Ubiquiti USW-Enterprise-48-PoE, 48x2,5 Gb, 4x 10G SFP+

10G support Network - Yes
Accessories included -
AC input frequency Power - 50 - 60 Hz
AC input voltage Power - 100 - 240 V
Application - Medium and large companies
Basic switching RJ-45 Ethernet ports quantity Ports & interfaces - 48
Basic switching RJ-45 Ethernet ports type Ports & interfaces - 2.5G Ethernet (100/1000/2500)
brand - Ubiquiti
category - Mājas un biroju tīkli > Komutatori > PoE komutatori
Category 1 - Netzwerk
Category 2 - Switching Hubs
Category Code - SWI
Category_1 - Network and Servers
Category_2 - Network - Switches and Hubs
Certificates - Compliance certificates - CE
Chassis type - Rack
Code - USW-Enterprise-48-PoE
Compliance certificates Certificates - CE
Data transmission - Forwarding rate - 238.095 Mpps
Data transmission - Switching capacity - 360 Gbit/s
Data transmission - Throughput - 160 Gbit/s
Data transmission > Maximum data transfer rate - 320 Gbit/s
DC input voltage Power - 52 V
Depth Weight & dimensions - 400 mm
Description - Switch Enterprise 48 PoE (USW Enterprise 48 PoE) to w pełni zarządzalny przełącznik z (48) portami 2.5GbE, 802.3at PoE+ RJ45, (4) portami 10G SFP+ i całkowitym zasilaniem PoE 720 W. Oprócz funkcjonalności warstwy 3 przełącznik ten oferuje szeroki zestaw protokołów przełączania warstwy 2, w tym tryby pracy specyficzne dla portów (przełączanie, dublowanie, lub zagregowane). USW Enterprise 48 PoE jest również wyposażony w kolorowy ekran dotykowy LCM o przekątnej 1,3 cala, który w zwięzły sposób wyświetla kluczowe informacje o systemie i połączeniach. Redundantne zasilanie i nowy system chłodzenia
Zmodernizowany system chłodzenia USW-Enterprise-48-PoE pracuje przy minimalnym poziomie hałasu. Wielofunkcyjny kolorowy wyświetlacz dotykowy pokazuje w czasie rzeczywistym informacje o ogólnym stanie przełącznika i dostarcza informacji o podłączonych urządzeniach za pomocą narzędzi rzeczywistości rozszerzonej. Redundancja zasilania przełącznika z UniFi SmartPower Redundant Power System zapewnia dodatkową ochronę przed przerwami w dostawie prądu. Kolorowy ekran dotykowy 1,3" LCM z zarządzaniem przełącznikami AR Porty RJ45 2.5GbE, 802.3at PoE+ RJ45 porty 10G SFP+ wejście USP RPS DC PoE 720 W Funkcje przełączania w warstwie 3
Description - The Switch Enterprise 48 PoE (USW Enterprise 48 PoE) is a fully managed switch with (48) 2.5GbE, 802.3at PoE+ RJ45 ports, (4) 10G SFP+ ports, and a 720W total PoE supply. Along with its Layer 3 functionality, this switch offers an extensive suite of Layer 2 switching protocols, including port-specific operation modes (switching, mirroring, or aggregate).The USW Enterprise 48 PoE also features a 1.3" LCM color touchscreen that concisely displays key system and connection insights. Additionally, the USW Enterprise 48 PoE offers enhanced power supply failure protection when connected to the SmartPower Redundant Power System (USP RPS sold separately). This switch can be monitored or configured from anywhere with the powerful, intuitive UniFi Network web application and mobile app.(1) 1.3" LCM color touchscreen with AR switch management(48) 2.5GbE, 802.3at PoE+ RJ45 ports(4) 10G SFP+ ports(1) USP RPS DC input720W total PoE supplyLayer 3 switching features
Design - Housing material - Steel
Design - Product colour - White
Design - Reset button - Yes
Design > Form factor - Rackmountable
Design > Housing material - SGCC steel
Designation - CE+WEEE
dimensionalWeight - 7300
dimension depth - 510 mm
dimension height - 540 mm
Dimensions - 442 x 44 x 400 mm
dimension weight - 8000 g
dimension width - 130 mm
EAN - 810010074768
ean - 810010074768
EAN - 0810010074768
EAN_code - 0810010074768
Fan - Yes
Forwarding rate - 238.095 Mpps
Forwarding rate Data transmission - 238.095 Mpps
Gross Weight Kg - 6,5
guarantee - 12
guarantee_type - normal
Harmonized System (HS) code Logistics data - 85176990
height - 0.15 m
Height Weight & dimensions - 44 mm
Housing material Design - Steel
Input current Power - 10 A
L2 features -
L3 features -
length - 0.54 m
Link - https://store.ui.com/collections/unifi-network-switching/products/switch-enterprise-48-poe
Logistics data - Harmonized System (HS) code - 85176990
Management, monitoring, configuration -
Management features - Switch layer - L3
Management features - Switch type - Managed
Management features - Web-based management - Yes
Management features > Reset button - Yes (Factory Reset)
Management features > Switch type - Managed L3
Manufacturer - Ubiquiti
Manufacturer Code - USW-ENTERPRISE-48-POE
Manufacturer Name - Ubiquiti Networks
Manufacturer_code - USW-Enterprise-48-PoE
Model name - ENTERPRISE-48-POE
mpn - USW-Enterprise-48-PoE
MPN - USW-ENTERPRISE-48-POE
Name - 48+4P UbiQuiti Unifi USW-ENTERPRISE-48-POE 720W POE+ M RM
name - SW 48x2,5G 4x10G USW-ENTERPRISE-48-PO
Name - Ubiquiti Unifi USW-Enterprise-48-PoE, Switch
Name - Ubiquiti | Switch Enterprise 48 PoE | USW-Enterprise-48-PoE | Managed L3 | Rackmountable | Gigabit Ethernet (copper) ports quantity 48 (100MbE/1GbE/2.5GbE) | SFP+ ports quantity 4 | PoE+ ports quantity 48 | Power supply type AC/DC, internal, 100-240V, 10A max, 750W
Network - 10G support - Yes
Network - Networking standards - IEEE 802.3af
Network - Networking standards - IEEE 802.3at
Network architecture - GigabitEthernet
Networking standards Network - IEEE 802.3af, IEEE 802.3at
Number of 10/100/1000 Mbps ports - 48
Number of PoE ports (PoE & PoE+) - 48
Number of SFP+ ports - 4
Operating relative humidity (H-H) Operational conditions - 10 - 90%
Operating temperature (T-T) Operational conditions - -5 - 40 °C
Operational conditions - Operating relative humidity (H-H) - 10 - 90%
Operational conditions - Operating temperature (T-T) - -5 - 40 °C
Operational conditions > Operating relative humidity (H-H) - 10 - 90% Noncondensing %
Operational conditions > Operating temperature (T-T) - -5 to 40° C °C
Other features -
Other features > Power supply type - AC/DC, internal, 100-240V, 10A max, 750W
Other functions -
Package features > Embeeded battery - No
Package features > Gross depth (mm) - 540 mm
Package features > Gross depth master carton - 550 mm
Package features > Gross height (mm) - 520 mm
Package features > Gross height master carton - 545 mm
Package features > Gross width (mm) - 120 mm
Package features > Gross width master carton - 260 mm
Package features > Net weight master carton - 16 kg
Package features > Packing quantity - 2 pc(s)
Package features > Palette Qty - 44 pc(s)
Package features > Paper/Pasteboard - 158.85 g
Package features > Plastic (No PET) - 17.65 g
Package features > Tare weight (kg) - 1.77 kg
Package features > Tare weight master carton - 1.325 kg
Package features > Volume (m3) - 0.033696 m³
Package features > WEE classification - CL109:6:2017-04-01
Package features > WEEE tax - Yes
Performance > Certification - CE, FCC, IC
Ports & interfaces - Basic switching RJ-45 Ethernet ports quantity - 48
Ports & interfaces - Basic switching RJ-45 Ethernet ports type - 2.5G Ethernet (100/1000/2500)
Ports & interfaces - SFP+ module slots quantity - 4
Ports & interfaces > Gigabit Ethernet (copper) ports quantity - 48 (100MbE/1GbE/2.5GbE)
Ports & interfaces > POE - PoE 802.3 af and PoE+ 802.3 at
Ports & interfaces > PoE+ ports quantity - 48
Ports & interfaces > Predominant port type - 10/100/1000/2500 Mbps (RJ-45)
Ports & interfaces > SFP+ ports quantity - 4
Power - AC input frequency - 50 - 60 Hz
Power - AC input voltage - 100 - 240 V
Power - DC input voltage - 52 V
Power - Input current - 10 A
Power - Power source - AC/DC
Power - Redundant power supply (RPS) support - Yes
Power > Power consumption (max) - 150 W
Power consumption - 150 W
Power over Ethernet (PoE) - Power over Ethernet (PoE) - No
Power over Ethernet (PoE) > Total Power over Ethernet (PoE) budget - 720 W
Power over Ethernet (PoE) Power over Ethernet (PoE) - No
Power source Power - AC/DC
Power supply - Uniwersalne wejście AC, 100-240VAC, 10A maks., 50/60 Hz Wejście DC USP-RPS, 52VDC, 13.84A; 11,5 V DC, 13 A Całkowite zasilanie PoE 720 W Maks. Moc PoE+ na port według PSE 34,2 W
Power supply - External
Power supply - Internal
producer - UBIQUITI
producerCode - USW-Enterprise-48-PoE
Producer product family - Switch Enterprise 48 PoE
Producer product name - USW-Enterprise-48-PoE
Product colour Design - White
productName - Ubiquiti UniFi USW-ENTERPRISE-48-POE network switch Managed L3 2.5G Ethernet (100/1000/2500) White
productSize - Normal
QoS -
Redundant power supply (RPS) support Power - Yes
Reset button Design - Yes
Safety warning - Warnings - Avoid contact of the device with liquid.
Safety warning - Warnings - Follow the safety guidelines for electrical current.
Safety warning - Warnings - Make sure the ventilation of the equipment is not blocked.
Security -
SFP+ module slots quantity Ports & interfaces - 4
Short description - Ubiquiti Switch UniFi 48xRJ45 2,5G/4xSFP+ 10G Managed PoE+ 19" Rack-Mountable, 1,3" Touchscreen, 720W PoE+
sizeX - 130
sizeY - 540
sizeZ - 520
Summary - Ubiquiti UniFi USW-ENTERPRISE-48-POE. Switch type: Managed, Switch layer: L3. Basic switching RJ-45 Ethernet ports type: 2.5G Ethernet (100/1000/2500), Basic switching RJ-45 Ethernet ports quantity: 48. Switching capacity: 360 Gbit/s. Networking standards: IEEE 802.3af, IEEE 802.3at. DC input voltage: 52 V
Supported protocols and standards - IEEE 802.3af/at (pins 1, 2+; 3, 6)
Support for Jumbo frames - No
Switch class - Managed
Switching capacity Data transmission - 360 Gbit/s
Switch layer - L3
Switch layer Management features - L3
Switch type Management features - Managed
Technical details > Gross weight - 8 kg
Technical details > Net weight - 6.235 kg
Technical details > Producer - Ubiquiti
Technical details > Software type - UniFi Network application: Version 6.2.26 and later
Throughput - 160 Gb/s
Throughput Data transmission - 160 Gbit/s
title - Ubiquiti UniFi Switch Enterprise 48 PoE
Unit Box Height - 0.125
Unit Box Length - 0.54
Unit Box Width - 0.26
Unit Calculated Volume - 0.01755 cubm
Unit Calculated Weight - 8.1 kg
Units per Shipping Box - 2
Vendor Homepage - https://eu.store.ui.com/collections/unifi-network-routing-switching/products/switch-enterprise-48-poe
vendpn - USW-ENTERPRISE-48-POE
VLAN -
Warranty - 12
Warranty - 12 month(s)
Warranty - 12 months
warrantyLength - 24
warrantyType - G
Web-based management Management features - Yes
Weight - 6.2 kg
Weight - 7,95
Weight - 7.98
weight - 8.8 kg
weight - 8115
Weight & dimensions - Depth - 400 mm
Weight & dimensions - Height - 44 mm
Weight & dimensions - Weight - 6.2 kg
Weight & dimensions - Width - 442 mm
Weight Weight & dimensions - 6.2 kg
width - 0.52 m
Width Weight & dimensions - 442 mm
