Cudy HS105, 5x2.5Gb

10/100/1000/2500 Mbps ports - 5
Accessories included - HS105 Power Adapter Installation Guide Mounting Kit
Application - Home and small office
Brand - Cudy
BrandPartCode - HS105 3.0
Category - Network Switches
Category1 - Network
Category 1 - Netzwerk
Category 2 - Switching Hubs
Chassis type - Desktop
Console port - No
Data Act - Link
Data transmission - Forwarding rate - 18.6 Mpps
Data transmission - Jumbo frames - 9000
Data transmission - Jumbo frames support - Yes
Data transmission - MAC address table - 4096 entries
Data transmission - MAC address table - 8000 entries
Data transmission - Number of trunks - 2
Data transmission - Packet buffer memory - 0.5 MB
Data transmission - Packet buffer memory - 4 MB
Data transmission - Switching capacity - 25 Gbit/s
Description - 5-Port 2.5G Unmanaged Switch A 5-Port 2.5G switch with metal casing ideal for 2.5Gbps wired network expansion for NAS or bandwidth-intensive demands. 5 x 2.5G Ethernet Ports IGMP Snooping, Loop Prevention Max 10.5W, Idle 4.7W Desktop, Wall-Mount Metal Casing 119 x 85 x 28 mm
Description1 - Cudy Switch HS105 - 5 Ports - 5x GE (10/1000/2500)
Design - Housing material - Metal
Design - LED indicators - Power
Design - LED indicators - Power, Speed, Link, Activity
Design - Product colour - Black
Design - Rack mounting - No
Design - Reset button - No
Design - Reset button - Yes
Design - Stackable - No
Design - Version - 3.0
Design - Wall mountable - Yes
Designation - CE+WEEE
dimensionalWeight - 280
dimension depth - 70 mm
dimension height - 130 mm
Dimensions - 119 x 85 x 28 mm
dimension weight - 490 g
dimension width - 180 mm
ean - 6971690793197
EAN - 6971690793197
Environment requirements - Operating Temperature: 0 ~ 40°C  Storage Temperature: -40 ~ 70°C  Operating Humidity: 0% ~ 100% non-condensing Storage Humidity: 10% ~ 95% non-condensing
Fan - No
Forwarding rate - 18.6 Mpps
GTIN - 6971690793197
guarantee - 24
guarantee_type - normal
Jumbo frame size - 15 KB
L2 features - IGMP Snooping Loop Prevention Loop Detection
Logistics data - Master (outer) case gross weight - 10.2 kg
Logistics data - Master (outer) case height - 338 mm
Logistics data - Master (outer) case length - 376 mm
Logistics data - Master (outer) case net weight - 9.6 kg
Logistics data - Master (outer) case width - 264 mm
Logistics data - Products per master (outer) case - 20 pc(s)
LongDesc - Next-Gen ChipsetStable. Consistent. 2.5G.The next-gen chipset delivers full throughput at all ports with 1.7× greater power efficiency, generating less heat while sustaining peak performance.Fanless CoolingQuiet OperationThanks to the high-efficiency chipset, enjoy a noise-free 2.5G networking experience.Clear Status IndicatorEasily check the speed, link, and activity status of each port at a glance from the port-side LEDs.Save the Rewiring Work.Upgrade to 2.5G Easily.If your current cabling already runs at 1G, you can upgrade to 2.5G without replacing a single cable. Just swap the switch and enjoy the speed boost.Elegant Design. Wallmount.For NAS UsersUnleash Full NAS SpeedConnect your 2.5G NAS with 2.5G Ethernet to enable more devices to back up files at higher speed.For TeamsBoost Sharing Speed and ProductivityTransfer, upload, and share files at up to 2500 Mbps — so your whole team moves faster.Extra Handy FeaturesStatic Link AggregationCreate Link Aggregation Groups to increase throughput to uplink switches, NAS devices, and more.Port MirroringMirror traffic from selected ports to a monitoring port for traffic analysis and troubleshooting.Loop Detection/PreventionAutomatically detects and blocks network loops, with blinking LEDs to identify the affected port.Remote ManagementControl the switch via Cudy Cloud on your phone. *Requires firmware upgrade in July 2026.802.1Q/MTU/Port-Based VLANDSCP/802.1p QoS detects and prioritizes latency-sensitive traffic during transmission — ideal for video calls and gaming. You can also assign ports the highest priority so their traffic is always forwarded first.DSCP/802.1p/Port-Based QoSDSCP/802.1p QoS identifies DSCP packets in the tranmission and prioritize those latency-sensitive data. Or assign a port with highest priority so all data will be forwarded in the first rank.
LongProductName - 5-Port 2.5G Easy-Managed Switch, HS105 3.0
LongSummaryDescription - Cudy 5-Port 2.5G Easy-Managed Switch, HS105 3.0. Switch type: Managed, Switch layer: L2. Basic switching RJ-45 Ethernet ports type: 2.5G Ethernet (100/1000/2500), Basic switching RJ-45 Ethernet ports quantity: 5. MAC address table: 4096 entries, Switching capacity: 25 Gbit/s. Networking standards: IEEE 802.1Q, IEEE 802.1p, IEEE 802.3x, IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3bz, IEEE.... DC input voltage: 12 V. Wall mountable
MAC address table size - 8192
Management features - Cloud-managed - No
Management features - Cloud-managed - Yes
Management features - Quality of Service (QoS) support - No
Management features - Quality of Service (QoS) support - Yes
Management features - Switch layer - L2
Management features - Switch type - Managed
Management features - Switch type - Unmanaged
Management features - Web-based management - No
Management features - Web-based management - Yes
Manufacturer - Cudy
ManufacturerID - HS105
MPN - HS105
Name - 5P Cudy HS105
name - Desktop Switch HS105 5-Port 2.5G
Network - 10G support - No
Network - Broadcast storm control - Yes
Network - Cable length detection - Yes
Network - Cable types supported - Cat3
Network - Cable types supported - Cat3, Cat5, Cat5e
Network - Cable types supported - Cat5
Network - Cable types supported - Cat5e
Network - Cable types supported - Cat6
Network - Cable types supported - Cat6a
Network - Copper ethernet cabling technology - 2.5GBASE-T
Network - Copper ethernet cabling technology - 10BASE-T, 100BASE-T, 1000BASE-T, 2.5GBASE-T
Network - Copper ethernet cabling technology - 100BASE-T
Network - Copper ethernet cabling technology - 1000BASE-T
Network - Flow control support - Yes
Network - Link aggregation - No
Network - Link aggregation - Yes
Network - Networking standards - IEEE 802.1Q, IEEE 802.1p, IEEE 802.3x, IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3bz, IEEE 802.3az
Network - Networking standards - IEEE 802.3
Network - Networking standards - IEEE 802.3bz
Network - Networking standards - IEEE 802.3u
Network - Networking standards - IEEE 802.3x
Network - Port mirroring - No
Network - Port mirroring - Yes
Network - Rate limiting - Yes
Network - VLAN support - No
Network - VLAN support - Yes
Network architecture - GigabitEthernet
Operational conditions - Operating relative humidity (H-H) - 0 - 100%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Operational conditions - Storage relative humidity (H-H) - 10 - 95%
Operational conditions - Storage temperature (T-T) - -20 - 70 °C
Operational conditions - Storage temperature (T-T) - -40 - 70 °C
PackageHeight - 66
PackageLength - 181
PackageWeight - 450
PackageWidth - 127
Packaging content - User guide - Yes
Packaging data - AC adapter included - Yes
Packaging data - Package depth - 123 mm
Packaging data - Package height - 60 mm
Packaging data - Package weight - 480.8 g
Packaging data - Package width - 165 mm
Performance - Firmware upgradeable - Yes
Performance - Flash memory - 4 MB
Ports & interfaces - 2.5G Ethernet (copper) ports quantity - 5
Ports & interfaces - Basic switching RJ-45 Ethernet ports quantity - 5
Ports & interfaces - Basic switching RJ-45 Ethernet ports type - 2.5G Ethernet (100/1000/2500)
Power - AC input frequency - 50/60 Hz
Power - AC input voltage - 100 - 240 V
Power - DC input voltage - 12 V
Power - Input current - 1 A
Power - Power consumption (max) - 6 W
Power - Power saving mode (EEE) - Yes
Power - Power source - DC
Power - Power supply included - Yes
Power - Surge protection - Yes
Power - Surge protection voltage - 8 kV
Power consumption - 10.5 W
Power over Ethernet (PoE) - Power over Ethernet (PoE) - No
Power supply - Input: 100-240V~, 50/60Hz Output: 12V1A
Power supply - External
producer - Cudy
producerCode - HS105
ProductName - 5-Port 2.5G Easy-Managed Switch, HS105 3.0
productName - CUDY HS105 unmanaged 5-port switch
productSize - Normal
Security - Loop protection - Yes
ShortSummaryDescription - Cudy 5-Port 2.5G Easy-Managed Switch, HS105 3.0, Managed, L2, 2.5G Ethernet (100/1000/2500), Wall mountable
sizeX - 130
sizeY - 60
sizeZ - 180
Stackability - No
Supported protocols and standards - 802.3x Flow Control 802.3u 100BASE-TX 802.3ab 1000BASE-T 802.3bz 2.5GBASE-T and 5GBASE-T
Support for Jumbo frames - Yes
Switch class - Unmanaged
Switch layer - L2
Throughput - 25 Gb/s
Title - Cudy 5-Port 2.5G Easy-Managed Switch, HS105 3.0 L2 2.5G Ethernet (100/1000/2500) Black
URL - https://www.cudy.com/products/hs105-3-0?_pos=1&_psq=HS105&_ss=e&_v=1.0#features
vendpn - HS105
WarrantyInfo -
warrantyLength - 24
warrantyType - G
WEEE - DE46285170
Weight - 0.477
Weight - 267 g
weight - 482
Weight & dimensions - Depth - 85 mm
Weight & dimensions - Height - 28 mm
Weight & dimensions - Weight - 286.5 g
Weight & dimensions - Width - 119 mm
