Accessories included -
ARTIKEL1 - 8MP TURRET NETWORK CAMERA
ARTIKEL2 - FULL-COLOR
Audio - Audio formats supported - G.711
Audio - Audio system - 2-way
Audio - Built-in microphone - Yes
Audio - Built-in speaker(s) - Yes
Audio - Sample rate - 8 kHz
Audio - Signal-to-Noise Ratio (SNR) - 52 dB
Brand - TP-Link
BrandPartCode - VIGIC485_4MM
Breite - 0
Camera - Angle of rotation - 360°
Camera - Camera shutter speed - 1/3 to 1/10000
Camera - Lens viewing angle, diagonal - 109.6°
Camera - Lens viewing angle, horizontal - 91.5°
Camera - Lens viewing angle, vertical - 46.1°
Camera - Minimum illumination - 0.005 lx
Camera - Number of Privacy masking areas - 4
Camera - Pan range - 0 - 360°
Camera - Tilt angle range - 0 - 85°
Camera design - Eyeball
Category - Security Cameras
Category 1 - Netzwerk
Category 2 - Netzwerkkameras
Category Code - FNC
Certificates - CE, NTRA, VCCI, KC, BSMI, FCC, IC
Color - Black
Color - White
Connectors - microSD
Connectors - RJ-45
Description - VIGI C485 VIGI 8MP Full-Color Turret Network Camera 4K (8MP) Ultra HD and 24h Full-Color Human & Vehicle Classification Smart Detection Smart Video Enhancement Technology Active Defense and Two-Way Audio IP67 Waterproof H.265+ Compression Technology 12V DC/PoE
Description - W pełni kolorowa kamera sieciowa VIGI typu Turret, 8MP 4K Ultra HD (8MP) i Pełnia kolorów przez 24h Klasyfikacja ludzi i pojazdów Wykrywanie Smart Inteligentne ulepszanie wideo Aktywna ochrona i Dwukierunkowa transmisja audio Klasa szczelności IP67 Technologia kompresji H.265+ Zasilanie 12V DC/PoE Klasyfikacja ludzi i pojazdów
Kamera rozróżnia ludzi i pojazdy od innych obiektów, dzięki czemu możesz otrzymywać dokładniejsze powiadomienia o zdarzeniach. Technologie inteligentnego ulepszania wideo True WDR: Analizuje i łączy różne ekspozycje, dzięki czemu zarówno jasne, jak i ciemne obszary będą prawidłowo naświetlone, zapewniając zrównoważony i naturalny obraz nawet w środowiskach o wysokim kontraście oświetlenia. Smart IR: Dostosowuje dynamicznie doświetlenie podczerwone, aby zapobiegać nadmiernemu oświetleniu i odblaskom, zwiększając w ten sposób widoczność na różnych odległościach i wyraźniejszy obraz. 3D DNR: Technologia redukująca szum, która analizuje dane obrazu z wielu klatek w celu selektywnej redukcji szumu i jednoczesnego zachowania ważnych szczegółów. Balans bieli: Zapewnia neutralną biel obrazu, niezależnie od warunków oświetlenia.
Design - Form factor - Turret
Design - Housing material - Metal
Design - International Protection (IP) code - IP67
Design - Mounting type - Ceiling
Design - Product colour - White
Designation - CE+WEEE
dimension depth - 160 mm
dimension height - 160 mm
Dimensions - 111 × 111 × 83.7 mm
dimension weight - 730 g
dimension width - 160 mm
ean - 4895252502442
EAN - 4895252502442
EANCode - 4895252502442
Effective pixels - 3840 X 2160
Electronic Shutter Speed - 1/3 to 1/10000 s
Environment - Outdoor
Environment requirements - Dopuszczalna temperatura pracy: -30-60 °C Dopuszczalna temperatura przechowywania: -40-60 °C Dopuszczalna wilgotność powietrza: 95% lub mniej (bez kondensacji) Dopuszczalna wilgotność przechowywania: 95% lub mniej (bez kondensacji)
Focal Length - 4 mm
Frames per second - 25
Gewicht - 0
GRUPPE1 - Security
GRUPPE2 - Network Cameras
GTIN - 4895252502442
guarantee - 36
guarantee_type - normal
HERSTELLER - TP-LINK
Hoehe - 0
HSTNUMMER - VIGI C485(4MM)
Image sensor - Optical sensor size - 25.4 / 2.7 mm (1 / 2.7")
Image sensor - Progressive scan - Yes
Image sensor - Sensor type - CMOS
IR Illumination - Yes
Laenge - 0
Lens - Typ: Soczewka stałoogniskowa Długość ogniskowej: Kamera występuje w dwóch różnych wersjach: 2,8 mm lub 4 mm Przysłona: F1.6
Lens Mount - M12
Lens system - Detect distance - 107 m
Lens system - Fixed focal length - 4 mm
Lens system - Identify distance - 11 m
Lens system - Maximum aperture number - 1.6
Lens system - Number of lenses - 1
Lens system - Observe distance - 44 m
Lens system - Recognize distance - 21 m
LongDesc - Human & Vehicle ClassificationDistinguish humans and vehicles from other objects and receive more accurate event notifications.Smart Video Enhancement TechnologyTrue WDR: By analyzing and blending different exposures, True WDR ensures both bright and dark areas remain properly exposed, delivering a well-balanced and natural-looking image even in environments with high-contrast lighting.Smart IR: Smart IR dynamically adjusts infrared lighting to prevent overexposure and glare, improve visibility at different distances, and ensure clearer footage.3D DNR: 3D DNR is a noise reduction technology that analyzes image data across frames to selectively reduce noise while preserving important details.White Balance: White Balance ensures neutral whites in an image, regardless of the lighting conditions.Efficient H.265+ Compression TechnologyH.265+ reduces the required bandwidth and storage space for videos while maintaining excellent image quality. It saves 57.5% and 15% more storage space compared to H.264 and H.265, respectively.
LongProductName - 8MP Full-Color Turret Network Camera
LongSummaryDescription - TP-Link VIGI C485. Type: IP security camera, Placement supported: Outdoor, Connectivity technology: Wired. Mounting type: Ceiling, Product colour: White, Form factor: Turret. Minimum illumination: 0.005 lx, Angle of rotation: 360°, Lens viewing angle, horizontal: 91.5°. Sensor type: CMOS, Optical sensor size: 25.4 / 2.7 mm (1 / 2.7"). Detect distance: 107 m, Observe distance: 44 m, Recognize distance: 21 m
Management, monitoring, configuration - Zdarzenia podstawowe Wykrywanie ruchu Wykrywanie manipulacji wideo Wyjątek (błędne logowanie) Wykrywanie zmiany Sceny Połączenie alarmu
Nagrywanie wideo na kartę pamięci Powiadomienia Push Ostrzeżenie dźwiękowe Migające białe światło
Management features - Reset button - Yes
Manufacturer - TP-Link
Memory card reader - Yes
Memory standard - SD
Memory standard - SDHC
Memory standard - SDXC
Microphone - Yes
Min. illuminance - 0.005 lx
Min. Illumination - 0.005 Lux
Model - VIGI C485(4MM)
Motion detection - Yes
MPN - VIGI C485(4mm)(UN)
name - Camera VIGI C485(4mm) 8MP Full-Color Turret
Name - TP-Link Omada IPCam VIGI C485(4mm) 8MP Full-Color Turret
Network - Bluetooth - No
Network - Ethernet LAN - Yes
Network - Live view - Yes
Network - Supported network protocols - TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS
Network - Wi-Fi - No
Network Camera Type - HDTV/Megapixel/Outdoor
Network protocols - TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS
Night mode - Yes
Night vision - Infra-red wavelength - 850 nm
Night vision - LED type - IR/White
Night vision - Night vision - Yes
Night vision - Night vision distance - 30 m
Night vision - Number of illumination LEDs - 4
Operating temperature range - -30–60 °C
Operational conditions - Operating relative humidity (H-H) - 0 - 95%
Operational conditions - Operating temperature (T-T) - -30 - 60 °C
Operational conditions - Storage relative humidity (H-H) - 0 - 95%
Operational conditions - Storage temperature (T-T) - -40 - 60 °C
Other features -
Packaging content - Mounting kit - Yes
Packaging content - Number of cameras - 1
Packaging content - Waterproof connector - Yes
Performance - Built-in light - Yes
Performance - Connectivity technology - Wired
Performance - Day/night mode - Yes
Performance - Dynamic range - 120 dB
Performance - Infrared (IR) cut-off filter - Yes
Performance - Placement supported - Outdoor
Performance - Type - IP security camera
Performance - Wide Dynamic Range (WDR) - Yes
Ports & interfaces - DC-in jack - Yes
Ports & interfaces - Ethernet LAN (RJ-45) ports - 1
Power - DC output voltage - 12
Power - Power consumption (max) - 11.5 W
Power - Power consumption (Power over Ethernet (PoE)) - 12.5 W
Power - Power source type - DC, PoE
Power options - 12V/PoE
Power supply - 12V DC +/- 5%, Maks. 11,5 W, 5,5mm Współosiowa wtyczka zasilania PoE: 802.3af/at, class 0, Maks. 12,5 W
Power supply requirements - 12V DC ± 5%, Max. 11.5 W, 5.5 mm Coaxial Power Plug,PoE: 802.3af/at, class 0, Max. 12.5 W
producer - TP-LINK
ProductName - C485
Product Net Weight - 0.48 kg
Protection class - IP67
Resolution - 4K Ultra HD (3840 x 2160)
Resolution - 8 Mega Pixel
RJ45 Input/Output connectors - 1
Security - Bezpieczeństwo transmisji: Ochrona hasłem, Szyfrowanie HTTPS, Filtr adresów IP, Autoryzacja Digest
Security - HTTPS encryption - Yes
Security - Human and vehicle targets classification - Yes
Security - IP address filtering - Yes
Security - Password protection - Yes
Security - Video motion detection - Yes
Sensor - 1/2.7 Progressive Scan CMOS
Sensor size - 1/2.7” Progressive Scan CMOS
ShortSummaryDescription - TP-Link VIGI C485, IP security camera, Outdoor, Wired, 120 dB, Ceiling, White
Speakers built-in - Yes
Special functions -
Standards - 802.3af
Standards - 802.3at
Stck_Kart - 18
Stck_Pal - 0
Storage - Built-in HDD - No
Storage - Card reader integrated - Yes
Storage - Compatible memory cards - MicroSD (TransFlash)
Storage - Maximum memory card size - 512 GB
Storno - N
Supports card capacities up to - 512GB
System Requirements -
Title - TP-Link VIGI C485 Turret IP security camera Outdoor 3840 x 2160 pixels Ceiling
Two-way transmission - Yes
type - fixed dome camera
Unit Box Height - 0.16
Unit Box Length - 0.16
Unit Box Width - 0.12
Unit Calculated Volume - 0.003072 cubm
Unit Calculated Weight - 0.73 kg
Units per Shipping Box - 1
URL - https://www.tp-link.com/en/business-networking/vigi-network-camera/vigi-c485/v1%20(4mm%20lens)/#highlights
Vendor Homepage - www.tp-link.com/en/business-networking/vigi-network-camera/vigi-c485/v1%20(4mm%20lens)/
vendpn - VIGI C485(4mm)
Video - Back Light Compensation (BLC) - Yes
Video - Bit rate control - Constant Bit Rate (CBR), Variable Bit Rate (VBR)
Video - Frame rate - 25 fps
Video - Highlight Compensation (HLC) - Yes
Video - Image quality adjustment - Brightness, Contrast, Mirror, Saturation, Sharpness
Video - Maximum resolution - 3840 x 2160 pixels
Video - Noise reduction - Yes
Video - Noise reduction technology - 3D noise reduction
Video - Privacy masking - Yes
Video - Region of Interest (ROI) encoding - Yes
Video - Smart IR - Yes
Video - Supported graphics resolutions - 1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 2048 x 1280, 2304 x 1296, 2560 x 1440, 3840 x 2160
Video - Total megapixels - 8 MP
Video - Video compression formats - H.264, H.264+, H.265, H.265+
Video - Video streaming - Yes
Viewing angle, horizontal - 107 °
Viewing angle, vertical - 44 °
Warranty - 36 months
WarrantyInfo -
Weight - 0.48 kg
Weight & dimensions - Depth - 111 mm
Weight & dimensions - Height - 83.7 mm
Weight & dimensions - Weight - 480 g
Weight & dimensions - Width - 111 mm
Wireless communication - No
