Ubiquiti Switch full managed Layer3 28 Port USW-Pro-HD-24-PoE

2.5GbE Ports - 22
10/100/1000/2500 Mbps ports - 22
10GbE Ports - 2
Accessories included -
Application - Medium and large companies
brand - Ubiquiti
category - Mājas un biroju tīkli > Komutatori > PoE komutatori
Category 1 - Netzwerk
Category 2 - Switching Hubs
Category Code - SWI
Certificates - CE, FCC, IC
Certificates - Compliance certificates - CE
Certificates - Compliance certificates - Federal Communications Commission (FCC)
Certificates - Compliance certificates - Industry Canada (IC)
Chassis type - Rack
Console port - No
Data transmission - Forwarding rate - 171 Mpps
Data transmission - Jumbo frames support - Yes
Data transmission - MAC address table - 32000 entries
Data transmission - Packet buffer memory - 2 MB
Data transmission - Static route - Yes
Data transmission - Switching capacity - 230 Gbit/s
Data transmission - Throughput - 115 Gbit/s
Description - Pro HD 24 PoE
USW-Pro-HD-24-PoE (600W)
Profesjonalny przeĹÄcznik Etherlighting warstwy 3 z portami (2) 10 GbE PoE++, (22) 2,5 GbE PoE++ i (4) 10G SFP+.
Description - UBIQUITI Pro HD 24 PoE Professional-grade, Layer 3 Etherlighting switch with (2) 10 GbE PoE++, (22) 2.5 GbE PoE++, and (4) 10G SFP+ ports.
Design - Display type - LCM
Design - Form factor - 1U
Design - Housing material - SGCC
Design - LED indicators - Link
Design - LED indicators - Speed
Design - LED indicators - Status
Design - Product colour - Grey
Design - Rack mounting - Yes
Design - Reset button - Yes
Design - Stackable - Yes
Designation - CE+WEEE
dimensionalWeight - 6739
dimension depth - 550 mm
dimension height - 530 mm
Dimensions - 442 x 400 x 44 mm
Dimensions - 442 x 400 x 44 мм
dimension weight - 9000 g
dimension width - 130 mm
ean - 810084696606
EAN - 0810084696606
Environment requirements - Temperatura otoczenia podczas pracy: -5 do 40°C WilgotnoĹÄ otoczenia podczas pracy: 10 do 90% bez kondensacji
Forwarding rate - 171 Mpps
Forwarding rate - 171 Mpps
Gross Weight Kg - 5,4
guarantee - 12
guarantee_type - normal
height - 0.14 m
L2 features - LACP Port Aggregation STP & RSTP QoS (DSCP) Pro AV Profiles (Play, Dante, Q-SYS, NDI, SDVoE, Shure, AES67, Crestron) Advanced IGMP Configuration (Querier, Fast Leave, Router Port) IGMP Snooping 802.1X Control MAC-Based ACLs & Device Isolation DHCP Snooping & Guarding Egress Rate Limit Flow Control Storm Control Multicast & Broadcast Rate Limiting MAC Address Blocking IP-Based ACLs & Network Isolation MAC-Based Port Restriction Port Isolation Port Mirroring Jumbo Frames LLDP-MED Voice VLAN Loop Protection
L3 features - Serwer DHCP (sieci lokalne) PrzekaĹşnik DHCP Routing miÄdzy sieciami VLAN (sieci lokalne) Routing statyczny (sieci lokalne)
length - 0.54 m
MAC address table size - 32000
Management, monitoring, configuration -
Management features - Quality of Service (QoS) support - Yes
Management features - Switch layer - L2/L3
Management features - Switch type - Managed
Manufacturer - Ubiquiti
Manufacturer Code - USW-PRO-HD-24-POE
Manufacturer Name - Ubiquiti Networks
Memory buffer - 2 MB
Model - USW-PRO-HD-24-POE
mpn - USW-Pro-HD-24-PoE
MPN - USW-PRO-HD-24-POE
Multicast features - Multicast support - Yes
Name - Ubiquiti Switch full managed Layer3 28 Port USW-Pro-HD-24-PoE
name - Ubiquiti UniFi Switch Pro HD USW-Pro-HD-24-Po
Network - 10G support - Yes
Network - Broadcast storm control - Yes
Network - Flow control support - Yes
Network - IPv4 routes - 12000
Network - Networking standards - IEEE 802.1x
Network - Number of VLANs - 1000
Network - Port mirroring - Yes
Network - Rate limiting - Yes
Network - Virtual LAN features - Voice VLAN
Network - VLAN support - Yes
Network architecture - GigabitEthernet
Number of 10/100 Mbps ports - None
Number of 10/100/1000 Mbps ports - None
Number of 10Gb ports - None
Number of COMBO ports - None
Number of PoE+ ports - None
Number of PoE ports (PoE & PoE+) - None
Number of ports 1G/2.5G/5G/10G - 2
Number of ports 25Gb - None
Number of QSFP+ ports - None
Number of QSFP28 ports - 1
Number of SFP+ ports - 4
Number of SFP ports - None
Number of VLAN groups - 1000
Operational conditions - Operating relative humidity (H-H) - 10 - 90%
Operational conditions - Operating temperature (T-T) - -5 - 40 °C
Other features -
Other functions -
Packaging content - Cables included - Power
Packaging content - Rack mount kit - Yes
PoE ports - 24
PoE power budget - 600 Watts
Ports & interfaces - 2.5G Ethernet (copper) ports quantity - 22
Ports & interfaces - 10G Ethernet (copper) ports quantity - 2
Ports & interfaces - Basic switching RJ-45 Ethernet ports quantity - 22
Ports & interfaces - Basic switching RJ-45 Ethernet ports type - 2.5G Ethernet (100/1000/2500)
Ports & interfaces - Power connector - AC/DC
Ports & interfaces - SFP+ module slots quantity - 4
Power - AC input frequency - 50/60 Hz
Power - AC input voltage - 100 - 240 V
Power - Power consumption (max) - 60 W
Power - Power source - AC/DC/PoE
Power - Power supply included - Yes
Power - Redundant power supply (RPS) support - Yes
Power over Ethernet (PoE) - Power over Ethernet (PoE) - Yes
Power over Ethernet (PoE) - Power over Ethernet (PoE) power per port - 15.4 W
Power over Ethernet (PoE) - Power over Ethernet 4PPoE (PoE++) ports quantity - 24
Power over Ethernet (PoE) - Total Power over Ethernet (PoE) budget - 600 W
Power supply - SposĂłb zasilania: wejĹcie AC Zasilanie: AC/DC, wewnÄtrzne, 660 W ObsĹugiwany zakres napiÄcia: 100240 V AC SposĂłb zasilania: (1) WejĹcie uniwersalne, 100240 V AC, 50/60 Hz (1) WejĹcie DC USP RPS
Power supply - Internal
producer - UBIQUITI
producerCode - USW-Pro-HD-24-PoE
productName - Ubiquiti UniFi Pro HD 24 PoE Managed L2/L3 2.5G Ethernet (100/1000/2500) Power over Ethernet (PoE) 1U Grey
Product Net Weight - 6.3 kg
productSize - Normal
QoS -
Rack 1U Mounting Type - Yes
Security -
Security - DHCP features - DHCP guarding
Security - DHCP features - DHCP relay
Security - DHCP features - DHCP server
Security - DHCP features - DHCP snooping
Security - IGMP snooping - Yes
Security - Loop protection - Yes
SFP+ Ports - 2
Short description - Ubiquiti Switch UniFi 22x2.5G RJ45/2x10G RJ45/4xSFP+ Managed PoE++ 600W 19" Rack-Mountable, 1,3" Touchscreen
sizeX - 520
sizeY - 120
sizeZ - 540
Supported protocols and standards -
Support for Jumbo frames - Yes
Switch class - Managed
Switching capacity - 230 Gbps
Switch layer - L2
Switch layer - L3
Switch type - L3
Throughput - 230 GB/s
title - Ubiquiti UniFi Switch Pro HD 24 PoE
Unit Box Height - 0.52
Unit Box Length - 0.54
Unit Box Width - 0.12
Unit Calculated Volume - 0.04008 cubm
Unit Calculated Weight - 8.38 kg
Units per Pallet - 0
Units per Shipping Box - 2
Vendor Homepage - eu.store.ui.com/eu/en/products/usw-pro-hd-24-poe
vendpn - USW-Pro-HD-24-PoE
VLAN -
Warranty - 12 months
warrantyLength - 24
warrantyType - G
Weight - 7.76
weight - 8.6 kg
weight - 7680
Weight & dimensions - Depth - 400 mm
Weight & dimensions - Height - 44 mm
Weight & dimensions - Weight - 6.2 kg
Weight & dimensions - Width - 442.4 mm
width - 0.52 m
