TP-LINK Camera InSight S445(2.8mm)

Accessories included - Quick Installation Guide Cable Sealing Accessories Mounting Accessories
Audio - Audio formats supported - G.711 A-law
Audio - Audio input channels - 1.0 channels
Audio - Audio output channels - 1.0 channels
Audio - Audio system - 2-way
Audio - Bit rate range - 0 - 64 Kbit/s
Audio - Built-in microphone - Yes
Audio - Built-in speaker(s) - Yes
Audio - Number of microphones - 1
Audio - Sample rate - 8 kHz
Brand - TP-Link
BrandPartCode - INSIGHT S445(2.8MM)
Camera - Camera shutter speed - 1/3 to 1/10000
Camera - Lens viewing angle, diagonal - 118°
Camera - Lens viewing angle, horizontal - 100°
Camera - Lens viewing angle, vertical - 54°
Camera - Minimum illumination - 0 lx
Camera - Tilt angle range - 0 - 90°
Category - Security Cameras
Certificates - CE, NTRA, VCCI, KC, BSMI, FCC, IC
Color - White
Connectors - RJ-45
Description - InSight S445
4MP Full-Color VIGI Turret Network Camera 4MP Super High Definition and 24/7 Full Color Human and Vehicle Feature Analysis Human and Vehicle Classification Smart Detection Intelligent Video Enhancement Active Defense and Two-Way Audio IP67 Sealing H.265+ Compression Technology
Design - Form factor - Turret
Design - Housing material - Metal
Design - International Protection (IP) code - IP67
Design - Mounting type - Ceiling
Design - Product colour - White
Design - Protection features - Waterproof
Design - Weatherproof - Yes
Designation - CE+WEEE
dimension depth - 160 mm
dimension height - 120 mm
Dimensions - 111 × 111 × 83.7 mm
dimension weight - 745 g
dimension width - 160 mm
ean - 8885020628203
Environment requirements - Operating temperature: -30°C to 60°C Storage temperature: -40°C to 60°C Humidity: 95% or less (non-condensing) Storage humidity: 95% or less (non-condensing)
Frames per second - 0
GTIN - 0810142823982
GTIN - 810142823982
GTIN - 1210002606325
GTIN - 8885020628203
guarantee - 36
guarantee_type - normal
Image sensor - Optical sensor size - 25.4 / 2.7 mm (1 / 2.7")
Image sensor - Progressive scan - Yes
Image sensor - Sensor type - CMOS
Lens - Focal length: 2.8 mm Aperture: F1.6
Lens system - Detect distance - 64 m
Lens system - Fixed focal length - 2.8 mm
Lens system - Fixed focus - Yes
Lens system - Identify distance - 6 m
Lens system - Maximum aperture number - 1.6
Lens system - Observe distance - 27 m
Lens system - Recognize distance - 13 m
LongDesc - People & Vehicle AnalyticsSearch and filter to people or vehicle of interest based on many different attributes, making post-event search faster and easier.Human & Vehicle ClassificationDistinguish humans and vehicles from other objects and receive more accurate event notifications.True WDR: By analyzing and blending different exposures, True WDR ensures both bright and dark areas remain properly exposed, delivering a well-balanced and natural-looking image even in environments with high-contrast lighting.△Smart IR: Smart IR dynamically adjusts infrared lighting to prevent overexposure and glare, improve visibility at different distances, and ensure clearer footage.3D DNR: 3D DNR is a noise reduction technology that analyzes image data across frames to selectively reduce noise while preserving important details.White Balance: White Balance ensures that white appears neutral in an image, regardless of the lighting conditions.Efficient H.265+ Compression TechnologyH.265+ reduces the required bandwidth and storage space for videos while maintaining excellent image quality. It saves 57.5% and 15% more storage space compared to H.264 and H.265, respectively.
LongProductName - VIGI 4MP Full-Color Turret Network Camera, 1/2.7”, 1/3 to 1/10000 s, F1.6, 2688 x 1520, CBR, VBR, BLC/3D DNR/HLC/SmartIR, 120 dB, 12V DC ± 5%, Max. 11 W, 5.5 mm Coaxial Power Plug, PoE: 802.3af/at, class 0, Max. 12 W, IP67, 111 x 111 x 83.7 mm, 0.48 kg, White
LongSummaryDescription - TP-Link INSIGHT S445. Type: IP security camera, Placement supported: Outdoor, Connectivity technology: Wired. Mounting type: Ceiling, Product colour: White, Form factor: Turret. Lens viewing angle, horizontal: 100°, Lens viewing angle, vertical: 54°, Lens viewing angle, diagonal: 118°. Sensor type: CMOS, Optical sensor size: 25.4 / 2.7 mm (1 / 2.7"). Detect distance: 64 m, Observe distance: 27 m, Recognize distance: 13 m
Management, monitoring, configuration - Smart Events Intrusion Detection Line Crossing Detection Zone Entry Detection Zone Exit Detection Abandoned Object Detection Taken Object Detection Loitering Detection People Detection Vehicle Detection Unexpected Sound Detection Scene Change Detection
Management features - Cloud-managed - Yes
Management features - Reset button - Yes
Management features - Web-based management - Yes
Management features - Web browser - Yes
Memory card reader - No
Microphone - built-in
Microphone - Yes
Minimum illuminance - 0.005 lx
Mobile support - None
Motion detection - Yes
name - Camera InSight S445(2.8mm)
Network - Bluetooth - No
Network - Ethernet LAN - Yes
Network - Live view - Yes
Network - Networking standards - IEEE 802.3af, IEEE 802.3at
Network - Supported network protocols - TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS, FTP/SFTP, RTP, IPv4, IPv6, ARP
Network - Wi-Fi - No
Network protocols - TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, 802.1x, DNS, RTSP, NTP, UPnP, SSL/TLS, FTP/SFTP, RTP, IPv4, IPv6, ARP, SMTP, SNMP, RTMP
Night mode - Yes
Night vision - LED type - IR/White
Night vision - Night vision - Yes
Operational conditions - Operating relative humidity (H-H) - 0 - 95%
Operational conditions - Operating temperature (T-T) - -30 - 60 °C
Operational conditions - Storage relative humidity (H-H) - 0 - 95%
Operational conditions - Storage temperature (T-T) - -40 - 60 °C
Packaging content - Drilling template included - Yes
Packaging content - Manual - Yes
Packaging content - Mounting kit - Yes
Packaging content - Number of cameras - 1
Packaging content - Screws included - Yes
Packaging data - Package type - Box
Performance - Connectivity technology - Wired
Performance - Day/night mode - Yes
Performance - Dynamic range - 120 dB
Performance - Infrared (IR) cut-off filter - Yes
Performance - Maximum operating distance - 64 m
Performance - Placement supported - Outdoor
Performance - Remote viewing - Yes
Performance - Type - IP security camera
Performance - Wide Dynamic Range (WDR) - Yes
Ports & interfaces - DC-in jack - Yes
Ports & interfaces - Ethernet LAN (RJ-45) ports - 1
Power - DC output voltage - 12
Power - Power consumption (max) - 11 W
Power - Power consumption (Power over Ethernet (PoE)) - 12 W
Power - Power source type - DC, PoE
Power supply - DC Power 12V DC +/- 5%, 11W maximum, 5.5mm coaxial power plug Recommended power supply: T120100-2C1 (for European countries) PoE Power PoE: 802.3af/at, class 0, 12W maximum
producer - TP-LINK
ProductName - INSIGHT S445
Protection class - IP67
Resolution - 2688 x 1520
Security - Transmission security: Password protection, HTTPS encryption, IP address filter, Digest authorization, 802.1X authentication
Security - Alert notification type - Push notification
Security - Built-in siren - Yes
Security - Digest authentication - Yes
Security - HTTPS encryption - Yes
Security - Human and vehicle targets classification - Yes
Security - IP address filtering - Yes
Security - Mirror - Yes
Security - Motion sensor - Yes
Security - Password protection - Yes
Security - Video motion detection - Yes
Sensor -
ShortSummaryDescription - TP-Link INSIGHT S445, IP security camera, Outdoor, Wired, 64 m, 120 dB, Ceiling
Speakers built-in - Yes
Standards - 802.3af
Standards - 802.3at
Storage - Compatible memory cards - MicroSD (TransFlash)
Storage - Maximum memory card size - 512 GB
Title - TP-Link INSIGHT S445 Turret IP security camera Outdoor 2688 x 1520 pixels Ceiling
Two-way transmission - Yes
type - fixed dome camera
URL - https://www.tp-link.com/uk/business-networking/vigi-network-camera/insight-s445/v1%20(2.8mm%20lens)/#specifications
vendpn - InSight S445(2.8mm)
Video - Back Light Compensation (BLC) - Yes
Video - Bit rate - Main Stream: 256 Kbps to 6 Mbps, Sub-Stream: 64 Kbps to 512 Kbps
Video - Bit rate control - Constant Bit Rate (CBR)/Variable Bit Rate (VBR)
Video - Digital Wide Dynamic Range (DWDR) - Yes
Video - Highlight Compensation (HLC) - Yes
Video - Image quality adjustment - Brightness, Contrast, Mirror, Saturation, Sharpness
Video - Maximum resolution - 2688 x 1520 pixels
Video - Supported graphics resolutions - 1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 2048 x 1280, 2304 x 1296, 2560 x 1440, 2688 x 1520
Video - Total megapixels - 4 MP
Video - Video compression formats - H.264, H.264+, H.265, H.265+
Video - Video recording - Yes
Video compression - H.264
Video compression - H.264+
Video compression - H.265
Video compression - H.265+
Viewing angle, horizontal - 80 °
Viewing angle, vertical - 41 °
Visual angle diagonal - 118 °
WarrantyInfo -
Weight - 0.48 kg
Weight & dimensions - Height - 83.7 mm
Weight & dimensions - Length - 111 mm
Weight & dimensions - Weight - 480 g
Weight & dimensions - Width - 111 mm
Wireless communication - No
