteWave 5-Port Gigabit Desktop Switch with 4-Port PoE+
productSize - Normal
QoS -
Quality of Service (QoS) support Management features - Yes
Safety warning - Warnings - Do not open the case or try to repair it yourself.
Safety warning - Warnings - Ensure the unit is adequately ventilated during operation.
Safety warning - Warnings - The product is not suitable for disposal in the regular waste bin. Take your used electronic equipment to a recycling centre in accordance with local regulations.
Security -
Security - IGMP snooping - Yes
ShortSummaryDescription - TP-Link LiteWave 5-Port Gigabit Desktop Switch with 4-Port PoE+, Unmanaged, Gigabit Ethernet (10/100/1000), Power over Ethernet (PoE)
sizeX - 200
sizeY - 130
sizeZ - 120
Stackability - No
Storage relative humidity (H-H) Operational conditions - 5 - 90%
Storage temperature (T-T) Operational conditions - -40 - 70 °C
Store-and-forward Data transmission - Yes
Summary - TP-Link LiteWave 5-Port Gigabit Desktop Switch with 4-Port PoE+. Switch type: Unmanaged. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 5. MAC address table: 2000 entries, Switching capacity: 10 Gbit/s. Networking standards: IEEE 802.1p, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x. DC input voltage: 53.5 V. Power over Ethernet (PoE)
Supported protocols and standards -
Support for Jumbo frames - Yes
Switch class - Unmanaged
Switching capacity Data transmission - 10 Gbit/s
Switch type Management features - Unmanaged
Technical details > Gross weight - 0.94 kg
Technical details > Net weight - 0.74 kg
Technical details > Producer - TP-LINK
Technical details > Producer product family - 5-Port Gigabit Desktop Switch with 4-Port PoE+
Technical details > Producer product name - LS105GP
Throughput - 10 Gb/s
Title - TP-Link LiteWave 5-Port Gigabit Desktop Switch with 4-Port PoE+
Total Power over Ethernet (PoE) budget Power over Ethernet (PoE) - 65 W
Unit Box Height - 0.122
Unit Box Length - 0.197
Unit Box Width - 0.13
Unit Calculated Volume - 0.003124 cubm
Unit Calculated Weight - 0.68 kg
Units per Shipping Box - 1
URL - https://www.tp-link.com/uk/business-networking/soho-switch-poe/ls105gp/#specifications
User guide Packaging content - Yes
Vendor Homepage - https://www.tp-link.com/uk/business-networking/soho-switch-poe/ls105gp/#specifications
vendpn - LS105GP
VLAN -
Warranty - 60
Warranty - 60 month(s)
Warranty - 60 months
WarrantyInfo -
warrantyLength - 60
warrantyType - G
weight - 790
Weight & dimensions - Depth - 98 mm
Weight & dimensions - Height - 25 mm
Weight & dimensions - Width - 99.8 mm
Width Weight & dimensions - 99.8 mm
