Eaton ELP850IEC, 850VA 510W, IEC

ACoutletsquantity - 4 AC outlet(s)
ACoutlettypes - C13 coupler
AutomaticVoltageRegulationAVR -
Battery -
Battery - Automatic battery test - Yes
Battery - Battery technology - Sealed Lead Acid (VRLA)
Battery - Cold start - Yes
Battery - Hot-swap battery - No
Battery - Typical backup time at half load - 9 min
Batterycapacity -
Batterytechnology - Sealed Lead Acid (VRLA)
Batteryvoltage -
Brand - Eaton
BrandPartCode - ELP850IEC
Cablesincluded -
Category - Uninterruptible Power Supplies (UPSs)
Depth - 285 mm
Design -
Design - Display type - LCD
Design - Form factor - Tower
Design - LED indicators - Yes
Design - Product colour - Black
Design - Rack capacity - 2U
Design - Safety - IEC/EN 62040-1, IEC/EN 62040 -2, CB, CE
dimensionalWeight - 3439
Displaytype - LCD
Efficiency -
Features -
Features - Emergency Power Off (EPO) - Yes
Features - Input frequency - 50/60 Hz
Features - Input operation voltage (max) - 285 V
Features - Input operation voltage (min) - 150 V
Features - Output frequency - 50 Hz
Features - Output operation voltage (max) - 240 V
Features - Output operation voltage (min) - 220 V
Features - Output power - 510 W
Features - Output power capacity - 0.85 kVA
Features - Surge protection - Yes
Features - Surge protection features - Fax
Features - Surge protection features - Fax, Modem, Network, Telephone
Features - Surge protection features - Modem
Features - Surge protection features - Network
Features - Surge protection features - Telephone
Features - UPS topology - Line-Interactive
Formfactor - Tower
GTIN - 0743172437648
GTIN - 743172437648
Heatdissipation -
Height - 260 mm
HighLights -
Hotswapbattery - No
Inputfrequency - 50/60 Hz
Inputoperationvoltagemax - 285 V
Inputoperationvoltagemin - 150 V
Logistics data - Harmonized System (HS) code - 85078000
LongDesc - The Eaton Ellipse PRO 650–1600VA is a line interactive UPS specifically developed to protect workstations running demanding applications. The Ellipse PRO features an LCD display for real-time status and measurements. It also features EcoControl power outlets, which enable energy savings up to 20 percent and Advanced Surge Reduction (ASR) that complies fully with the requirements of the IEC 616431-1 standard.
LongDesc - The Eaton Ellipse PRO 650–1600VA is a line interactive UPS specifically developed to protect workstations running demanding applications. The Ellipse PRO features an LCD display for real-time status and measurements. It also features EcoControl power outlets, which enable energy savings up to 20 percent and Advanced Surge Reduction (ASR) that complies fully with the requirements of the IEC 616431-1 standard.- LCD display for real-time status and measurements.- Delivers clean output with Automatic Voltage Regulation (AVR, with buck and boost).- EcoControl function helps you save up to 20% energy compared to previous generation UPSs.- Includes a high performance surge-protection device which complies with IEC 61643-1 standard.- Up to 8 outlets to connect your PC & peripherals.- Convenient extra-flat design for easy installation in any office environment.- USB port & Eaton UPS Companion software that enables safe system shutdown, energy usage metering and easy configuration of UPS settings.- Protects data connections such as Ethernet, internet and telephone lines.
LongProductName - Ellipse PRO 850 IEC
LongSummaryDescription - Eaton Ellipse PRO 850 IEC. UPS topology: Line-Interactive, Output power capacity: 0.85 kVA, Output power: 510 W. AC outlet types: C13 coupler, Power plug: C14 coupler, AC outlets quantity: 4 AC outlet(s). Battery technology: Sealed Lead Acid (VRLA), Typical backup time at half load: 9 min. Form factor: Tower, Product colour: Black, Rack capacity: 2U. Safety: IEC/EN 62040-1, IEC/EN 62040 -2, CB, CE
ManufDatasheet -
Networkcardslot -
Noiselevel -
Numberofbatterycells -
Numberofinputphases -
Numberofoutputphases -
Operatingaltitude -
OperatingrelativehumidityHH -
OperatingtemperatureTT -
Operationalconditions -
Other features - Nominal input voltage - 230 V
Outputfrequency - 50 Hz
Outputoperationvoltagemax - 240 V
Outputoperationvoltagemin - 220 V
Outputpower - 510 W
Outputpowercapacity - 0.85 kVA
Packagingcontent -
Ports & interfaces - AC outlets quantity - 4 AC outlet(s)
Ports & interfaces - AC outlet types - C13 coupler
Ports & interfaces - Ethernet LAN (RJ-45) ports - 1
Ports & interfaces - Modem (RJ-11) ports - 1
Ports & interfaces - Power plug - C14 coupler
Ports & interfaces - USB 2.0 ports quantity - 1
Portsinterfaces -
Powerfactor -
Powerplug - C14 coupler
ProdDesc - 850VA/510W UPS, line-interactive, IEC 3+1
producerCode - ELP850IEC
Productcolour - Black
Productcondition - Original
ProductHighLights -

• Line-Interactive
• 0.85 kVA 510 W
• 4 AC outlet(s)
• Sealed Lead Acid (VRLA)
• Tower Black

productName - Eaton Ellipse PRO 850 IEC uninterruptible power supply (UPS) Line-Interactive 0.85 kVA 510 W 4 AC outlet(s)
ProductName - Ellipse PRO 850 IEC
ProductPicture - https://www.tdbaltic.ee/images/products/EATON/ELP850IEC_1.jpg
ProductPicture1 - https://www.tdbaltic.ee/images/products/EATON/ELP850IEC_2.jpg
ProductPicture2 - https://www.tdbaltic.ee/images/products/EATON/ELP850IEC_3.jpg
ProductPicture3 -
ProductPicture4 -
ProductPicture5 -
productSize - Normal
Quickinstallationguide -
Rackmountkit -
RS232ports -
Safety regulation & standards - Safety - IEC/EN 62040-1, IEC/EN 62040 -2, CB, CE
Serialinterface -
Serialinterfacetype -
Serialportsquantity -
ShortSummaryDescription - Eaton Ellipse PRO 850 IEC, Line-Interactive, 0.85 kVA, 510 W, 150 V, 285 V, 50/60 Hz
sizeX - 390
sizeY - 140
sizeZ - 315
Title - Eaton Ellipse PRO 850 IEC uninterruptible power supply (UPS) Line-Interactive 0.85 kVA 510 W 4 AC outlet(s)
Typicalbackuptimeathalfload - 9 min
UPStopology - Line-Interactive
URL - https://powerquality.eaton.com/Products-services/Backup-Power-UPS/Ellipse-PRO.aspx?cx=88
USBport -
USBporttype -
Warranty - 24 months
Warrantyandmisc -
WarrantyInfo - 3 year
warrantyLength - 36
warrantyType - F
Waveform -
Weight - 7.3 kg
weight - 8215
Weight & dimensions - Depth - 285 mm
Weight & dimensions - Height - 260 mm
Weight & dimensions - Weight - 7.3 kg
Weight & dimensions - Width - 82 mm
Weightdimensions -
Width - 82 mm
