10/100/1000/2500 Mbps ports - None
Accessories included -
Application - Medium and large companies
ARTIKEL1 - XGS1935-28
ARTIKEL2 - 28-PORT SMART MGD SWITCH
Brand - Zyxel
BrandPartCode - XGS1935-28-EU0101F
Breite - 0
Category - Network Switches
Certificates - LVD BSMI FCC Part 15 (Class A) CE (Class A) BSMI EMC RoHS
Chassis type - Rack
Console port - No
Data transmission - Forwarding rate - 95.2 Mpps
Data transmission - Jumbo frames - 9000
Data transmission - Jumbo frames support - Yes
Data transmission - MAC address table - 16000 entries
Data transmission - Packet buffer memory - 1.5 MB
Data transmission - Switching capacity - 128 Gbit/s
Description - Seria Zyxel XGS1935 to rodzina inteligentnych przełączników zarządzanych Lite-L3, która obejmuje cztery modele, w tym opcje z 28 i 52 portami, zarówno z PoE, jak i bez PoE. Wszystkie cztery modele są wyposażone w dodatkowe cztery porty światłowodowe 10GbE, które odpowiadają na rosnące potrzeby Twojej firmy w zakresie wysokich prędkości sieci. Seria ta została zaprojektowana z inteligentnym wentylatorem, który automatycznie dostosowuje prędkość w zależności od temperatury urządzenia, zapewniając niemal bezgłośną pracę przełącznika.
Description - ZYXEL XGS1935-28, 28 PORT LITE-L3 SMART MANAGED SWITCH, 24X GIGABIT COPPER AND 4X 10G SFP+, HYBRID MODE, STANDALONE OR NEBULAFLEX CLOUD
Design - Form factor - 1U
Design - LED indicators - Yes
Design - Product colour - Black
Design - Rack mounting - Yes
Design - Stackable - Yes
Designation - CE+WEEE
dimensionalWeight - 3844
dimension depth - 395 mm
dimension height - 95 mm
Dimensions - 440 x 270 x 43 mm
Dimensions W x D x H, mm - 440 x 270 x 43
dimension weight - 4200 g
dimension width - 510 mm
ean - 4718937636297
EANCode - 4718937636297
Environment requirements - Warunki pracy: Temperatura: -20°C do 50°C Wilgotność: 10% do 95% (bez kondensacji) Przechowywanie: Temperatura: -40°C do 70°C Wilgotność: 10% do 95% (bez kondensacji)
Ethernet LAN (RJ-45) ports quantity - 24
Fan - No
Forwarding rate - 95.2 Mpps
GRUPPE1 - Network
GRUPPE2 - Switches Managed
GTIN - 4718937636297
guarantee - -1
guarantee_type - external
Height - 93.000000
HERSTELLER - ZYXEL
Hoehe - 0
HSTNUMMER - XGS1935-28-EU0101F
Jumbo frame size - 9 KB
L2 features -
L3 features -
Laenge - 0
Length - 510.000000
Logistics data - Country of origin - China
LongDesc - The most affordable choice for 10G migrationThe XGS1930 series, a new 10G uplink smart managed switch, comes with a stylish new look and enables cloud manageability with Zyxel NebulaFlexTM technology.Built for convenienceThis smart-looking switch features an intuitive design that simplifies daily network management for SMBs.Manage it your way!The XGS1930 series introduces Zyxel NebulaFlexTM, which allows you to easily switch between standalone mode and our license-free Nebula cloud management platform anytime with just a few simple clicks.Don’t overspend to upgrade your wired networkWith Gigabit connectivity plus four 10G uplinks, the XGS1930 series is ideal for those seeking to upgrade to an easier-to-manage network—and at an affordable price.
LongProductName - XGS1935-28 - 24-port GbE Lite-L3 Smart Managed Switch met 4x 10G Uplink, EU
LongSummaryDescription - Zyxel XGS1935-28-EU0101F. Switch type: Managed, Switch layer: L2+/L3. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 24. MAC address table: 16000 entries, Switching capacity: 128 Gbit/s. Networking standards: IEEE 802.1D, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE.... Rack mounting, Form factor: 1U
MAC address table, entries - 16 K
MAC address table size - 16000
Management, monitoring, configuration - Support NebulaFlex for hybrid mode Standalone management by Web interface Cloud management by Nebula Control Center Setup Wizard Management through Telnet Management through Web, SNMP Firmware upgrade by FTP/Web Configuration saving and retrieving Multiple login supported Configure clone DHCP relay per VLAN DHCP client IPv4 DHCP client IPv6 DHCP option 82 Daylight saving NTP Server (IPv4/IPv6) - Support DNS format Display port utilization Port mirroring Scheduled PoE PoE default consumption mode PoE power management extended configuration Web login warning page Restore to last custom default
Management features - ARP inspection - Yes
Management features - Cloud-managed - Yes
Management features - Configuring Location Settings (CLI) - Yes
Management features - Quality of Service (QoS) support - Yes
Management features - Switch layer - L2+/L3
Management features - Switch type - Managed
Management features - System event log - Yes
Management features - Traffic classification - Yes
Management features - Traffic shaping - Yes
Management features - Web-based management - Yes
Manufacturer - Zyxel
ManufacturerPartNumber - XGS1935-28-EU0101F
Mean time between failures (MTBF) - 518332 h
Multicast features - Multicast support - Yes
name - Switch XGS1935-28-EU0101F
Network - 10G support - Yes
Network - Networking standards - IEEE 802.1D
Network - Networking standards - IEEE 802.1D, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Network - Networking standards - IEEE 802.1p
Network - Networking standards - IEEE 802.1s
Network - Networking standards - IEEE 802.1w
Network - Networking standards - IEEE 802.1x
Network - Networking standards - IEEE 802.3
Network - Networking standards - IEEE 802.3ab
Network - Networking standards - IEEE 802.3ad
Network - Networking standards - IEEE 802.3az
Network - Networking standards - IEEE 802.3u
Network - Networking standards - IEEE 802.3x
Network - Networking standards - IEEE 802.3z
Network - VLAN support - Yes
Network architecture - GigabitEthernet
Number of 10/100 Mbps ports - None
Number of 10/100/1000 Mbps ports - 24
Number of 10Gb ports - 4
Number of COMBO ports - None
Number of PoE+ ports - None
Number of PoE ports (PoE & PoE+) - None
Number of ports 1G/2.5G/5G/10G - 1
Number of ports 25Gb - None
Number of QSFP+ ports - None
Number of SFP+ ports - 4
Number of SFP56 ports - None
Number of SFP ports - None
Operating temperature range (T-T), °C - -20 - 50
Operational conditions - Operating relative humidity (H-H) - 10 - 90%
Operational conditions - Operating temperature (T-T) - -20 - 50 °C
Operational conditions - Storage temperature (T-T) - -40 - 70 °C
Other features -
Other functions -
Packaging content - Cables included - AC
Packaging content - Rack mount kit - Yes
Packaging data - Package depth - 394 mm
Packaging data - Package height - 90 mm
Packaging data - Package weight - 4.58 kg
Packaging data - Package width - 508 mm
Packet buffer - 1.5 MB
Packet transfer speed - 95.2 Mpps
Performance - Flash memory - 32 MB
Performance - Internal memory - 512 MB
Performance - Memory type - RAM / Flash
PeriodofWarranty -
Ports & interfaces - Basic switching RJ-45 Ethernet ports quantity - 24
Ports & interfaces - Basic switching RJ-45 Ethernet ports type - Gigabit Ethernet (10/100/1000)
Ports & interfaces - SFP+ module slots quantity - 4
Ports quantity - 28
Power - AC input frequency - 50/60 Hz
Power - AC input voltage - 100 - 240 V
Power - Power consumption (max) - 23.2 W
Power - Power consumption (typical) - 11.5 W
Power - Power source - AC
Power - Power supply included - Yes
Power consumption - 23.2 W
Power consumption (max.), W - 23.2
Power over Ethernet (PoE) - Power over Ethernet (PoE) - No
Power over Ethernet (PoE) Support - No
Power supply - 100 do 240 V prądu przemiennego, 50/60 Hz
Power supply - External
producer - Zyxel
producerCode - XGS1935-28-EU0101F
ProductName - XGS1935-28-EU0101F
productName - Zyxel XGS1935-28-EU0101F network switch Managed L2+/L3 Gigabit Ethernet (10/100/1000) 1U Black
productSize - Normal
QoS - No. of hardware queues per port: 8 802.1p queuing methods: SPQ, WRR, WFQ Storm control: broadcast, unknown L2MC, unknown unicast (DLF) Rate limiting per port Policy-based rate limiting Policy-based prioritization
Safety warning - Warnings - Avoid contact of the device with liquid.
Safety warning - Warnings - Follow the safety guidelines for electrical current.
Safety warning - Warnings - Make sure the ventilation of the equipment is not blocked.
Security - 802.1X Port security MAC authentication Static MAC forwarding SSL Static ARP Policy-based security filtering Port isolation MAC search Guest VLAN PPPoE relay agent PPPoE option 82 PPPoE IA Interface related trap enable/ disable (by port) CPU protection SHA2 HTTPS certification Login authentication by RADIUS RADIUS accounting Authorization on RADIUS Multiple RADIUS servers 802.1x VLAN and bandwidth assignment by RADIUS ACL packet filtering (IPv4)
Security - DHCP features - DHCP client
Security - DHCP features - DHCP client, DHCP relay
Security - DHCP features - DHCP relay
Security - IGMP snooping - Yes
SFP+ slots quantity - 4
ShortSummaryDescription - Zyxel XGS1935-28-EU0101F, Managed, L2+/L3, Gigabit Ethernet (10/100/1000), Rack mounting, 1U
sizeX - 95
sizeY - 511
sizeZ - 396
Stackability - Yes
Stck_Kart - 1
Stck_Pal - 0
Storage temperature range (T-T), °C - -40 - 70
Storno - Y
Supported protocols and standards - IEEE 802.3 10BASE-T Ethernet IEEE 802.3u 100BASE-TX Ethernet IEEE 802.3ab 1000BASE-T Ethernet IEEE 802.3z 1000BASE-X IEEE 802.3ae 10-Gigabit Ethernet Over Fiber IEEE 802.3af PoE IEEE 802.3at PoE Plus IEEE 802.3az EEE IEEE 802.3x flow control IEEE 802.3ad LACP aggregation IEEE 802.1D Spanning Tree Protocol (STP) IEEE 802.1w Rapid Spanning Tree Protocol (RSTP) IEEE 802.1s Multiple Spanning Tree Protocol (MSTP) IEEE 802.1p Class of Service (CoS) prioritization IEEE 802.1X port authentication
Support for Jumbo frames - Yes
Switch class - Managed
Switch class - SMART
Switching capacity, Gbit/s - 128
Switch layer - L3
Switch type - Managed
Throughput - 128 Gb/s
Title - Zyxel XGS1935-28-EU0101F network switch Managed L2+/L3 Gigabit Ethernet (10/100/1000) 1U Black
URL - https://www.zyxel.com/
vendpn - XGS1935-28-EU0101F
VLAN -
WarrantyInfo -
warrantyType - W
Weight - 3.1 kg
Weight - 4.650000
weight - 4640
Weight & dimensions - Depth - 270 mm
Weight & dimensions - Height - 433 mm
Weight & dimensions - Weight - 3.1 kg
Weight & dimensions - Width - 440 mm
Weight, g - 3100
Width - 395.000000
