ARTIKEL1 - 10-PORT 1G EASY MANAGED SWITCH
ARTIKEL2 - 63 W POE POWER WITH 8-PORT POE+
Brand - TP-Link
BrandPartCode - ES210GP
Breite - 0
Category - Network Switches
Certificates - Compliance certificates - CE, Federal Communications Commission (FCC), RoHS
Data transmission - Forwarding rate - 14.88 Mpps
Data transmission - Jumbo frames - 15000
Data transmission - Jumbo frames support - Yes
Data transmission - MAC address table - 8000 entries
Data transmission - Packet buffer memory - 0.5 MB
Data transmission - Store-and-forward - Yes
Data transmission - Switching capacity - 20 Gbit/s
Design - Form factor - DIN rail
Design - LED indicators - Yes
Design - Product colour - Black
Design - Rack mounting - Yes
EAN - 1210002609722
EANCode - 1210002609722
Gross Weight Kg - 3,5
GRUPPE1 - Network
GRUPPE2 - Switches Managed
GTIN - 0840460603614
GTIN - 840460603614
GTIN - 1210002609722
HERSTELLER - TP-LINK
Hoehe - 0
HSTNUMMER - ES210GP
Laenge - 0
LongDesc -
LongProductName - 8× PoE+, 1× RJ45, 1× RJ45/SFP Combo, 63W Total PoE, 209 × 126 × 26 mm
LongSummaryDescription - TP-Link Omada ES210GP. Switch type: Managed, Switch layer: L2. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 10. MAC address table: 8000 entries, Switching capacity: 20 Gbit/s. Networking standards: IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt. DC input voltage: 53 V. Power over Ethernet (PoE). Rack mounting, Form factor: DIN rail
Management features - Cloud-managed - Yes
Management features - Quality of Service (QoS) support - Yes
Management features - Switch layer - L2
Management features - Switch type - Managed
Management features - Web-based management - Yes
Manufacturer Code - ES210GP
Manufacturer Name - TP-LINK
Multicast features - Multicast support - Yes
Network - 10G support - No
Network - Auto-negotiation - Yes
Network - Auto MDI/MDI-X - Yes
Network - Broadcast storm control - Yes
Network - Ethernet LAN data rates - 10,100,1000 Mbit/s
Network - Flow control support - Yes
Network - Link aggregation - Yes
Network - Networking standards - IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt
Network - Number of VLANs - 4000
Network - Port mirroring - Yes
Network - Virtual LAN features - MTU VLAN, Port-based VLAN, Tagged VLAN
Network - VLAN support - Yes
Operational conditions - Operating relative humidity (H-H) - 10 - 90%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Operational conditions - Storage relative humidity (H-H) - 5 - 90%
Operational conditions - Storage temperature (T-T) - -40 - 70 °C
Optical fiber - Transmission distance (max) - 0.25 km
Packaging content - Cables included - Power
Packaging content - Quick start guide - Yes
Ports & interfaces - Basic switching RJ-45 Ethernet ports quantity - 10
Ports & interfaces - Basic switching RJ-45 Ethernet ports type - Gigabit Ethernet (10/100/1000)
Ports & interfaces - Combo SFP ports quantity - 1
Power - DC input voltage - 53 V
Power - Input current - 1.31 A
Power - Power source - DC
Power over Ethernet (PoE) - Power over Ethernet (PoE) - Yes
Power over Ethernet (PoE) - Power over Ethernet (PoE) type supported - PoE+
Power over Ethernet (PoE) - Power over Ethernet plus (PoE+) ports quantity - 8
Power over Ethernet (PoE) - Total Power over Ethernet (PoE) budget - 63 W
ProductName - ES210GP
Security - DHCP features - DHCP client
Security - IGMP snooping - Yes
Security - Loop protection - Yes
Short description - TP-LINK Switch Omada ES210GP 10xGBit 8xPoE+ Managed
ShortSummaryDescription - TP-Link Omada ES210GP, Managed, L2, Gigabit Ethernet (10/100/1000), Power over Ethernet (PoE), Rack mounting, DIN rail
Stck_Kart - 9998
Stck_Pal - 0
Storno - Y
Title - TP-Link Omada ES210GP network switch Managed L2 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) DIN rail Black
URL - https://www.omadanetworks.com/my/business-networking/omada-switch-agile/es210gp/#specifications
WarrantyInfo -
Weight & dimensions - Depth - 126 mm
Weight & dimensions - Height - 26 mm
Weight & dimensions - Width - 209 mm
