Alarm In Input/Output connectors - 1
Alarm Out Input/Output connectors - 1
Audio-In Input/Output connectors - 1
Audio-Out Input/Output connectors - 1
Camera design - Other
Category Code - FNC
Colour - White
Description - > 6-MP 1/2.5" CMOS image sensor, low luminance, and high definition image. > Outputs max. 6 MP (2560 × 2560)@25/30 fps. > 360° fisheye monitoring covers all the corners without any blind zone. > Supports fisheye front-dewarp and back-dewarp. > Supports split screen for 2 and 4 windows. > Built-in IR LED, and the max. illumination distance is 15 m. > ROI, AI H.264/H.265, flexible coding, applicable to various bandwidth and storage environments. > WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes. > With deep learning algorithm, it supports: Perimeter Protection, People Counting, Heat map. > Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 1TB Micro SD card; > Built-in speaker and dual Mic. Supports two-way talk. > 12 VDC/ PoE(802.3af) power supply. > IP67 and IK10 protection. > Focal Length 1.68 mm, Field of View 185*185°
Dimensions - Φ122 mm × 53.3 mm
Effective pixels - 2560 (H) × 2560 (V)
Electronic Shutter Speed - Auto/Manual 1/3 s–1/100,000 s
Environment - Outdoor
Focal Length - 1.68 mm
IR Illumination - Yes
Lens Mount - M12
Microphone - Built-in
Min. Illumination - 0.0006 Lux
Model - IPC-EBW5641-AS
Network Camera Type - HDTV/Megapixel
Operating temperature range - –30 °C to +60 °C
Power consumption - 10.1 Watts
Power options - PoE
Power supply requirements - 12 VDC, 1 A; PoE (802.3af)
Product Net Weight - 0.46 kg
Resolution - 6 Mega Pixel
RJ45 Input/Output connectors - 1
Sensor size - 1/2.5" CMOS
Supports card capacities up to - 512GB
Unit Box Height - 0.16
Unit Box Length - 0.16
Unit Box Width - 0.11
Unit Calculated Volume - 0.002816 cubm
Unit Calculated Weight - 0.77 kg
Units per Shipping Box - 1
Vendor Homepage - www.dahuasecurity.com/products/All-Products/Network-Cameras/WizMind-Panoramic-Series/Fisheye-Series/IPC-EBW5641-AS
Warranty - 36 months
