TP-LINK Router TP-Link EX520

Accessories included - EX520 Power Supply RJ45 Ethernet Cable Quick Installation Guide
Antenna - Fixed external
Antenna - Antenna design - External
Antenna - Antennas quantity - 4
Brand - TP-Link
BrandPartCode - EX520
Category - Wireless Routers
Certificates - CE
Certificates - Certification - CE
Color - Black
Description - AX3000 Dual-Band WiFi 6 Router
Dual-Band WiFi 6: Up to 2402 Mbps on the 5 GHz band and up to 574 Mbps on the 2.4 GHz band Extensive Coverage: Beamforming technology and four powerful antennas ensure a strong and reliable Wi-Fi signal throughout your home More Connections: OFDMA and MU-MIMO technologies increase network capacity and enable simultaneous transmission with more devices EasyMesh: Creates a smart mesh network with seamless coverage and high flexibility Enhanced Security: WPA3 encryption, Multi-SSID, and Parental Controls provide a personalized and secure online experience Gigabit Ports: 1 Gigabit WAN port and 4 Gigabit LAN ports provide fast and flexible internet access Easy Setup: Configure your router in minutes with the TP-Link Aginet app Remote Management: Supports TAUC (TP-Link Aginet Unified) Cloud), TR-069, TR-098, TR-181, TR-111, and TR-143
Dual-band Wi-Fi 6 with speeds up to 3.0 Gbps
Wi-Fi 6 (802.11ax) technology delivers higher speeds, lower latency, and greater capacity, enabling more simultaneous connections in your home. Every app will run more smoothly with significantly increased Wi-Fi speeds. The 2.4GHz and 5GHz bands have been upgraded to the latest generation of Wi-Fi, making them ideal for 4K/8K streaming, online gaming, and fast downloads.
Extensive Wi-Fi Coverage
Beamforming technology and high-gain antennas ensure Wi-Fi coverage throughout your home and focus the signal towards every device.
Create a Flexible and Intelligent Mesh Wi-Fi Network
Create a seamless Mesh Wi-Fi network throughout your home using multiple EX520s or other EasyMesh-compatible devices working together.
Gigabit Broadband Access
Gigabit Ethernet ports allow you to fully utilize your broadband speeds of up to 1 Gbps. Connect your computers, Smart TVs, and game consoles to the Gigabit Ethernet LAN ports for fast, stable wired connections.
Easy Setup and Use
Whether you prefer the intuitive Aginet app or the extensive web interface, you can configure your device in minutes. The Aginet app also allows you to manage network settings from your smartphone or tablet.
TR-069 Remote Management Support
ISPs can remotely configure and manage devices via ACS (Auto-Configuration Server). High-level operations are supported by the TR-181, TR-111, and TR-143 protocols.
Design - Built-in display - No
Design - Indication light - Yes
Design - On/off switch - Yes
Design - Product colour - Black
Design - Product type - Tabletop router
Designation - CE+WEEE
dimensionalWeight - 1155
dimension depth - 75 mm
dimension height - 240 mm
Dimensions - 260,2 × 135,0 × 41,6 mm
dimension weight - 833 g
dimension width - 330 mm
ean - 4897098684795
Environment requirements - Permissible operating temperature: 0-40°C Permissible storage temperature: -40-60°C Permissible air humidity: 10%-90% non-condensing Permissible storage humidity: 5%-90% non-condensing
guarantee - 36
guarantee_type - normal
I/O ports - None
LongDesc - Dual-Band WiFi 6 Up to 3.0 GbpsWiFi 6 (802.11ax) technology brings faster speeds, less lag, and higher capacity, enabling more simultaneous connections on your home network. Every application feels more fluid with drastically improved WiFi speeds. Both the 2.4 GHz band and 5 GHz band get upgraded to the latest generation—perfect for 4K/8K streaming, online gaming, and fast downloading.More Connections at High SpeedEasily handle dozens of devices streaming and gaming at the same time. OFDMA and MU-MIMO future-proof your home network by providing greater capacity to connect more devices.Extensive WiFi CoverageBeamforming technology and high-performance antennas combine to adapt WiFi coverage to perfectly fit your home and concentrate signal strength towards every device.Create Smart Mesh WiFi with Great FlexibilityCreate a unified mesh WiFi network with several EX520’s working together or with other EasyMesh-compatible router or mesh AP for seamless whole home coverage.Gigabit Broadband Internet AccessThe Gigabit Ethernet ports allow you to take full advantage of your broadband speed up to 1 Gbps. Plug your PCs, smart TVs, and game consoles into one of the four Gigabit Ethernet LAN ports for fast and reliable wired connections. Easy to Set Up and UseYou can set up your device and network in minutes, whether you prefer the powerful Aginet app or the intuitive web interface. The Aginet app allows you to manage your network from a smartphone or tablet.Support TR-069 Remote ManagementISPs can remotely configure and manage the devices via ACS (Auto-Configuration Server). High-level operations support TR-181, TR-111, and TR-143 protocols.Aginet Solution: End-to-End Management Platform for ISPsThe Aginet solution offers ISPs powerful and flexible platforms to manage multiple devices for connected homes, such as dynamic service provisioning, zero-touch firmware upgrading, and remote troubleshooting and mesh WiFi diagnostics.
LongProductName - AX3000 Dual Band WiFi 6 Router
LongSummaryDescription - TP-Link EX520. WAN connection type: RJ-45. Wi-Fi band: Dual-band (2.4 GHz / 5 GHz), Top Wi-Fi standard: Wi-Fi 6 (802.11ax), WLAN data transfer rate (max): 1775 Mbit/s. Ethernet LAN interface type: Gigabit Ethernet, Ethernet LAN data rates: 10,100,1000 Mbit/s. Security algorithms: WPA, WPA2, WPA3-Enterprise. Product type: Tabletop router, Product colour: Black
Management, monitoring, configuration - Funkcja Quality of Service: Sprzętowy QoS, Klasyfikacja przepływu Zarządzanie lokalne: Interfejs Web, Aplikacja Aginet (dla użytkowników końcowych) Zarządzanie zdalne :Aginet ACS, TR-069, TR-098, TR-181, TR-369, TR-111, TR-143 (dla dostawców internetu) Zarządzanie w chmurze: TP-Link Aginet Unified Cloud (TAUC)
Management features - MIMO - Yes
Management features - MU-MIMO technology - Yes
Management features - Quality of Service (QoS) support - Yes
Management features - Reset button - Yes
Management features - Wireless statistics - Yes
Management features - WPS push button - Yes
Mobile network - 3G - No
Mobile network - 4G - No
Mobile network - 5G - No
Mobile network - Mobile network generation - Not supported
Model - EX520
name - TP-Link EX520
Network - Cabling technology - 10/100/1000Base-T(X)
Network - Dynamic DNS (DDNS) - Yes
Network - Ethernet LAN - Yes
Network - Ethernet LAN data rates - 10
Network - Ethernet LAN data rates - 10,100,1000 Mbit/s
Network - Ethernet LAN data rates - 100
Network - Ethernet LAN data rates - 1000 Mbit/s
Network - Ethernet LAN interface type - Gigabit Ethernet
Network - Networking standards - IEEE 802.11a
Network - Networking standards - IEEE 802.11ac
Network - Networking standards - IEEE 802.11ax
Network - Networking standards - IEEE 802.11b
Network - Networking standards - IEEE 802.11g
Network - Networking standards - IEEE 802.11n
Network - Port forwarding - Yes
Network - VPN Passthrough - Yes
Network - VPN support - PPTP, OpenVPN, IPSec
Network architecture - GigabitEthernet
Number of antennas - 4
Operating frequency - 2,4 GHz
Operating frequency - 5 GHz
Operational conditions - Operating relative humidity (H-H) - 10 - 90%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Operational conditions - Storage relative humidity (H-H) - 5 - 90%
Operational conditions - Storage temperature (T-T) - -40 - 60 °C
Other features - Input voltage - 12 V
Packaging content - AC adapter included - Yes
Packaging content - Antenna included - Yes
Packaging content - Cables included - LAN (RJ-45)
Packaging content - Quick installation guide - Yes
Packaging data - Number of products included - 1 pc(s)
Ports & interfaces - DC-in jack - Yes
Ports & interfaces - Ethernet LAN (RJ-45) ports - 4
Ports & interfaces - USB port - No
Power - External power adapter - Yes
Power - Output current - 1.5 A
Power - Output voltage - 12 V
Power - Power source type - DC
Power supply - External power supply: 12V / 1.5A
producer - TP-LINK
producerCode - EX520
ProductName - EX520
productName - TP-Link EX520 WLAN-Router Gigabit Ethernet Dual-Band (2,4 GHz/5 GHz) Black
productSize - Normal
Protocols - DHCP client - Yes
Protocols - DHCP server - Yes
Protocols - Supported network protocols - IPv4, IPv6
Protocols - Universal Plug and Play (UPnP) - Yes
Safety warning - Warnings - Avoid contact with liquids as this may cause electric shock.
Safety warning - Warnings - Do not open the appliance housing - risk of electric shock.
Safety warning - Warnings - The product may emit radio waves that may interfere with other electronic devices.
Security - Wireless Security: WPA/WPA2/WPA3 Encryption Firewall Security: DoS, SPI Firewall, IP and MAC Address Binding
Security - Access Control List (ACL) - Yes
Security - DMZ support - Yes
Security - DoS attack prevention - Yes
Security - Firewall - Yes
Security - Firewall security - SPI
Security - Schedule access - Yes
Security - Security algorithms - SSID
Security - Security algorithms - WPA
Security - Security algorithms - WPA, WPA2, WPA3-Enterprise
Security - Security algorithms - WPA2
Security - Security algorithms - WPA3
Security - Stateful Packet Inspection (SPI) - Yes
ShortSummaryDescription - TP-Link EX520, Wi-Fi 6 (802.11ax), Dual-band (2.4 GHz / 5 GHz), Ethernet LAN, Black, Tabletop router
sizeX - 70
sizeY - 330
sizeZ - 250
Special functions - TX Beamforming, MU-MIMO, DL/UL OFDMA, Airtime Fairness
Standards - 802.11a
Standards - 802.11ac
Standards - 802.11ax
Standards - 802.11b
Standards - 802.11g
Standards - 802.11n
Supported operating systems - Linux
Supported operating systems - Mac OS
Supported operating systems - Novell NetWare
Supported operating systems - Unix
Supported operating systems - Windows 7
Supported operating systems - Windows 8
Supported operating systems - Windows 8.1
Supported operating systems - Windows 10
Supported operating systems - Windows 98 SE
Supported operating systems - Windows 2000
Supported operating systems - Windows NT
Supported operating systems - Windows Vista
Supported operating systems - Windows XP
Sustainability - Sustainability certificates - CE
Sustainability - Sustainability compliance - Yes
System Requirements - Microsoft Windows 98SE/NT/2000/XP/Vista/7/8/8.1/10, MAC OS, NetWare, UNIX, or Linux Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0, or other browser with JavaScript enabled Internet access
System requirements - Browser supported - Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0
System requirements - Linux operating systems supported - Yes
System requirements - Mac operating systems supported - Yes
System requirements - Windows operating systems supported - Yes
Title - TP-Link EX520 wireless router Gigabit Ethernet Dual-band (2.4 GHz / 5 GHz) Black
Type - xDSL
URL - https://service-provider.tp-link.com/wifi-router/ex520/
vendpn - EX520
WAN connection - 3G/4G USB modem compatibility - No
WAN connection - DSL WAN - No
WAN connection - Ethernet WAN - Yes
WAN connection - SIM card slot - No
WAN connection - WAN connection type - RJ-45
WarrantyInfo -
warrantyLength - 36
warrantyType - G
weight - 900
Weight & dimensions - Depth - 94 mm
Weight & dimensions - Depth - 135 mm
Weight & dimensions - Height - 33.3 mm
Weight & dimensions - Height - 41.6 mm
Weight & dimensions - Width - 182.7 mm
Weight & dimensions - Width - 260.2 mm
Wireless LAN features - Top Wi-Fi standard - Wi-Fi 6 (802.11ax)
Wireless LAN features - Wi-Fi band - Dual-band (2.4 GHz / 5 GHz)
Wireless LAN features - Wi-Fi standards - 802.11a
Wireless LAN features - Wi-Fi standards - 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
Wireless LAN features - Wi-Fi standards - 802.11b
Wireless LAN features - Wi-Fi standards - 802.11g
Wireless LAN features - Wi-Fi standards - Wi-Fi 4 (802.11n)
Wireless LAN features - Wi-Fi standards - Wi-Fi 5 (802.11ac)
Wireless LAN features - Wi-Fi standards - Wi-Fi 6 (802.11ax)
Wireless LAN features - WLAN data transfer rate (first band) - 574 Mbit/s
Wireless LAN features - WLAN data transfer rate (first band) - 1201 Mbit/s
Wireless LAN features - WLAN data transfer rate (max) - 1775 Mbit/s
Wireless LAN features - WLAN data transfer rate (max) - 3000 Mbit/s
Wireless LAN features - WLAN data transfer rate (second band) - 574 Mbit/s
Wireless LAN features - WLAN data transfer rate (second band) - 2402 Mbit/s
