ARTIKEL1 - 4-PORT ACS800 SERIAL CONSOLE
ARTIKEL2 - W/ ANALOG MODEM EXTERNAL AC/DC
Brand - Vertiv
BrandPartCode - ACS804MEAC-404
Category - Console Servers
Certificates - Certification - FCC Class A, CE Class A (EU), ICES-003 (Canada), VCCI (Japan), RCM (Australia), Customs Union (CU), KCC (Korea)
EANCode - 0636430087436
Gewicht - 1.94
GRUPPE1 - Cables
GRUPPE2 - Usb Cable
GTIN - 0636430087436
GTIN - 636430087436
HERSTELLER - VERTIV
HSTNUMMER - ACS804MEAC-404
LongDesc - The Vertiv Avocent ACS 800 serial console system takes our renowned enterprise class technologies utilized in data centers around the world and packages the key features into an exciting compact and cost effective form factor. Providing serial access, environmental monitoring, IoT integration and remote networking capability to the Edge oriented market sectors of financial institutions, retail chains, education and others.\n\nRegional IT managers and facility engineers will benefit with the ability to perform secure, remote management and out-of-band management of IT assets from anywhere in the world. Featuring a dual-core ARM processor architecture with expanded memory capabilities, RS232/RS485/RS422 serial access, USB, Gigabit Ethernet and environmental sensor access, the Yochto project based Linux operating system and available DSView™ management software, provides the Avocent ACS 800 optimal performance, security, reliability for a complete out-of-band management solution.\n\n- Support for Liebert GXT4 UPS systems and Rack PDUs from Vertiv, ServerTech, APC, Raritan and Eaton\n- 4 USB ports to support new IT equipment and external devices\n- Console event logging and notification, including “last gasp” capture\n- Regulatory compliance and easy troubleshooting – online and off-line data logging with time stamps\n- Strong dial-up and secure dial-back using optional built-in modem\n- Environmental sensor port to connect temperature, humidity, differential pressure, leak, door pin sensors (up to 8 can be daisy chained)
LongProductName - 4-Port ACS800 Serial Console with analog modem, external AC/DC Power Brick - Jumper cord: Plug C14 to connector C13
LongSummaryDescription - Vertiv Avocent 4-Port ACS800 Serial Console with analog modem, external AC/DC Power Brick - Jumper cord: Plug C14 to connector C13. Management protocols: CLI, HTTP/HTTPS, SNMP. Authentication method: LOCAL, RADIUS, LDAP, TACACS+ and ONE TIME PASSWORD(OTP), Security algorithms: 3DES, 128-bit AES, 192-bit AES, 256-bit AES, FIPS 140-2, HTTPS, IPSec, SHA-256, SNMP, SNMPv3, SSH,.... Console port: RJ-45. Operating system installed: Embedded LINUX. Dimensions (WxDxH): 212.6 x 181.9 x 29.5 mm, Weight: 1.09 kg
Management features - Management protocols - CLI, HTTP/HTTPS, SNMP
Memory - Card reader integrated - No
Memory - eMMC capacity - 16 GB
Memory - Flash memory - 16000 MB
Memory - RAM capacity - 1024 MB
Memory - RAM type - DDR3L
Network - Cable types supported - Cat5, Cat5e, Cat6, Cat6+, Cat6a, Cat6e, Cat7, Fiber
Network - Copper ethernet cabling technology - 10BASE-T, 100BASE-T, 1000BASE-T
Network - IP forwarding support - Yes
Network - Supported network protocols - IPv6
Operational conditions - Operating relative humidity (H-H) - 20 - 80%
Operational conditions - Operating temperature (T-T) - 0 - 70 °C
Operational conditions - Storage relative humidity (H-H) - 5 - 95%
Operational conditions - Storage temperature (T-T) - -20 - 90 °C
Other features - Safety - UL (USA), cUL (CANADA), EN-60950 (EU), CB, Customs Union (CU)
Ports & interfaces - Console port - RJ-45
Ports & interfaces - Ethernet LAN (RJ-45) ports - 2
Ports & interfaces - Serial ports quantity - 4
Ports & interfaces - USB 2.0 ports quantity - 4
Power - AC input frequency - 50 - 60 Hz
Power - AC input voltage - 100 - 240 V
Power - DC input voltage - 12 V
Power - Number of power supply units - 1
Power - Power consumption (max) - 28 W
Power - Power consumption (typical) - 7 W
Power - Power source type - AC, DC
Processor - Processor architecture - ARM Cortex-A9
Processor - Processor cores - 2
Processor - Processor family - ARM Cortex-A9
Processor - Processor frequency - 667 MHz
ProductName - 4-Port ACS800 Serial Console with analog modem, external AC/DC Power Brick - Jumper cord: Plug C14 to connector C13
Security - Authentication method - LOCAL, RADIUS, LDAP, TACACS+ and ONE TIME PASSWORD(OTP)
Security - IP address filtering - Yes
Security - One-time password (OTP) - Yes
Security - RSA SecurID - Yes
Security - Security algorithms - 3DES, 128-bit AES, 192-bit AES, 256-bit AES, FIPS 140-2, HTTPS, IPSec, SHA-256, SNMP, SNMPv3, SSH, SSH-2
ShortSummaryDescription - Vertiv Avocent 4-Port ACS800 Serial Console with analog modem, external AC/DC Power Brick - Jumper cord: Plug C14 to connector C13, CLI, HTTP/HTTPS, SNMP, LOCAL, RADIUS, LDAP, TACACS+ and ONE TIME PASSWORD(OTP), 3DES, 128-bit AES, 192-bit AES, 256-bit AES, FIPS 140-2, HTTPS, IPSec, SHA-256, SNMP, SNMPv3, SSH,..., RJ-45, Embedded LINUX, 212.6 x 181.9 x 29.5 mm
Software - Operating system installed - Embedded LINUX
Stck_Kart - 10
Stck_Pal - 0
Storno - Y
Technical details - Event logging - Yes
Technical details - Internal modem - Yes
Technical details - Product colour - Black
Technical details - Rack mounting - Yes
Technical details - Temperature sensor - Yes
Technical details - Web-based management - Yes
Technical details - Zero Touch Provisioning (ZTP) - Yes
Title - Vertiv Avocent 4-Port ACS800 Serial Console with analog modem, external AC/DC Power Brick - Jumper cord: Plug C14 to connector C13
URL - https://www.vertiv.com/
WarrantyInfo -
Weight & dimensions - Dimensions (WxDxH) - 212.6 x 181.9 x 29.5 mm
Weight & dimensions - Weight - 1.09 kg
