Newstar TV/Monitor Wall Mount, 10-40"

Angle of rotation Ergonomics - 360°
Brand - Neomounts
BrandPartCode - FPMA-W825
Category - TV Mounts & Stands
Category Code - TMS
Country of origin Technical details - China
Description - NEWSTAR FLAT SCREEN WALL MOUNT (2 PIVOTS & TILTABLE) 10-40" BLACK
Description - The Neomounts wall mount, model FPMA-W825 is a tilt-, swivel and rotatable wall mount for flat screens up to 40" (102 cm). This mount is a great choice when you want the ultimate viewing flexibility with your flat screen. Effortless pull the display out from the wall, position it in almost any direction, turn it around corners and then smoothly return it to the wall when finished. Neomounts' tilt (30°), rotate (360°) and swivel (180°) technology allows the mount to change to any viewing angle to fully benefit from the capabilities of the flat screen. The mount is easily depth adjustable from 9 to 26 centimetres. Cable management conceals and routes cables from mount to flat screen. Hide your cables to keep living room, bedroom or home cinema installation nice and tidy. Neomounts FPMA-W825 has two pivot points and is suitable for screens up to 40" (102 cm). The weight capacity of this product is 20 kg each screen. The wall mount is suitable for screens that meet VESA hole pattern 75x75 to 200x200mm. Different hole patterns can be covered using Neomounts VESA adapter plates. Create a clean design ambiance for your flat screen TV in the living room, bedroom or home cinema. All installation material is included with the product.
Design - Housing material - Aluminium
Design - Product colour - Black
Distance to the wall (max) Ergonomics - 26 cm
Distance to the wall (min) Ergonomics - 9 cm
Ergonomics - Angle of rotation - 360°
Ergonomics - Distance to the wall (max) - 26 cm
Ergonomics - Distance to the wall (min) - 9 cm
Ergonomics - Rotating - Yes
Ergonomics - Swivel angle - 180°
Ergonomics - Swivel angle range - 0 - 180°
Ergonomics - Swivelling - Yes
Ergonomics - Tilt adjustment - Yes
Ergonomics - Tilt angle range - 0 - 30°
Ergonomics - Type - Full motion
GTIN - 8435397350278
GTIN - 8717371443115
Harmonized System (HS) code Logistics data - 7326909890
Height - 257.000000
Height adjustment - No
Housing material Design - Aluminium
Length - 87.000000
Logistics data - Harmonized System (HS) code - 7326909890
Logistics data - Master (outer) case gross weight - 14.7 kg
Logistics data - Master (outer) case height - 190 mm
Logistics data - Master (outer) case length - 534 mm
Logistics data - Master (outer) case net weight - 11.7 kg
Logistics data - Master (outer) case width - 670 mm
Logistics data - Products per master (outer) case - 8 pc(s)
Logistics data - Products per pallet (EU) - 128 pc(s)
LongDesc - The Neomounts wall mount, model FPMA-W825 is a tilt-, swivel and rotatable wall mount for flat screens up to 40" (102 cm). This mount is a great choice when you want the ultimate viewing flexibility with your flat screen. Effortless pull the display out from the wall, position it in almost any direction, turn it around corners and then smoothly return it to the wall when finished. Neomounts' tilt (30°), rotate (360°) and swivel (180°) technology allows the mount to change to any viewing angle to fully benefit from the capabilities of the flat screen. The mount is easily depth adjustable from 9 to 26 centimetres. Cable management conceals and routes cables from mount to flat screen. Hide your cables to keep living room, bedroom or home cinema installation nice and tidy.Neomounts FPMA-W825 has two pivot points and is suitable for screens up to 40" (102 cm). The weight capacity of this product is 20 kg each screen. The wall mount is suitable for screens that meet VESA hole pattern 75x75 to 200x200mm. Different hole patterns can be covered using Neomounts VESA adapter plates.Create a clean design ambiance for your flat screen TV in the living room, bedroom or home cinema. All installation material is included with the product.
LongProductName - Neomounts FPMA-W825 Full motion Monitor/TV mount wall - 10-40" - max 20 kg - VESA 75x75-200x200 - d 9-26 cm - black
LongSummaryDescription - Neomounts FPMA-W825 Monitor/TV mount wall 10-40" - full motion. Maximum weight capacity: 20 kg, Minimum screen size: 25.4 cm (10"), Maximum screen size: 101.6 cm (40"), Minimum VESA mount: 75 x 75 mm, Maximum VESA mount: 200 x 200 mm. Tilt angle range: 0 - 30°, Swivel angle range: 0 - 180°, Angle of rotation: 360°, Distance to the wall (min): 9 cm, Distance to the wall (max): 26 cm. Product colour: Black
Manufacturer - Neomounts
ManufacturerPartNumber - FPMA-W825
Master (outer) case gross weight Logistics data - 14.7 kg
Master (outer) case height Logistics data - 190 mm
Master (outer) case length Logistics data - 534 mm
Master (outer) case net weight Logistics data - 11.7 kg
Master (outer) case width Logistics data - 670 mm
Maximum screen size Mounting - 101.6 cm (40")
Maximum VESA mount Mounting - 200 x 200 mm
Maximum weight (capacity), kg - 20
Maximum weight capacity (per display) Mounting - 20 kg
Maximum weight capacity Mounting - 20 kg
Minimum screen size Mounting - 25.4 cm (10")
Minimum VESA mount Mounting - 75 x 75 mm
Motorized - No
Mounting - Maximum screen size - 101.6 cm (40")
Mounting - Maximum VESA mount - 200 x 200 mm
Mounting - Maximum weight capacity - 20 kg
Mounting - Maximum weight capacity (per display) - 20 kg
Mounting - Minimum screen size - 25.4 cm (10")
Mounting - Minimum VESA mount - 75 x 75 mm
Mounting - Mounting type - Wall
Mounting - Number of displays supported - 1
Mounting - Panel mounting interface - 100 x 200,100 x 100,200 x 100,200 x 200,75 x 75
Mounting type Mounting - Wall
Number of displays supported Mounting - 1
Package depth Packaging data - 85 mm
Package height Packaging data - 320 mm
Package net weight Technical details - 1.46 kg
Package weight Packaging data - 1.5 kg
Package width Packaging data - 255 mm
Packaging data - Package depth - 85 mm
Packaging data - Package height - 320 mm
Packaging data - Package weight - 1.5 kg
Packaging data - Package width - 255 mm
Panel mounting interface Mounting - 100 x 200,100 x 100,200 x 100,200 x 200,75 x 75
PeriodofWarranty - 5 Y
Product colour Design - Black
ProductName - Neomounts FPMA-W825 Monitor/TV mount wall 10-40" - full motion
Products per master (outer) case Logistics data - 8 pc(s)
Products per pallet (EU) Logistics data - 128 pc(s)
Rotating Ergonomics - Yes
Short summary - Neomounts FPMA-W825 Full motion Monitor/TV mount wall - 10-40" - max 20 kg - VESA 75x75-200x200 - d 9-26 cm - black
ShortSummaryDescription - Neomounts FPMA-W825 Monitor/TV mount wall 10-40" - full motion, 75 x 75 mm, 200 x 200 mm, 0 - 30°, 0 - 180°, 360°, Black
Stand/mount type - Wall
Summary - Neomounts FPMA-W825 Monitor/TV mount wall 10-40" - full motion. Maximum weight capacity: 20 kg, Minimum screen size: 25.4 cm (10"), Maximum screen size: 101.6 cm (40"), Minimum VESA mount: 75 x 75 mm, Maximum VESA mount: 200 x 200 mm. Tilt angle range: 0 - 30°, Swivel angle range: 0 - 180°, Angle of rotation: 360°, Distance to the wall (min): 9 cm, Distance to the wall (max): 26 cm. Product colour: Black
Swivel angle Ergonomics - 180°
Swivel angle range Ergonomics - 0 - 180°
Swivelling Ergonomics - Yes
Technical details - Country of origin - China
Technical details - Package net weight - 1.46 kg
Tilt - Yes
Tilt adjustment Ergonomics - Yes
Tilt angle range Ergonomics - 0 - 30°
Title - Neomounts FPMA-W825 Monitor/TV mount wall 10-40" - full motion
Turn - Yes
Type Ergonomics - Full motion
Unit Box Height - 0.08
Unit Box Length - 0.26
Unit Box Width - 0.32
Unit Calculated Volume - 0.006656 cubm
Unit Calculated Weight - 1.7 kg
Units per Shipping Box - 1
URL - https://www.neomounts.com/default.asp?pageid=44&artdetail=FPMA-W825
Vendor Homepage - https://www.neomounts.com/default.asp?pageid=44&artdetail=FPMA-W825
VESA-standard, mm - 75 x 75
VESA-standard, mm - 200 x 200
Warranty - 60 months
WarrantyInfo - 5 year
Weight - 1.800000
Weight & dimensions - Weight - 1.46 kg
Weight Weight & dimensions - 1.46 kg
Wheels - No
Width - 325.000000
