10G support Network - No
AC input frequency Power - 47/63 Hz
AC input voltage Power - 100 - 240 V
Basic switching RJ-45 Ethernet ports quantity Ports & interfaces - 18
Basic switching RJ-45 Ethernet ports type Ports & interfaces - Gigabit Ethernet (10/100/1000)
Brand - Dahua Technology
BrandPartCode - CS4220-16GT-135
Category - Network Switches
Category Code - SWI
Cloud-managed Management features - Yes
Data transmission - Forwarding rate - 29.76 Mpps
Data transmission - Jumbo frames - 15000
Data transmission - Jumbo frames support - Yes
Data transmission - MAC address table - 8000 entries
Data transmission - Packet buffer memory - 4 MB
Data transmission - Switching capacity - 40 Gbit/s
Depth Weight & dimensions - 220 mm
Description - 20-Port Cloud Managed Desktop Gigabit Switch with 16-Port PoEMeets the requirements of IEEE802.3,IEEE802.3u,IEEE802.3x,IEEE802.3ab,IEEE802.3z standardsMeets the requirements of IEEE802.3af, IEEE802.3at, Hi-PoE, and IEEE802.3bt power supply standardsManages PoE power consumption and PoE power on/off. Supports Intelligent PoEA wide operating temperature range and a full metal casing that is fully-enclosed and dust-proof
Design - Housing material - Metal
Design - Product colour - Black
Design - Rack mounting - Yes
Design - Reset button - Yes
DHCP features Security - DHCP client
Ethernet LAN data rates Network - 10,100,1000 Mbit/s
Flow control support Network - Yes
Forwarding rate Data transmission - 29.76 Mpps
Gigabit Ethernet (copper) ports quantity Ports & interfaces - 18
Height Weight & dimensions - 44 mm
Housing material Design - Metal
Input current Power - 3 A
Jumbo frames Data transmission - 15000
Jumbo frames support Data transmission - Yes
LongDesc - 20-Port Cloud Managed Desktop Gigabit Switch with 16-Port PoE
LongProductName - Gigabit Ethernet, Layer 2, 40 Gbps, 29.76 Mpps, PoE, 2.26 kg
LongSummaryDescription - Dahua Technology CS4220-16GT-135. Switch type: Managed, Switch layer: L2. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 18. MAC address table: 8000 entries, Switching capacity: 40 Gbit/s. Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt, IEEE 802.3u, IEEE 802.3x, IEEE.... Power over Ethernet (PoE). Rack mounting
MAC address table Data transmission - 8000 entries
Management features - Cloud-managed - Yes
Management features - Switch layer - L2
Management features - Switch type - Managed
Management features - Web-based management - Yes
Network - 10G support - No
Network - Ethernet LAN data rates - 10,100,1000 Mbit/s
Network - Flow control support - Yes
Network - Networking standards - IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Network - Number of VLANs - 32
Network - VLAN support - Yes
Networking standards Network - IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Number of VLANs Network - 32
Operating relative humidity (H-H) Operational conditions - 5 - 95%
Operating temperature (T-T) Operational conditions - -10 - 55 °C
Operational conditions - Operating relative humidity (H-H) - 5 - 95%
Operational conditions - Operating temperature (T-T) - -10 - 55 °C
Operational conditions - Storage relative humidity (H-H) - 5 - 95%
Operational conditions - Storage temperature (T-T) - -40 - 70 °C
Package depth Packaging data - 342 mm
Package height Packaging data - 90 mm
Package weight Packaging data - 2.91 kg
Package width Packaging data - 540 mm
Packaging data - Package depth - 342 mm
Packaging data - Package height - 90 mm
Packaging data - Package weight - 2.91 kg
Packaging data - Package width - 540 mm
Packet buffer memory Data transmission - 4 MB
Ports & interfaces - Basic switching RJ-45 Ethernet ports quantity - 18
Ports & interfaces - Basic switching RJ-45 Ethernet ports type - Gigabit Ethernet (10/100/1000)
Ports & interfaces - Gigabit Ethernet (copper) ports quantity - 18
Ports & interfaces - SFP module slots quantity - 2
Power - AC input frequency - 47/63 Hz
Power - AC input voltage - 100 - 240 V
Power - Input current - 3 A
Power - Power consumption (typical) - 154 W
Power - Power source - AC
Power consumption (typical) Power - 154 W
Power over Ethernet (PoE) - Power over Ethernet (PoE) - Yes
Power over Ethernet (PoE) - Power over Ethernet (PoE) ports quantity - 16
Power over Ethernet (PoE) - Total Power over Ethernet (PoE) budget - 135 W
Power over Ethernet (PoE) ports quantity Power over Ethernet (PoE) - 16
Power over Ethernet (PoE) Power over Ethernet (PoE) - Yes
Power source Power - AC
Product colour Design - Black
ProductName - CS4220-16GT-135
Rack mounting Design - Yes
Reset button Design - Yes
Security - DHCP features - DHCP client
SFP module slots quantity Ports & interfaces - 2
ShortSummaryDescription - Dahua Technology CS4220-16GT-135, Managed, L2, Gigabit Ethernet (10/100/1000), Power over Ethernet (PoE), Rack mounting
Storage relative humidity (H-H) Operational conditions - 5 - 95%
Storage temperature (T-T) Operational conditions - -40 - 70 °C
Summary - Dahua Technology CS4220-16GT-135. Switch type: Managed, Switch layer: L2. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 18. MAC address table: 8000 entries, Switching capacity: 40 Gbit/s. Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt, IEEE 802.3u, IEEE 802.3x, IEEE.... Power over Ethernet (PoE). Rack mounting
Switching capacity Data transmission - 40 Gbit/s
Switch layer Management features - L2
Switch type Management features - Managed
Title - Dahua Technology CS4220-16GT-135 network switch Managed L2 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Black
Total Power over Ethernet (PoE) budget Power over Ethernet (PoE) - 135 W
Unit Box Height - 0.345
Unit Box Length - 0.535
Unit Box Width - 0.09
Unit Calculated Volume - 0.01661 cubm
Unit Calculated Weight - 3.15 kg
Units per Shipping Box - 1
URL - https://www.dahuasecurity.com/la/products/All-Products/Transmission/Cloud-Managed-Switches/CS4220-16GT-135
Vendor Homepage - https://www.dahuasecurity.com/la/products/All-Products/Transmission/Cloud-Managed-Switches/CS4220-16GT-135
VLAN support Network - Yes
Warranty - 36 months
WarrantyInfo -
Web-based management Management features - Yes
Weight & dimensions - Depth - 220 mm
Weight & dimensions - Height - 44 mm
Weight & dimensions - Weight - 2.26 kg
Weight & dimensions - Width - 440 mm
Weight Weight & dimensions - 2.26 kg
Width Weight & dimensions - 440 mm
