15pin D-sub Input/Output connectors - 1
Alarm In Input/Output connectors - 4
Alarm Out Input/Output connectors - 2
Audio-In Input/Output connectors - 1
Audio-Out Input/Output connectors - 1
Brand - Dahua Technology
BrandPartCode - DHI-NVR5216-16P-EI
Category - Network Video Recorders (NVR)
Category Code - NVR
CPU - Industrial-grade processor
Description - 16 IP channel max, up to 32MP resolution Max 384 Mbps incoming Bandwidth VGA/HDMI up to 4K output, 16-channel 4 MP@30 fps 2 SATA interface up to 16TB, Gigabit LAN PoE Port: 16 ports, 10/100 Mbps, IEEE 802.3 af/at, 1-8 ports support ePoE; 130W max total No front panel controls, 4/2 alarm I/O, 1/1 Audio I/O, RS232, RS485, 2 USB 1U 19” chassis, mouse included AI by recorder: 2-channel face detection and recognition, 4-channel perimeter protection, and 8-channel SMD Plus AI by camera: Face detection and recognition, perimeter protection, SMD Plus, metadata, ANPR, and people counting. Other brands IP cameras supported. ONVIF 21.12(Profile T; Profile S; Profile G); CGI; SDK Free IP monitoring software available
Desktop/pedestal Mounting Type - Yes
Dimensions - 375.0 mm × 329.3 mm x 53.0mm
GTIN - 6923172589828
Hard drive - Number of HDDs installed - 2
HDMI Input/Output connectors - 1
LongDesc -
LongProductName - 16 channels, 100–240 VAC, 47-63 Hz, 2.66 kg, Black
LongSummaryDescription - Dahua Technology DHI-NVR5216-16P-EI. Video input channels: 16 channels, Maximum resolution: 3840 x 2160 pixels, Audio formats supported: G.711u, PCM. Supported network protocols: HTTP; HTTPS; TCP/IP; IPv4; UDP; NTP; DHCP; DNS; SMTP; UPnP; DDNS; Alarm Server; IP Search.... AC input voltage: 100 - 240 V, AC input frequency: 47 - 63 Hz. Width: 375 mm, Depth: 329.3 mm, Height: 53 mm
Model - NVR5216-16P-EI
Number of Channels - 16
Number of drives/bays - 2
Operational conditions - Operating relative humidity (H-H) - 10 - 39%
Operational conditions - Operating temperature (T-T) - -10 - 55 °C
Operational conditions - Storage temperature (T-T) - -20 - 60 °C
Performance - Alarm input channels - 4
Performance - Alarm output channels - 2
Performance - Audio formats supported - G.711u, PCM
Performance - Face detection - Yes
Performance - Image formats supported - MJPEG
Performance - Maximum resolution - 3840 x 2160 pixels
Performance - Video formats supported - H.264, H.264+, H.265, H.265+
Performance - Video input channels - 16 channels
PoE ports - 16
Ports & interfaces - Ethernet LAN (RJ-45) ports - 1
Ports & interfaces - HDMI ports quantity - 1
Ports & interfaces - Power over Ethernet (PoE) - Yes
Ports & interfaces - Power over Ethernet (PoE) ports quantity - 16
Ports & interfaces - RS-232 interface - Yes
Ports & interfaces - RS-485 ports - 1
Ports & interfaces - Supported network protocols - HTTP; HTTPS; TCP/IP; IPv4; UDP; NTP; DHCP; DNS; SMTP; UPnP; DDNS; Alarm Server; IP Search (Supports Dahua IP camera, DVR, NVS, etc.); Multicast; P2P; Auto Registration; iSCSI
Ports & interfaces - USB 2.0 ports quantity - 1
Ports & interfaces - USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity - 1
Ports & interfaces - VGA (D-Sub) output ports - 1
Power - AC input frequency - 47 - 63 Hz
Power - AC input voltage - 100 - 240 V
Power supply requirements - 100–240 VAC, 47-63 Hz
ProductName - DHI-NVR5216-16P-EI
Product Net Weight - 2.66 kg
Rack Mounting Type - Yes
RJ45 Input/Output connectors - 1
RS-485 Input/Output connectors - 1
RS232 Input/Output connectors - 1
ShortSummaryDescription - Dahua Technology DHI-NVR5216-16P-EI, 16 channels, 3840 x 2160 pixels, G.711u, PCM, H.264, H.264+, H.265, H.265+, MJPEG, HTTP; HTTPS; TCP/IP; IPv4; UDP; NTP; DHCP; DNS; SMTP; UPnP; DDNS; Alarm Server; IP Search...
Technical details - Compliance certificates - Federal Communications Commission (FCC)
Title - Dahua Technology DHI-NVR5216-16P-EI network video recorder
Unit Box Height - 0.42
Unit Box Length - 0.45
Unit Box Width - 0.15
Unit Calculated Volume - 0.02835 cubm
Unit Calculated Weight - 3.95 kg
Units per Shipping Box - 1
URL - https://www.dahuasecurity.com/la/products/All-Products/Network-Recorders/WizSense-Series/NVR-5-EI-Series/2HDD/NVR5216-16P-EI
USB 2.0 Input/Output connectors - 1
USB 3.0 Input/Output connectors - 1
Vendor Homepage - www.dahuasecurity.com/products/All-Products/Network-Recorders/WizSense-Series/NVR-5-EI-Series/2HDD/NVR5216-16P-EI
Warranty - 36 months
WarrantyInfo -
Weight & dimensions - Depth - 329.3 mm
Weight & dimensions - Height - 53 mm
Weight & dimensions - Package depth - 147 mm
Weight & dimensions - Package height - 425 mm
Weight & dimensions - Package weight - 3.82 kg
Weight & dimensions - Package width - 451 mm
Weight & dimensions - Weight - 2.66 kg
Weight & dimensions - Width - 375 mm
