10G support Network - No
AC adapter included Packaging data - Yes
Basic switching RJ-45 Ethernet ports quantity Ports & interfaces - 8
Basic switching RJ-45 Ethernet ports type Ports & interfaces - Gigabit Ethernet (10/100/1000)
Brand - Dahua Technology
BrandPartCode - DH-PFS3008-8GT-V2
Category - Network Switches
Category Code - SWI
Certificates - Compliance certificates - CE, Federal Communications Commission (FCC)
Compliance certificates Certificates - CE, Federal Communications Commission (FCC)
Copper ethernet cabling technology Network - 10BASE-T, 100BASE-T, 1000BASE-T
Data transmission - Forwarding rate - 11.904 Mpps
Data transmission - MAC address table - 2000 entries
Data transmission - Packet buffer memory - 1.5 MB
Data transmission - Switching capacity - 16 Gbit/s
DC input voltage Power - 5 V
Depth Weight & dimensions - 133.5 mm
Description - The Device is a layer-2 commercial switch. It has a high-performance switching engine and a large buffer memory to ensure smooth video stream transmission. With a full-metal and fanless design, the Device
features great heat dissipation capability on the shell surface. The Device is an unmanaged switch, so it does not need to be configured through web interface, which simplifies installation Robust Design
Built to last, the architecture of the switch makes it highly reliable, operating with high-efficiency non-stop. Plug and Play
Hassle-free, it does not require any configuration. Simply use after it is powered on. Optimized Performance
All ports can transmit streams at high speeds without delay. Easy Installation
Both desktop and wall mount installation are supported, making it suitable for a wide variety of scenarios.Supports eight 10/100/1000 Mbps adaptive portsSmall and light, it is easy to carry and has multiple chips embedded in itEasy to operate
Design - Housing material - Metal
Design - LED indicators - Yes
Design - Product colour - Black
Design - Rack mounting - No
Forwarding rate Data transmission - 11.904 Mpps
Gigabit Ethernet (copper) ports quantity Ports & interfaces - 8
GTIN - 6923172582065
Height Weight & dimensions - 22 mm
Housing material Design - Metal
Input current Power - 1 A
LED indicators Design - Yes
LongDesc - The Device is a layer-2 commercial switch. It has a high-performance switching engine and a large buffer memory to ensure smooth video stream transmission. With a full-metal and fanless design, the Devicefeatures great heat dissipation capability on the shell surface. The Device is an unmanaged switch, so it does not need to be configured through web interface, which simplifies installationRobust DesignBuilt to last, the architecture of the switch makes it highly reliable, operating with high-efficiency non-stop.Plug and PlayHassle-free, it does not require any configuration. Simply use after it is powered on.Optimized PerformanceAll ports can transmit streams at high speeds without delay.Easy InstallationBoth desktop and wall mount installation are supported, making it suitable for a wide variety of scenarios.
LongProductName - 8 x 10/100/1000 Base-T, 16 Gbps, 11.904 Mpps, 768 kbit, 2K MAC, 0.23 kg
LongSummaryDescription - Dahua Technology Access 8-Port Unmanaged Gigabit Switch. Switch type: Unmanaged, Switch layer: L2. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 8. MAC address table: 2000 entries, Switching capacity: 16 Gbit/s. DC input voltage: 5 V. Power connector: DC-in jack
MAC address table Data transmission - 2000 entries
Management features - Switch layer - L2
Management features - Switch type - Unmanaged
Mean time between failures (MTBF) Performance - 5051758.14 h
Model name - PFS3008-8GT-V2
Network - 10G support - No
Network - Copper ethernet cabling technology - 10BASE-T, 100BASE-T, 1000BASE-T
Operating relative humidity (H-H) Operational conditions - 5 - 95%
Operating temperature (T-T) Operational conditions - 0 - 45 °C
Operational conditions - Operating relative humidity (H-H) - 5 - 95%
Operational conditions - Operating temperature (T-T) - 0 - 45 °C
Operational conditions - Storage relative humidity (H-H) - 5 - 95%
Operational conditions - Storage temperature (T-T) - -40 - 70 °C
Package depth Packaging data - 136 mm
Package height Packaging data - 153 mm
Package weight Packaging data - 350 g
Package width Packaging data - 55 mm
Packaging data - Package depth - 136 mm
Packaging data - Package height - 153 mm
Packaging data - Package weight - 350 g
Packaging data - Package width - 55 mm
Packet buffer memory Data transmission - 1.5 MB
Performance - Mean time between failures (MTBF) - 5051758.14 h
Ports & interfaces - Basic switching RJ-45 Ethernet ports quantity - 8
Ports & interfaces - Basic switching RJ-45 Ethernet ports type - Gigabit Ethernet (10/100/1000)
Ports & interfaces - Gigabit Ethernet (copper) ports quantity - 8
Ports & interfaces - Power connector - DC-in jack
Power - DC input voltage - 5 V
Power - Input current - 1 A
Power - Power consumption (max) - 3 W
Power connector Ports & interfaces - DC-in jack
Power consumption (max) Power - 3 W
Power over Ethernet (PoE) - Power over Ethernet (PoE) - No
Power over Ethernet (PoE) Power over Ethernet (PoE) - No
Product colour Design - Black
ProductName - 8-Port Unmanaged Gigabit Switch
Rack mounting Design - No
ShortSummaryDescription - Dahua Technology Access 8-Port Unmanaged Gigabit Switch, Unmanaged, L2, Gigabit Ethernet (10/100/1000)
Storage relative humidity (H-H) Operational conditions - 5 - 95%
Storage temperature (T-T) Operational conditions - -40 - 70 °C
Summary - Dahua Technology Access 8-Port Unmanaged Gigabit Switch. Switch type: Unmanaged, Switch layer: L2. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 8. MAC address table: 2000 entries, Switching capacity: 16 Gbit/s. DC input voltage: 5 V. Power connector: DC-in jack
Sustainability - Sustainability compliance - Yes
Sustainability compliance Sustainability - Yes
Switching capacity Data transmission - 16 Gbit/s
Switch layer Management features - L2
Switch type Management features - Unmanaged
Title - Dahua Technology Access 8-Port Unmanaged Gigabit Switch
Unit Box Height - 0.055
Unit Box Length - 0.155
Unit Box Width - 0.14
Unit Calculated Volume - 0.001193 cubm
Unit Calculated Weight - 0.306 kg
Units per Shipping Box - 1
URL - https://www.dahuasecurity.com/products/All-Products/Transmission/Access-Switches/Metal/PFS3008-8GT
Vendor Homepage - https://www.dahuasecurity.com/products/All-Products/Transmission/Access-Switches/Metal/PFS3008-8GT
Warranty - 36 months
WarrantyInfo -
Weight & dimensions - Depth - 133.5 mm
Weight & dimensions - Height - 22 mm
Weight & dimensions - Weight - 230 g
Weight & dimensions - Width - 56 mm
Weight Weight & dimensions - 230 g
Width Weight & dimensions - 56 mm
