10Base-T / 100Base-TX / 1000Base-T Ports - 8
Brand - Dahua Technology
BrandPartCode - DH-CS4010-8GT-110
Category - Network Switches
Category Code - SWI
Certificates - Compliance certificates - CE
Data transmission - Forwarding rate - 4.17 Mpps
Data transmission - Jumbo frames - 15000
Data transmission - Jumbo frames support - Yes
Data transmission - MAC address table - 8000 entries
Data transmission - Packet buffer memory - 0.5 MB
Data transmission - Switching capacity - 20 Gbit/s
Description - "10-Port Cloud Managed Desktop Gigabit Switch with 8-Port PoE > Meets the requirements of IEEE802.3,IEEE802.3u,IEEE802.3x,IEEE802.3ab standards > Meets the requirements of IEEE802.3af, IEEE802.3at, Hi-PoE, and IEEE802.3bt power supply standards. > Manages PoE power consumption and PoE power on/off. Supports Intelligent PoE. > A wide operating temperature range and a full metal casing that is fully-enclosed and dust-proof."
Design - Housing material - Metal
Design - LED indicators - Yes
Design - Product colour - Black
Design - Rack mounting - No
Design - Reset button - Yes
Desktop/pedestal Mounting Type - Yes
Dimensions - 190 × 106 × 30 mm
Forwarding rate - 14.88 Mpps
Full Description Line - Type L2|Desktop/pedestal|8x10Base-T / 100Base-TX / 1000Base-T|IEEE 802.3|IEEE 802.3ab|IEEE 802.3u|IEEE 802.3x|PoE ports 8|Switching capacity 20 Gbps|Forwarding rate 14.88 Mpps|Power supply External|Dimensions 190 × 106 × 30 mm|Unit Net Weight 0.55 kg
GTIN - 6923172571151
IEEE 802.3 Network standard - Yes
IEEE 802.3ab Network standard - Yes
IEEE 802.3u Network standard - Yes
IEEE 802.3x Network standard - Yes
LongDesc -
LongProductName - 10-Port Cloud Managed Desktop Gigabit Switch with 8-Port PoE
LongSummaryDescription - Dahua Technology DH-CS4010-8GT-110. Switch type: Managed, Switch layer: L2. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 10. MAC address table: 8000 entries, Switching capacity: 20 Gbit/s. Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt, IEEE 802.3u, IEEE 802.3x. DC input voltage: 54 V. Power over Ethernet (PoE)
Management features - Cloud-managed - Yes
Management features - Quality of Service (QoS) support - Yes
Management features - Switch layer - L2
Management features - Switch type - Managed
Management features - Web-based management - Yes
Model name - CS4010-8GT-110
Network - 10G support - No
Network - Copper ethernet cabling technology - 10BASE-T, 100BASE-TX, 1000BASE-T
Network - Ethernet LAN data rates - 10,100,1000 Mbit/s
Network - Flow control support - Yes
Network - Networking standards - IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt, IEEE 802.3u, IEEE 802.3x
Network - Number of VLANs - 32
Network - Spanning tree protocol - Yes
Network - Virtual LAN features - Port-based VLAN
Network - VLAN support - Yes
Operational conditions - Operating relative humidity (H-H) - 5 - 95%
Operational conditions - Operating temperature (T-T) - -10 - 55 °C
Operational conditions - Storage relative humidity (H-H) - 5 - 95%
Operational conditions - Storage temperature (T-T) - -40 - 70 °C
Packaging data - Package depth - 244 mm
Packaging data - Package height - 87 mm
Packaging data - Package weight - 1.3 kg
Packaging data - Package width - 256 mm
PoE ports - 8
Ports & interfaces - Basic switching RJ-45 Ethernet ports quantity - 10
Ports & interfaces - Basic switching RJ-45 Ethernet ports type - Gigabit Ethernet (10/100/1000)
Ports & interfaces - Gigabit Ethernet (copper) ports quantity - 10
Power - DC input voltage - 54 V
Power - Input current - 2.22 A
Power - Power consumption (max) - 110 W
Power - Power source - DC/PoE
Power - Power supply included - Yes
Power - Redundant power supply (RPS) support - Yes
Power over Ethernet (PoE) - Power over Ethernet (PoE) - Yes
Power over Ethernet (PoE) - Power over Ethernet (PoE) ports quantity - 8
Power supply - External
Primary port count - 8
ProductName - DH-CS4010-8GT-110
Security - DHCP features - DHCP client
Shipping Box Depth Shipping/Package Box Dimensions - 25.5 cm
Shipping Box Height Shipping/Package Box Dimensions - 9 cm
Shipping box quantity - 1
Shipping Box Weight Shipping/Package Box Dimensions - 1.28 kg
Shipping Box Width Shipping/Package Box Dimensions - 24.5 cm
ShortSummaryDescription - Dahua Technology DH-CS4010-8GT-110, Managed, L2, Gigabit Ethernet (10/100/1000), Power over Ethernet (PoE)
Sustainability - Sustainability compliance - Yes
Switching capacity - 20 Gbps
Switch type - L2
Title - Dahua Technology DH-CS4010-8GT-110 network switch Managed L2 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Black
Unit Box Height - 0.09
Unit Box Length - 0.255
Unit Box Width - 0.245
Unit Brutto Volume - 0.005623 cubm
Unit Gross Weight - 1.28 kg
Unit Net Weight - 0.55 kg
URL - https://www.dahuasecurity.com/products/All-Products/Transmission/Cloud-Managed-Switches/CS4010-8GT-110
Vendor Homepage - www.dahuasecurity.com/products/All-Products/Transmission/Cloud-Managed-Switches/CS4010-8GT-110
Warranty - 36 months
WarrantyInfo -
Weight & dimensions - Depth - 106 mm
Weight & dimensions - Height - 30 mm
Weight & dimensions - Weight - 550 g
Weight & dimensions - Width - 190 mm
