TP-LINK XZ000-G7 GPON 1-port Gigabit GPON SFU

Accessories included - Zasilacz XZ000-G7
Brand - TP-Link
BrandPartCode - XZ000-G7
Category - Network Terminals/Units
Certificates - Compliance certificates - RoHS
Description - Gigabit internet access: one PON and one gigabit LAN port ensure high transfer speeds XPON support: dual EPON + GPON mode provides greater flexibility for fibre internet access Sustainability: Intelligent power saving method Remote management: Supports OMCI (ONU Management Control Interface) protocol for centralised configuration and management
Design - LED indicators - Yes
Design - Product colour - White
Design - Product type - Optical network terminal (ONT)
Designation - CE+WEEE
dimensionalWeight - 162
dimension depth - 85 mm
dimension height - 90 mm
Dimensions - 95 x 75 x 29,3 mm
dimension weight - 188 g
dimension width - 100 mm
ean - 4895252500011
GTIN - 4895252500028
guarantee - 36
guarantee_type - normal
I/O ports - 1 x 10/100/1000 Mbit/s
I/O ports - 1 x PON
LongDesc - 1-PortGigabit XPON TerminalHigh-Speed GPON ServiceCompliant with the ITU-T G.984 GPON standards, XZ000-G7 supports maximum data rates of upto 2.488 Gbps downstream, 1.244 Gbps upstream.MakeFiber-to-the-Home YoursTP-Link’s XZ000-G7 is a GPON (Gigabit Passive Optical Network) + EPON (Ethernet Passive Optical Network) combo terminal, ideal for Fiber-to-the-Home solution.Gigabit Internet AccessOne PON port and one Gigabit Ethernet port, XZ000-G7 provides high-performance forwarding capabilities to ensure smooth VoIP, HD video streaming experiences.Ease of UseQuick and hassle-free installation
LongProductName - 10/100/1000 Mbps RJ45, PON, 20 Km Max, 95 x 75 x 29.3 mm
LongSummaryDescription - TP-Link 1-Port Gigabit XPON Terminal. Product type: Optical network terminal (ONT), Product colour: White. Networking standards: IEEE 802.1Q, IEEE 802.1p, IEEE 802.3u, ITU standards: G.984.1, G.984.3, G.984.4, Ethernet LAN data rates: 10,100,1000 Mbit/s. Fiber optic connector: SC/APC. Output voltage: 9 V, Output current: 0.6 A. Compliance certificates: RoHS
Management features - Quality of Service (QoS) support - Yes
Management features - Reset button - Yes
Management features - Web-based management - Yes
Max download speed - 2.488 Gb/s
Max upload speed - 1.244 Gb/s
name - XZ000-G7 GPON 1-port Gigabit GPON SFU
Network - Downstream data rate - 2488 Mbit/s
Network - Ethernet LAN data rates - 10,100,1000 Mbit/s
Network - ITU standards - G.984.1, G.984.3, G.984.4
Network - Networking standards - IEEE 802.1Q, IEEE 802.1p, IEEE 802.3u
Network - Transmission distance (max) - 20 km
Network - Upstream data rate - 1244 Mbit/s
Operational conditions - Operating relative humidity (H-H) - 10 - 90%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Operational conditions - Storage relative humidity (H-H) - 5 - 90%
Operational conditions - Storage temperature (T-T) - -40 - 60 °C
Other features - Optical module: Class B+ Recipient: Super-TIA Transmitter: DFB Laser
Packaging content - AC adapter included - Yes
Packaging content - Quantity per pack - 1 pc(s)
Packaging content - Quick start guide - Yes
Ports & interfaces - DC-in jack - Yes
Ports & interfaces - Ethernet LAN (RJ-45) ports - 1
Ports & interfaces - Fiber optic connector - SC/APC
Ports & interfaces - Fiber ports quantity - 1
Power - Output current - 0.6 A
Power - Output voltage - 9 V
Power supply - 9 V DC/0,6 A
producer - TP-LINK
producerCode - XZ000-G7
ProductName - 1-Port Gigabit XPON Terminal
productName - GPON TP-Link XZ000-G7 MTW 1-port Gigabit GPON SFU
productSize - Normal
ShortSummaryDescription - TP-Link 1-Port Gigabit XPON Terminal, Optical network terminal (ONT), White, IEEE 802.1Q, IEEE 802.1p, IEEE 802.3u, G.984.1, G.984.3, G.984.4, 10,100,1000 Mbit/s, 1244 Mbit/s
sizeX - 100
sizeY - 90
sizeZ - 90
Standards - 802.1p
Standards - 802.1Q
Standards - 802.3
Standards - 802.3u
Sustainability - Sustainability compliance - Yes
Title - TP-Link 1-Port Gigabit XPON Terminal
URL - https://www.tp-link.com/uk/service-provider/gpon/xz000-g7/
vendpn - XZ000-G7
VLAN - 802.1Q VLAN tag, VLAN transparent mode/VLAN translation mode/VLAN link mode, serial number and password authentication, VLAN auto discovery
WarrantyInfo -
warrantyLength - 36
warrantyType - G
weight - 190
Weight & dimensions - Depth - 75 mm
Weight & dimensions - Height - 29.3 mm
Weight & dimensions - Width - 95 mm
