Alarm input/output Performance - Yes
Alarm input channels Security - 1
Alarm output channels Security - 1
Angle of rotation Camera - 360°
Audio - Audio formats supported - G.711 A-law, G.711 μ-law, G.723, G.726, PCM
Audio - Built-in microphone - Yes
Audio formats supported Audio - G.711 A-law, G.711 μ-law, G.723, G.726, PCM
Back Light Compensation (BLC) Video - Yes
Bit rate control Video - Constant Bit Rate (CBR)/Variable Bit Rate (VBR)
Bluetooth Network - No
Brand - Dahua Technology
BrandPartCode - IPC-HFW5541E-ASE-0360B-S3
Built-in HDD Storage - No
Built-in microphone Audio - Yes
Camera - Angle of rotation - 360°
Camera - Camera pan control - Yes
Camera - Camera shutter speed - 1/3 - 1/100000 s
Camera - Camera tilt control - Yes
Camera - Lens viewing angle, diagonal - 110°
Camera - Lens viewing angle, horizontal - 92°
Camera - Lens viewing angle, vertical - 45°
Camera - Minimum illumination - 0.0005 lx
Camera - Number of Privacy masking areas - 8
Camera - Pan range - 0 - 360°
Camera - Tilt angle range - 0 - 90°
Camera - White balance - Auto, Manual, Natural, Outdoor, Regional custom, Street lamp
Camera pan control Camera - Yes
Camera shutter speed Camera - 1/3 - 1/100000 s
Camera tilt control Camera - Yes
Card reader integrated Storage - Yes
Category - Security Cameras
Category Code - FNC
Closest focusing distance Lens system - 1.7 m
Compatible memory cards Storage - MicroSD (TransFlash)
Compliance certificates Sustainability - CE, Federal Communications Commission (FCC), UL
Connectivity technology Performance - Wired
Day/night mode Performance - Yes
DC-in jack Ports & interfaces - Yes
DC output voltage Power - 12
Description - 5-MP 1/2.7" CMOS image sensor, low luminance, and high definition imageOutputs max. 5 MP (2960×1668) @25/30fpsBuilt-in IR LED, and the max. illumination distance is 50 mROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environmentsRotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenesWith deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etcAlarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 1 TB Micro SD card, built-in MIC12 VDC/PoE power supply; ePoEIP67 protectionSMD 3.0
Design - Form factor - Bullet
Design - Housing material - Metal
Design - International Protection (IP) code - IP67
Design - Mounting type - Pole clamp
Design - Product colour - White
Detect distance Lens system - 85.4 m
Dynamic range Performance - 120 dB
Ethernet interface type Network - Fast Ethernet
Ethernet LAN (RJ-45) ports Ports & interfaces - 1
Ethernet LAN Network - Yes
Fixed focal length Lens system - 3.6 mm
Fixed focus Lens system - Yes
Form factor Design - Bullet
Frame rate Video - 30 fps
Gain control type Video - Auto
GTIN - 6923172585189
Height Weight & dimensions - 66.4 mm
Highlight Compensation (HLC) Video - Yes
Housing material Design - Metal
Human and vehicle targets classification Security - Yes
Identify distance Lens system - 8.5 m
Image sensor - Number of sensors - 1
Image sensor - Optical sensor size - 25.4 / 2.7 mm (1 / 2.7")
Image sensor - Progressive scan - Yes
Image sensor - Sensor type - CMOS
Intelligent Video Surveillance (IVS) system features Security - Intrusion, Tripwire
International Protection (IP) code Design - IP67
IP address filtering Security - Yes
LED type Night vision - IR
Length Weight & dimensions - 192.7 mm
Lens system - Closest focusing distance - 1.7 m
Lens system - Detect distance - 85.4 m
Lens system - Fixed focal length - 3.6 mm
Lens system - Fixed focus - Yes
Lens system - Identify distance - 8.5 m
Lens system - Maximum aperture number - 1.6
Lens system - Observe distance - 34.2 m
Lens system - Recognize distance - 17.1 m
Lens viewing angle, diagonal Camera - 110°
Lens viewing angle, horizontal Camera - 92°
Lens viewing angle, vertical Camera - 45°
LongDesc -
LongProductName - Bullet, 5 MP, CMOS, 2960 x 1668, IP67, DC/PoE
LongSummaryDescription - Dahua Technology WizMind IPC-HFW5541E-ASE-0360B-S3. Type: IP security camera, Placement supported: Indoor, Connectivity technology: Wired. Mounting type: Pole clamp, Product colour: White, Form factor: Bullet. Minimum illumination: 0.0005 lx, Angle of rotation: 360°, Lens viewing angle, horizontal: 92°. Sensor type: CMOS, Optical sensor size: 25.4 / 2.7 mm (1 / 2.7"). Detect distance: 85.4 m, Observe distance: 34.2 m, Recognize distance: 17.1 m
Manual Packaging content - Yes
Maximum aperture number Lens system - 1.6
Maximum memory card size Storage - 1 TB
Maximum resolution Video - 2960 x 1668 pixels
Minimum illumination Camera - 0.0005 lx
Mirror Security - Yes
Mobile operating systems supported System requirements - Android, iOS
Model - IPC-HFW5541E-ASE-0360B-S3
Mounting type Design - Pole clamp
Network - Bluetooth - No
Network - Ethernet interface type - Fast Ethernet
Network - Ethernet LAN - Yes
Network - Networking standards - IEEE 802.1x, IEEE 802.3af
Network - Quality of Service (QoS) support - Yes
Network - Streaming method - Multicast
Network - Supported network protocols - IPv4, IPv6, HTTP, TCP, UDP, ARP, RTP, RTSP, RTCP, RTMP, SMTP, FTP, SFTP, DHCP, DNS, DDNS, QoS, UPnP, NTP, ICMP, IGMP, NFS, SAMBA, PPPoE, SNMP, P2P
Network - Wi-Fi - No
Network access storage (NAS) Security - Yes
Networking standards Network - IEEE 802.1x, IEEE 802.3af
Night vision - LED type - IR
Night vision - Night vision - Yes
Night vision - Night vision distance - 50 m
Night vision - Number of illumination LEDs - 1
Night vision distance Night vision - 50 m
Night vision Night vision - Yes
Noise reduction technology Video - 3D noise reduction
Noise reduction Video - Yes
Number of cameras Packaging content - 1
Number of illumination LEDs Night vision - 1
Number of Privacy masking areas Camera - 8
Number of sensors Image sensor - 1
Observe distance Lens system - 34.2 m
Operating temperature (T-T) Operational conditions - -40 - 60 °C
Operational conditions - Operating temperature (T-T) - -40 - 60 °C
Operational conditions - Storage relative humidity (H-H) - 10 - 95%
Operational conditions - Storage temperature (T-T) - -40 - 60 °C
Optical sensor size Image sensor - 25.4 / 2.7 mm (1 / 2.7")
Package weight Packaging data - 780 g
Packaging content - Manual - Yes
Packaging content - Number of cameras - 1
Packaging data - Package weight - 780 g
Pan range Camera - 0 - 360°
People counting function Performance - Yes
Performance - Alarm input/output - Yes
Performance - Connectivity technology - Wired
Performance - Day/night mode - Yes
Performance - Dynamic range - 120 dB
Performance - People counting function - Yes
Performance - Placement supported - Indoor
Performance - Type - IP security camera
Performance - Wide Dynamic Range (WDR) - Yes
Placement supported Performance - Indoor
Ports & interfaces - DC-in jack - Yes
Ports & interfaces - Ethernet LAN (RJ-45) ports - 1
Power - DC output voltage - 12
Power - Power consumption (max) - 6.2 W
Power - Power consumption (typical) - 4 W
Power - Power source type - DC, PoE
Power consumption (max) Power - 6.2 W
Power consumption (typical) Power - 4 W
Power source type Power - DC, PoE
Product colour Design - White
ProductName - IPC-HFW5541E-ASE-0360B-S3
Progressive scan Image sensor - Yes
Quality of Service (QoS) support Network - Yes
RAM capacity Storage - 1024 MB
Recognize distance Lens system - 17.1 m
Region of Interest (ROI) encoding Video - Yes
ROM capacity Storage - 4096 MB
Security - Alarm input channels - 1
Security - Alarm output channels - 1
Security - Human and vehicle targets classification - Yes
Security - Intelligent Video Surveillance (IVS) system features - Intrusion, Tripwire
Security - IP address filtering - Yes
Security - Mirror - Yes
Security - Network access storage (NAS) - Yes
Security - Video motion detection - Yes
Sensor type Image sensor - CMOS
ShortSummaryDescription - Dahua Technology WizMind IPC-HFW5541E-ASE-0360B-S3, IP security camera, Indoor, Wired, 120 dB, Pole clamp, White
Storage - Built-in HDD - No
Storage - Card reader integrated - Yes
Storage - Compatible memory cards - MicroSD (TransFlash)
Storage - Maximum memory card size - 1 TB
Storage - RAM capacity - 1024 MB
Storage - ROM capacity - 4096 MB
Storage relative humidity (H-H) Operational conditions - 10 - 95%
Storage temperature (T-T) Operational conditions - -40 - 60 °C
Streaming method Network - Multicast
Summary - Dahua Technology WizMind IPC-HFW5541E-ASE-0360B-S3. Type: IP security camera, Placement supported: Indoor, Connectivity technology: Wired. Mounting type: Pole clamp, Product colour: White, Form factor: Bullet. Minimum illumination: 0.0005 lx, Angle of rotation: 360°, Lens viewing angle, horizontal: 92°. Sensor type: CMOS, Optical sensor size: 25.4 / 2.7 mm (1 / 2.7"). Detect distance: 85.4 m, Observe distance: 34.2 m, Recognize distance: 17.1 m
Supported network protocols Network - IPv4, IPv6, HTTP, TCP, UDP, ARP, RTP, RTSP, RTCP, RTMP, SMTP, FTP, SFTP, DHCP, DNS, DDNS, QoS, UPnP, NTP, ICMP, IGMP, NFS, SAMBA, PPPoE, SNMP, P2P
Sustainability - Compliance certificates - CE, Federal Communications Commission (FCC), UL
System requirements - Mobile operating systems supported - Android, iOS
Tilt angle range Camera - 0 - 90°
Title - Dahua Technology WizMind IPC-HFW5541E-ASE-0360B-S3 security camera Bullet IP security camera Indoor 2960 x 1668 pixels Pole clamp
Total megapixels Video - 5 MP
Type Performance - IP security camera
Unit Box Height - 0.1
Unit Box Length - 0.22
Unit Box Width - 0.11
Unit Calculated Volume - 0.00242 cubm
Unit Calculated Weight - 0.78 kg
Units per Shipping Box - 1
URL - https://www.dahuasecurity.com/products/All-Products/Network-Cameras/WizMind-5-Series/S-Series/5MP/IPC-HFW5541E-ASE=S3
Vendor Homepage - https://www.dahuasecurity.com/products/All-Products/Network-Cameras/WizMind-5-Series/S-Series/5MP/IPC-HFW5541E-ASE=S3
Video - Back Light Compensation (BLC) - Yes
Video - Bit rate control - Constant Bit Rate (CBR)/Variable Bit Rate (VBR)
Video - Frame rate - 30 fps
Video - Gain control type - Auto
Video - Highlight Compensation (HLC) - Yes
Video - Maximum resolution - 2960 x 1668 pixels
Video - Noise reduction - Yes
Video - Noise reduction technology - 3D noise reduction
Video - Region of Interest (ROI) encoding - Yes
Video - Total megapixels - 5 MP
Video - Video compression formats - H.264, H.264B, H.264H, H.265, M-JPEG
Video - Video recording - Yes
Video - Video streaming - Yes
Video compression formats Video - H.264, H.264B, H.264H, H.265, M-JPEG
Video motion detection Security - Yes
Video recording Video - Yes
Video streaming Video - Yes
Warranty - 36 months
WarrantyInfo -
Weight & dimensions - Height - 66.4 mm
Weight & dimensions - Length - 192.7 mm
Weight & dimensions - Weight - 590 g
Weight & dimensions - Width - 70.5 mm
Weight Weight & dimensions - 590 g
White balance Camera - Auto, Manual, Natural, Outdoor, Regional custom, Street lamp
Wi-Fi Network - No
Wide Dynamic Range (WDR) Performance - Yes
Width Weight & dimensions - 70.5 mm
