TP-LINK SX3032F 32 SFP+

10/100/1000/2500 Mbps ports - None
Access Control List (ACL) Security - Yes
Accessories included - Przełącznik SX3032F 2× przewody zasilające Skrócona instrukcja instalacji Zestaw do montażu w szafie typu rack Gumowe nóżki
AC input frequency Power - 50/60 Hz
AC input voltage Power - 100 - 240 V
Application - Medium and large companies
ARP inspection Management features - Yes
ARTIKEL1 - 32-PORT 10GE SFP+ L2+ SWITCH
ARTIKEL2 - MANAGED 32X 10G SFP+ SLOTS
Authentication Security - MAC-based authentication, Port-based authentication
Authentication type Security - AAA, TACACS+
Basic switching RJ-45 Ethernet ports quantity Ports & interfaces - 1
Brand - TP-Link
BrandPartCode - SX3032F
Breite - 0
Broadcast storm control Network - Yes
Cables included Packaging content - Power
Category - Network Switches
Category Code - SWI
Certificates - CE, FCC, RoHS
Certificates - Compliance certificates - CE, Federal Communications Commission (FCC), RoHS
Chassis type - Rack
Cloud-managed Management features - Yes
Compliance certificates Certificates - CE, Federal Communications Commission (FCC), RoHS
Configuring Location Settings (CLI) Management features - Yes
Console port - Yes
Console port Ports & interfaces - RJ-45/Micro-USB
Data transmission - Forwarding rate - 240 Mpps
Data transmission - Jumbo frames - 9
Data transmission - Jumbo frames support - Yes
Data transmission - MAC address table - 32000 entries
Data transmission - Number of IP interfaces - 128
Data transmission - Number of queues - 8
Data transmission - Number of static routes - 128
Data transmission - Packet buffer memory - 24 MB
Data transmission - Static route - Yes
Data transmission - Switching capacity - 640 Gbit/s
Depth Weight & dimensions - 330 mm
Description - 32× sloty SFP+ 10 Gbps 640 Gbps przepustowości przełączania Dwa moduły zasilające wzajemnie się wspierają Centralne zarządzanie w chmurze przez web lub aplikację Omada Samodzielne zarządzanie przez web, CLI, SNMP i RMON Routing statyczny pomaga kierować ruchem wewnętrznym dla większej wydajności VLAN, ACL, QoS, IGMP Snooping, OAM i DDM Wytrzymała metalowa obudowa i montaż w szafie rackowej
Description - Omada 32-Port 10GE SFP+ L2+ Managed Switch Easily Build a Whole 10G Multi-gigabit Network Software Defined Networking (SDN) with Cloud Access
Remotely manage your access points, switches, and gateways across multiple sites all from a single interface.32× 10 Gbps SFP+ slots640 Gbps switching capacityTwo internal fixed power supply modules back each other upCentralized cloud management via the web or the Omada app†Standalone management via web, CLI, SNMP, and RMONStatic Routing helps route internal traffic for higher efficiencyVLAN, ACL, QoS, IGMP Snooping, OAM, and DDMERPS supports rapid protection and recovery in a ring topologyDurable metal casing and rack-mountable design
Design - Number of fans - 2 fan(s)
Design - Product colour - Black
Design - Rack mounting - Yes
Design - Redundant fans support - Yes
Designation - CE+WEEE
DHCP features Security - DHCP relay, DHCP server, DHCPv6 snooping
dimension depth - 100 mm
dimension height - 470 mm
Dimensions - 440 × 330 × 44 mm
dimension weight - 6200 g
dimension width - 530 mm
ean - 4895252504477
EAN - 4895252504477
EANCode - 4895252504477
Environment requirements - Temperatura pracy: 0-45 stopni Celsjusza Temperatura przechowywania: -40-70 stopni Celsjusza
Fan - Yes
Flow control support Network - Yes
Forwarding mode - Store-and-forward
Forwarding rate - 476.16 Mpps
Forwarding rate Data transmission - 240 Mpps
GARP VLAN Registration Protocol (GVRP) Protocols - Yes
Gewicht - 6.16
Gross Weight Kg - 4,77
GRUPPE1 - Network
GRUPPE2 - Switches Managed
GTIN - 0840030710551
GTIN - 840030710551
GTIN - 4895252504477
GTIN - 4895252504484
guarantee - 60
guarantee_type - normal
Height Weight & dimensions - 44 mm
HERSTELLER - TP-LINK
Hoehe - 0
HSTNUMMER - SX3032F
IGMP snooping Security - Yes
Installed SFP+ modules quantity Ports & interfaces - 32
IP-MAC-Port binding Security - Yes
IP Source Guard (IPSG) Protocols - Yes
IPv4 & IPv6 features Protocols - Dual stack IPv4/IPv6, ICMPv6, IPv6 TFTP
IPv4 routes Network - 48
IPv6 routes Network - 48
Jumbo frames Data transmission - 9
Jumbo frame size - 9 KB
Jumbo frames support Data transmission - Yes
L2 features -
L3 features -
Laenge - 0
Link aggregation Network - Yes
LongDesc - Omada 32-Port 10GE SFP+ L2+ Managed SwitchEasily Build a Whole 10G Multi-gigabit NetworkSoftware Defined Networking (SDN) with Cloud AccessRemotely manage your access points, switches, and gateways across multiple sites all from a single interface.
LongProductName - L2+, 32× 10-Gbit/s-SFP+, 640 Gbit/s, 32 K MAC, 9 KB Jumbo, 440 x 330 x 44 mm
LongSummaryDescription - TP-Link Omada 32-Port 10GE SFP+ L2+ Managed Switch. Switch type: Managed, Switch layer: L2+. Basic switching RJ-45 Ethernet ports quantity: 1, Installed SFP+ modules quantity: 32, Console port: RJ-45/Micro-USB. MAC address table: 32000 entries, Switching capacity: 640 Gbit/s. Networking standards: IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1x, IEEE 802.3ah, IEEE 802.3x. Rack mounting
Loop protection Security - Yes
MAC address table Data transmission - 32000 entries
MAC address table size - 32000
Management, monitoring, configuration -
Management features - ARP inspection - Yes
Management features - Cloud-managed - Yes
Management features - Configuring Location Settings (CLI) - Yes
Management features - MIB support - • MIB II (RFC1213) • Interface MIB (RFC2233) • Ethernet Interface MIB (RFC1643) • Bridge MIB (RFC1493) • P/Q-Bridge MIB (RFC2674) • RMON MIB (RFC2819) • RMON2 MIB (RFC2021) • Radius Accounting Client MIB (RFC2620) • Radius Authentication Client MIB (RFC2618) • Remote Ping, Traceroute MIB (RFC2925) • Support TP-Link private MIB
Management features - Quality of Service (QoS) support - Yes
Management features - Switch layer - L2+
Management features - Switch type - Managed
Manufacturer Code - SX3032F
Manufacturer Name - TP-LINK
Memory buffer - 23 MB
MIB support Management features - • MIB II (RFC1213) • Interface MIB (RFC2233) • Ethernet Interface MIB (RFC1643) • Bridge MIB (RFC1493) • P/Q-Bridge MIB (RFC2674) • RMON MIB (RFC2819) • RMON2 MIB (RFC2021) • Radius Accounting Client MIB (RFC2620) • Radius Authentication Client MIB (RFC26
Model - Omada
Multicast features - Multicast Listener Discovery (MLD) snooping - Yes
Multicast features - Multicast support - Yes
Multicast features - Number of multicast groups filtered - 4000
Multicast Listener Discovery (MLD) snooping Multicast features - Yes
Multicast support Multicast features - Yes
name - Switch SX3032F 32xSFP+
Network - Broadcast storm control - Yes
Network - Flow control support - Yes
Network - IPv4 routes - 48
Network - IPv6 routes - 48
Network - Link aggregation - Yes
Network - Networking standards - IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1x, IEEE 802.3ah, IEEE 802.3x
Network - Number of VLANs - 30
Network - Port mirroring - Yes
Network - Rate limiting - Yes
Network - Spanning tree protocol - Yes
Network - Virtual LAN features - Protocol-based VLAN, SSID-based VLAN assignment, Tagged VLAN, VLAN mapping, Voice VLAN
Network - VLAN support - Yes
Network architecture - GigabitEthernet
Networking standards Network - IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1x, IEEE 802.3ah, IEEE 802.3x
Number of 10/100 Mbps ports - None
Number of 10/100/1000 Mbps ports - 1
Number of 10Gb ports - 32
Number of COMBO ports - None
Number of fans Design - 2 fan(s)
Number of IP interfaces Data transmission - 128
Number of multicast groups filtered Multicast features - 4000
Number of PoE+ ports - None
Number of PoE ports (PoE & PoE+) - None
Number of ports 25Gb - None
Number of QSFP+ ports - None
Number of queues Data transmission - 8
Number of SFP+ ports - 32
Number of SFP56 ports - None
Number of SFP ports - None
Number of static routes Data transmission - 128
Number of VLANs Network - 30
Operating relative humidity (H-H) Operational conditions - 10 - 90%
Operating temperature (T-T) Operational conditions - -5 - 45 °C
Operational conditions - Operating relative humidity (H-H) - 10 - 90%
Operational conditions - Operating temperature (T-T) - -5 - 45 °C
Operational conditions - Storage relative humidity (H-H) - 5 - 90%
Operational conditions - Storage temperature (T-T) - 40 - 70 °C
Other features -
Other functions -
Packaging content - Cables included - Power
Packaging content - Quick start guide - Yes
Packet buffer memory Data transmission - 24 MB
Password protection Security - Yes
Port mirroring Network - Yes
Ports & interfaces - Basic switching RJ-45 Ethernet ports quantity - 1
Ports & interfaces - Console port - RJ-45/Micro-USB
Ports & interfaces - Installed SFP+ modules quantity - 32
Power - AC input frequency - 50/60 Hz
Power - AC input voltage - 100 - 240 V
Power - Power consumption (max) - 49.4 W
Power - Power source - AC
Power - Power supply included - Yes
Power consumption - 32.74 W
Power consumption (max) Power - 49.4 W
Power source Power - AC
Power supply - 100-240 V AC~50/60 Hz
Power supply - External
Power supply included Power - Yes
producer - TP-LINK
Product colour Design - Black
ProductName - Omada 32-Port 10GE SFP+ L2+ Managed Switch
Protocols - GARP VLAN Registration Protocol (GVRP) - Yes
Protocols - IP Source Guard (IPSG) - Yes
Protocols - IPv4 & IPv6 features - Dual stack IPv4/IPv6, ICMPv6, IPv6 TFTP
QoS -
Quality of Service (QoS) support Management features - Yes
Queue scheduling algorithms Security - Priority queuing (PQ), SP, Weighted Round Robin (WRR)
Quick start guide Packaging content - Yes
Rack mounting Design - Yes
Rate limiting Network - Yes
Redundant fans support Design - Yes
Security -
Security - Access Control List (ACL) - Yes
Security - Authentication - MAC-based authentication, Port-based authentication
Security - Authentication type - AAA, TACACS+
Security - DHCP features - DHCP relay, DHCP server, DHCPv6 snooping
Security - IGMP snooping - Yes
Security - IP-MAC-Port binding - Yes
Security - Loop protection - Yes
Security - Password protection - Yes
Security - Queue scheduling algorithms - Priority queuing (PQ), SP, Weighted Round Robin (WRR)
Security - SSH/SSL support - Yes
Security - Static port security - Yes
Series - SX3032F
Short description - TP-LINK Switch SX3032F 32x10G SFP+ L2+Managed Omada SDN
ShortSummaryDescription - TP-Link Omada 32-Port 10GE SFP+ L2+ Managed Switch, Managed, L2+, Rack mounting
Spanning tree protocol Network - Yes
SSH/SSL support Security - Yes
Stackability - No
Static port security Security - Yes
Static route Data transmission - Yes
Stck_Kart - 1
Stck_Pal - 0
Storage relative humidity (H-H) Operational conditions - 5 - 90%
Storage temperature (T-T) Operational conditions - 40 - 70 °C
Storno - Y
Summary - TP-Link Omada 32-Port 10GE SFP+ L2+ Managed Switch. Switch type: Managed, Switch layer: L2+. Basic switching RJ-45 Ethernet ports quantity: 1, Installed SFP+ modules quantity: 32, Console port: RJ-45/Micro-USB. MAC address table: 32000 entries, Switching capacity: 640 Gbit/s. Networking standards: IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1x, IEEE 802.3ah, IEEE 802.3x. Rack mounting
Supported protocols and standards -
Support for Jumbo frames - Yes
Switch class - Managed
Switching capacity Data transmission - 640 Gbit/s
Switch layer - L2+
Switch layer Management features - L2+
Switch type Management features - Managed
Throughput - 640 Gb/s
Title - TP-Link Omada 32-Port 10GE SFP+ L2+ Managed Switch
Unit Box Height - 0.1
Unit Box Length - 0.47
Unit Box Width - 0.53
Unit Calculated Volume - 0.030576 cubm
Unit Calculated Weight - 6.65 kg
Units per Shipping Box - 3
URL - https://www.tp-link.com/au/business-networking/omada-switch-easy-managed/es205g/
Vendor Homepage - https://www.tp-link.com/au/business-networking/omada-switch-easy-managed/es205g/
vendpn - SX3032F
Virtual LAN features Network - Protocol-based VLAN, SSID-based VLAN assignment, Tagged VLAN, VLAN mapping, Voice VLAN
VLAN -
VLAN support Network - Yes
Warranty - 60 months
WarrantyInfo -
Weight & dimensions - Depth - 330 mm
Weight & dimensions - Height - 44 mm
Weight & dimensions - Width - 440 mm
Width Weight & dimensions - 440 mm
