Accessories included -
Active power - 480 W
Apparent power - 800 VA
Backup time (100% load) - 15 min
Battery - Battery capacity - 7 Ah
Battery - Battery recharge time - 6 h
Battery - Battery technology - Sealed Lead Acid (VRLA)
Battery - Battery voltage - 12 V
Battery - Typical backup time at full load - 15 min
Battery capacity - 7 Ah
Brand - Legrand
BrandPartCode - 310084
Category - Root/Accessories | Exploitation/Power supply/UPSs and power strips/UPSs
Category - Uninterruptible Power Supplies (UPSs)
Certificates - Certification - EN 62040-1, EN 62040-2
Charging time - 6 h
Color - Black
Color - White
Data Act - Link
Description - UPS o mocy pozornej 800 VA wyposażony w elektroniczny układ AVR. Praca w trybie Line-Interactive. 6 gniazd zasilających, 1 gniazdo USB oraz RJ45.
Design - Form factor - Compact
Design - LED indicators - Yes
Design - Product colour - Black, White
Designation - CE+WEEE
dimension depth - 390 mm
dimension height - 275 mm
Dimensions - 190 x 296 x 89,5 mm
dimension weight - 5400 g
dimension width - 150 mm
ean - 3414971227279
Eans - 3414971227279
Environment requirements - Temperaturowy zakres pracy 0-40 st. C
Features - Audible alarm(s) - Yes
Features - Automatic Voltage Regulation (AVR) - Yes
Features - Auto shut-off - No
Features - Efficiency - 97%
Features - Input frequency - 45/65 Hz
Features - Input operation voltage (max) - 280 V
Features - Input operation voltage (min) - 170 V
Features - Noise level - 40 dB
Features - Number of input phases - 1
Features - Number of output phases - 1
Features - Output frequency - 50/60 Hz
Features - Output frequency regulation - 1 Hz
Features - Output operation voltage (max) - 253 V
Features - Output operation voltage (min) - 207 V
Features - Output power - 480 W
Features - Output power capacity - 0.8 kVA
Features - Output power factor - 0.6
Features - Output voltage regulation - 10%
Features - Potential-free output - No
Features - Power protection features - Overcharge, Overdischarge, Overload, Short circuit
Features - Power source type - AC
Features - Surge protection - Yes
Features - UPS topology - Line-Interactive
Features - Waveform - Sine
Filters / protection - Circuit
Filters / protection - Overcharging
Filters / protection - Overdischarge
Filters / protection - Overload
Filters / protection - Surge
GTIN - 3414971227279
guarantee - 24
guarantee_type - external
Hold-up time (maks) - 6 ms
I/O connectors - 1 x RJ-45 LAN
I/O connectors - 1 x USB 2.0
Input power ports - Wtyczka sieciowa
Logistics data - Master (outer) case gross weight - 6.4 kg
Logistics data - Master (outer) case height - 290 mm
Logistics data - Master (outer) case length - 390 mm
Logistics data - Master (outer) case width - 158 mm
Logistics data - Pallet net height - 104 cm
Logistics data - Pallet net length - 100 cm
Logistics data - Pallet net weight - 345.6 kg
Logistics data - Pallet net width - 120 cm
Logistics data - Products per master (outer) case - 1 pc(s)
Logistics data - Products per pallet - 54 pc(s)
LongDesc - The Keor Multiplug is a uninterruptible power supply with interactive line technology. It delivers a rated power of 600VA and 800VA, it is CPU-controlled and is equipped, internally, with valve-regulated, hermetically sealed lead accumulator battery.The presence of an electronic stabiliser (AVR) inside the UPS provides the connected loads with effective protection against any interference in the electrical mains.
LongProductName - Compact Line Interactive multisocket UPS designed for home infotainment devices such as TVs, DVR, Modem, Router, Game Console, TV box, etc.
LongSummaryDescription - Legrand Keor ASI MULTIPLUG 800 FR. UPS topology: Line-Interactive, Output power capacity: 0.8 kVA, Output power: 480 W. AC outlet types: Type E, Power plug: Type F, AC outlets quantity: 6 AC outlet(s). Battery technology: Sealed Lead Acid (VRLA), Battery capacity: 7 Ah, Battery voltage: 12 V. Form factor: Compact, Product colour: Black, White. Certification: EN 62040-1, EN 62040-2
Name - Legrand UPS Keor Multiplug 800 AVR
name - UPS Keor Multiplug 800 AVR 4+2 FR 310084
No. of batteries - 1
Number of phases input - 1 (230V)
Operational conditions - Operating relative humidity (H-H) - 0 - 95%
Operational conditions - Operating temperature (T-T) - 0 - 40 °C
Other features -
Output power ports - 6 x C/E type
Packaging data - Package depth - 5.03 mm
Packaging data - Package height - 89.5 mm
Packaging data - Package weight - 6.08 kg
Packaging data - Package width - 190 mm
Ports & interfaces - AC outlets quantity - 6 AC outlet(s)
Ports & interfaces - AC outlet types - Type E
Ports & interfaces - Power plug - Type F
Ports & interfaces - USB 2.0 ports quantity - 1
Ports & interfaces - USB port - Yes
Ports & interfaces - USB port type - USB Type-A
producer - Legrand
Producer - Legrand
ProducerCode - 310084
ProductName - ASI KEOR MULTIPLUG 800 FR
ShortDescription -
ShortSummaryDescription - Legrand Keor ASI MULTIPLUG 800 FR, Line-Interactive, 0.8 kVA, 480 W, Sine, 170 V, 280 V
Software -
Special functions -
Title - Legrand Keor ASI MULTIPLUG 800 FR uninterruptible power supply (UPS) Line-Interactive 0.8 kVA 480 W 6 AC outlet(s)
UPS Architecture - line-interactive
URL - https://ups.legrand.com/
vendpn - 310084
Voltage - 12 V
WarrantyInfo -
Weight - 5.5 kg
Weight & dimensions - Depth - 296 mm
Weight & dimensions - Height - 89.5 mm
Weight & dimensions - Weight - 5.5 kg
Weight & dimensions - Width - 190 mm
