Brand - GIGABYTE
BrandPartCode - GV-N3070GAMING OC-8GD 2.0
Category - Graphics Cards
Category 1 - Grafikkarten
Category 2 - NVidia PCI-Express Grafikkarten
Design - Cooling technology - GIGABYTE WINDFORCE 3X
Design - Cooling type - Active
Design - Fan diameter - 8 cm
Design - Illumination - Yes
Design - Illumination colour - Multi
Design - Number of fans - 3 fan(s)
Design - Product colour - Black
EAN - 4719331309404
GTIN - 4719331309404
Logistics data - Harmonized System (HS) code - 84733020
LongDesc - WINDFORCE 3XCOOLING SYSTEMThe WINDFORCE 3X cooling system features 3X80mm unique blade fans, alternate spinning, 5 composite copper heat pipes direct touch GPU, 3D active fan and Screen cooling, which together provide high efficiency heat dissipation.ALTERNATE SPINNINGAlternate Spinning can reduce the turbulence of adjacent fans and increase air pressure.SMOOTH AIRFLOWGIGABYTE turns the adjacent fans in the opposite direction, so that the airflow direction between the two fans is the same, reducing the turbulence and enhancing the airflow pressure.3D ACTIVE FANThe 3D Active Fan provides semi-passive cooling, and the fans will remain off when the GPU is in a low load or low power game.UNIQUE BLADE FANThe airflow is spilt by the triangular fan edge, and guided smoothly through the 3D stripe curve on the fan surface.GRAPHENE NANO LUBRICANTGraphene nano lubricant can extend the life of fan by 2.1 times, close to the life of double ball bearing, and is quieter.SCREEN COOLINGExtended heatsink design allows air flow to pass through, providing better heat dissipation.HEAT PIPES DIRECT TOUCHThe shape of the pure copper heat pipe maximizes the direct contact area with the GPU. The heat pipe also covers the VRAM through a large metal plate contact to ensure proper cooling.RGB FUSION 2.0With 16.7M customizable color options and numerous lighting effects, you can choose lighting effects or synchronize with other AORUS devices.PROTECTION METAL BACK PLATEThe metal back plate not only provides an aesthetical shape, but also enhances the structure of the graphics card to provide complete protection.DUAL BIOSSilent mode will provide a quieter experience. The mode switch requires a reboot to take effect. The default is OC mode.EXTREME DURABILITY AND OVERCLOCKINGThe graphics card uses the better power phase design to allow the MOSFET to operate at lower temperature, and over-temperature protection design and load balancing for each MOSFET, plus the Ultra Durable certified chokes and capacitors, to provide excellent performance and longer system life.FRIENDLY PCB DESIGNFully automated production process ensures top quality of the circuit boards and eliminates sharp protrusions of the solder connectors seen on the conventional PCB surface. This friendly design prevents your hands from getting cut or inadvertently damaging components when making your build.AORUS ENGINEThe cutting edge intuitive interface allows you to adjust the clock speed, voltage, fan performance and power target in real-time according to your game’s requirements.
LongProductName - GeForce RTX 3070, 8GB, GDDR6, 256-bit, PCI Express 4.0 x16, 2x HDMI, 2x DP, 1x6-pin+1x 8-pin, 266x115x51 mm
LongSummaryDescription - GIGABYTE GAMING GeForce RTX 3070 OC 8G (rev. 2.0). Graphics processor family: NVIDIA, Graphics processor: GeForce RTX 3070, Processor frequency: 1815 MHz. Discrete graphics card memory: 8 GB, Graphics card memory type: GDDR6, Memory bus: 256 bit, Memory clock speed: 14000 MHz. Maximum resolution: 7680 x 4320 pixels. DirectX version: 12 Ultimate, OpenGL version: 4.6. Interface type: PCI Express x16 4.0. Cooling type: Active, Number of fans: 3 fan(s), Illumination colour: Multi
Manufacturer - Gigabyte
Memory - Discrete graphics card memory - 8 GB
Memory - Graphics card memory type - GDDR6
Memory - Memory bandwidth (max) - 448 GB/s
Memory - Memory bus - 256 bit
Memory - Memory clock speed - 14000 MHz
MPN - GV-N3070GAMING OC-8GD 2.0
Name - RTX 3070 8GB Gigabyte GAMING OC 2.0 LHR GDDR6 3Fan
Packaging content - User guide - Yes
Packaging data - Package type - Box
Performance - DirectX version - 12 Ultimate
Performance - Dual Link DVI - No
Performance - HDCP - Yes
Performance - OpenGL version - 4.6
Performance - TV tuner integrated - No
Ports & interfaces - DisplayPorts quantity - 2
Ports & interfaces - DisplayPort version - 1.4a
Ports & interfaces - HDMI ports quantity - 2
Ports & interfaces - HDMI version - 2.1
Ports & interfaces - Interface type - PCI Express x16 4.0
Power - Minimum system power supply - 650 W
Power - Supplementary power connectors - 1x 6-pin, 1x 8-pin
Processor - CUDA - Yes
Processor - CUDA cores - 5888
Processor - FireStream - No
Processor - Graphics processor - GeForce RTX 3070
Processor - Graphics processor family - NVIDIA
Processor - Maximum displays per videocard - 4
Processor - Maximum resolution - 7680 x 4320 pixels
Processor - Processor frequency - 1815 MHz
ProductName - GeForce RTX 3070 GAMING OC 8G (rev. 2.0)
ShortSummaryDescription - GIGABYTE GAMING GeForce RTX 3070 OC 8G (rev. 2.0), GeForce RTX 3070, 8 GB, GDDR6, 256 bit, 7680 x 4320 pixels, PCI Express x16 4.0
Title - GIGABYTE GAMING GeForce RTX 3070 OC 8G (rev. 2.0) NVIDIA 8 GB GDDR6
URL - https://www.gigabyte.com/Graphics-Card/GV-N3070GAMING-OC-8GD-rev-20#kf
WarrantyInfo - 4 Years Warranty (Online registration required)
Weight - 1.56
Weight & dimensions - Depth - 51 mm
Weight & dimensions - Height - 115 mm
Weight & dimensions - Length - 286 mm
