Digitus DN-80114 8-port

Accessories included - Quick guide Power cable Mounting accessories
Application - Home and small office
ARTIKEL1 - 8-PORT GIGABIT ETHERNET SWITCH
ARTIKEL2 - 10IN 8X10/100/1000MBPS RJ45
Category_1 - Network and Servers
Category_2 - Network - Switches and Hubs
Chassis type - Desktop
Chassis type - Rack
Code - DN-80114
Description - Switch 10 "8-port GigabitEthernet 8x10 / 100 / 1000Mbps RJ45, integrated power supply, rack ears.
Thanks to the compact size, the switch can be built into a 10-inch rack cabinet. Mounting ears are included with the product.
Design > Form factor - Rackmountable
Designation - CE+WEEE
dimension depth - 60 mm
dimension height - 237 mm
Dimensions - (length x width x height): 150 x 250 x 42mm
dimension weight - 1299 g
dimension width - 310 mm
EAN - 4016032441007
ean - 4016032441007
EANCode - 4016032441007
EAN_code - 4016032441007
Fan - No
Forwarding mode - Store-and-forward
Gewicht - 1.27
GRUPPE1 - Network
GRUPPE2 - Lan Switch Unmanaged
guarantee - 24
guarantee_type - external
HERSTELLER - DIGITUS
HSTNUMMER - DN-80114
Link - https://www.assmann.com/en/products/active-network-components/network-switches/10-network-switches/dn-80114/
Management features > Switch type - Unmanaged
Manufacturer - Digitus
Manufacturer_code - DN-80114
Name - Digitus DN-80114, switch
Name - Digitus | 8-port Gigabit Ethernet Switch | DN-80114 | Unmanaged | Rackmountable | Power supply type Internal
name - Switch 10 inches Rack 8-port GigabitEthernet, 8x10/100/1000Mbps
Network architecture - GigabitEthernet
Number of 10/100/1000 Mbps ports - 8
Other features - Automatic speed setting and full and half duplex recognition 20/200/2000Mbit in full-duplex mode Auto MDI / MDI-X function Mounting plate with 16Gbps bandwidth Supports up to 8,000 MAC addresses Working temperature: 0°C - 40°C
Other features > Power supply type - Internal
Package features > Embeeded battery - No
Package features > Gross depth (mm) - 315 mm
Package features > Gross depth master carton - 500 mm
Package features > Gross height (mm) - 235 mm
Package features > Gross height master carton - 350 mm
Package features > Gross width (mm) - 60 mm
Package features > Gross width master carton - 340 mm
Package features > Net weight master carton - 12.5 kg
Package features > Packing quantity - 10 pc(s)
Package features > Palette Qty - 290 pc(s)
Package features > Paper/Pasteboard - 23 g
Package features > Plastic (No PET) - 3 g
Package features > Tare weight (kg) - 0.03 kg
Package features > Tare weight master carton - 1.012 kg
Package features > Volume (m3) - 0.0044415 m³
Package features > WEE classification - CL109:6:2017-04-01
Package features > WEEE tax - Yes
Ports & interfaces > Ethernet LAN (RJ-45) ports - 8
Ports & interfaces > POE - No
Ports & interfaces > Predominant port type - 10/100/1000 Mbps (RJ-45)
Power consumption - 5 W
Power supply - Integrated power supply Power consumption: 5W
Power supply - Internal
producer - Digitus
Producer product family - 8-port Gigabit Ethernet Switch
Producer product name - DN-80114
Stck_Kart - 10
Stck_Pal - 9998
Storno - Y
Supported protocols and standards - Meets the standards of IEEE 802.3, IEEE 802.3u, IEEE 802.3ab and IEEE 802.3x networks Supports non-blocking and non-head-of-line architecture Store and forward technology that guarantees optimal data transfer
Switch class - Unmanaged
Switch layer - L2
Technical details > Gross weight - 1.25 kg
Technical details > Net weight - 1.224 kg
Technical details > Other features - Installation type: 10 inch, Desktop
Technical details > Producer - Digitus
vendpn - DN-80114
Warranty - 24
Warranty - 24 month(s)
Weight - 1,30
Wireless LAN features > Wi-Fi standards - 802.3 u/ab/x
